INTRODUCTIONS

PAUL W. CUMMINGS, AICP, LEED AP Senior Planner ETHAN J. GADDY, AICP Planner

slide-3
SLIDE 3

OVERVIEW

  • Quick GIS Background
  • GIS Collector For Stormwater & Infrastructure

Management

  • GIS Site Suitability Analysis for On-Lot Septic System

Management

  • GIS for Watershed-Scale Stormwater Management
slide-4
SLIDE 4

GIS BACKGROUND

Geographic Information System (GIS)

“A system designed to capture, store, manipulate, analyze, manage, and present spatial or geographic data.”

slide-5
SLIDE 5

GIS BACKGROUND

STATIC MAP ACCESSIBLE DYNAMIC GIS MAP

slide-6
SLIDE 6

STORMWATER & INFRASTRUCTURE MANAGEMENT

  • MOBILE APPLICATIONS ALLOW FIELD STAFF TO

COLLECT AND UPDATE GEOSPATIAL INFORMATION

  • “OUT OF THE BOX” FUNCTIONALITY
  • EASY TO USE
  • EASY TO CREATE AND MAINTAIN DATA
  • WORKS ACROSS VARIOUS DEVICES (WINDOWS,

ANDROID, AND IOS)

  • UTILIZES CLOUD BASED SERVICES/ UPDATES

CLOUD BASED GIS APPLICATIONS

slide-7
SLIDE 7

STORMWATER & INFRASTRUCTURE MANAGEMENT

MS4 community Aging infrastructure Sensitive environmental setting Small tax base requires strategic infrastructure management

LAKE GEORGE VILLAGE CASE STUDY

slide-8
SLIDE 8

STORMWATER & INFRASTRUCTURE MANAGEMENT

HOW TO CONNECT PEOPLE INVOLVED IN THE DAY TO DAY BUSINESS

OF OPERATING AND MAINTAINING INFRASTRUCTURE WITH

NECESSARY INFORMATION?

  • COMPILE RECORD MAPPING
  • WORK WITH STAFF TO DETERMINE NEEDS
  • DEVELOP A DATA DICTIONARY
  • HANDS ON TRAINING AND TESTING
  • LAUNCH AND MANAGEMENT
slide-9
SLIDE 9

STORMWATER & INFRASTRUCTURE MANAGEMENT

Streamlined data entry and connectivity

Reduced or eliminated “post-processing” Reduced amounts of hardware Smart photologs Back office support with real-time feedback

slide-10
SLIDE 10

SITE SUITABILITY ANALYSIS

LAKE GEORGE WATERSHED DATA ATLAS

THE LAKE GEORGE WATERSHED INCLUDES A PORTION OF

SEVERAL MUNICIPALITIES. THIS MAKES WATERSHED- SPECIFIC INFORMATION GATHERING DIFFICULT:

  • THREE (3) COUNTIES
  • ELEVEN (11) TOWNS
  • ONE (1) VILLAGE
  • MULTIPLE US CENSUS TRACTS,

BLOCK GROUPS, AND BLOCKS

slide-11
SLIDE 11

SITE SUITABILITY ANALYSIS

2,498 1,887 1,184 1,516 1,097 404 418 635 266 1,986 1,829 1,600 777 453 675 587 193 491

  • 500

1,000 1,500 2,000 2,500 3,000 3,500 4,000 4,500 5,000 Bolton Lake George (T) Hague Queensbury Ticonderoga Fort Ann Putnam Lake George (V) Dresden Warrensburg Lake Luzerne Horicon

EXISTING & POTENTIAL NEW RESIDENTIAL UNITS IN WATERSHED

Existing Residential Potential New Residential

2,498 1,887 1,184 1,516 1,097 404 418 635 266 1,986 1,829 1,600 777 453 675 587 193 491

  • 500

1,000 1,500 2,000 2,500 3,000 3,500 4,000 4,500 5,000 Bolton Lake George (T) Hague Queensbury Ticonderoga Fort Ann Putnam Lake George (V) Dresden Warrensburg Lake Luzerne Horicon

EXISTING & POTENTIAL NEW RESIDENTIAL UNITS IN WATERSHED

Existing Residential Potential New Residential

Residential Homes Built Prior to 2015

BUILDOUT ANALYSIS:

Existing & Potential New Residential Units

slide-12
SLIDE 12

SITE SUITABILITY ANALYSIS

ONSITE WASTEWATER TREATMENT SYSTEMS (OWTS)

& WATER QUALITY (E.G., ALGAE)

  • CONCERNS INCLUDE METAL SEPTIC TANKS (THAT

MAY OR MAY NOT BE CORRODED AND LEAKING) AND CESSPOOLS. POSSIBLE FAILURES IN SOIL TREATMENT AREAS (STA) AND SEEPAGE PITS ARE ALSO BEING LOOKED AT, AS WELL OVERALL AGE OF SYSTEMS

  • THERE IS LIKELY A NUMBER OF EXISTING

PROPERTIES WITHIN 500 FEET OF LAKE GEORGE AND 100 FEET OF STREAMS THAT POTENTIALLY NEED RETROFIT OR SOME LEVEL OF REPLACEMENT OF OWTS

slide-13
SLIDE 13

SITE SUITABILITY ANALYSIS

PROJECT BOUNDARIES:

  • PHASE I: DIAMOND POINT AREA
  • PHASE II: CANNON POINT TO

HEARTHSTONE

  • PHASE III: HEARTHSTONE TO

ENGLISH BROOK

  • PHASE IV: EAST SIDE (PLUM POINT

TO WIAWAKA, AND ELM SCHOOL SOUTH)

slide-14
SLIDE 14

SITE SUITABILITY ANALYSIS

BASE INVENTORY & SURVEY

slide-15
SLIDE 15

SITE SUITABILITY ANALYSIS

OWTS INVENTORY ASSESSMENT WITH GIS PARCEL DATA Joins & Relates

GIS Parcel Attribute Data SIP Inventory Data

slide-16
SLIDE 16

SITE SUITABILITY ANALYSIS

GIS OWTS SITE SUITABILITY ANALYSIS:

*Created a 200’ shoreline buffer, which was then divided into 200’ wide segments that corresponded to sample point locations. Each of these segments was assigned the data values of the corresponding sample point.

slide-17
SLIDE 17

SITE SUITABILITY ANALYSIS

GIS OWTS SITE SUITABILITY ANALYSIS (MODEL DIAGRAM):

slide-18
SLIDE 18

SITE SUITABILITY ANALYSIS

COMBINED MAPPING & HIGH PRIORITY AREA ANALYSIS:

*Figure Does Not Depict Actual Results

Site Suitability Map Results OWTS Inventory Assessment Priority Retrofit Areas

=

+

slide-19
SLIDE 19

WATERSHED STORMWATER MANAGEMENT

LAKE GEORGE: LAKE VIEW CIRCLE

slide-20
SLIDE 20

WATERSHED STORMWATER MANAGEMENT

LAKE GEORGE: LAKE VIEW CIRCLE

slide-21
SLIDE 21

WATERSHED STORMWATER MANAGEMENT

LAKE GEORGE: LAKE VIEW CIRCLE

slide-22
SLIDE 22

WATERSHED STORMWATER MANAGEMENT

SARATOGA LAKE: STILLWATER, NY

slide-23
SLIDE 23

WATERSHED STORMWATER MANAGEMENT

SARATOGA LAKE: STILLWATER, NY

slide-24
SLIDE 24

WATERSHED STORMWATER MANAGEMENT

SARATOGA LAKE: STILLWATER, NY

slide-25
SLIDE 25

WATERSHED STORMWATER MANAGEMENT

SARATOGA LAKE: STILLWATER, NY

NEXT STEPS:

  • DEVELOP A WATERSHED OVERLAY DISTRICT THAT PROTECTS KEY NATURAL RESOURCES AND

REQUIRES CONSERVATION BASED DEVELOPMENT

  • INCORPORATE ZONING THAT RESULTS IN REDUCED DENSITIES AS YOU MOVE AWAY FROM

EXISTING DEVELOPMENT*

  • CONTINUE TO MODEL AND ANALYZE EXISTING HYDROLOGY AND STORMWATER AS IT

RELATES TO WATER QUALITY (THIS EFFORT WAS RECENTLY AWARDED TWO GRANTS)

  • DESIGN CENTRAL AND NONCENTRAL GREEN INFRASTRUCTURE TREATMENTS THROUGHOUT

PRIORITY SUBCATCHMENTS

  • IMPROVE EXISTING STORMWATER CONTROLS AND UPDATE TO CURRENT STANDARDS
  • INCREASE STORMWATER DESIGN STANDARDS TO CAPTURE SMALLER PROJECTS
  • WORK WITH NONPROFIT AND EDUCATIONAL COMMUNITY TO ENHANCES WATER QUALITY

AWARENESS AND PARTICIPATION

slide-26
SLIDE 26

QUESTIONS?

Paul Cummings, AICP, LEED AP Senior Planner The Chazen Companies pcummings@chazencompanies.com 518-812-0513
