From Development to Production: Many Uses of Serverless Observability

EMRAH SAMDAN | SEPTEMBER 9, 2019

Community Day 2019 Sponsors

@emrahsamdan

Who am I?

• Developer for 6+ years
• Product manager for 2 years
• VP of Product for Thundra
• Organizing committee
• Serverlessdays İstanbul

On October 3rd!

@emrahsamdan

Agenda

• Let’s define serverless (yes once again!)
• Is observability a buzzword or a real thing?
• Observability challenges in serverless
• Observability Driven Development
• How/When to test serverless applications
• What to check to monitor serverless stack
• Troubleshooting serverless applications

@emrahsamdan

What’s serverless

Serverless computing is a cloud-computing execution model in which the cloud provider runs the server, and dynamically manages the allocation of machine

• resources. Pricing is based on the actual amount of resources consumed by an

application, rather than on pre-purchased units of capacity.

Wikipedia: https://en.wikipedia.org/wiki/Serverless_computing

@emrahsamdan

What is serverless?

Operational construct? Things that run perfectly and I don’t need to manage. Is Stripe, Auth0 serverless?

@emrahsamdan

@emrahsamdan

What’s serverless?

Utility computing I only pay per what I use.

@emrahsamdan

What’s serverless?

A doctrine, a thought model helping you deliver faster and put your focus on the value you provide to your customers.

Ben Kehoe Paul Johnston

I agree you all. But! All the ups can go down when you don’t pay attention what’s really happening with serverless.

Shared Responsibility Model Cloud vendor will handle scalability and reliability. But performance and security IS still ON US.

@emrahsamdan

Serverless Observability

• Serverless is full of hidden

traps that can harm its promise.

• Can be very costly.
• Can perform really poor.
• You need to check what’s

going on.

@emrahsamdan

What’s observability?

https://medium.com/@copyconstruct/monitoring-and-observability-8417d1952e1c

@emrahsamdan

Are we ready for unknown unknowns?

Known knowns Things that we understand and we are aware of. Follow the metric charts. Known unknowns Things that we are aware of but don’t understand at a glance. Yes, there is a peak over there. Let me dig the traces and logs. Unknown knowns Things that we can understand but we are not aware of. I would have fixed this if I had that that metric chart :( Unknown unknowns Things we neither understand nor aware of. That things are kaputt and I have no freaking idea with what I have.

@emrahsamdan

The pillars

Traces Metrics Logs Visualization Machine Learning and Insights Alerts

@emrahsamdan

Observability Challenges in Serverless

• No access to underlying infrastructure
• You either take whatever cloud vendor provides or accept that there will

be an overhead.

• Overhead?

○ Gathering intelligence (should be acceptable) ○ Transporting it to where necessary (you only have invocation life time to take the data

• ut)
• Everything is event-driven and distributed.

Fix the Charizard. If you can!

@emrahsamdan

Observability-Driven Development

@emrahsamdan

Observability-Driven Development

• Recall that unknown-unknowns.
• What do you need to when you have to

troubleshoot a unknown-unknown?

• Can an observability tool know your

unknowns?

• If you don’t know what to know what

can you do?

Known knowns Things that we understand and we are aware of. Follow the metric charts. Known unknowns Things that we are aware of but don’t understand at a glance. Yes, there is a peak over

• there. Let me dig the traces

and logs. Unknown knowns Things that we can understand but we are not aware of. I would have fixed this if I had that that metric chart :( Unknown unknowns Things we neither understand nor aware of. That things are kaputt and I have no freaking idea with what I have.

ASK

Your observability tool should give you auto-replies. But it should also let you ask wise questions.

@emrahsamdan

Observability-Driven Development

• Not a replacement for test-driven development.
• Think of the answers that you can give for any type of question.
• If you are thinking about questions, request that feature from your tool.
• Structured logging and manual instrumentation is the key.

Retrieved from: https://dzone.com/articles/what-is-structured-logging

@emrahsamdan

Observability-Driven Development (Cons)

• Observability coverage?
• Hard to accustom.
• You can’t sample a thing.

TESTING

@emrahsamdan

Testing challenges in Serverless

• Local testing is a pain.

○ How to mock the cloud resources. Is it actually correct to mock them? ○ How should you test the chain of many invocations? ○ How to integrate it with CI/CD tools?

• Integration testing with real resources is still the best effort but again

how?

@emrahsamdan

Integration testing

• Serverless != Functions
• Test your business logic against the

resources.

• See how your messages being

transformed in the flow.

• Async events can cause problems

that you can never guess.

@emrahsamdan

Integration Testing (Cons)

• Still you’re dealing only with known-knowns.
• Resources that are not pay-per-use.

○ Setting up a test environment. Still?

• Not with the production data.

@emrahsamdan

Chaos Testing Serverless Applications

• Serverless fits the chaos engineering greatly because

○ Distributed ○ Lots of possibilities of failures in async environment ○ Event-driven (So poisonous events) ○ Roles and permissions are so granular that access can slip away.

@emrahsamdan

Chaos testing on serverless what?

• What would happen if inner

Lambda starts to respond slow?

• Are you sure that you properly

tuned timeouts?

• Test with injecting latency.

@emrahsamdan

Chaos testing on serverless what?

• What if we lose the connection

to Redis?

@emrahsamdan

Chaos testing on serverless. How?

• https://github.com/adhorn/aws-lambda-chaos-injection
• https://github.com/gunnargrosch/

Adrian Hornsby Gunnar Grosch

MONITORING

How large should be my screen to see the charts for thousands of functions?

@emrahsamdan

How to discover an anomaly in serverless?

@emrahsamdan

@emrahsamdan

Serverless is more than functions, so is monitoring.

• Issues can stay local before you notice them.
• It is slow. Why?

○ API slowdown? ○ Throttle on any resource? ○ Bad coding practice?

• Invocation counts go crazy.

○ Seasonal peak? ○ Successful product? ○ Retry storms?

@emrahsamdan

@emrahsamdan

Monitoring Latency

• Abnormal latency is mostly not related

with the function code.

○ Idly waiting for a third party API. ○ Throttled resource

• Set aggregated alerts

○ Alert on transaction duration ○ Alert on function duration. ○ Alert on operation duration

@emrahsamdan

Storm of retries and errors

• When your code fails for some reason, your function will retry several

times.

○ Sync events: You should control it. ○ Async events: Different retry mechanisms. ○ Stream based events: Risk of losing data.

• Does this solve?
• Check

○ Iterator age ○ Number of retries ○ Number of errors ○ Memory usage ○ Cold starts

TROUBLESHOOTING

Bad things happen in serverless, too. Now, it’s time to battle!

@emrahsamdan

Failure modes of serverless

• https://github.com/adhorn/aws-lambda-chaos-injection
• https://github.com/gunnargrosch/

@emrahsamdan

Failure modes of serverless

Bad-tuned memory Timeout Error in code or in a managed resource

@emrahsamdan

Consequences

Downtimes Huge Bills Unhappy customers

@emrahsamdan

Challenges of Troubleshooting

How to trace the distributed async events with non-aggregated traces, metrics and logs? How to trace requests to external resources? How to trace the async distributed events?

@emrahsamdan

Distributed Tracing

• Trace the distributed

transactions: chain of multiple invocations

• Understand what is

wrong with a glance

• But?! What if the I

have a bad coding practice in the code?

@emrahsamdan

Local Tracing

• Instrument the code itself

and check against code quality.

• Good for discovering

○ Bad coding practices ○ Value of local variables in the code. ○ Debugging the code without breakpoints.

@emrahsamdan

Actionable Alerts in Serverless

• Alert on code errors

○ Stacktrace ○ Code line it caused ○ Values of (Local variables)

• Alert on latencies and timeout

errors

○ Slow API communications ○ Slow DB interaction for bad queries

@emrahsamdan

How to respond to the issues on serverless

• Issue may not be your code.
• Check the third parties.
• Check other metrics

○ Iterator age of streams ○ Throttles on resources

• Have some runbooks

○ Exponential backoffs to APIs, Alternative APIs ○ Healthy on-call structures

@emrahsamdan

Key Takeaways

• Serverless observability is not an after-production issue.
• Observability with all three pillars aggregated is life-saving.
• Automation is king! But, get yourself ready to ask questions with ODD.
• Sadly, no testing scenario is sufficient in serverless. Step into chaos

engineering before your engineering run into chaos!

• Change the way you monitor your system. Look beyond functions and

discover local bottlenecks with an architectural view!

• Serverless transaction= A chain of invocations commuting between

resources and APIs. Full tracing required!

• Make your alerts actionable and start keeping runbooks for the issues

that you can predict.

Thank you! Danke schön!
