CONFIDENTIAL FREDRIK SAHLN, ANNA ANDERS SON, ABB CORPORATE RES EARCH Graphene VBIK Ludvika 2018-05-14 Graphene Tape dispenser at Nobel Museum in Stockholm M ay 18, 2018 S lide 2 Agenda Graphene structure

slide-1
SLIDE 1

—

—

CONFIDENTIAL

FREDRIK SAHLÉN, ANNA ANDERS SON, ABB CORPORATE RES EARCH

Graphene

VBIK Ludvika 2018-05-14

slide-2
SLIDE 2

— Graphene

M ay 18, 2018 S lide 2

Tape dispenser at Nobel Museum in Stockholm

slide-3
SLIDE 3

—

  • Graphene structure
  • Graphene properties
  • Graphene manufacturing
  • Applications
  • SIO Graphene
  • Graphene Flagship
  • ABB development

Agenda

M ay 18, 2018 S lide 3

slide-4
SLIDE 4

— Nobel Prize in Physics 2010

M ay 18, 2018 S lide 4

Konstantin Novoselov, Andre Geim University of M anchester Novel work in isolating graphene in 2004 Nobel M useum in S tockholm Tape dispenser and a lump of graphite Nobel prize in physics 2010

slide-5
SLIDE 5

— Alleotropesof carbon

M ay 18, 2018 S lide 5

Diamond Carbon nanotubes (S EM ) Graphite Amorphous soot, carbon black Graphene on plastic substrate

slide-6
SLIDE 6

— Bond structure

M ay 18, 2018 S lide 6

Carbon has 4 bond sites 3 sp2 hybridized orbitals 1 p orbital

slide-7
SLIDE 7

— Graphene oxide, reduced graphene oxide

M ay 18, 2018 S lide 7

Graphene oxide (GO)

slide-8
SLIDE 8

— Properties

M ay 18, 2018 S lide 8

  • Thinnes material– 1 one atom layer
  • Strongest material
  • Low weight
  • Flexible
  • Large surface area
  • High thermal conductivity
  • High electrical conductivity
  • Transparent
  • Good barrier properties
  • Affinity to other molecules
slide-9
SLIDE 9

— M anufacturing technologies

M ay 18, 2018 S lide 9

slide-10
SLIDE 10

— Applications

M ay 18, 2018 S lide 10

Corrosion protection Hydrophobic surfaces Barrieres M initurized coolers Sensors, electronics M ultifunctional composites Filters

slide-11
SLIDE 11

— Products on the market

M ay 18, 2018 S lide 11

Composite materials

slide-12
SLIDE 12
slide-13
SLIDE 13

Sverige är ett av världens tio främsta länder på att utnyttja grafen för att säkerställa industriellt ledarskap år 2030

slide-14
SLIDE 14

Mål

  • Etablera grafen som industriellt styrkeområde
  • Stärka samverkan
  • Stimulera svenskt grafentillverkning
  • Strategisk vägledning
slide-15
SLIDE 15

Materialtillverkning, karaktärisering, processutveckling, testbäddar, produktionsutveckling Sensorer, tryckt elektronik, högfrekvenselektronik

Polymerbaserade med

  • ch utan fiber, textilier,

betong, metall

Beläggningar, membran, barriärer, filter Lagring, generering, termisk och elektrisk ledning Medicinteknik, miljö- och hälsoaspekter

slide-16
SLIDE 16
  • 49 innovationsprojekt initierade
  • > 60 organisationer har deltagit
  • 31 SMF
  • Produkter av 2D fab och Graphensic

Så här långt..

slide-17
SLIDE 17

Innovationsprojekt i Sverige

  • Kylning av elektronik
  • Smörjmedel
  • Vattenrening
  • Tryckt elektronik
  • Gassensorer
  • Förstärkning av cement och betong
  • Barriärer i förpackningar
  • Kamouflage
  • Ytbeläggningar – antikorrosion, biofouling, nötning
  • Ledande adhesiv
  • Tillverkning av grafen och grafenbläck
  • Multifunktionella kompositer och textilier
slide-18
SLIDE 18

FET Flagships

“FET Flagships are ambitious large-scale, science-driven, research initiatives that aim to achieve a visionary goal. The scientific advance should provide a strong and broad basis for future technological innovation and economic exploitation in a variety of areas, as well as novel benefits for society.” Scale: 10 year project period, 1 B€ project cost (500 M€ from EC) Graphene (coordinated by Chalmers) and the Human Brain Project (EPFL). New flagships are in progress. 2013, October 1: Project start with a 30 month ramp-up phase. 2016, April 1: Enter Horizon 2020 phase.

18 M ay 2018 www.graphene-flagship.eu 18

slide-19
SLIDE 19

Core 1 today

Core 1 started on April 1, 2016:

– 156 partners in 23 countries; about 1/3 industry, 1/2 academia and 1/6 other – 15 S&T work packages, 5 supporting work packages – 450 full-time equivalent persons,

  • ver 1,300 individuals

– 80 Associated Members, many of whom are involved in 19 Partnering Projects

Output includes thus far

– Nearly 1,500 publications with over 21,000 citations – About 40 patents applied and 20 products launched – Some 350 hired graduate students

18 M ay 2018 www.graphene-flagship.eu 19

slide-20
SLIDE 20

Roadmap

slide-21
SLIDE 21
  • Helena Theander
  • Jon Wingborg
  • Johan Ek Weiss
  • Sophie Charpentier
  • Jari Kinaret
  • Vincenzo Palermo

Thank you for contributions to the presentation

M ay 18, 2018 Slide 21
