CSCI 125 & 161 / ENGR 144 Lecture 13

Martin van Bommel

Floating Point Data

• Floating point numbers are not exact
• Value 0.1 is very close to 1/10, but not

precisely equal to it

• 0.110 = 0.000110011001100110011... 2
• Cannot rely on accuracy of floating point

values

for With Floating Point Data

• Following for loop is syntactically correct

for (x = 1.0; x <= 2.0; x += 0.1) ...

• On some machines, x will never take on value

2.0, but will become 2.00000000000001, which fails the test

for With Floating Point Values

• Better to use the for loop

for (i = 10; i <= 20; i++) ...

• Then use the calculation

x = i / 10.0;

to give the floating point values for x

Equality With Floating Points

• Testing floating point data for equality leads

to problems with precision

• Want to test if equal within some epsilon
• In reality, test if absolute value of difference

between numbers, divided by the smaller of their absolute values, is less than ε

ε < − |) | |, min(| | | y x y x

Approximately Equal

#define Epsilon 0.000001 bool ApproximatelyEqual(double x, double y) { double diff = abs(x - y); y = abs(y); x = abs(x); if (y < x) x = y; return ((diff / x) < Epsilon); }

2

Numerical Algorithms

• Techniques used by computers to

implement mathematical functions like sqrt

• sqrt function exists in math library
• Most people just use it
• How is it implemented?

– Successive approximation? – Series expansion?

Successive Approximation

• Steps:
• 1. Make a guess at the answer
• 2. Use guess to generate a better answer
• 3. If getting closer to actual answer, repeat until

guess is close enough

• How to generate next guess?

– need a converging sequence of guesses

Newton’s Method

• e.g.

– Suppose want square root of 16 – Use 8 as first guess - too large, 8 x 8 = 64 – Derive next guess by dividing value by guess – 16 / 8 = 2, answer must be between 2 and 8 – Use (2 + 8) / 2 = 5 as next guess – 16 / 5 = 3.2, (3.2 + 5) / 2 = 4.1 as next guess – Next guesses: 4.001219512 and 4.00000018584

Problem with Successive Approx

• Process will never guarantee an exact answer
• Can continue until close enough (?)
• Use ApproximatelyEqual function
• Continue until square of guess approx. equal

to original number

Newton’s Algorithm

double Sqrt(double x) { double g = x; if (x == 0) return 0; if (x < 0) { cout << ”Sqrt on negative number\n”); return 0; } while (!ApproximatelyEqual(x, g*g)) g = (g + x / g) / 2; return g; }

Series Expansion

• Value of function approximated by adding

terms in a mathematical series

• If addition of new term brings total closer to

desired value, series converges and can be used to approximate result

• Taylor Series Approximation for 0 < x < 2
• +

− − − + − − − + ≅ ! 4 ) 1 ( 16 15 ! 3 ) 1 ( 8 3 ! 2 ) 1 ( 4 1 ) 1 ( 2 1 1

4 3 2

x x x x x

3

Implement Series Expansion

• For a series such as:

Think of each inside term as

• Initially

sign = odd = 1;

• Then, for the next term

sign = -sign;

• dd = odd + 2;

) 9 1 7 1 5 1 3 1 1 ( 4

• −

+ − + − ≅ π

• dd

sign 1

Implementing Taylor Series

• Think of each term as
• +

− − − + − − − + ≅ ! 4 ) 1 ( 16 15 ! 3 ) 1 ( 8 3 ! 2 ) 1 ( 4 1 ) 1 ( 2 1 1

4 3 2

x x x x x

factorial xpower coeff

• Then, for next term
• xpower *= (x-1);
• factorial *= (i+1);
• coeff *= (0.5-i);

Taylor Algorithm

double TaylorSqrt(double x) { double sum, factorial, coeff, term, xpower; int i; factorial = coeff = xpower = term = 1.0; sum = 0.0; for (i = 0; sum != sum + term; i++) { sum += term; coeff *= (0.5 - i); xpower *= (x - 1); factorial *= (i + 1); term = coeff * xpower / factorial; } return sum; }

Fixing Limitation

• Taylor Series Approx works for 0 < x < 2
• How can we use it for larger x?
• Recall

x x x 2 4 4 = =

• Then divide by 4 until within range, then

calcuate sqrt, and multiply by 2’s to recover

• e.g. sqrt(24) = sqrt(4*4*1.5) = 2*2*sqrt(1.5)

Taylor Fix

double TSqrt(double x) { int mult = 1; if (x == 0) return (0); if (x < 0) { cout << "TSqrt of negative value " << x << endl; return 0; } while (x >= 2){ x /= 4; mult *= 2; } return mult * TaylorSqrt(x); }
