3D GIS

Jackie Leung

Importance of 3D GIS

Transformation of 3D GIS Transformation of 3D GIS

Reference: 3D GIS: A Technology Whose Time has Come (Gary Smith and Joshua Friedman)

3D GIS Display

3D Building Model 3D Terrain Model 3D Street F urniture

True Stereoscopic Viewing 2D GIS Display 2D GIS Display Paper Map Paper Map

What is 3D GIS? What is 3D GIS?

• Accurately represent real-world GIS entities

– Viewing, analyzing and storing spatial data with a 3D component – Seamless transitions between global, local and street-level scale data

Local Local Regional Regional Global Global Across Scales Across Scales

• Performing GIS analysis with 3D data

– Edit data in 3D – Analyze 3D data which affects decision making

• Gain insights into your data

Who benefits from 3DGIS? Who benefits from 3DGIS?

Local government Civil engineering Facilities management Natural resources Defense / Public Safety

3D GIS 3D GIS

City Planning Visibility Shadow Analysis Viewshed, elevation Emergency 3D routing Interior transportation networks Threat domes

Components of 3D GIS Components of 3D GIS

Elevation Imagery Topographic (Roads and Infrastructure) Subsurface Models and Multipatches Other features (Street furniture)

Esri Solutions for 3D GIS Esri Solutions for 3D GIS

ArcG IS 10 3D Analyst ArcG IS 10 3D Analyst

What is ArcGIS 3D Analyst? What is ArcGIS 3D Analyst?

ArcGIS extension that provides an extensive set of features to build, visualize, and analyze data in three dimensions

Platforms of 3D GIS in ArcGIS Platforms of 3D GIS in ArcGIS

ArcGlobe ArcGlobe ArcGlobe ArcScene ArcScene ArcScene ArcGI S Explorer ArcGI S Explorer ArcGI S Explorer

New Features of ArcGIS 10 3D Analyst New Features of ArcGIS 10 3D Analyst

• 1. Faster rendering of 2D map caches in

ArcGlobe

• 2. Improved display performance of 3D

annotation / Point labeling (built-in conflict detection)

• 3. Faster display of textured multi-patches

(automatic textures management)

• 4. Improved display performance of 3D

vectors (surface-hugging vectors)

• 5. Georeferenced Video Layers
• n ArcGlobe Surface

New Features of ArcGIS 10 3D Analyst New Features of ArcGIS 10 3D Analyst

• 1. 3D editing environment is now available
• both ArcScene & ArcGlobe
• 2. Support standard editing capabilities
• Feature Templates, Delete, Undo/

Redo, Attribute edits, Relationship classes..

• 3. Allow 3D geometry edits
• Place 3D models directly
• Move, rotate, scale, and replace

feature geometry

• 4. Tools for managing Lidar data and TIN

editing

• 1. 3D boolean operators (closed multipatch)
• Union 3D, Intersect 3D, Difference 3D

and Inside 3D

• 2. Geoprocessing tools for virtual city

workflows

• Skyline and Skyline Barrier
• 3. Enhancement of existing GP tools
• Line of Sight (with multipatch)
• Select by Location (with 3D operator)
• Intersect 3D Line with Multipatch
• Construct Sight lines
• 4. Measure in 3D
• 5. Network Datasets with full 3D connectivity

New Features of ArcGIS 10 3D Analyst New Features of ArcGIS 10 3D Analyst

New Features of ArcGIS 10 3D Analyst New Features of ArcGIS 10 3D Analyst

• 1. Share 3D views of GIS data by

publishing Globe Services

• 2. Share 3D analytical tools by

geoprocessing services

• 3. Create high quality video

animations and screen capture

Demonstration Demonstration

Planning of the new development project with ArcGIS 3D Analyst

Resources Resources

• 3D Resources Centre

http://resources.arcgis.com/zh-cn/content/3dgis/10.0/about

Thank You!
