Extreme Packaging Machinery Continuous-motion wrappers continuously Continuous vs. Intermittent Intermittent motion Continuous motion Side Sealer Trim NextGen OEM Side Sealer Kit Trim Lap Sealer product size Forming plow Direct Drives

SLIDE 1

Extreme Packaging Machinery

SLIDE 2

SLIDE 3

continuously

Continuous-motion wrappers

SLIDE 4

Continuous vs. Intermittent

Intermittent motion Continuous motion

SLIDE 5

Side Sealer

Trim

SLIDE 6

NextGen OEM Side Sealer Kit

Trim

SLIDE 7

product size

Lap Sealer

Forming plow

SLIDE 8

All Extreme wrappers use Direct Drives

Direct Drives

Direct Drive

SLIDE 9

Terminology

Customers may use different terminology!!

Shrink wrapper
Flow wrapper
Bundler
Stretch wrapper

Bundler has bulls eye Stretch wrapper Shrink wrapper-total enclosure

SLIDE 10

XT Tunnels

SLIDE 11

Extreme Selling Points

less film width

This is what the competition offers!!

SLIDE 12

Applications

Think large numbers

SLIDE 13

Wireless Remote Operation

SLIDE 14

Qualify Application

SLIDE 15

Production Rate

Wrapper speed (parts per minute) Rate per hour Rate per Day Rate per Week Rate per Month Rate per Year 10 500 4,000 20,000 80,000 940,000 15 750 6,000 30,000 120,000 1,410,000 20 1,000 8,000 40,000 160,000 1,880,000 25 1,000 10,000 50,000 200,000 2,350,000 30 1,500 12,000 60,000 240,000 2,820,000 35 1,750 14,000 70,000 280,000 3,290,000 40 2,000 16,000 80,000 320,000 3,760,000 50 2,500 20,000 100,000 400,000 4,700,000 60 3,000 21,000 120,000 480,000 5,640,000 70 3,500 28,000 140,000 560,000 6,580,000 80 4,000 32,000 160,000 640,000 7,520,000 90 4,500 36,000 180,000 720,000 8,460,000 100 5,000 40,000 300,000 800,000 9,400,000 110 5,500 44,000 220,000 880,000 10,340,000 120 6,000 48,000 240,000 960,000 11,280,000 150 7,500 60,000 300,000 1,200,000 14,100,000 Above figures are based on 50 minute hour 8 hour day 5 day week 4 week month 47 week per year

SLIDE 16

Wrapper Selection

speed product arrive

SLIDE 17

Wrapper Models

Series

Description Maximum Speeds Base Price, includes infeed AL Pneumatic cross seal 110 FPM, 75 PPM $81,800.00 SAL Servo (B&R Automation Controls) 120 FPM, 100 PPM $90,875.00 S Servo (Allen Bradley Controls) 150 FPM, 120 PPM $106,800.00 XS Servo (Allen Bradley Controls) 175 FPM, 150 PPM $138,800.00 XR Servo rotary (Allen Bradley Controls) Patented cross seal 250 FPM, 200+ PPM $162,500.00

Machine width

Max. product dimension

Cross Seal Dimension Film capacity 18” 18” Wide x 8” High x Infinite Length 20” Wide x 8.5” High 25” CF / 50” Flat 44” Flat on Lap Seal 24” 24” Wide x 12” High x Infinite Length 26” Wide x 12.5” High 31” CF / 62” Fla 30” 30” Wide x 12” High x Infinite Length 33” Wide x 12.5” High 38” CF / 76” Flat

SLIDE 18

ROI Calculation

SLIDE 19

ROI Calculation- Film Savings

calculator

If you are offering a $100K SAL wrapper and customer is considering a $50K intermittent motion Wrapper How do you calculate ROI?

SLIDE 20

ROI Calculation- Film & Labor

Potential solution

Labor savings $40K per year Wrappers 4 Lbars Labor 4 operators (4 x 40K/year =160K)

Labor savings

SLIDE 21

Extreme Sales Process

SLIDE 22

Application Videos

XR-Rotary Wrapper High Speed Pizza and Baked Goods SST IP67 Full Wash Down XR-Rotary Wrapper High Speed Prepared Food

SLIDE 23

Application Videos

Cucumber shrink wrapping Potato shrink wrapping
