Green Gas Certification Scheme Ciaran Burns 17 November 2016 GGCS - - PowerPoint PPT Presentation

Overview of the Green Gas Certification Scheme Ciaran Burns 17 November 2016

GGCS outline

• GGCS tracks commercial transactions of grid injected

biomethane through the supply chain

• Each unit of green gas injected into the grid displaces

the need for a unit of conventional gas

• Unique identifiers ensure there is no double-counting or

double-selling of green gas

• Certificates are valid for 3 years from the injection date,

at which point they are retired out of the system

GGCS process at a glance

Information

• Date of creation
• Customer name
• Range of RGGOs
• Injection Date
• Technology/feedstock
• Country of injection
• Total amount kWh
• Producer
• Supplier
• Pin Code
• CO2 figure associated

with LCA – more later

Validate certificates

http://www.greengas.org.uk/certificates/validate

Who are the suppliers?

http://www.greengas.org.uk/certificates/for-sale

Current scheme status

• 26 producers registered
• Capacity of producers 1.3 TWh per annum
• 22 suppliers registered
• Over 960 million kWh registered on the scheme since 2012
• 265 million kWh certificates sold
• 700 million kWh unsold (700 GWh)

13 4 10 50 100 150 200 250 300 350 400 450 500

Biogas from food waste Biogas from waste water treatment Biogas from agricultural activities

Volume of certificates registered (GWh)

Total volume of units registered and number of producers registered

• Large volumes of the gas injected for 2016 not yet registered
• 2015 figures still increasing
• Waste water and food waste plants are larger but take longer to develop

1 2 8 15 26 5 10 15 20 25 30 50 100 150 200 250 300 350 400 450 500

2012 2013 2014 2015 2016 Millions of KWh (or GWh)

Number of members registered and the volmes of gas registered between 2012 and 2016

Gas from agricultural activities Gas from waste water treatment Gas from food waste Number of plants

1 3 12 22 1 2 6 11 5 10 15 20 25 20 40 60 80 100 120 140 160

2013 2014 2015 2016

GWh

Volume of certificates sold and number of suppliers on the scheme

Volume of gas sold Number of Suppliers Number of suppliers that have sold certificates

• As it’s a new product several suppliers not yet active.
• Current energy supplier might already be a member

GGCS successes to date

• Low Carbon Emission Bus

– Green Gas Certificates (GGCs) proof of biomethane use – providing access to BSOG subsidy

• Recognition of Green Gas certificates under the GHG Protocol –

more later!

• Defra GHG reporting

– Inclusion of GGCs as reporting tool… – …Defra sitting on conclusion for 3 years now

• Explored use of GGCs as part of Zero Carbon Homes policy

– But Chancellor scrapped Government ambition on this in July 2015

• Buses paid 6p/km for using biomethane (BSOG). Settlement at end of year.
• 5 green energy suppliers now members in 2016
• Commercial suppliers now offering green tariffs

6 31 69 1 1 37 59 5 20 20 1 2 4 4 20 40 60 80 100 120 140

2013 2014 2015 2016 Volume of certificates (GWh)

Volume of certificates sold to each market sector each year

Transport Buses Corporate Energy Suppliers

CO2 emission figure

• Biomass fuel used by RHI participants must meet a lifecycle

GHG emissions target of 34.8g CO2 eq/MJ of heat;

• Since all biomethane on the GGCS has received the RHI then it

is possible to say that all units of biomethane have emitted no more than 34.8g CO2 eq/MJ

• 125.28g CO2 eq/kWh
• These are Scope 3 emissions – More later from Syed, Sacha

and Sarah!!!

Looking Forward

• GGCs as a reporting tool in GHG Protocol

– International standards on how organisations should report the GHG emissions associated with their operations.

• Guarantees of Origin for Biopropane (BioLPG) with Calor Gas
• London Zero Carbon Homes policy

– ZCH standard to be introduced in London 1 October 2016 –already developer interest in green gas – One major development already committed to use of green gas certificates

• Use of green gas/green gas certificates in transport sector

– Considered in detail in REA ‘Use of gaseous fuels in transport’ REA report – Forthcoming RTFO will consider potential of grid-injected biomethane

For more information

www.greengas.org.uk

Twitter: @GreenGasCertificates cburns@greengas.org.uk
