FleetShield is a new exciting product from Dulux catering for - - PowerPoint PPT Presentation

1

FleetShield is a new exciting product from Dulux catering for commercial vehicle (CV) refinishing. FleetShield offers 5 different premium quality two pack bases, increasing colour range and superior coverage. A complete range of solid colour tinters and pearls tinters to tint, match and customise any single layer 2K colour. 1200 colours are available for the Dulux 2K PR system with a approximately 200 colours added from local matching & aligned with Snapshot. FleetShield offers a complete range of ancillary products, primers, clears and a range of hardeners and thinners to suit all temperatures and job sizes. Flattening base for reduced gloss levels. A complete range of products to suit plastic parts.

2

Base Line Shade Max Tint By Weight Colours which can be Tinted

Red Base 428-S0011 20% Red, maroon, dark orange Yellow Base 428-S0062 20% Yellow, mid to light orange, bright green Clear Base 428-S0047 30% Mid to dark blue, green and purple, pearl White Base 428-S0204 20% Light blue, green, purple, light grey and all white. Black Base 428-89943 20% Mid grey to Black

RED_BASE___ _ YELLOW BASE___________CLEAR BASE___________ CLEAR /WHITE BASE

3

White Base 428-S0204 is aligned with Autospeed PR 427-T0204. Replaces HS White 488-89289 with Approx 20% less pigment Red Base 428-S0011 is aligned with Autospeed PR 427-T0011. Yellow Base 428-S0062 is aligned with Autospeed PR 427-T0062. Black Base 428-89843 is aligned to 2K Black 488-89843 and is unchanged.

4

Break down of the 38 Tinters Reds 12 Oranges 2 Yellows 6 Greens 4 Blues 7 Violets 2 Blacks 4 White 1

38 tinters 30 x 0.9L tinters 8 x 3.7L tinters 4 x reduced strength Tinters included PR 2K tinters are used to tint the 5 Bases

5

• 46 Pearl tinters can be used to match and customise colours.
• Mixture of Mica and special effect pearls.
• 9 special custom pearls.
• Can be mixed into Clear base.
• Can be mixed into coloured bases.

Mixing

• TBA

6

AUTOSPEED MT Flat Base 485-89915 x 0.9L Used to achieve

• Matt Finish 10% Gloss
• Satin finishes 30% Gloss
• Semi Gloss 50% Gloss

Mixing

• Matt Finish 70 – 80% by weight
• Satin Finish 20 – 30% by weight
• Semi Gloss 30 – 40% by weight

*MT Flat Base is mixed in after hardening colour

7

AUTOSPEED Flex Additive 485-89930 x 0.9L Add to primer, colour and clear Add 20% Flex Additive prior to hardener AUTOSPEED Plastic Cleaner 485-S0017 x 4L Cleaning with anti static properties AUTOSPEED Plastic Primer 485-89943 x 5L Adhesion to a wide range of plastic substrates

8

Hardeners 2:1 Mixing Ratio

• AUTOSPEED RP Hardener 980-89790 (fast)
• AUTOSPEED 2K Hardener Normal 980-89290
• AUTOSPEED Hardener Slow 980-S0028

Hardeners come in 1L and 2.5L sizes

Thinners 10 – 20% Thinning Ratio

• AUTOSPEED RP Thinner 920-89819 x 20L.
• AUTOSPEED 2K Normal 920-89292 x 20L.
• AUTOSPEED 2K High Temp 920-89847 x 20L.

AUTOSPEED 2K X Slow 920- 89963 x 4L.

9

Etch Primers Primer Fillers Aerosol Primers

10

Snapshot is a spectrophotometer designed to read colour for easier Identification. Works in conjunction with iPhone and Android phones.

Dulux FleetShield app is now available for iPhone and iPad through iTunes store Dulux FleetShield app is now available for Android devices through Google Play Store

11

http://duluxrefinish.rockpaint.co.jp/duluxrefinish

12

1. Click on Mix Formula Search which will open this page. 2. Click on Fleet Shield.

13

1. Select Car Manufacture – Commercial Vehicles. 2. Type in Colour code if known 3. Or 4. Type in colour name if known Follow on with normal Micom mixing

14

Viscosity is the measure of a fluid’s resistance to flow

Conditions that cause higher viscosity

• Paint is cold especially during winter months
• Container not sealed properly in storage
• Container left opened to allow solvent evaporation
• Using catalysed product that is past its pot life

Results of high viscosity paint

• Harder application
• Orange peel
• High film build
• Trapped air
• Trapped solvent causing solvent boil

15

• Hold viscosity cup by handle & completely submerge into paint
• Hold stop watch in other hand, ready to start
• Lift viscosity cup out of paint and start stop watch immediately
• As soon as paint flow from cup breaks, stop the stop watch.
• Check time on stop watch to Technical Data Sheet.
• If time is out more than 2 -3 seconds either side, add reducer
• Test again

Spray Viscosity Ford Din 4 @ 250C 18 – 20 seconds

Plastic Alloys & Aluminium Steel Fibreglass

Curtains

PPE

• 1. Clean surface areas

with Plastic cleaner 965-S0017.

• 2. New plastic sand

with grey scouring pad.

• 3. Repairs sand with

P240 – P320

• 4. Clean again Plastic

Cleaner

• 1. Clean areas with

Prepwash 965- 89784.

• 2. If required sand

repair areas P80- P120 for body fillers

• 3. No repairs sand with

P180-P240

• 4. Red scourer for AL
• 5. Clean again with

Prepwash

• 6. No Prepwash on

body fillers Nitrile gloves and dust / particle mask

• 1. Alloys-No Repairs

CV Ultraetch or DP42

• 2. Alloys Repairs

CV Ultraetch or DP42 + HS Primer.

• 3. Steel

CV Ultraetch or DP42 or Epoxy Urethane primer, HS Primer .

• 4. Fiberglass

Epoxy Urethane Primer + HS primer

• 1. Apply Plastic Primer

485-89943.

• 2. Single wet coat
• 3. Allow to flash of

3 – 5 mins before applying topcoats Nitrile Gloves, Respirator / air feed hood, Overalls & eye protection

• 1. FleetShield 2:1 2K

mix colour.

• 2. 2:1:10%-20%
• 3. 5-10min flash off

between coats.

• 4. Air Dry overnight
• 5. Baking

30min@60oC

• 6. Infrared 8-20 min

depending on type

• f Infra Red.
• 1. FleetShield 2:1 2K

mixed colour with Flex Additive 485- 89930.

• 2. Plastic Parts mix

5:1 then mix at 2:1 with Hardener.

• 3. Curtains mix the

same. Nitrile gloves, overalls, Air Feed Hood & eye protection

Substrate Preparation Primer Topcoat Always refer to Technical Data Sheets & SDS

5 Year Standard Warranty

Heavy Steel (Chassis) New

Heavy Steel (Chassis) Refurbishment

PPE

• 1. Degrease surface

areas with Prepwash.

• 2. Sand P80 to P120

to remove rust, flaking paint.

• 3. Sand P240 – P320 +

Red scouring pad to abrade surface for adhesion.

• 4. Clean again

Prepwash

• 1. Abrasive blast to

remove Mill Scale to SA2.5 Standard*.

• 2. Clean with Prepwash
• 3. Sand with P80 to

P180

• 4. Clean again with

Prepwash.

*SA2.5 Standard refers to

cleanliness of steel. Very thorough blast cleaning. Near white metal 85% clean.

Nitrile gloves and dust / particle mask

• 1. Etch Primer. CV

Ultraetch or DP42 or Epoxy Urethane Primer

• 2. Repairs

HS Primer Nitrile Gloves, Respirator / air feed hood, Overalls & eye protection

• 1. FleetShield 2:1 2K

mix colour.

• 2. 2:1:10%-20%
• 3. 5-10min flash off

between coats.

• 4. Air Dry overnight
• 5. Baking

30min@60oC

• 6. Infrared 8-20 min

depending on type

• f Infra Red.

Nitrile gloves, overalls, Air Feed Hood & eye protection

Substrate Preparation Primer Topcoat Always refer to Technical Data Sheets & SDS

5 Year Standard Warranty

Dulux Refinish Etch Primer such CV Ultraetch , DP42 and Epoxy Urethane Primer can be topcoated directly Identify whether the Paint spec requires a special protective coating e.g. Zinc or needs temperature ratings prior to primer coats

18

• OEM Commercial Vehicles.
• CV Body Builders.
• CV Truck Repair.
• Trailer Manufacturers.
• PV Body shops who use single layer solid colours as
• pposed to basecoat/clearcoat.
• Retail and Inspiration opportunities.
• PV Distributors.

19

This range of product contains Isocyanates and Solvents. Toxic fumes and vapours can be harmful. Always wear PPE equipment. Always refer back to Technical Data Sheets & Safety Data Sheets.
