slide-1
SLIDE 1

Asian Carp Control in the Great Lakes GLSLCI Meeting June 18 2010

Asian Carp Regional Coordinating Committee

John D. Rogner Illinois Department of Natural Resources

Asian Carp Control in the Great Lakes GLSLCI Meeting June 18 2010

John D. Rogner Illinois Department of Natural Resources

slide-2
SLIDE 2

Overview

  • Asian carp
  • Chicago Area Drainage
  • Range and spread of carp
  • Asian Carp and Dispersal Barrier Background
  • Draft Framework Approach

Asian Carp Regional Coordinating Committee

  • Draft Framework Approach

– Draft Framework Short­term Actions – Draft Framework Long­term Actions

  • Funding
  • Comments

Overview

Chicago Area Drainage Range and spread of carp Asian Carp and Dispersal Barrier Background Draft Framework Approach Draft Framework Approach

term Actions term Actions

slide-3
SLIDE 3

Muskegon Chronicle/ Mlive.com

slide-4
SLIDE 4
slide-5
SLIDE 5

Why we’re worried

  • Large bodied (>100 lbs)

– Bighead: 5 feet, 90 pounds – Silver: 3 feet, 60 pounds

  • Eating machines

– Up to 20% of body weight/day – Planktivores

Asian Carp Regional Coordinating Committee

– Planktivores – Eat same food as natives

  • Reproduce, develop quickly

– 1 female = 1­ 500 million eggs – Grow to ~10” in year 1

  • Tend to jump when startled

Why we’re worried

Large bodied (>100 lbs)

Bighead: 5 feet, 90 pounds Silver: 3 feet, 60 pounds Up to 20% of body weight/day Eat same food as natives

Reproduce, develop quickly

500 million eggs

Tend to jump when startled

slide-6
SLIDE 6

Asian Carp Regional Coordinating Committee

slide-7
SLIDE 7

Asian Carp Regional Coordinating Committee

Saint Louis

slide-8
SLIDE 8

Asian Carp Regional Coordinating Committee

slide-9
SLIDE 9

Chicago Area Drainage

Asian Carp Regional Coordinating Committee

Chicago Area Drainage

slide-10
SLIDE 10

Chronologic Upstream Movement

  • f Asian Carp

Asian Carp Regional Coordinating Committee

Chronologic Upstream Movement

  • f Asian Carp
slide-11
SLIDE 11

Asian Carp Regional Coordinating Committee

slide-12
SLIDE 12

Chicago Sanitary and Ship Canal Des Plaines River

Asian Carp Regional Coordinating Committee

Chicago Sanitary and Ship Canal I&M Canal Barriers

slide-13
SLIDE 13

Barrier Effect

Asian Carp Regional Coordinating Committee

Barrier Effect

slide-14
SLIDE 14

RRP ­Turn up Barrier 2A volts per inch, 15 Hertz frequency and 6.5 milliseconds pulse rate

Asian Carp Regional Coordinating Committee

Turn up Barrier 2A ­two volts per inch, 15 Hertz frequency and 6.5 milliseconds pulse rate (08.12.09)

slide-15
SLIDE 15

Stopping the Spread: Rapid Response Rotenone Application

  • December 2009, Barrier IIA

down for maintenance

  • 400+ respondents, 30+ agencies

and organizations

  • Results…

Asian Carp Regional Coordinating Committee

  • Results…

– Barrier maintenance success – Confirmed presence of Asian carp in canal

Stopping the Spread: Rapid Response Rotenone Application

December 2009, Barrier IIA 400+ respondents, 30+ agencies

Barrier maintenance success Confirmed presence of Asian carp

slide-16
SLIDE 16

yellow lines represent locations set on 12/05/09 and raised on 12/06/09 reset on 12/06/09 and raised on 12/07/09

One additional net was set downstream

Asian Carp Regional Coordinating Committee

Net Locations yellow lines represent locations set on 12/05/09 and raised on 12/06/09 reset on 12/06/09 and raised on 12/07/09

600 linear feet trammel net (all other nets were 300 linear feet)

slide-17
SLIDE 17

Asian Carp Regional Coordinating Committee

slide-18
SLIDE 18

Overland Flow

Asian Carp Regional Coordinating Committee

Overland Flow

slide-19
SLIDE 19

eDNA Monitoring and Detection

Asian Carp Regional Coordinating Committee

eDNA Monitoring and Detection

Positive eDNA detections above barriers

slide-20
SLIDE 20

ASIAN CARP REGIONAL COORDINATING COMMITTEE STRUCTURE

RCC

USEPA, USFWS, USCG, USACE, USGS, GLFC, IDNR, IEPA, InDNR, MWRD, City of Chicago

Asian Carp Regional Coordinating Committee

Invasion Control WG Monitoring and Rapid Response WG

ASIAN CARP REGIONAL COORDINATING COMMITTEE STRUCTURE

RCC

USEPA, USFWS, USCG, USACE, USGS, GLFC, IDNR, IEPA, InDNR, MWRD, City of Chicago Monitoring and Rapid Response WG Communications WG

slide-21
SLIDE 21

Asian Carp Regional Coordinating Committee

slide-22
SLIDE 22

Asian Carp Control Strategy Framework

  • Goal: Prevent establishment of self

populations in the Great Lakes

– Integrate and unify future actions of participating agencies, develop collaborative approach – Transition to multi­tiered defense (beyond barriers)

Asian Carp Regional Coordinating Committee

  • Dynamic document based on growing body of knowledge

gained from research and monitoring

  • Strategy: “…move quickly on proven solutions, and

consider, develop, and test potential solutions and employ those that are most sound.”

Asian Carp Control Strategy Framework

Goal: Prevent establishment of self­sustaining carp populations in the Great Lakes

Integrate and unify future actions of participating agencies, develop collaborative approach tiered defense (beyond barriers)

Dynamic document based on growing body of knowledge gained from research and monitoring Strategy: “…move quickly on proven solutions, and consider, develop, and test potential solutions and employ those that are most sound.”

slide-23
SLIDE 23

Strategic Framework: Short Strategic Framework: Short and Long and Long­ ­term Actions term Actions

Asian Carp Regional Coordinating Committee

Strategic Framework: Short Strategic Framework: Short­ ­ term Actions term Actions

slide-24
SLIDE 24

Framework: Short­term Actions

  • Carp population suppression measures
  • Enhanced detection measures

– Increased sample collection – eDNA indicator refinement

  • Structural operation variations

Asian Carp Regional Coordinating Committee

  • Structural operation variations
  • Emergency engineering measures
  • Expedited biological control

assessments

  • Enhanced electric barrier operations

Framework: term Actions

Carp population suppression measures Enhanced detection measures Structural operation variations Structural operation variations Emergency engineering measures Enhanced electric barrier operations

slide-25
SLIDE 25

Barrier Status and Funding

  • Construction Status

– Barrier I activated in 2002 – Barrier II A activated in 2009 – Barrier II B to be completed in late 2010

  • Funding Status

Asian Carp Regional Coordinating Committee

  • Funding Status

– Funding provided in federal budgets – Construction and operations

Barrier Status and Funding

Barrier I activated in 2002 Barrier II A activated in 2009 Barrier II B to be completed in late 2010 Funding provided in federal budgets Construction and operations

slide-26
SLIDE 26

Chicago Area Drainage

Asian Carp Regional Coordinating Committee

Chicago Area Drainage

slide-27
SLIDE 27

Net Sets #3 and #4 #3 – 200 feet 3 inch mesh trammel net – set from bank to bank #4 – 900 feet – 3.25 inch mesh trammel net – set down middle of channel Net #5 – 600 feet – 3.25 inch mesh trammel net – set down middle of channel

Asian Carp Regional Coordinating Committee

Net #6 – 600 feet – 3 inch mesh trammel net – set down middle of channel

slide-28
SLIDE 28

Sampling Totals from 5/12/10

  • Common Carp – 439
  • Goldfish – 7
  • Carp X Goldfish Hybrid –
  • Gizzard Shad – 42
  • Channel Catfish – 5

Asian Carp Regional Coordinating Committee

  • Channel Catfish – 5
  • Largemouth Bass – 9
  • Northern Pike – 1
  • Rock Bass – 2
  • Black Bullhead – 2
  • White Sucker – 11

Sampling Totals from 5/12/10

– 27

slide-29
SLIDE 29

Asian Carp Regional Coordinating Committee

slide-30
SLIDE 30

Asian Carp Regional Coordinating Committee

slide-31
SLIDE 31

Asian Carp Regional Coordinating Committee

slide-32
SLIDE 32

Asian Carp Regional Coordinating Committee

slide-33
SLIDE 33

Asian Carp Regional Coordinating Committee

slide-34
SLIDE 34

Asian Carp Regional Coordinating Committee

slide-35
SLIDE 35

Asian Carp Regional Coordinating Committee

slide-36
SLIDE 36

EVALUATION OF RISK

Must we seek to eliminate all Asian carp above the barrier? If not, how few provide an acceptable risk?

Asian Carp Regional Coordinating Committee

If so, are there effective and more targeted control options besides broad rotenone applications?

EVALUATION OF RISK

Must we seek to eliminate all Asian carp If not, how few provide an acceptable risk? If so, are there effective and more targeted control options besides broad rotenone

slide-37
SLIDE 37

Framework: Long­term Actions

  • Efficacy study
  • Inter­basin feasibility study
  • Ecological­separation
  • Modified lock operations
  • Commercial market

Asian Carp Regional Coordinating Committee

  • Commercial market

enhancement and ongoing fish population suppression

  • Biological controls

Framework: term Actions

basin feasibility study Modified lock operations Commercial market Commercial market enhancement and ongoing fish population suppression

slide-38
SLIDE 38

Framework: Funding

  • Short­term actions

– $38.6 million

  • Long­term actions

– $39.9 million

  • Funding Sources

Asian Carp Regional Coordinating Committee

  • Funding Sources

– Great Lakes Restoration Initiative: $57.4 million – Base Program Funding: $21.1 million

Framework: Funding

Great Lakes Restoration Base Program Funding: $21.1

slide-39
SLIDE 39

The Future: Ecological Separation?

  • Ecological separation means…

– NO interbasin transfer of aquatic organisms – PREVENT the movement; 100% effectiveness

  • Ecological separation does not necessarily mean…

Asian Carp Regional Coordinating Committee

  • Ecological separation does not necessarily mean…

– Stopping shipping or recreational traffic – Lock closure – More frequent or more severe floods

The Future: Ecological Separation?

Ecological separation means…

NO interbasin transfer of aquatic organisms PREVENT the movement; 100% effectiveness

Ecological separation does not necessarily mean… Ecological separation does not necessarily mean…

Stopping shipping or recreational traffic More frequent or more severe floods

slide-40
SLIDE 40
  • Ecological separation might entail . . .

– New infrastructure

  • E.g.: Lift lock for recreational vessels, similar to the Big

Chute Marine Railway on the Trent Severn Waterway, Ontario

– Chemical/heat barriers

The Future: Ecological Separation?

Asian Carp Regional Coordinating Committee

– Chemical/heat barriers – Altered traffic flows (commercial and recreational navigation) – Changes to hydrology – Different management of stormwater and wastewater – Improved transportation infrastructure – Enhanced infrastructure for tourism – Ecological restoration of waterways

Ecological separation might entail . . .

E.g.: Lift lock for recreational vessels, similar to the Big Chute Marine Railway on the Trent Severn Waterway,

The Future: Ecological Separation?

Altered traffic flows (commercial and recreational Different management of stormwater and wastewater Improved transportation infrastructure Enhanced infrastructure for tourism Ecological restoration of waterways

slide-41
SLIDE 41

The Future: Ecological Separation?

Asian Carp Regional Coordinating Committee

The Future: Ecological Separation?

slide-42
SLIDE 42
  • USACE “Feasibility Study”

– Corps authorized to investigate “range of options” for separation – Multi­year study

The Future: Ecological Separation?

Asian Carp Regional Coordinating Committee

  • Other elements for others:

– Investigate the transportation and water management needs for the region; – Propose new infrastructure needs; – Take into consideration all be severed.

USACE “Feasibility Study”

Corps authorized to investigate “range of options” for

The Future: Ecological Separation?

Other elements for others:

Investigate the transportation and water management Propose new infrastructure needs; all connections that need to

slide-43
SLIDE 43

Thank You!

Asian Carp Regional Coordinating Committee

carpcomments@gmail.com

Need to know more?

www.asiancarp.org

Want to Comment? Email

carpcomments@gmail.com
