GUITAR TONE PRODUCTION Amir Alav Arman Pa x ad GUITAR PARTS WOODS - - PowerPoint PPT Presentation
GUITAR TONE PRODUCTION Amir Alav Arman Pa x ad GUITAR PARTS WOODS - - PowerPoint PPT Presentation
www.AmirAlav.com GUITAR TONE PRODUCTION Amir Alav Arman Pa x ad GUITAR PARTS WOODS STRINGS PICKUPS GUITAR ACCESSORIES IMPEDANCE GUITAR CABLE Slide show TAHA HI-Z / LOW-Z HI-Z / LOW-Z HI-Z / LOW-Z EFFECTS EFFECT PEDALS Stomp boxes, or
SLIDE 2
SLIDE 3
WOODS
SLIDE 4
STRINGS
SLIDE 5
PICKUPS
SLIDE 6
GUITAR ACCESSORIES
SLIDE 7
IMPEDANCE
SLIDE 8
Slide show TAHA
GUITAR CABLE
SLIDE 9
HI-Z / LOW-Z
SLIDE 10
HI-Z / LOW-Z
SLIDE 11
HI-Z / LOW-Z
SLIDE 12
EFFECTS
SLIDE 13
EFFECT PEDALS
Stomp boxes, or effects pedals, are effects units designed to sit on the floor or a pedalboard and be turned on and off with the user's feet. They typically house a single effect.
SLIDE 14
RACKMOUNT
Rackmounts are most commonly used in recording studios and "front of house" live sound mixing situations, though many musicians use them in place of stompboxes. Rackmounts are controlled by knobs or switches on their front panel, and often by a MIDI digital control interface. During live performances, a musician can operate rackmounted effects using a "foot controller“. (Amir)
SLIDE 15
BUILT-IN
SLIDE 16
MULTI-EFFECTS
SLIDE 17
PLUGINS
SLIDE 18
EFFECTS CATEGORIES
SLIDE 19
BASIC SIGNAL CHAIN
- Understanding the Building Blocks of the Signal Chain (Taha)
SLIDE 20
ROUTING
SLIDE 21
ROUTING
SLIDE 22
SIGNAL CHAIN
SLIDE 23
TRUE BYPASS / BUFFER BYPASS
SLIDE 24
BUFFER
SLIDE 25
TUNER - BUFER
SLIDE 26
NOISE GATE
SLIDE 27
WAH WAH
- T
echnically it is a band pass or high Q lowpass filter.
- Engineers at VOX noticed that a midrange boost amplifier circuit
made a distinctive vocal sound when switching between two frequencies.
- The pedal sweeps the peak response of a frequency filter up and down in frequency to
create the sound, a spectral glide, also known as "the wah effect".
- Auto wah
SLIDE 28
EQ BASED
- Ring Modular
- Envelop Filters or Auto Wahs
SLIDE 29
EQUALIZER
SLIDE 30
VOLUME OR EXPRESSION PEDAL
High or Low Impedance Active or Passive Pedal
SLIDE 31
COMPRESSOR
- compression is dynamic volume attenuation. It makes loud sounds quieter,
and quiet sounds louder.
SLIDE 32
DISTORTION & OVERDRIVE & FUZZ
- One of the channels on the board was “broken” and produced a distorted sound. He decided
to use it to record Grady Martin’s guitar solo on the Marty Robbins’ tune “Don’t Worry”.
- Overdrive — Audio at a low input level is driven by higher input levels in a non-linear curve
characteristic
- Distortion — a wider tonal area than overdrive operating at a higher non-linear region of a
curve
- Fuzz — complete non-linear behavior , harder/harsher than distortion
SLIDE 33
FUZZ & DISTORTION & OVERDRIVE
- What is the difference between Fuzz, Distortion, and Overdrive?
SLIDE 34
FUZZ
Germanium or Silicon Fuzz
SLIDE 35
LOW FREQUENCY OSCILLATOR
- Low-frequency oscillation (LFO) is an electronic signal which is usually below
20 Hz and creates a rhythmic pulse or sweep. This pulse or sweep is often used to modulate synthesizers, delay lines and other audio equipment in order to create effects used in the production of electronic music.Audio effects such as vibrato, tremolo and phasing are examples
SLIDE 36
CHORUS
- The Chorus effect delays the original signal. The delay time is modulated with an
- LFO. The delayed, modulated signal is mixed with the original, dry signal.
- Provides a vibrato or pitch modulation effect.
SLIDE 37
FLANGER
- The Flanger effect works in much the same way as the Chorus effect, but it uses a
significantly shorter delay time. In addition, the effect signal can be feedback into the input of the delay line.
SLIDE 38
PHASER
The Phaser effect combines the original signal with a copy that is slightly out of phase with the original. This means that the amplitudes of the two signals reach their highest and lowest points at slightly different times. The timing differences between the two signals are modulated by two independent LFOs
SLIDE 39
TREMOLO
The Tremolo effect modulates the amplitude of the incoming signal, resulting in periodic volume changes. You’ll recognize this effect from vintage guitar combo amps (where it is sometimes incorrectly referred to as vibrato). The graphic display shows all parameters, except Rate.
SLIDE 40
VIBRATO
Pulsating change of pitch Vibrato is typically characterized in terms of two factors: the amount of pitch variation ("extent of vibrato”) and the speed with which the pitch is varied ("rate of vibrato") UniVibe
SLIDE 41
DELAY
an input signal to an audio storage medium, and then plays it back after a period of
- time. The delayed signal may either be played back multiple times, or played back into
the recording again, to create the sound of a repeating, decaying echo.
SLIDE 42
DELAY (ECHO)
SLIDE 43
REVERB
SLIDE 44
REVERB
SLIDE 45
FX LOOP
SLIDE 46
FX LOOP
SLIDE 47
FX LOOP
SLIDE 48
NOISE
SLIDE 49
NOISE
SLIDE 50
AMPLIFIERS
SLIDE 51
AMPLIFIER TYPES
SLIDE 52
AMPLIFIER SIGNAL CHAIN
SLIDE 53
AMPLIFIER SIGNAL CHAIN
SLIDE 54
TRIODE CIRCUIT
SLIDE 55
ANALOG – DIGITAL – SOLID STATE
SLIDE 56
ATTENUATOR
SLIDE 57
ISOLATION
SLIDE 58
ISOLATION
SLIDE 59
SPEAKER
SLIDE 60
SPEAKER WIRING
Speakers wired in series: Speakers wired in parallel:
SLIDE 61
SPEAKER WIRING
Speakers wired in series- parallel:
SLIDE 62
OPEN BACK / CLOSE BACK
SLIDE 63
OPEN BACK / CLOSE BACK
SLIDE 64
OPEN BACK / CLOSE BACK
SLIDE 65
DYNAMIC MICS
SLIDE 66
CONDENSER MICS
SLIDE 67
RIBBON MICS
SLIDE 68
PHASE
SLIDE 69
HEADROOM
SLIDE 70
THANK YOU !
- Darbast Platform
- Kargadan Studio
If you have any questions, ask me: Info@AmirAlav.com
