QIMP11, May 29 th June 10 th , 2011, Dresden PRSENTATION Far from equilibrium and time-dependent phenomena for electron transport in quantum dots Renaud Leturcq IEMN CNRS, Department ISEN, Villeneuve d'Ascq, France Outline


slide-1
SLIDE 1

PRÉSENTATION

Far from equilibrium and time-dependent phenomena

for electron transport in quantum dots Renaud Leturcq

IEMN – CNRS, Department ISEN, Villeneuve d'Ascq, France QIMP11, May 29th – June 10th, 2011, Dresden

slide-2
SLIDE 2

Outline Introduction Part I: Single electron transport in quantum dots

Electron and spin in quantum dots Time-resolved single electron detection Single electron manipulation Interaction with photons and phonons

Part II: Kondo effect in quantum dots

slide-3
SLIDE 3

Introduction

slide-4
SLIDE 4

Challenges for quantum electronic transport

  • Low-frequency linear transport in non interacting systems

is well understood

– Landauer-Büttiker theory

  • Understanding the experiments requires to go beyond!

– non-equilibrium effects (large bias voltage, current noise) – role of electron-electron interactions – interaction with the environment ⇒ finite coherence time – high-frequency response (adiabatic or non-adiabatic regime) – role of the electron spin

  • Quantum dots as an “ideal” playground to provide answers

G= e2 h ∑

n

T n

slide-5
SLIDE 5

Transport in quantum dots

source drain quantum dot S D EC  kBT

  • Small island

– large capacitance C charging energy EC = e2/C – quantum confinement level spacing Δ ~ ħ2/(m*r2)

source drain tunnel barriers QD S D gate

trapped electron = quantum impurity connected to Fermi leads

kBT≪EC

transport through a single atomic level

slide-6
SLIDE 6

Fabrication of semiconductor quantum dots

  • Most successful up to now: GaAs heterostructures
  • R. Hanson et al., Rev. Mod. Phys. 79, 1217 (2007)

Most of the demonstrative experiments on quantum dots were performed on this system.

slide-7
SLIDE 7

Fabrication of semiconductor quantum dots

  • Most successful up to now: GaAs heterostructures

– extensive tuning of parameters

  • number of electrons N
  • confinement potential Δ
  • coupling to the leads ΓS, ΓD
  • bias voltage VSD
  • What is difficult to achieve with GaAs heterostructures?

– change the intrinsic electronic properties (m*, g-factor,...) – coupling with other materials (superconductors, ferromagnetic) – new geometries (interaction with motion) – optically active quantum dots

source drain quantum dot S D EC  kBT eVSD

slide-8
SLIDE 8

Fabrication of semiconductor quantum dots

  • Necessity of tuning the material properties

– change the intrinsic electronic properties

  • effective mass  broader range of level spacing
  • spin-orbit interaction (InAs, InSb: strong SOI)
  • zero nuclear spin (Si, C)  long spin coherence time

– coupling with other materials

  • superconductors
  • ferromagnetic materials

– new geometries

  • suspended nanostructures (nanowire, nanotubes)
  • heterogeneous integration

– optically active quantum dots

(see lecture A. Imamoglu)

Δ≈ ℏ

2

m

∗r 2

slide-9
SLIDE 9

Fabrication of semiconductor quantum dots

  • Carbon-based nanostructures

– carbon nanotubes, fullerene

  • M. Bockrath et al., Science 275, 1922 (1997)
  • H. Park et al., Nature 407, 57 (2000)

– graphene

  • L. A. Ponomarenko et al., Science 320, 356 (2008)
  • Semiconductor nanowire

– InP, Si, InAs, Ge, InSb

  • S. De Franceschi et al., Appl. Phys Lett. 83, 244 (2003)
  • Z. Zhong et al., Nano Lett. 5, 1143 (2003)
  • M. T. Björk et al., Nano Lett. 4, 1621 (2004)
  • Y. Hu et al., Nature Nanotechnol. 2, 622 (2007)
  • H. A. Nilsson et al., Nano Lett. 9, 3151 (2009)
slide-10
SLIDE 10

Take-away message (1) High tunability of semiconductor quantum dots for transport through quantum impurities

electronic properties material properties interaction with the environment

next: what can we probe in transport experiments?

slide-11
SLIDE 11

Part I Single electron transport in quantum dots

  • 1. Transport mechanisms in quantum dots
  • 2. Time-resolved single electron detection
  • 3. Single electron manipulation
  • 4. Interaction with photons
  • 5. Interaction with phonons
slide-12
SLIDE 12

Single electron transistor (SET)

source drain tunnel barriers SET S D gate

CG VG +V/2

  • V/2

I

=

+

=

+

=

+

Ne

review: Single Charge Tunneling, ed. Graber & Devoret, Plenum Press (1992)

Ecl N ,V g= Q L

2

2CL  Q R

2

2C R  Q g

2

2Cg C=C LCRC g −Ne=Q gQ LQ R V g=Q L CL −Q g Cg =QR C R −Q g C g ≈N e−C gV g

2

2C

slide-13
SLIDE 13

Single electron transistor (SET)

source drain tunnel barriers SET S D gate

CG VG +V/2

  • V/2

I

=

+

=

+

=

+

Ne

N-1 N N+1 N+2

Ecl(N,VG)

N+3 N-2

VG

 EC = e2/C Ecl N ,V g≈N e−C gV g

2

2C

review: Single Charge Tunneling, ed. Graber & Devoret, Plenum Press (1992)

I VG

current at low bias voltage energy conservation  Ecl(N,Vg) = Ecl(N+1,Vg)

slide-14
SLIDE 14

Transport in quantum dots

VPG (mV) GSD (10-3 e2/h)

kBT≪EC

source drain quantum dot EC  kBT source drain quantum dot S D EC  kBT N N+1 N-1 EC (+Δ)

T = 50 mK

slide-15
SLIDE 15

High bias spectroscopy

  • Charge stability diagram (SET)

VSD VG +

  • I

N-1 N N+1

EC EC EC

N ↔ N+1 N-1 ↔ N N-1 ↔ N ↔ N+1

slide-16
SLIDE 16

High bias spectroscopy

  • Charge stability diagram (SET)

VSD VG

dI/dV N-1 N N+1

slide-17
SLIDE 17

High bias spectroscopy

  • Charge stability diagram (QD): spin filling

VSD VG

dI/dV N-1 N N+1

E DOS

N even

slide-18
SLIDE 18

High bias spectroscopy

  • N ↔ N+1 excited states

VSD VG

dI/dV N-1 N+1 N

EC EC EC

slide-19
SLIDE 19

High bias spectroscopy

  • Constant interaction model: EC independent of N
slide-20
SLIDE 20

High bias spectroscopy

  • Spectroscopy of an InAs nanowire QD

VSD (mV)

10

  • 10
  • 0.04
  • 0.02

Vgates

  • 20

20 T = 100 mK

EC EC+Δ Δ

N even N+1 N+2

EC ≈  ≈ 6 meV gives a QD radius

  • f 20 nm

S D

GL GC GR S D GL GR GC

slide-21
SLIDE 21

Spin spectroscopy

  • At high magnetic field: splitting of the degenerate spin

states → can be used as a spin filter

see also: R. Hanson et al., Phys. Rev. Lett. 91, 196802 (2003)

 E Z=g

∗B B

|g*| = 5.5, due to quantum confinement (bulk InAs, |g*| = 15)

slide-22
SLIDE 22

Signature of spin-orbit interaction

  • Spin-orbit Hamiltonien: coupling of the spin and orbital

degrees of freedom

  • Mixing of spin states in InAs quantum dots
  • C. Fasth et al., PRL 98, 266801 (2007)
  • A. Pfund et al.,PRB 76, 161308(R) (2007)

H SO=− B⋅ p×E 2m c

2 =− B⋅Beff S(2,0) T+(2,0) T0(2,0) T-(2,0)

S T

ST

T- T0 T+

g*µBB

2 electrons states |g*|= 7 SO = 0.2 meV

slide-23
SLIDE 23

Single electron transport mechanisms

  • Sequential tunneling model

– master equation approach

Beenakker, Phys. Rev. B 44, 1646 (1991)

d dt ∣ p ,t 〉=−̂ L∣ p(t)〉

Lmn=δn, mγn−Γm←n

pn = probability to find the system in a state n

γn=∑

m≠n

Γm←n

n = transition rate from state n to state m

slide-24
SLIDE 24

Single electron transport mechanisms

  • Higher order processes:

– elastic and inelastic cotunneling

  • S. de Franceschi et al., PRL 86, 878 (2001)
slide-25
SLIDE 25

Take-away message (2) Transport experiment can probe the quantum structure of the quantum dot

electron and spin states... … assuming the constant interaction model ! transport mechanism via sequential co-tunneling

next: can we access the transport time-scales?

slide-26
SLIDE 26

Time scales for single electron transport

  • Inverse tunneling rates

1/ΓS, 1/ΓD = 10 ps – infinity

– time scale for a trapped electron to escape

  • Charge or spin decay time

1/Γd = few ns – 1 second

– coherent manipulation

  • h/EC, h/Δ = 1 – 100 ps

– non-adiabatic transistion

source drain quantum dot S D EC  kBT d

GS ES time frequency energy 1 ps 1 ns 1 μs 1 ms 1 THz 1 GHz 1 MHz 1 kHz 4 meV 4 μeV 4 neV 4 peV 500 K 0.5 K 0.5 μK 1 s 1 Hz 4 feV 0.5 nK 0.5 mK

time-resolved detection (I.2) pulsed gate experiments (I.3) microwave experiments (I.4)

slide-27
SLIDE 27
  • 2. Time-resolved single electron detection

conductor

A

time shot noise: SI = 2eI (Schottky, 1918) time

?

slide-28
SLIDE 28

Single charge detection with a quantum point contact

gate source drain gate

Vgates IQPC

source drain dot gate

  • M. Field et al., PRL 70, 1311 (1993)

working point

slide-29
SLIDE 29

Time-resolved single electron detection

  • Thermal fluctuations between leads and dot
  • W. Lu et al., Nature 423, 422 (2003)
  • R. Schleser et al., APL 85, 2005 (2004)
  • L. Vandersypen et al., APL 85, 4394 (2004)

source drain quantum dot

S D

kBT

  • R. Scheser et al., APL 85, 2005 (2004)
slide-30
SLIDE 30

Time-resolved detection of single electron transport

  • Large bias voltage ⇒ directional flow
  • S. Gustavsson, RL et al., PRL 96, 076605 (2006)

N N+1

time current

source drain quantum dot

S D

kBT

slide-31
SLIDE 31

Histograms of current fluctuations

  • Poisson distribution for

asymmetric coupling

  • Sub-Poisson distribution

for symmetric coupling

  • S. Gustavsson, RL et al., PRL 96, 076605 (2006)

Theory:

Hershfield et al., PRB 47, 1967 (1993) Bagrets & Nazarov, PRB 67, 085316 (2003)

slide-32
SLIDE 32

Histograms of current fluctuations

  • Asymmetric coupling

– statistics dominated by the thicker barrier

  • Symmetric coupling

– Coulomb blockade “orders” the electrons

source drain quantum dot S D kBT source drain quantum dot S D kBT

slide-33
SLIDE 33

Experimental measurement of the full counting statistics

  • More than noise: access to the full counting statistics

(distribution function)

– I = eµ/t0, µ = <n> – SI = 2e2µ2/t0, µ2 = <(n-<n>)2> – SI

3 = e3µ3/t0,

µ3 = <(n-<n>)3> – and many more... T = 10 min

slide-34
SLIDE 34

take-away message (3) Real-time measurement of single electron transport in quantum dots

determination of the full counting statistics (current noise) but still limited to the sequential tunneling regime

next: manipulating electron states in real time

slide-35
SLIDE 35
  • 3. Single electron manipulation
  • Fast gate sweep

– rise time: τ ~ 100 ps – 10 ns

  • Adiabatic regime

source drain quantum dot S D EC  kBT d

τ≫h/Δ τ<1/Γd ,1/ΓS ,1/ΓD

slide-36
SLIDE 36

Measurement of the spin relaxation time

  • J. Elzerman et al., Nature 430, 431 (2004)

limited by the spin-orbit interaction more recently: T1 up to 1 second at 1 Tesla

  • S. Amasha et al., Phys. Rev. Lett. 100, 046803 (2008)

relaxation

slide-37
SLIDE 37

Double quantum dot

source drain dot 1 S G1 dot 2 G2 int D

CG1 VG1 +V/2

  • V/2

I

=

+

=

+

=

+

CG2 VG2

=

+

(0,0) (0,1) (0,2) (1,0) (2,0) (1,1) (2,1) (1,2) (2,2)

VG1 VG2

review: W.G. van der Wiel et al., Rev. Mod. Phys. 75, 1 (2003)

∝EC2 ∝EC1 ∝Eint

slide-38
SLIDE 38

Electron transport through a double quantum dot

  • Small bias voltage: current at degeneracy points

– electron cycle (n,m) (n+1,m) (n,m+1) (n+1,m+1)

decreasing energy (n,m) (n+1,m) (n,m+1) (n+1,m+1)

slide-39
SLIDE 39

Electron transport through a double quantum dot

  • Small bias voltage: current at degeneracy points

– hole cycle (n,m) (n+1,m+1) (n+1,m) (n,m+1)

(n,m) (n+1,m) (n,m+1) (n+1,m+1)

slide-40
SLIDE 40

Electron transport through a double quantum dot

(n,m) (n,m+1) (n+1,m) (n+1,m+1)

S D GL GR GC

T = 100 mK

(n,m) (n+1,m) (n,m+1) (n+1,m+1)

S D

GL GC GR

slide-41
SLIDE 41

Inter-dot tunnel coupling

  • weak coupling
  • strong coupling

detuning  E detuning  E 2t

slide-42
SLIDE 42

Inter-dot tunnel coupling

S D GL GR GC

increasing the coupling (VGC)

  • weak coupling
  • strong coupling
slide-43
SLIDE 43

Coherent manipulation of charges

  • T. Hayashi et al., Phys. Rev. Lett. 91, 226804 (2003)
  • Coherent evolution in a double quantum dot

detuning  E 2t

slide-44
SLIDE 44

Take-away message (4) Manipulation of quantum states on time-scales smaller than the relaxation and coherence times

quantitative investigation of relaxation and decoherence coherent manipulation of quantum states

next: non-adiabatic manipulation at high frequency

slide-45
SLIDE 45
  • 4. Interaction with photons
  • Absorption of light by an

(artificial) atom through electronic transition

  • Quantum dots in GaAs

–  = 10 – 100 Ghz – tunable electronic properties – measurement by electronic transport ⇒ use as functional device (detector)

h 

source drain tunnel barriers dot S D gate h 

slide-46
SLIDE 46

Photon-assisted tunneling

  • Single quantum dot
  • T. H. Oosterkamp et al., PRL 78, 1536 (1997)

– side-bands due to photon-assited tunneling to the leads

slide-47
SLIDE 47

Photon-assisted tunneling

W.G. Van der Wiel et al., RMP 75, 1 (2003)

  • Double quantum dot

– probing internal transitions

slide-48
SLIDE 48

Coherent single spin manipulation

  • Electron spin resonance with a single spin

– first with GaAs quantum dots and high frequency magnetic field

  • F. H. L. Koppens et al., Nature 442, 766 (2006)

– with InAs nanowire QDs using the spin-orbit interaction

  • S. Nadj-Perge et al., Nature 468, 1084 (2010)
slide-49
SLIDE 49

Time-resolved detection of photon-assisted tunneling

time IQPC

~kHz ~GHz ~kHz

IQPC

h 

D rel S

slide-50
SLIDE 50

Time-resolved detection of photon-assisted tunneling

out

 out= 1 〈out〉 =  D rel  ph

D/

rel~10-5: efficiency of the single-photon

to single-electron conversion T=100 mK

What is our source of photons??? High frequency noise of the quantum point contact!

slide-51
SLIDE 51

High-frequency shot noise of a quantum point contact

  • Shot noise at high frequency
  • G. B. Lesovik, JETP Lett. 49, 592 (1989); S. E. Yang, Solid State Comm. 81, 375 (1992);
  • M. Büttiker, PRB 45, 3807 (1992); R. Aguado & L. P. Kouwenhoven, PRL 83, 1986 (2000)

⇒ emission of microwave photons

  • C. W. J. Beenakker & H. Schomerus, PRL 86, 700 (2001)
slide-52
SLIDE 52

Detection of the high-frequency noise of the quantum point contact

  • Shot noise of the quantum point contact at high

frequency

see also: E. Onac et al., PRL 96, 176601 (2006) – on chip with a single quantum dot

  • E. Zakka-Bajjani et al., PRL 99, 236803 (2007) – direct detection

Γ ph∝S I=2e

2

h T (1−T )(e∣V QPC∣ −h∣ν∣)

  • S. Gustavsson et al., PRL 99, 206804 (2007)
slide-53
SLIDE 53

Take-away message (5) Photon-assisted tunneling for investigating the internal quantum structure of a quantum dot

  • ptical spectroscopy at microwave frequency

single state manipulation

next: Role of the phonons in the energy transfer?

  • V. S. Khrapai et al., PRL 97, 176803 (2006)
slide-54
SLIDE 54
  • 5. Interaction with phonons
  • Quantum dots ⇔ artificial atoms and molecules

– already seen for shell filling and electronic transitions – what about vibrational transitions?

  • H. Park et al., Nature 407, 57 (2000)

dot source drain tunnel barriers S D gate

slide-55
SLIDE 55

Relaxation due to electron-phonon coupling

  • Coupling to bulk phonons

– relaxation mediated by the electron-phonon coupling

  • T. Fujisawa et al., Science 282, 932 (1998)
slide-56
SLIDE 56

Relaxation due to electron-phonon coupling

  • Coupling to confined phonons in a nanowire double

quantum dot

– phonons confined in the diameter of the nanowire

  • C. Weber et al., PRL 104, 036801 (2010)
  • P. Roulleau et al., Nature Comm. 2, 239 (2011)
slide-57
SLIDE 57

200 nm

Franck-Condon blockade in a suspended quantum dot

  • Suspended carbon nanotube quantum dot

– vibronic excited states Evib  0.8 meV

  • S. Sapmaz et al., PRL 96, 026801 (2006)
  • R. Leturcq et al., Nature Phys. 5, 327 (2009)

VTG (V) 0.12 0.14 0.16 0.18

  • 5
  • 10

5 10 VSD (mV) dISD/dVSD (µs) 1

  • 1
slide-58
SLIDE 58

Franck-Condon blockade in a suspended quantum dot

T = 5 K VTG (V) 0.165 0.175

  • Vibron-assisted tunneling at higher temperature

T = 1.3 K VSD (mV) 5

  • 5

VTG (V) 0.165 0.175 VTG (V) 0.165 0.175 T = 7 K

emission peaks: absorption peak:

G max∝ 1 k BT G max∝ 1 k BT 1 expℏ 0/k BT −1

ℏ0 = 0.96  0.08 meV  Evib T (K) 2 4 6 Gmax (S) 0.2 0.4

  • R. Leturcq, C. Stampfer et al., Nature Phys. 5, 327 (2009)
slide-59
SLIDE 59

Franck-Condon blockade in a suspended quantum dot

  • Suppression of current at zero bias voltage

VSD (mV) dISD/dVSD (e2/h) 0.01 0.02

  • 0.01

5 10

  • 5
  • 10

strong electron-vibron coupling g > 1 N

Evib

N+1  2gl osc

  • R. Leturcq, C. Stampfer et al., Nature Phys. 5, 327 (2009)
slide-60
SLIDE 60

take-away message (6) Investigation of the electron-phonon coupling on the single particle level

weak coupling: relaxation strong coupling: Franck-Condon blockade

slide-61
SLIDE 61

Conclusion – part I

  • Transport in quantum dots

– wide tunability – time-resolved measurement and manipulation – interaction of single quantum states with the environment

  • Single impurity coupled to Fermi leads ⇔ Kondo physics

– How the tools available in quantum dots allow to study the Kondo effect on the single impurity level – Show what has been done experimentally with quantum dots, discuss what can(not) be done

slide-62
SLIDE 62
  • P. W. Anderson,
  • Phys. Rev. 124, 41 (1961)

Kondo physics in quantum dots

  • Single impurity coupled to Fermi leads ⇔ Kondo problem
  • L. I. Glazman & M. E. Raikh, JETP Lett. 47, 452 (1988)
  • T. K. Ng & P. A. Lee, PRL 61, 1768 (1988)

– due to on-site Coulomb interaction in the quantum dot – widely tunable Kondo effect (U, ε0, νk... TK)

source drain tunnel barriers QD S D gate

  • W. J. De Haas & G. J. Van Den Berg,

Physica 3, 440 (1936)

  • D. Goldhaber-Gordon et al.,

PRL 81, 5225 (1998) conductance resistance

slide-63
SLIDE 63
slide-64
SLIDE 64

Single electron transport mechanisms

  • Sequential tunneling model

– master equation approach for a single level at energy ϵ

Beenakker, Phys. Rev. B 44, 1646 (1991)

I =−eΓL[ p0 f L−p1(1− f L)] f L= f ( EL−E F) f R= f (E R−E F) E L=ϵ+ηeV E R=ϵ−(1−η)eV

d dt( p0 p1)=( −ΓL f L−ΓR f R ΓL(1− f L)+ΓR(1− f R) ΓL f L+ΓR f R −ΓL(1− f L)−ΓR(1− f R))( p0 p1)

p0+ p1=1 d p0 d t = d p1 d t =0

stationarity:

eV ≫k BT ⇒ I =−e ΓLΓR ΓL+ΓR

slide-65
SLIDE 65

Electron transport through a double quantum dot

  • Large bias voltage: spectroscopy

B = 0 T, VSD = -3 mV

  • 25
  • 20

135 140

VGR (mV) VGL (mV) ISD (pA)

10 20 30 40 145 detuning global energy
