Full Bayesian Network Classifiers by Jiang Su and Harry Zhang

Flemming Jensen November 2008

Purpose

To introduce the full Bayesian network classifier(FBC).

Introduction

Bayesian networks are often used for the classification problem, where a learner attempts to construct a classifier from a given set

• f labeled training examples.

Introduction

Bayesian networks are often used for the classification problem, where a learner attempts to construct a classifier from a given set

• f labeled training examples.

Since the number of possible network structures is extremely huge, structure learning often has high computational complexity.

Introduction

Bayesian networks are often used for the classification problem, where a learner attempts to construct a classifier from a given set

• f labeled training examples.

Since the number of possible network structures is extremely huge, structure learning often has high computational complexity. The idea behind the full Bayesian network classifier is to reduce the computational complexity of structure learning by using a full Bayesian network as the structure, and represent variable independence in the conditional probability tables instead of in the network structure.

Introduction

Bayesian networks are often used for the classification problem, where a learner attempts to construct a classifier from a given set

• f labeled training examples.

Since the number of possible network structures is extremely huge, structure learning often has high computational complexity. The idea behind the full Bayesian network classifier is to reduce the computational complexity of structure learning by using a full Bayesian network as the structure, and represent variable independence in the conditional probability tables instead of in the network structure. We use decision trees to represent the conditional probability tables to keep the compact representation of the joint distribution.

Variable Independence

Definition - Conditionally independence Let X, Y , Z be subsets of the variable set W . The subsets X and Y are conditionally independent given Z if: P(X|Y , Z) = P(X|Z)

Variable Independence

Definition - Conditionally independence Let X, Y , Z be subsets of the variable set W . The subsets X and Y are conditionally independent given Z if: P(X|Y , Z) = P(X|Z) Definition - Contextually independence Let X, Y , Z, T be disjoint subsets of the variable set W . The subsets X and Y are contextually independent given Z and the context t if: P(X|Y , Z, t) = P(X|Z, t)

Existence

Theorem - Existence For any BN B, there exists an FBC FB, such that B and FB encode the same variable independencies.

Existence

Theorem - Existence For any BN B, there exists an FBC FB, such that B and FB encode the same variable independencies. Proof:

Existence

Theorem - Existence For any BN B, there exists an FBC FB, such that B and FB encode the same variable independencies. Proof: Since B is an acyclic graph, the nodes of B can be sorted on the basis of the topological ordering.

Existence

Theorem - Existence For any BN B, there exists an FBC FB, such that B and FB encode the same variable independencies. Proof: Since B is an acyclic graph, the nodes of B can be sorted on the basis of the topological ordering. Go through each node X in the topological ordering, and add arcs to all the nodes ranked after X.

Existence

Theorem - Existence For any BN B, there exists an FBC FB, such that B and FB encode the same variable independencies. Proof: Since B is an acyclic graph, the nodes of B can be sorted on the basis of the topological ordering. Go through each node X in the topological ordering, and add arcs to all the nodes ranked after X. The resulting network FB is a full BN.

Existence

Theorem - Existence For any BN B, there exists an FBC FB, such that B and FB encode the same variable independencies. Proof: Since B is an acyclic graph, the nodes of B can be sorted on the basis of the topological ordering. Go through each node X in the topological ordering, and add arcs to all the nodes ranked after X. The resulting network FB is a full BN. Build a CPT-tree for each node X in FB, such that any variable that is not in the parent set ΠX of X in B does not

• ccur in the CPT-tree of X in FB.

Example - FBC for Naive Bayes

Example of a naive Bayes

C X

1

X2 X3 X4

Example - FBC for Naive Bayes

Example of an FBC for the naive Bayes

C X

1

X2 X3 X4 X1 X1 C

p

11p 12 p 13p 14

X2 X2 C

p

21p 22 p 23p 24

X3 X3 C

p

31p 32 p 33p 34

X4 X4 C

p

41p 42 p 43p 44

Learning Full Bayesian Network Classifiers

Learning an FBC consists of two parts:

Learning Full Bayesian Network Classifiers

Learning an FBC consists of two parts: Construction of a full BN.

Learning Full Bayesian Network Classifiers

Learning an FBC consists of two parts: Construction of a full BN. Learning of decision trees to represent the CPT of each variable.

Learning Full Bayesian Network Classifiers

Learning an FBC consists of two parts: Construction of a full BN. Learning of decision trees to represent the CPT of each variable. The full BN is implemented using a Bayesian multinet.

Learning Full Bayesian Network Classifiers

Learning an FBC consists of two parts: Construction of a full BN. Learning of decision trees to represent the CPT of each variable. The full BN is implemented using a Bayesian multinet. Definition - Bayesian multinet A Bayesian multinet is a set of Bayesian networks, each of which corresponds to a value c of the class variable C.

Structure Learning

Learning the structure of a full BN actually means learning an

• rder of variables and then adding arcs from a variable to all the

variables ranked after it.

Structure Learning

Learning the structure of a full BN actually means learning an

• rder of variables and then adding arcs from a variable to all the

variables ranked after it. A variable is ranked based on its total influence on other variables.

Structure Learning

Learning the structure of a full BN actually means learning an

• rder of variables and then adding arcs from a variable to all the

variables ranked after it. A variable is ranked based on its total influence on other variables. The influence (dependency) between two variables can be measured by mutual information.

Structure Learning

Learning the structure of a full BN actually means learning an

• rder of variables and then adding arcs from a variable to all the

variables ranked after it. A variable is ranked based on its total influence on other variables. The influence (dependency) between two variables can be measured by mutual information. Definition - Mutual information Let X and Y be two variables in a Bayesian network. The mutual information is defined as: M(X; Y ) =

• x∈X,y∈Y

P(x, y)log P(x, y) P(x)P(y)

Structure Learning

It is possible that the dependency between two variables, measured by mutual information, is caused merely by noise.

Structure Learning

It is possible that the dependency between two variables, measured by mutual information, is caused merely by noise. Results by Friedman are used as a dependency threshold to filter

• ut unreliable dependencies.

Structure Learning

It is possible that the dependency between two variables, measured by mutual information, is caused merely by noise. Results by Friedman are used as a dependency threshold to filter

• ut unreliable dependencies.

Definition - Dependency threshold Let Xi and Xj be two variables in a Bayesian network. The dependency threshold, denoted by φ, is defined as: φ(Xi, Xj) = logN

2N × Tij, where Tij = |Xi| × |Xj|.

Structure Learning

The total influence of a variable on other variables can now be defined:

Structure Learning

The total influence of a variable on other variables can now be defined: Definition - Total influence Let Xi be a variable in a Bayesian network. The total influence of Xi on other variables, denoted by W (Xi), is defined as: W (Xi) =

M(Xi;Xj)>φ(Xi,Xj)

• j(j=i)

M(Xi; Xj).

Structure Learning Algorithm

Algorithm FBC-Structure(S, X)

Structure Learning Algorithm

Algorithm FBC-Structure(S, X)

1 B = empty.

Structure Learning Algorithm

Algorithm FBC-Structure(S, X)

1 B = empty. 2 Partition the training data S into |C| subsets Sc by the class

value c.

Structure Learning Algorithm

Algorithm FBC-Structure(S, X)

1 B = empty. 2 Partition the training data S into |C| subsets Sc by the class

value c.

3 For each training data set Sc

Structure Learning Algorithm

Algorithm FBC-Structure(S, X)

1 B = empty. 2 Partition the training data S into |C| subsets Sc by the class

value c.

3 For each training data set Sc

Compute the mutual information M(Xi; Xj) and the dependency threshold φ(Xi, Xj) between each pair of variables Xi and Xj.

Structure Learning Algorithm

Algorithm FBC-Structure(S, X)

1 B = empty. 2 Partition the training data S into |C| subsets Sc by the class

value c.

3 For each training data set Sc

Compute the mutual information M(Xi; Xj) and the dependency threshold φ(Xi, Xj) between each pair of variables Xi and Xj. Compute W (Xi) for each variable Xi.

Structure Learning Algorithm

Algorithm FBC-Structure(S, X)

1 B = empty. 2 Partition the training data S into |C| subsets Sc by the class

value c.

3 For each training data set Sc

Compute the mutual information M(Xi; Xj) and the dependency threshold φ(Xi, Xj) between each pair of variables Xi and Xj. Compute W (Xi) for each variable Xi. For all variables Xi in X

Structure Learning Algorithm

Algorithm FBC-Structure(S, X)

1 B = empty. 2 Partition the training data S into |C| subsets Sc by the class

value c.

3 For each training data set Sc

Compute the mutual information M(Xi; Xj) and the dependency threshold φ(Xi, Xj) between each pair of variables Xi and Xj. Compute W (Xi) for each variable Xi. For all variables Xi in X

• Add all the variables Xj with W (Xj) > W (Xi) to the parent

set ΠXi of Xi.

Structure Learning Algorithm

Algorithm FBC-Structure(S, X)

1 B = empty. 2 Partition the training data S into |C| subsets Sc by the class

value c.

3 For each training data set Sc

Compute the mutual information M(Xi; Xj) and the dependency threshold φ(Xi, Xj) between each pair of variables Xi and Xj. Compute W (Xi) for each variable Xi. For all variables Xi in X

• Add all the variables Xj with W (Xj) > W (Xi) to the parent

set ΠXi of Xi.

• Add arcs from all the variables Xj in ΠXi to Xi.

Structure Learning Algorithm

Algorithm FBC-Structure(S, X)

1 B = empty. 2 Partition the training data S into |C| subsets Sc by the class

value c.

3 For each training data set Sc

Compute the mutual information M(Xi; Xj) and the dependency threshold φ(Xi, Xj) between each pair of variables Xi and Xj. Compute W (Xi) for each variable Xi. For all variables Xi in X

• Add all the variables Xj with W (Xj) > W (Xi) to the parent

set ΠXi of Xi.

• Add arcs from all the variables Xj in ΠXi to Xi.

Add the resulting network Bc to B.

Structure Learning Algorithm

Algorithm FBC-Structure(S, X)

1 B = empty. 2 Partition the training data S into |C| subsets Sc by the class

value c.

3 For each training data set Sc

Compute the mutual information M(Xi; Xj) and the dependency threshold φ(Xi, Xj) between each pair of variables Xi and Xj. Compute W (Xi) for each variable Xi. For all variables Xi in X

• Add all the variables Xj with W (Xj) > W (Xi) to the parent

set ΠXi of Xi.

• Add arcs from all the variables Xj in ΠXi to Xi.

Add the resulting network Bc to B.

4 Return B.

Example - Structure Learning Algorithm

Example using 1000 labeled instances, where C is the class variable and A, B, and D are feature variables. C A B D # c1 a1 b1 d1 11 c1 a1 b1 d2 5 c1 a1 b2 d1 7 c1 a1 b2 d2 17 c1 a2 b1 d1 227 c1 a2 b1 d2 97 c1 a2 b2 d1 11 c1 a2 b2 d2 25 C A B D # c2 a1 b1 d1 36 c2 a1 b1 d2 36 c2 a1 b2 d1 259 c2 a1 b2 d2 29 c2 a2 b1 d1 96 c2 a2 b1 d2 96 c2 a2 b2 d1 43 c2 a2 b2 d2 5

Example - Structure Learning Algorithm

C A B D # c1 a1 b1 d1 11 c1 a1 b1 d2 5 c1 a1 b2 d1 7 c1 a1 b2 d2 17 c1 a2 b1 d1 227 c1 a2 b1 d2 97 c1 a2 b2 d1 11 c1 a2 b2 d2 25 The 400 data instances where C = c1. b1 b2 a1

11+5 400 7+17 400

a2

227+97 400 11+25 400

P(A, B)

Example - Structure Learning Algorithm

C A B D # c1 a1 b1 d1 11 c1 a1 b1 d2 5 c1 a1 b2 d1 7 c1 a1 b2 d2 17 c1 a2 b1 d1 227 c1 a2 b1 d2 97 c1 a2 b2 d1 11 c1 a2 b2 d2 25 The 400 data instances where C = c1. b1 b2 a1

11+5 400 7+17 400

a2

227+97 400 11+25 400

P(A, B)

Example - Structure Learning Algorithm

C A B D # c1 a1 b1 d1 11 c1 a1 b1 d2 5 c1 a1 b2 d1 7 c1 a1 b2 d2 17 c1 a2 b1 d1 227 c1 a2 b1 d2 97 c1 a2 b2 d1 11 c1 a2 b2 d2 25 The 400 data instances where C = c1. b1 b2 a1

11+5 400 7+17 400

a2

227+97 400 11+25 400

P(A, B)

Example - Structure Learning Algorithm

C A B D # c1 a1 b1 d1 11 c1 a1 b1 d2 5 c1 a1 b2 d1 7 c1 a1 b2 d2 17 c1 a2 b1 d1 227 c1 a2 b1 d2 97 c1 a2 b2 d1 11 c1 a2 b2 d2 25 The 400 data instances where C = c1. b1 b2 a1

11+5 400 7+17 400

a2

227+97 400 11+25 400

P(A, B)

Example - Structure Learning Algorithm

C A B D # c1 a1 b1 d1 11 c1 a1 b1 d2 5 c1 a1 b2 d1 7 c1 a1 b2 d2 17 c1 a2 b1 d1 227 c1 a2 b1 d2 97 c1 a2 b2 d1 11 c1 a2 b2 d2 25 The 400 data instances where C = c1. b1 b2 a1

11+5 400 7+17 400

a2

227+97 400 11+25 400

P(A, B)

Example - Structure Learning Algorithm

C A B D # c1 a1 b1 d1 11 c1 a1 b1 d2 5 c1 a1 b2 d1 7 c1 a1 b2 d2 17 c1 a2 b1 d1 227 c1 a2 b1 d2 97 c1 a2 b2 d1 11 c1 a2 b2 d2 25 The 400 data instances where C = c1. b1 b2 a1

11+5 400 7+17 400

a2

227+97 400 11+25 400

P(A, B)

Example - Structure Learning Algorithm

C A B D # c1 a1 b1 d1 11 c1 a1 b1 d2 5 c1 a1 b2 d1 7 c1 a1 b2 d2 17 c1 a2 b1 d1 227 c1 a2 b1 d2 97 c1 a2 b2 d1 11 c1 a2 b2 d2 25 The 400 data instances where C = c1. b1 b2 a1 0.04 0.06 a2 0.81 0.09 P(A, B)

Example - Structure Learning Algorithm

b1 b2 a1 0.04 0.06 a2 0.81 0.09 P(A, B) b1 b2 a1 (0.04 + 0.06) · (0.04 + 0.81) (0.04 + 0.06) · (0.06 + 0.09) a2 (0.81 + 0.09) · (0.04 + 0.81) (0.81 + 0.09) · (0.06 + 0.09) P(A)P(B) M(X; Y ) =

• x∈X,y∈Y

P(x, y)log P(x, y) P(x)P(y) M(A; B)= 0.04 · log( 0.04 0.085) + 0.81 · log( 0.81 0.765) +0.06 · log( 0.06 0.015) + 0.09 · log( 0.09 0.135) = 0.027

Example - Structure Learning Algorithm

b1 b2 a1 0.04 0.06 a2 0.81 0.09 P(A, B) b1 b2 a1 (0.04 + 0.06) · (0.04 + 0.81) (0.04 + 0.06) · (0.06 + 0.09) a2 (0.81 + 0.09) · (0.04 + 0.81) (0.81 + 0.09) · (0.06 + 0.09) P(A)P(B) M(X; Y ) =

• x∈X,y∈Y

P(x, y)log P(x, y) P(x)P(y) M(A; B)= 0.04 · log( 0.04 0.085) + 0.81 · log( 0.81 0.765) +0.06 · log( 0.06 0.015) + 0.09 · log( 0.09 0.135) = 0.027

Example - Structure Learning Algorithm

b1 b2 a1 0.04 0.06 a2 0.81 0.09 P(A, B) b1 b2 a1 (0.04 + 0.06) · (0.04 + 0.81) (0.04 + 0.06) · (0.06 + 0.09) a2 (0.81 + 0.09) · (0.04 + 0.81) (0.81 + 0.09) · (0.06 + 0.09) P(A)P(B) M(X; Y ) =

• x∈X,y∈Y

P(x, y)log P(x, y) P(x)P(y) M(A; B)= 0.04 · log( 0.04 0.085) + 0.81 · log( 0.81 0.765) +0.06 · log( 0.06 0.015) + 0.09 · log( 0.09 0.135) = 0.027

Example - Structure Learning Algorithm

b1 b2 a1 0.04 0.06 a2 0.81 0.09 P(A, B) b1 b2 a1 (0.04 + 0.06) · (0.04 + 0.81) (0.04 + 0.06) · (0.06 + 0.09) a2 (0.81 + 0.09) · (0.04 + 0.81) (0.81 + 0.09) · (0.06 + 0.09) P(A)P(B) M(X; Y ) =

• x∈X,y∈Y

P(x, y)log P(x, y) P(x)P(y) M(A; B)= 0.04 · log( 0.04 0.085) + 0.81 · log( 0.81 0.765) +0.06 · log( 0.06 0.015) + 0.09 · log( 0.09 0.135) = 0.027

Example - Structure Learning Algorithm

b1 b2 a1 0.04 0.06 a2 0.81 0.09 P(A, B) b1 b2 a1 (0.04 + 0.06) · (0.04 + 0.81) (0.04 + 0.06) · (0.06 + 0.09) a2 (0.81 + 0.09) · (0.04 + 0.81) (0.81 + 0.09) · (0.06 + 0.09) P(A)P(B) M(X; Y ) =

• x∈X,y∈Y

P(x, y)log P(x, y) P(x)P(y) M(A; B)= 0.04 · log( 0.04 0.085) + 0.81 · log( 0.81 0.765) +0.06 · log( 0.06 0.015) + 0.09 · log( 0.09 0.135) = 0.027

Example - Structure Learning Algorithm

b1 b2 a1 0.04 0.06 a2 0.81 0.09 P(A, B) b1 b2 a1 (0.04 + 0.06) · (0.04 + 0.81) (0.04 + 0.06) · (0.06 + 0.09) a2 (0.81 + 0.09) · (0.04 + 0.81) (0.81 + 0.09) · (0.06 + 0.09) P(A)P(B) M(X; Y ) =

• x∈X,y∈Y

P(x, y)log P(x, y) P(x)P(y) M(A; B)= 0.04 · log( 0.04 0.085) + 0.81 · log( 0.81 0.765) +0.06 · log( 0.06 0.015) + 0.09 · log( 0.09 0.135) = 0.027

Example - Structure Learning Algorithm

b1 b2 a1 0.04 0.06 a2 0.81 0.09 P(A, B) b1 b2 a1 0.085 0.015 a2 0.765 0.135 P(A)P(B) M(X; Y ) =

• x∈X,y∈Y

P(x, y)log P(x, y) P(x)P(y) M(A; B)= 0.04 · log( 0.04 0.085) + 0.81 · log( 0.81 0.765) +0.06 · log( 0.06 0.015) + 0.09 · log( 0.09 0.135) = 0.027

Example - Structure Learning Algorithm

b1 b2 a1 0.04 0.06 a2 0.81 0.09 P(A, B) b1 b2 a1 0.085 0.015 a2 0.765 0.135 P(A)P(B) M(X; Y ) =

• x∈X,y∈Y

P(x, y)log P(x, y) P(x)P(y) M(A; B)= 0.04 · log( 0.04 0.085) + 0.81 · log( 0.81 0.765) +0.06 · log( 0.06 0.015) + 0.09 · log( 0.09 0.135) = 0.027

Example - Structure Learning Algorithm

b1 b2 a1 0.04 0.06 a2 0.81 0.09 P(A, B) b1 b2 a1 0.085 0.015 a2 0.765 0.135 P(A)P(B) M(X; Y ) =

• x∈X,y∈Y

P(x, y)log P(x, y) P(x)P(y) M(A; B) = 0.04 · log( 0.04 0.085) + 0.81 · log( 0.81 0.765) +0.06 · log( 0.06 0.015) + 0.09 · log( 0.09 0.135) = 0.027

Example - Structure Learning Algorithm

b1 b2 a1 0.04 0.06 a2 0.81 0.09 P(A, B) b1 b2 a1 0.085 0.015 a2 0.765 0.135 P(A)P(B) M(X; Y ) =

• x∈X,y∈Y

P(x, y)log P(x, y) P(x)P(y) M(A; B) = 0.04 · log( 0.04 0.085)+0.81 · log( 0.81 0.765) +0.06 · log( 0.06 0.015) + 0.09 · log( 0.09 0.135) = 0.027

Example - Structure Learning Algorithm

b1 b2 a1 0.04 0.06 a2 0.81 0.09 P(A, B) b1 b2 a1 0.085 0.015 a2 0.765 0.135 P(A)P(B) M(X; Y ) =

• x∈X,y∈Y

P(x, y)log P(x, y) P(x)P(y) M(A; B) = 0.04 · log( 0.04 0.085) + 0.81 · log( 0.81 0.765) +0.06 · log( 0.06 0.015) + 0.09 · log( 0.09 0.135) = 0.027

Example - Structure Learning Algorithm

b1 b2 a1 0.04 0.06 a2 0.81 0.09 P(A, B) b1 b2 a1 0.085 0.015 a2 0.765 0.135 P(A)P(B) M(X; Y ) =

• x∈X,y∈Y

P(x, y)log P(x, y) P(x)P(y) M(A; B) = 0.04 · log( 0.04 0.085) + 0.81 · log( 0.81 0.765) + 0.06 · log( 0.06 0.015)+0.09 · log( 0.09 0.135) = 0.027

Example - Structure Learning Algorithm

b1 b2 a1 0.04 0.06 a2 0.81 0.09 P(A, B) b1 b2 a1 0.085 0.015 a2 0.765 0.135 P(A)P(B) M(X; Y ) =

• x∈X,y∈Y

P(x, y)log P(x, y) P(x)P(y) M(A; B) = 0.04 · log( 0.04 0.085) + 0.81 · log( 0.81 0.765) + 0.06 · log( 0.06 0.015) + 0.09 · log( 0.09 0.135)= 0.027

Example - Structure Learning Algorithm

b1 b2 a1 0.04 0.06 a2 0.81 0.09 P(A, B) b1 b2 a1 0.085 0.015 a2 0.765 0.135 P(A)P(B) M(X; Y ) =

• x∈X,y∈Y

P(x, y)log P(x, y) P(x)P(y) M(A; B) = 0.04 · log( 0.04 0.085) + 0.81 · log( 0.81 0.765) + 0.06 · log( 0.06 0.015) + 0.09 · log( 0.09 0.135) = 0.027

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018 Dependency threshold φ(Xi, Xj) = logN

2N × Tij

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018 Dependency threshold φ(Xi, Xj) = logN

2N × Tij

φ(A, B) = φ(A, D) = φ(B, D)

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018 Dependency threshold φ(Xi, Xj) = logN

2N × Tij

φ(A, B) = φ(A, D) = φ(B, D) = 4log400

800

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018 Dependency threshold φ(Xi, Xj) = logN

2N × Tij

φ(A, B) = φ(A, D) = φ(B, D) = 4log400

800

= 0.013

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018 Dependency threshold φ(Xi, Xj) = logN

2N × Tij

φ(A, B) = φ(A, D) = φ(B, D) = 4log400

800

= 0.013 Total influence W (Xi) =

M(Xi;Xj)>φ(Xi,Xj)

• j(j=i)

M(Xi; Xj)

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018 Dependency threshold φ(Xi, Xj) = logN

2N × Tij

φ(A, B) = φ(A, D) = φ(B, D) = 4log400

800

= 0.013 Total influence W (Xi) =

M(Xi;Xj)>φ(Xi,Xj)

• j(j=i)

M(Xi; Xj) indent indent indentW (A)

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018 Dependency threshold φ(Xi, Xj) = logN

2N × Tij

φ(A, B) = φ(A, D) = φ(B, D) = 4log400

800

= 0.013 Total influence W (Xi) =

M(Xi;Xj)>φ(Xi,Xj)

• j(j=i)

M(Xi; Xj) indent indent indentW (A) = M(A; B)

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018 Dependency threshold φ(Xi, Xj) = logN

2N × Tij

φ(A, B) = φ(A, D) = φ(B, D) = 4log400

800

= 0.013 Total influence W (Xi) =

M(Xi;Xj)>φ(Xi,Xj)

• j(j=i)

M(Xi; Xj) indent indent indentW (A) = M(A; B) = 0.027

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018 Dependency threshold φ(Xi, Xj) = logN

2N × Tij

φ(A, B) = φ(A, D) = φ(B, D) = 4log400

800

= 0.013 Total influence W (Xi) =

M(Xi;Xj)>φ(Xi,Xj)

• j(j=i)

M(Xi; Xj) indent indent indentW (A) = M(A; B) = 0.027 indent indent indentW (B)

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018 Dependency threshold φ(Xi, Xj) = logN

2N × Tij

φ(A, B) = φ(A, D) = φ(B, D) = 4log400

800

= 0.013 Total influence W (Xi) =

M(Xi;Xj)>φ(Xi,Xj)

• j(j=i)

M(Xi; Xj) indent indent indentW (A) = M(A; B) = 0.027 indent indent indentW (B) = M(A; B)

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018 Dependency threshold φ(Xi, Xj) = logN

2N × Tij

φ(A, B) = φ(A, D) = φ(B, D) = 4log400

800

= 0.013 Total influence W (Xi) =

M(Xi;Xj)>φ(Xi,Xj)

• j(j=i)

M(Xi; Xj) indent indent indentW (A) = M(A; B) = 0.027 indent indent indentW (B) = M(A; B) +M(B; D)

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018 Dependency threshold φ(Xi, Xj) = logN

2N × Tij

φ(A, B) = φ(A, D) = φ(B, D) = 4log400

800

= 0.013 Total influence W (Xi) =

M(Xi;Xj)>φ(Xi,Xj)

• j(j=i)

M(Xi; Xj) indent indent indentW (A) = M(A; B) = 0.027 indent indent indentW (B) = M(A; B) +M(B; D) = 0.045

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018 Dependency threshold φ(Xi, Xj) = logN

2N × Tij

φ(A, B) = φ(A, D) = φ(B, D) = 4log400

800

= 0.013 Total influence W (Xi) =

M(Xi;Xj)>φ(Xi,Xj)

• j(j=i)

M(Xi; Xj) indent indent indentW (A) = M(A; B) = 0.027 indent indent indentW (B) = M(A; B) +M(B; D) = 0.045 indent indent indentW (D)

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018 Dependency threshold φ(Xi, Xj) = logN

2N × Tij

φ(A, B) = φ(A, D) = φ(B, D) = 4log400

800

= 0.013 Total influence W (Xi) =

M(Xi;Xj)>φ(Xi,Xj)

• j(j=i)

M(Xi; Xj) indent indent indentW (A) = M(A; B) = 0.027 indent indent indentW (B) = M(A; B) +M(B; D) = 0.045 indent indent indentW (D) = M(B; D)

Example - Structure Learning Algorithm

Mutual information M(A; B) = 0.027 M(A; D) = 0.004 M(B; D) = 0.018 Dependency threshold φ(Xi, Xj) = logN

2N × Tij

φ(A, B) = φ(A, D) = φ(B, D) = 4log400

800

= 0.013 Total influence W (Xi) =

M(Xi;Xj)>φ(Xi,Xj)

• j(j=i)

M(Xi; Xj) indent indent indentW (A) = M(A; B) = 0.027 indent indent indentW (B) = M(A; B) +M(B; D) = 0.045 indent indent indentW (D) = M(B; D) = 0.018

Example - Structure Learning Algorithm

We now construct a full Bayesian network with variable order according to the total influence values:

B A D

Example - Structure Learning Algorithm

We now construct a full Bayesian network with variable order according to the total influence values: W (A) = 0.027 W (B) = 0.045 W (D) = 0.018

B A D

Example - Structure Learning Algorithm

We now construct a full Bayesian network with variable order according to the total influence values: W (A) = 0.027 W (B) = 0.045 W (D) = 0.018 W (B) > W (A) > W (D)

B A D

Example - Structure Learning Algorithm

We now construct a full Bayesian network with variable order according to the total influence values: W (A) = 0.027 W (B) = 0.045 W (D) = 0.018 W (B) > W (A) > W (D)

B A D

We now have the full Bayesian network Bc1, which is the part of the multinet that corresponds to C = c1. We should now repeat the process to construct Bc2 and thereby complete the FBC structure learning.

Example - Structure Learning Algorithm

We now construct a full Bayesian network with variable order according to the total influence values: W (A) = 0.027 W (B) = 0.045 W (D) = 0.018 W (B) > W (A) > W (D)

B A D

We now have the full Bayesian network Bc1, which is the part of the multinet that corresponds to C = c1. We should now repeat the process to construct Bc2 and thereby complete the FBC structure learning.

Example - Structure Learning Algorithm

We now construct a full Bayesian network with variable order according to the total influence values: W (A) = 0.027 W (B) = 0.045 W (D) = 0.018 W (B) > W (A) > W (D)

B A D

We now have the full Bayesian network Bc1, which is the part of the multinet that corresponds to C = c1. We should now repeat the process to construct Bc2 and thereby complete the FBC structure learning.

Example - Structure Learning Algorithm

We now construct a full Bayesian network with variable order according to the total influence values: W (A) = 0.027 W (B) = 0.045 W (D) = 0.018 W (B) > W (A) > W (D)

B A D

We now have the full Bayesian network Bc1, which is the part of the multinet that corresponds to C = c1. We should now repeat the process to construct Bc2 and thereby complete the FBC structure learning.

Example - Structure Learning Algorithm

We now construct a full Bayesian network with variable order according to the total influence values: W (A) = 0.027 W (B) = 0.045 W (D) = 0.018 W (B) > W (A) > W (D)

B A D

We now have the full Bayesian network Bc1, which is the part of the multinet that corresponds to C = c1. We should now repeat the process to construct Bc2 and thereby complete the FBC structure learning.

CPT-tree Learning

We now need to learn a CPT-tree for each variable in the full BN.

CPT-tree Learning

We now need to learn a CPT-tree for each variable in the full BN. A traditional decision tree learning algorithm, such as C4.5, can be used to learn CPT-trees. However, since the time complexity typically is O(n2 · N) the resulting FBC learning algorithm would have a complexity of O(n3 · N).

CPT-tree Learning

We now need to learn a CPT-tree for each variable in the full BN. A traditional decision tree learning algorithm, such as C4.5, can be used to learn CPT-trees. However, since the time complexity typically is O(n2 · N) the resulting FBC learning algorithm would have a complexity of O(n3 · N). Instead a fast decision tree learning algorithm is purposed.

CPT-tree Learning

We now need to learn a CPT-tree for each variable in the full BN. A traditional decision tree learning algorithm, such as C4.5, can be used to learn CPT-trees. However, since the time complexity typically is O(n2 · N) the resulting FBC learning algorithm would have a complexity of O(n3 · N). Instead a fast decision tree learning algorithm is purposed. The algorithm uses the mutual information to determine a fixed

• rdering of variables from root to leaves.

CPT-tree Learning

We now need to learn a CPT-tree for each variable in the full BN. A traditional decision tree learning algorithm, such as C4.5, can be used to learn CPT-trees. However, since the time complexity typically is O(n2 · N) the resulting FBC learning algorithm would have a complexity of O(n3 · N). Instead a fast decision tree learning algorithm is purposed. The algorithm uses the mutual information to determine a fixed

• rdering of variables from root to leaves.

The predefined variable ordering makes the algorithm faster than traditional decision tree learning algorithms.

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T.

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T. 2 If (S is pure or empty) or (ΠXi is empty)

Return T.

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T. 2 If (S is pure or empty) or (ΠXi is empty)

Return T.

3 qualified = False.

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T. 2 If (S is pure or empty) or (ΠXi is empty)

Return T.

3 qualified = False. 4 While (qualified == False) and (ΠXi is not empty)

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T. 2 If (S is pure or empty) or (ΠXi is empty)

Return T.

3 qualified = False. 4 While (qualified == False) and (ΠXi is not empty)

Choose the variable Xj with the highest M(Xj; Xi).

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T. 2 If (S is pure or empty) or (ΠXi is empty)

Return T.

3 qualified = False. 4 While (qualified == False) and (ΠXi is not empty)

Choose the variable Xj with the highest M(Xj; Xi). Remove Xj from ΠXi.

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T. 2 If (S is pure or empty) or (ΠXi is empty)

Return T.

3 qualified = False. 4 While (qualified == False) and (ΠXi is not empty)

Choose the variable Xj with the highest M(Xj; Xi). Remove Xj from ΠXi. Compute the local mutual information MS(Xi; Xj) on S.

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T. 2 If (S is pure or empty) or (ΠXi is empty)

Return T.

3 qualified = False. 4 While (qualified == False) and (ΠXi is not empty)

Choose the variable Xj with the highest M(Xj; Xi). Remove Xj from ΠXi. Compute the local mutual information MS(Xi; Xj) on S. Compute the local dependency threshold φS(Xi, Xj) on S.

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T. 2 If (S is pure or empty) or (ΠXi is empty)

Return T.

3 qualified = False. 4 While (qualified == False) and (ΠXi is not empty)

Choose the variable Xj with the highest M(Xj; Xi). Remove Xj from ΠXi. Compute the local mutual information MS(Xi; Xj) on S. Compute the local dependency threshold φS(Xi, Xj) on S. If MS(Xi; Xj) > φS(Xi, Xj) qualified = True

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T. 2 If (S is pure or empty) or (ΠXi is empty)

Return T.

3 qualified = False. 4 While (qualified == False) and (ΠXi is not empty)

Choose the variable Xj with the highest M(Xj; Xi). Remove Xj from ΠXi. Compute the local mutual information MS(Xi; Xj) on S. Compute the local dependency threshold φS(Xi, Xj) on S. If MS(Xi; Xj) > φS(Xi, Xj) qualified = True

5 If qualified == True

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T. 2 If (S is pure or empty) or (ΠXi is empty)

Return T.

3 qualified = False. 4 While (qualified == False) and (ΠXi is not empty)

Choose the variable Xj with the highest M(Xj; Xi). Remove Xj from ΠXi. Compute the local mutual information MS(Xi; Xj) on S. Compute the local dependency threshold φS(Xi, Xj) on S. If MS(Xi; Xj) > φS(Xi, Xj) qualified = True

5 If qualified == True

Create a root Xj for T.

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T. 2 If (S is pure or empty) or (ΠXi is empty)

Return T.

3 qualified = False. 4 While (qualified == False) and (ΠXi is not empty)

Choose the variable Xj with the highest M(Xj; Xi). Remove Xj from ΠXi. Compute the local mutual information MS(Xi; Xj) on S. Compute the local dependency threshold φS(Xi, Xj) on S. If MS(Xi; Xj) > φS(Xi, Xj) qualified = True

5 If qualified == True

Create a root Xj for T. Partition S into disjoint subsets Sx, x is a value of Xj.

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T. 2 If (S is pure or empty) or (ΠXi is empty)

Return T.

3 qualified = False. 4 While (qualified == False) and (ΠXi is not empty)

Choose the variable Xj with the highest M(Xj; Xi). Remove Xj from ΠXi. Compute the local mutual information MS(Xi; Xj) on S. Compute the local dependency threshold φS(Xi, Xj) on S. If MS(Xi; Xj) > φS(Xi, Xj) qualified = True

5 If qualified == True

Create a root Xj for T. Partition S into disjoint subsets Sx, x is a value of Xj. For all values x of Xj

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T. 2 If (S is pure or empty) or (ΠXi is empty)

Return T.

3 qualified = False. 4 While (qualified == False) and (ΠXi is not empty)

Choose the variable Xj with the highest M(Xj; Xi). Remove Xj from ΠXi. Compute the local mutual information MS(Xi; Xj) on S. Compute the local dependency threshold φS(Xi, Xj) on S. If MS(Xi; Xj) > φS(Xi, Xj) qualified = True

5 If qualified == True

Create a root Xj for T. Partition S into disjoint subsets Sx, x is a value of Xj. For all values x of Xj

• Tx = Fast-CPT-Tree(ΠXi, Sx)

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T. 2 If (S is pure or empty) or (ΠXi is empty)

Return T.

3 qualified = False. 4 While (qualified == False) and (ΠXi is not empty)

Choose the variable Xj with the highest M(Xj; Xi). Remove Xj from ΠXi. Compute the local mutual information MS(Xi; Xj) on S. Compute the local dependency threshold φS(Xi, Xj) on S. If MS(Xi; Xj) > φS(Xi, Xj) qualified = True

5 If qualified == True

Create a root Xj for T. Partition S into disjoint subsets Sx, x is a value of Xj. For all values x of Xj

• Tx = Fast-CPT-Tree(ΠXi, Sx)
• Add Tx as a child of Xj.

CPT-tree Learning Algorithm

Algorithm Fast-CPT-Tree(ΠXi, S)

1 Create an empty tree T. 2 If (S is pure or empty) or (ΠXi is empty)

Return T.

3 qualified = False. 4 While (qualified == False) and (ΠXi is not empty)

Choose the variable Xj with the highest M(Xj; Xi). Remove Xj from ΠXi. Compute the local mutual information MS(Xi; Xj) on S. Compute the local dependency threshold φS(Xi, Xj) on S. If MS(Xi; Xj) > φS(Xi, Xj) qualified = True

5 If qualified == True

Create a root Xj for T. Partition S into disjoint subsets Sx, x is a value of Xj. For all values x of Xj

• Tx = Fast-CPT-Tree(ΠXi, Sx)
• Add Tx as a child of Xj.

6 Return T.

Example - CPT-tree Learning Algorithm

We construct the CPT-tree for the variable D first.

B b1 b2

Example - CPT-tree Learning Algorithm

We construct the CPT-tree for the variable D first. Fast-CPT-Tree(ΠD = {A, B}, S)

B b1 b2

Example - CPT-tree Learning Algorithm

We construct the CPT-tree for the variable D first. Fast-CPT-Tree(ΠD = {A, B}, S) M(D; B) = 0.018 > M(D; A) = 0.004 so Xj = B.

B b1 b2

Example - CPT-tree Learning Algorithm

We construct the CPT-tree for the variable D first. Fast-CPT-Tree(ΠD = {A, B}, S) M(D; B) = 0.018 > M(D; A) = 0.004 so Xj = B. MS(D; B) = M(D; B) = 0.018

B b1 b2

Example - CPT-tree Learning Algorithm

We construct the CPT-tree for the variable D first. Fast-CPT-Tree(ΠD = {A, B}, S) M(D; B) = 0.018 > M(D; A) = 0.004 so Xj = B. MS(D; B) = M(D; B) = 0.018 , φS(D, B) = φ(D, B) = 0.013

B b1 b2

Example - CPT-tree Learning Algorithm

We construct the CPT-tree for the variable D first. Fast-CPT-Tree(ΠD = {A, B}, S) M(D; B) = 0.018 > M(D; A) = 0.004 so Xj = B. MS(D; B) = M(D; B) = 0.018 , φS(D, B) = φ(D, B) = 0.013 MS(D; B) > φS(D, B) so qualified = True.

B b1 b2

Example - CPT-tree Learning Algorithm

We construct the CPT-tree for the variable D first. Fast-CPT-Tree(ΠD = {A, B}, S) M(D; B) = 0.018 > M(D; A) = 0.004 so Xj = B. MS(D; B) = M(D; B) = 0.018 , φS(D, B) = φ(D, B) = 0.013 MS(D; B) > φS(D, B) so qualified = True. Since qualified == True, create a root for Xj = B and partition S into the subsets Sb1 and Sb2.

B b1 b2

Example - CPT-tree Learning Algorithm

We construct the CPT-tree for the variable D first. Fast-CPT-Tree(ΠD = {A, B}, S) M(D; B) = 0.018 > M(D; A) = 0.004 so Xj = B. MS(D; B) = M(D; B) = 0.018 , φS(D, B) = φ(D, B) = 0.013 MS(D; B) > φS(D, B) so qualified = True. Since qualified == True, create a root for Xj = B and partition S into the subsets Sb1 and Sb2. Recursively call: Fast-CPT-Tree(ΠD = {A}, Sb1) and Fast-CPT-Tree(ΠD = {A}, Sb2)

B b1 b2

Example - CPT-tree Learning Algorithm

We construct the CPT-tree for the variable D first. Fast-CPT-Tree(ΠD = {A, B}, S) M(D; B) = 0.018 > M(D; A) = 0.004 so Xj = B. MS(D; B) = M(D; B) = 0.018 , φS(D, B) = φ(D, B) = 0.013 MS(D; B) > φS(D, B) so qualified = True. Since qualified == True, create a root for Xj = B and partition S into the subsets Sb1 and Sb2. Recursively call: Fast-CPT-Tree(ΠD = {A}, Sb1) and Fast-CPT-Tree(ΠD = {A}, Sb2) Add the resulting trees as children of Xj = B.

B b1 b2

Example - CPT-tree Learning Algorithm

We construct the CPT-tree for the variable D first. Fast-CPT-Tree(ΠD = {A, B}, S) M(D; B) = 0.018 > M(D; A) = 0.004 so Xj = B. MS(D; B) = M(D; B) = 0.018 , φS(D, B) = φ(D, B) = 0.013 MS(D; B) > φS(D, B) so qualified = True. Since qualified == True, create a root for Xj = B and partition S into the subsets Sb1 and Sb2. Recursively call: Fast-CPT-Tree(ΠD = {A}, Sb1) and Fast-CPT-Tree(ΠD = {A}, Sb2) Add the resulting trees as children of Xj = B.

B b1 b2

Example - CPT-tree Learning Algorithm

Fast-CPT-Tree(ΠD = {A}, Sb1)

Example - CPT-tree Learning Algorithm

Fast-CPT-Tree(ΠD = {A}, Sb1) Only one parent variable remains, so Xj = A.

Example - CPT-tree Learning Algorithm

Fast-CPT-Tree(ΠD = {A}, Sb1) Only one parent variable remains, so Xj = A. MSb1(D; A) = 7 · 10−6

Example - CPT-tree Learning Algorithm

Fast-CPT-Tree(ΠD = {A}, Sb1) Only one parent variable remains, so Xj = A. MSb1(D; A) = 7 · 10−6 , φSb1(D, A) = 0.015

Example - CPT-tree Learning Algorithm

Fast-CPT-Tree(ΠD = {A}, Sb1) Only one parent variable remains, so Xj = A. MSb1(D; A) = 7 · 10−6 , φSb1(D, A) = 0.015 MSb1(D; A) ≯ φSb1(D, A) so qualified = False.

Example - CPT-tree Learning Algorithm

Fast-CPT-Tree(ΠD = {A}, Sb1) Only one parent variable remains, so Xj = A. MSb1(D; A) = 7 · 10−6 , φSb1(D, A) = 0.015 MSb1(D; A) ≯ φSb1(D, A) so qualified = False. Since qualified == False, return the empty tree.

Example - CPT-tree Learning Algorithm

Fast-CPT-Tree(ΠD = {A}, Sb1) Only one parent variable remains, so Xj = A. MSb1(D; A) = 7 · 10−6 , φSb1(D, A) = 0.015 MSb1(D; A) ≯ φSb1(D, A) so qualified = False. Since qualified == False, return the empty tree. Fast-CPT-Tree(ΠD = {A}, Sb2)

Example - CPT-tree Learning Algorithm

Fast-CPT-Tree(ΠD = {A}, Sb1) Only one parent variable remains, so Xj = A. MSb1(D; A) = 7 · 10−6 , φSb1(D, A) = 0.015 MSb1(D; A) ≯ φSb1(D, A) so qualified = False. Since qualified == False, return the empty tree. Fast-CPT-Tree(ΠD = {A}, Sb2) Only one parent variable remains, so Xj = A.

Example - CPT-tree Learning Algorithm

Fast-CPT-Tree(ΠD = {A}, Sb1) Only one parent variable remains, so Xj = A. MSb1(D; A) = 7 · 10−6 , φSb1(D, A) = 0.015 MSb1(D; A) ≯ φSb1(D, A) so qualified = False. Since qualified == False, return the empty tree. Fast-CPT-Tree(ΠD = {A}, Sb2) Only one parent variable remains, so Xj = A. MSb2(D; A) = 4 · 10−5

Example - CPT-tree Learning Algorithm

Fast-CPT-Tree(ΠD = {A}, Sb1) Only one parent variable remains, so Xj = A. MSb1(D; A) = 7 · 10−6 , φSb1(D, A) = 0.015 MSb1(D; A) ≯ φSb1(D, A) so qualified = False. Since qualified == False, return the empty tree. Fast-CPT-Tree(ΠD = {A}, Sb2) Only one parent variable remains, so Xj = A. MSb2(D; A) = 4 · 10−5 , φSb2(D, A) = 0.059

Example - CPT-tree Learning Algorithm

Fast-CPT-Tree(ΠD = {A}, Sb1) Only one parent variable remains, so Xj = A. MSb1(D; A) = 7 · 10−6 , φSb1(D, A) = 0.015 MSb1(D; A) ≯ φSb1(D, A) so qualified = False. Since qualified == False, return the empty tree. Fast-CPT-Tree(ΠD = {A}, Sb2) Only one parent variable remains, so Xj = A. MSb2(D; A) = 4 · 10−5 , φSb2(D, A) = 0.059 MSb2(D; A) ≯ φSb2(D, A) so qualified = False.

Example - CPT-tree Learning Algorithm

Fast-CPT-Tree(ΠD = {A}, Sb1) Only one parent variable remains, so Xj = A. MSb1(D; A) = 7 · 10−6 , φSb1(D, A) = 0.015 MSb1(D; A) ≯ φSb1(D, A) so qualified = False. Since qualified == False, return the empty tree. Fast-CPT-Tree(ΠD = {A}, Sb2) Only one parent variable remains, so Xj = A. MSb2(D; A) = 4 · 10−5 , φSb2(D, A) = 0.059 MSb2(D; A) ≯ φSb2(D, A) so qualified = False. Since qualified == False, return the empty tree.

Example - CPT-tree Learning Algorithm

We now only need to add Xi = D as children of B and specify the probabilities, which are trivial to calculate.

B b1 b2

Example - CPT-tree Learning Algorithm

We now only need to add Xi = D as children of B and specify the probabilities, which are trivial to calculate.

B b1 b2

We should repeat this process for each variable in each network.

Example - CPT-tree Learning Algorithm

We now only need to add Xi = D as children of B and specify the probabilities, which are trivial to calculate.

B b1 b2 D d1 d2 D d1 d2

We should repeat this process for each variable in each network.

Example - CPT-tree Learning Algorithm

We now only need to add Xi = D as children of B and specify the probabilities, which are trivial to calculate.

B b1 b2 D d1 d2 D d1 d2

11+227 340 =0.7 5+97 340 =0.3 7+11 60 =0.3 17+25 60 =0.7

We should repeat this process for each variable in each network.

Complexity

Let n be the number of variables and N the number of data instances.

Complexity

Let n be the number of variables and N the number of data instances. FBC-Structure has time complexity O(n2 · N).

Complexity

Let n be the number of variables and N the number of data instances. FBC-Structure has time complexity O(n2 · N). Fast-CPT-Tree has time complexity O(n · N).

Complexity

Let n be the number of variables and N the number of data instances. FBC-Structure has time complexity O(n2 · N). Fast-CPT-Tree has time complexity O(n · N). Fast-CPT-Tree is called once for each variable in each of the |C| multinet parts. Hence the time complexity: O(|C| · n2 · N

|C|) = O(n2 · N).

Complexity

Let n be the number of variables and N the number of data instances. FBC-Structure has time complexity O(n2 · N). Fast-CPT-Tree has time complexity O(n · N). Fast-CPT-Tree is called once for each variable in each of the |C| multinet parts. Hence the time complexity: O(|C| · n2 · N

|C|) = O(n2 · N).

Thus, the FBC learning algorithm has the time complexity O(n2 · N).

Experiments - Results

33 UCI data sets, available in Weka, are used for experiments.

Experiments - Results

33 UCI data sets, available in Weka, are used for experiments. Performance of an algorithm on each data set is observed via 10 runs of 10-fold cross validation.

Experiments - Results

33 UCI data sets, available in Weka, are used for experiments. Performance of an algorithm on each data set is observed via 10 runs of 10-fold cross validation. Two-tailed t-test with a 95% confidence interval is conducted to compare each pair of algorithms on each data set.

Experiments - Results

33 UCI data sets, available in Weka, are used for experiments. Performance of an algorithm on each data set is observed via 10 runs of 10-fold cross validation. Two-tailed t-test with a 95% confidence interval is conducted to compare each pair of algorithms on each data set. Results on accuracy - classification (data sets won - draw - lost) AODE HGC TAN NBT C4.5 SMO FBC 8/22/3 4/27/2 6/27/0 6/27/0 11/19/3 6/24/2

Experiments - Results

33 UCI data sets, available in Weka, are used for experiments. Performance of an algorithm on each data set is observed via 10 runs of 10-fold cross validation. Two-tailed t-test with a 95% confidence interval is conducted to compare each pair of algorithms on each data set. Results on accuracy - classification (data sets won - draw - lost) AODE HGC TAN NBT C4.5 SMO FBC 8/22/3 4/27/2 6/27/0 6/27/0 11/19/3 6/24/2 Results on AUC - ranking (data sets won - draw - lost) AODE HGC TAN NBT C4.5L SMO FBC 7/22/4 6/25/2 9/24/0 8/24/1 25/7/1 10/20/3

Experiments - Complexity

Complexity of tested algorithms Training Classification FBC O(n2 · N) O(n) AODE O(n2 · N) O(n2) HGC O(n4 · N) O(n) TAN O(n2 · N) O(n) NBT O(n3 · N) O(n) C4.5 O(n2 · N) O(n) SMO O(n2.3) O(n)

Experiments - Conclusion

FBC demonstrates good performance in both classification and ranking.

Experiments - Conclusion

FBC demonstrates good performance in both classification and ranking. FBC is among the most efficient algorithms in both training and classification time.

Experiments - Conclusion

FBC demonstrates good performance in both classification and ranking. FBC is among the most efficient algorithms in both training and classification time. Overall, the performance of FBC is the best among the algorithms compared.
