Started in 2006 A team of coating and process experts 3 worldwide patents Unique value proposition Internationally oriented HQ & Production Sales Office Everywhere yet invisible Production Factory Innovation center


slide-1
SLIDE 1
slide-2
SLIDE 2

▪ Started in 2006 ▪ A team of coating and process experts ▪ 3 worldwide patents ▪ Unique value proposition ▪ Internationally oriented ▪ Everywhere yet invisible

HQ & Production Sales Office

Production Factory Innovation center

slide-3
SLIDE 3
slide-4
SLIDE 4

▪ ADB Headlamp

  • Straylight reduction
  • Enhanced light transmission
  • Application on complex 3D shapes

▪ LIDAR and Camera

  • 850nm, 905nm, 1050nm
  • Up to 97% transmission
  • Scratch-resistance
slide-5
SLIDE 5

▪ Outdoor Lighting

  • Straylight reduction
  • Enhanced light transmission
  • Minimized architecture complexity
  • Energy saving

▪ Covers

  • Straylight reduction
  • Coating on complex 3D shape
slide-6
SLIDE 6

Material Fresnel loss uncoated Fresnel loss coated PC 4,9% 0,4% PMMA 3,9% 0,7% Glass 4,2% 0,5%

slide-7
SLIDE 7

0,32% 0,44%

centering point 450 nm 475 nm 500 nm 525 nm 550 nm 575 nm 600 nm

Consequence of a ±50nm shift Colour variation easily noticeable

slide-8
SLIDE 8

Dipping direction

Coating limit

Hook Hook Hook

  • Coating forbidden above the part top
  • Coating limit : 1,3mm from part top +/- 1,2mm
  • Hook required to interface the lens to the machine
  • Steps or holes in the coating area to be avoided
  • Always prefer rounded edges
slide-9
SLIDE 9

Dipping direction

Coating limit

Hook Hook

  • Coating forbidden above the part top
  • Coating limit : 1,3mm from part top +/- 1,2mm
  • Hook required to interface the lens to the machine
  • Steps or holes in the coating area to be avoided
  • Always prefer rounded edges
slide-10
SLIDE 10

Dipping direction

Coating limit

  • Hook required to interface the lens to the machine
  • Steps or holes in the coating area to be avoided
  • Always prefer rounded edges

Hook Hook

slide-11
SLIDE 11

14 Avenue Pey Berland 33607 PESSAC - France Tel : +33 5 56 06 40 20 Mail : contact@polyrise.com WWW.POLYRISE.COM
