S7348: Deep Learning in Ford's Autonomous Vehicles

Bryan Goodman Argo AI 9 May 2017

1

Today: examples from

• Stereo image processing
• Object detection
• Using RNN’s
• Motorsports

2

Ford’s 12 Year History in Autonomous Driving

Stereo Matching Problem

• Determining the correspondences in stereo images
• Calculating the disparities
• But what is the correct correspondence?
• Basic stereo matching algorithm

− Compare pixels on the same epipolar line in two images − Choose the best match

3

Deep neural networks for stereo matching

• The brain can estimate the distance of

an object using the visual information from two eyes.

• We can use deep neural networks

4

Right Stereo Camera Deep Convolutional Neural Networks Post-Processing Left Stereo Camera Distance Map Estimation

Proposed deep convolutional neural network

• AV driving requires an intelligent distance map estimation, which filters out the
• bjects not of interest.
• Network I

− General network − Encoding and decoding layers − Retain objects of interest in the training data sets

5

Conv1

Conv5

Conv2 Conv3

Conv6 Deconv6

Conv7 Deconv7 Deconv8 Conv8 Deconv9

Encoder Decoder

Conv9

Loss Function

Deconv10 Conv10 Conv4

Proposed deep convolutional neural network II

− Specialized network − Encoding and decoding layers − The cross correlation layers force the network to look for correspondence on the epipolar line − The weights in the encoding layers are shared

6 Conv1L

Conv4L Loss Function Encoder Decoder

Conv2L Conv3L Conv1R

Conv4R

Conv2R Conv3R

CC5

Conv5

Conv6 CC6

Deconv6

Conv7 CC7 Deconv7 Deconv8 Conv8 Deconv9 Conv9

Proposed deep convolutional neural network

• Cross correlation (CC) layer

− Computes CC values between each pairs of patches − Outputs the CC values for each pair of patches − Does not lose any information

• Loss function

− In AV driving, closer objects are more important than distant ones − Assigns more weight to the closer objects − The closer object distance is estimated more accurately

7 0.2 0.4 0.6 0.8 1 1 0.4 0.2 α d 0.6 0.8

Performance on synthetic and real stereo data

• Synthetic data generation

− Generate 14,000 pairs of RGB stereo images − Synthetic distance maps are only generated for the objects of interest, e.g. cars or pedestrians − Gaussian noise added to the stereo images

8

Performance on synthetic and real stereo data

• Fine tuning with LIDAR data sets

− Project LIDAR point clouds onto the camera images − The baseline and optic axes are not the same as the synthetic data

9

Left camera Right camera Network I Network II

1/2x

10

Comparing Manual Annotation to DNN Model

11

12

Detection Result Original Image Enhanced Contrast

Network’s detection outperforms human labeler in low-contrast areas

Pedestrian detection Pedestrian misdetection Detected, but not labeled

Introducing Recurrence in Detection and Tracking

• Use RNN’s to detect occluded objects
• Remember location of static objects
• Predict location of non-static objects

13

Image 0 Feature Map

RNN Conv

Image 1 Feature Map Image 2 Feature Map

RNN Conv RNN Conv Detector Detector Detector

Orange = ground truth; Green = model prediction

14

15

Classifying NASCAR images

The Ford team reviews pictures during the race

16

Classifying NASCAR images

Looking for damage and

• ther performance indicators

Gap

17

Results – Boxing the Cars

Using ~2k images labeled with boxes around the vehicles, the model does well detecting cars

18

Results – Boxing the Cars

Classifying NASCAR images

Next – determine car number: labeled ~30k images

Classifying NASCAR images

Outliers easy to find in review

Classifying NASCAR images

Human: ??? Model: 78 Confidence: 0.999

Classifying NASCAR images

Human: ??? Model: 42 Confidence: 0.985

Inspecting the Neural Network

23

Activated Filter Input Image

The Model is not a black box. We can see that it is detecting the numbers – important for robustness when the paint changes

Argo AI

• Argo AI is an artificial intelligence company, established to tackle one
• f the most challenging applications in computer science, robotics

and artificial intelligence: self-driving vehicles

• Engineering hubs in Pittsburgh, Southeastern Michigan and the Bay

Area of California

• For more information regarding Argo AI and its work, please talk to

me at GTC or visit: www.argo.ai

24
