SLIDE 1
GLOS DMAC Infrastructure
- Hardware
– Server 1(Web/FTP/Application) x86_64 2* 4 Xeon CPU, 16GB RAM 300 GB RAID 1 – Server 2(New Purchase) x86_64 4* 4 Xeon CPU, 24GB RAM 600 GB RAID 5/LVM
- Software Suite
Great Lakes Observing System GLOS DMAC Infrastructure Hardware - - PowerPoint PPT Presentation
Great Lakes Observing System GLOS DMAC Infrastructure Hardware - - PowerPoint PPT Presentation
IOOS Regional Product Developers Workshop Great Lakes Observing System GLOS DMAC Infrastructure Hardware Server 1(Web/FTP/Application) x86_64 2* 4 Xeon CPU, 16GB RAM 300 GB RAID 1 Server 2(New Purchase) x86_64 4* 4 Xeon CPU,
SLIDE 2
SLIDE 3
GLOS Observation Explorer Featuring
- Data navigation through both map and text
list
- Fast access to the latest obs data through
interactive chart or table, up to 7 days
- Fast access to historic data in any 30 days
interval
- Record of the Day
- Switch time zone and unit conversion on
the fly
- RSS is available for mobile
SLIDE 4
GLOS Observation Explorer Structure
FTP (Push) Script (Pull) Application Server (Tomcat 6) Servlet Servlet Cache DAO DAO Pojo
Obs Database
JDBC/DBCP Web Server (httpd) Google Map API Google Charting Tool MIT SMILE API Jquery Ajax-enabled web pages Reversed Proxy
SLIDE 5
GLOS Observation Explorer Demo
http://www.glos.us/obs
SLIDE 6
GLOS Observation Explorer
SLIDE 7
Future Improvement of GLOS Observation Explorer
- Develop obs javascript API library to
expand the usage of observation data and engage third-party developers
- Add data access/downloading according to
IOOS DIF standards
- Explorer the mobile entry for the obs data
SLIDE 8
GLOS Huron to Erie Connecting Waterway Forecasting System
SLIDE 9
GLOS Huron to Erie Connecting Waterway Forecasting System Developed by GLERL, NOAA
- Dr. David J. Schwab
- Dr. Eric J. Anderson
- Mr. Gregory A. Lang
SLIDE 10
GLOS Huron to Erie Connecting Waterway Forecasting System
- FVCOM unstructured-grid model
- Predict currents, water-level for Lake St.
Clair, St. Clair River, and Detroit Revier
- Nowcasts every 3 hours, Forecasts every 12
hours
- 48 hours forecast
- Resolution varies from 30 meter in the
nearshore to 300 meter in the center of Lake St. Clair
- New high resolution grids added recently
for Clinton River
SLIDE 11
HECWFS Viewer on GLOS Featuring
- Visualize both hourly nowcast and forecast
data on the interactive map
- Identify water velocity and water level on
each grid with charts
- Switch time zone and unit conversion on
the fly
- Serve WMS-T service
SLIDE 12
HECWFS Viewer Work Flow
HECWFS NETCDF Shp file HECWFS Database MapServer CGI WMS-T
Map file Httpd
PHP Identify
Parser shp2pgsql
SLIDE 13
HECWFS Viewer Demo
http://www.glos.us/hecwfs
SLIDE 14
SLIDE 15
Experience with MapServer on HECWFS Viewer Development
- True North (not solved)
Mapserver lacks the ability to draw symbols
- r labels at angles relative to true
geographic north regardless of the map projection being used A temporary fix was provided by Steve Roberts from NOAA/PMEL
SLIDE 16
Experience with MapServer on HECWFS Viewer Development
- Symbol Rotation (Solved)
Mapserver used to only support rotation on the counter-clockwise angle (MS RFC 45) |0 90------|-------270 |180 ESRI ArcMap do Geographic and Arithmetic:
SLIDE 17
Experience with MapServer on HECWFS Viewer Development
Geographic: |0 270-----|--------90 |180 Arithmetic: |90 180-----|--------0 |270
