GRINDTEC AUGSBURG 2020 Informations regarding the GrindTec exhibition in Augsburg, from 18 th to 21 st March 2020. FAIRGROUND HALL N5 BOOTH 5118 LIZZINIS BOOTH IG FXS GRINDING MACHINE TECHNICAL DATA Distance between centre 250 mm

SLIDE 1

GRINDTEC AUGSBURG 2020

Informations regarding the GrindTec exhibition in Augsburg, from 18th to 21st March 2020.

SLIDE 2

FAIRGROUND

SLIDE 3

HALL N°5 – BOOTH 5118

SLIDE 4

LIZZINI’S BOOTH

SLIDE 5

IG FXS GRINDING MACHINE

TECHNICAL DATA Distance between centre 250 mm Centre height 200 / 250 mm

Max. grinding length

250 mm Wheels diameter 500 / 600 mm Machine weight

ca. 5500 kg

Transversal axis 300 mm Longitudinal axis 450 mm

The brand new IG FXS
Provided with one wheel for external grinding
Suitable for grinding small parts

SLIDE 6

IG FM GRINDING MACHINE

Hydrostatic guides for X and Z axes
Provided with two wheels for external grinding

and one for internal grinding TECHNICAL DATA Distance between centre 800 mm Centre height 200 / 250 mm

Max. grinding length

800 mm Wheels diameter 500 / 600 mm Machine weight

ca. 7500 kg

Transversal axis 300 mm Longitudinal axis 950 mm

SLIDE 7

IG FM GRINDING MACHINE IG FXS GRINDING MACHINE
