Experience Reg Kontz Green Leagues 2 Green Leagues 3 Meet and - - PowerPoint PPT Presentation

Green Leagues

Workshop # 2 –Outline

1. Introduction Ronak Patel 1. Energy Efficiency Basics Brandon Sandmaier, Generate Energy 2. Energy Efficiency Upgrades: Community Cloverdale’s Experience Reg Kontz

2

Green Leagues 3

Meet and Greet!

Name Community League Interest in Today’s Workshop

4

Green Leagues 5

Energy Efficiency

1.Sustainable Buildings 2.Sustainable People

This Photo by Unknown Author is licensed under CC BY-SA-NC

Green Leagues

Initiatives Lists Grant Information Frequently Asked Questions Sustainability Spotlight

Green Leagues

6

Green Leagues

Ronak Patel

Energy Transition Officer Edmonton Federation of Community Leagues

ronak.patel@efcl.org 780 437 2913

7

Saving Energy, Saving Carbon, Saving Money:

An Introduction to Energy Efficiency

Brandon Sandmaier Operations Manager, Partner

Nov 6, 2018

Brandon Sandmaier

Co-Founder & Partner with Generate Energy

• Certified Energy Auditor
• Renewable Energy Technologist
• Passionate about Energy Efficiency and Renewables

Vital Group of Companies

3D Energy – Energy Engineering Extensive experience with energy efficiency from – Residential to Institutional Energy Assessments on over 50 community/recreational facility’s throughout Alberta

Vital Group of Companies

About Generate Energy

• Green Leagues Consultant since 2016
• Design and install grid-tied solar PV systems
• Design and Install LED Lighting systems
• Passion for energy reduction, production, and education

Reduce Produce

Energy 101

Educate

Overview

• 1. Introduction to energy efficiency
• 2. Steps to implementing energy efficiency
• 3. Energy use in buildings and benchmarking
• 4. Energy audits
• 5. Energy-saving opportunities by system
• 6. Q and A

What is Energy Efficiency?

• Using less energy to perform the same function
• Technology-driven

How to Save Energy

• Behavioural Change

– Free / low cost – May compromise comfort

• r convenience
• Technological Change

– Preserves comfort and convenience

Why is Energy Efficiency Important?

• Triple Bottom Line

– Saves money (Profits) – Benefits environment (Planet) – Improves health and well- being (People)

Source: Capturing the multiple benefits of energy efficiency, IEA

Why is Energy Efficiency Important?

Reduces emissions and saves money

Source: Pathways to a low-carbon economy (version 2), McKinsey & Company

Energy Efficiency Improvements

Energy Efficiency Alberta

Energy Efficiency Alberta

Becoming a Green League

• Energy Transition Ambassadors

– Communicate importance of energy efficiency – Involve key individuals

• Facility manager
• Hall manager
• Treasurer

– Involve the community

• Home Energy Toolkit

Steps to Success

Have a Plan, Set Goals Efficiency and Maint.

Controls to Optimize Efficiency Monitor Use Regular Review

Begin with an Energy Audit

Efficiency Upgrades & Maintenance Reduce Operating Times

Monitor Energy Use Regular Team Check In: Are We Meeting Our Goals?

See the Difference

http://www.buildingdashboard.com/clients/stlawrence/

• Community League Dashboard

Community League A

Community League B

Electric Heat

Utility Bills

Energy Usage Energy Charges Delivery Charges Local Access Fees

Utility Bills

Water Usage Water Charges

Wastewater Treatment Charges

Drainage Fees

Benchmarking

• Comparing energy

performance

• GJ/m2 and $/m2
• Motivating
• ENERGY STAR

Portfolio Manager

• “You can’t manage

what you don’t measure!”

Benchmarking

Energy Use In Leagues

Why Do An Energy Audit?

What retrofits should you prioritize? Lighting? Old Furnace? Old Windows?

• 2. Site Visit: Survey building systems
• 3. Analysis/Research: Detailed report
• 4. Presentation of Findings

Energy Audit Steps

1.Bill Analysis: 2 – 3 yrs. of energy bills

Results

• Building energy use baseline: Critical first step
• Energy Conservation Measures

Green Leagues

• Burnewood Community League
• LEDs, Condensing Furnace, Door Seals, Attic Insulation
• 44% electricity savings post retrofits
• Solar was not suitable
• Blue Quill Community League
• LED’s, Sensor Light Switches, Outdoor Rink Lights, Exit Lighting
• 75% electricity savings post retrofit
• Solar added as second phase

Energy-Saving Opportunities (ESO)

Re-commissioning Controls & set points Behaviour Efficiency upgrades Maintenance

Energy Saving Examples

• Refrigerator always running

– Maintenance

Energy Saving Examples

• Furnace fans always running

– Controls

Energy Saving Examples

• Boiler and thermostats controls

– New condensing boiler – programmable thermostats

Energy Saving Examples

• Aged AC line insulation

– New Insulation and PCV jacket

Energy Saving Examples

• Damaged weather seal
• Missing door closer

Lighting

• 15% to 30% of energy use in commercial facilities
• First area to focus
• Short paybacks
• Principles for reducing energy use:

– Reduce illumination levels – Improve lighting system efficiency – Curtail operating hours – Take advantage of daylighting

Evansdale Community League

Lighting

• Incandescent to LED

– Exit signs

• T12/T8 fluorescent to T8-LED
• Sensors

– Occupancy – Daylight

• Lighting control
• Behavioural

Jeremy’s Lighting Retrofit

• Initial investment: $265
• Annual Savings: $124
• Simple Payback: 2.1 years

HVAC – Low Cost Opportunities

• Poor maintenance = Low efficiency
• Temperature set points, Get a smart thermostat
• Zone control

• Variable speed fan motors
• Heat recovery ventilators
• Upgrade HVAC unit to more efficient model

HVAC – Equipment Upgrades

• Heat recovery

– Marian Centre reduces 51% of daily hot water energy

• Solar thermal system

– When is hot water used?

• Gas over electric heating

– Electric 4x more expensive

• Insulate pipes and tanks

– Reduce thermal loss

Domestic Hot Water

Plug Loads

Perform your own plug load audit

• ENERGY STAR rated appliances

– Freezers – Refrigerators

• Avoid unnecessary electric

heating

– Commercial coffee makers

• Reduce phantom loads

– power bars, timers

Building Envelope

• Goals:

– Reduce heat exchange between building and

• utside

– Control solar and internal heat gains

Building Envelope Infrared Thermography

Building Envelope

• Replace old weather stripping
• Seal cracks and air gaps
• Add insulation

– Roofs – Basements

• Energy efficient windows

– Triple pane, low-emissivity

Water Conservation

• Taps, toilets, showerheads

– Low flow, Low flush

• Sensor taps

– Reduce run time, hygienic

• Hot water energy savings

Summary

• Significant opportunity for energy efficiency

– Conserve energy, save money, and reduce GHG emissions

• Energy audits

– Set energy goals and plan for the future – Benchmark building energy use

• Energy-saving opportunities
• Energy Transition Ambassadors

– Inspire your community

Vital Group of Companies

Energy Audits and Planning M + E Engineering Solar PV and LED Lighting

Mobile: (780) 916-3104 Office Line: (780) 328-4760 Email: brandon@generateenergy.ca #160, 2121 Premier Way, Sherwood Park, Alberta, T8H 0B8

Energy Efficiency Resources

ENERGY STAR

www.energystar.gov

MCCAC Project Showcase

www.mccac.ca/project-showcase

City of Edmonton Green Home Energy Toolkit

www.edmonton.ca/city_government/city_vision_and_strategic_plan/e nergy-toolkit.aspx

Alberta Energy Efficiency Alliance (AEEA)

www.aeea.ca/

Natural Resources Canada (NRCan)

www.nrcan.gc.ca/energy/efficiency

International Energy Agency (IEA)

www.iea.org/topics/energyefficiency/

Cloverdale Community League Sustainability Renovations

Energy 101 EFCL Community Sustainability Workshop Series November 6, 2018

Agenda

 Timeline  Overview of Cloverdale Community League Green Energy Retrofit & Renovations  Challenges  Learnings  Impact  Q & A

Timeline

 June 2015 – engaged Dandelion Renewables to conduct basic energy assessment report focused on electricity and natural gas consumption.

 Findings: electrical consumption could be reduced by 28% and natural gas consumption could be reduced by 31%

 June 2016 – engaged Carbon Busters to conduct ASHRAE Level II Energy Assessment  November 2016 – presented report to Cloverdale Community League

• membership. Motions to proceed with upgrades (83% in favour) and

replace deck (100% in favour)

Timeline (continued)

 January to March 2017 – submitted grant applications  Approvals and funds received between April 2017 and March 2018  Construction on ‘as funds available’ basis from May 2017 to present  Construction scheduled around hall activities

Carbon Busters Report Highlights

 Examined physical condition of building envelope, systems, maintenance procedures  Examined electricity & natural gas bills  Identified opportunities to reduce carbon footprint & opportunities to reduce or eliminate energy costs & fixed utility costs (ASHRAE Level II audit)  Presented wide range of potential retrofits & upgrades expected to yield positive IRR and/or minimum emission reductions of 1 tonne of CO2e.

Carbon Busters Report Summary

 Presented a Decision Tree

 Net Zero → Conventional

 Building Description

 Insulation deficit in foundation walls, crawlspace and attic  Exterior deficiencies

 Utility Consumption

 Electricity – 22,700 kWh per year  Natural Gas – 404 GJs per year  Detailed inventory of lighting

Carbon Busters Report Summary (cont.)

 HVAC

 Age, condition, sizing,

 Recommendations

 Energy Savings & Paybacks

 HVAC  Building Envelope (incl. windows & doors)

 Renewable Energy

 Geothermal  Photovoltaic (PV) Solar Panels

 Menu of Specific Recommendations/Costs  Pictures, Appendix

Carbon Footprint

Electricity - 48% Natural Gas - 51% Water - 1%

Objectives

 Plug the Holes  Improve Energy Efficiency  Harvest the Sun  Be Environmentally & Socially Responsible

Outcomes

 Decreased operating expenses  Increased comfort for building occupants  Extend the life cycle of the hall & equipment  Increased awareness of green energy options  Increased opportunity for reinvestment in Community League programmes  Demonstrated proactive approach to reduce carbon footprint

Plug the Holes

 Seal leaks in the building

 Caulk cracks & gaps in building envelope, interior & exterior repairs  Upgrade weather-stripping at windows and doors  Upgrade windows and doors

 Upgrade/add insulation

 Repair/replace vapour barrier  Add insulation to attic and crawlspace

Improve Energy Efficiency

 Replace furnaces with high-efficiency (96%) furnaces  Replace air conditioners with VRV units  Replace make up air units with HRVs  Replace existing lights with LED  Replace natural gas domestic hot water heater  Install energy monitoring systems

Harvest the Sun

 Re-roof hall (metal clad)  Install photo-voltaic (PV) solar panels on south facing roof  Participate in micro-generation contract with electricity utility provider to generate income from PV solar panels

Social Responsibility

 Decrease carbon footprint  Improved air quality  Reduce dependence on non-renewable energy  Improve environment for future generations  Buy green power  Be a learning resource for community (e.g. Bennett Centre, Cloverdale residents)  Demonstrate green energy options to Cloverdale and greater Edmonton

Cost Estimates

Retrofit Package Cost ($)

Carbon Busters Energy Audit & Green Visioning 8,900.00 Draft Proofing 3,300.00 Exterior Doors 19,790.00 Insulation 26,523.00 High Efficiency Furnaces 23,425.00 Heat Recovery Ventilators (HRVs) 29,584.00 Concession Ventilation 1 ,175.00 LED lights 11,644.00 On demand/point of use DHW heaters 4,955.00 E-gauge Monitoring systems 2, 600.00 Window Replacement 16,764.00

Cost Estimates (continued)

Retrofit Package Costs ($)

Photo-voltaic solar panels (48 panels; 19.2 kWh) 70,094.00 Insulate hot water pipes 15.00 VRV A/C 39,123.00 Re-roofing (metal clad) 108,274.00 Miscellaneous 2,200.00

Estimated Total Cost (incl. GST): 368,366.00

Funding

CFEP $125,000 31% CLIP Planning $4,500 1% CLIP Completed $17,500 4% CLIP Standard $100,000 25% MCCAC - Audit $2,500 1% MCCAC-Implementation $22,916 6% MCCAC - AMSP $14,400 4% Eco-City $43,280 11% CCL $70,000 17%

Sources of Funding Sustainable Energy Renovations & Upgrades Amount and % of Total ($400,096)

Challenges

 Timing of funding

 Lag between application and receipt of funding

 Competition for funds  Construction Scheduling

 Working around activities at the hall  Contractors other obligations

 Communications

 Internal – committee/community league  With contractors and suppliers

 Engagement of community league members

Learnings

 You need a ‘Champion’  Focus on benefits of renovations  ‘Green’ is still a niche, but growing  There’s no such thing as ‘Too Much’ communications  Get on the same page with your contractors and suppliers

More Learnings

 Conduct walk throughs and sign off on project elements – Document! What was done? What are the deficiencies? Action Plan for corrections  Learn how to operate new equipment to maximize efficiency  Report back to the community league members  Celebrate your achievements !

Tools

 City of Edmonton Solar Energy Estimator

 Solar Mapping Tool https://myheat.ca/solar/edmonton

 Energy Star Portfolio Manager

 Manage utility consumption  Reporting tool

 https://portfoliomanager.energystar.gov/pm/login.html

 Energy Efficiency Alberta

 https://www.efficiencyalberta.ca

 City of Edmonton

 https://changeforclimate.ca/?utm_source=google&utm_medium=cpc&utm_campaign=climate- change&gclid=EAIaIQobChMI7azO07683gIVheNkCh1PawNxEAAYASAAEgLhn_D_BwE

Impacts

 Cloverdale Solar Panels in Action  Electricity consumption 

6% in 2017

 Natural gas consumption 

9% in 2015-16, 13% in 2016-17

 Based on assessment by NAIT Alternative Energy Technology Students – February 2018  before majority of renovations were done and before installation of solar panels

 Six homes in Cloverdale have installed solar panels

Impacts

4,016.61 3,089.00 4,196.97 3,074.69 2,122.90 2,047.62 3,811.06 4,397.62 5,228.34 3,235.21 3,492.83 4,179.13 0.00 1,000.00 2,000.00 3,000.00 4,000.00 5,000.00 6,000.00 Jan-13 Jan-14 Jan-15 Jan-16 Jan-17 Jan-18 $ Year Mar-13 Mar-14 Mar-15 Mar-16 Mar-17 Mar-18 Electricity 4,016.61 3,089.00 4,196.97 3,074.69 2,122.90 2,047.62 Natural Gas 3,811.06 4,397.62 5,228.34 3,235.21 3,492.83 4,179.13

CCL Utility Costs from Financial Reports

Electricity Natural Gas

Personal Testimonial

 Installed 9 kW grid-tied solar array, with 31 panels, in 2014, before rebates were available  Net positive production  Converted to LEDs, low flow faucets, shower heads and toilets  Installed DHW recovery unit  It’s worth it!

Personal Testimonial

1,592.75 1,319.29 497.43 346.25 431.83 175.93

• 200.00

400.00 600.00 800.00 1,000.00 1,200.00 1,400.00 1,600.00 1,800.00

• 2,000.00

4,000.00 6,000.00 8,000.00 10,000.00 12,000.00 2013/01/01 2014/01/01 2015/01/01 2016/01/01 2017/01/01 2018/01/01 Dollars (unadjusted) Kilowatt Hours Years

My Residence - Electrical Consumption & Cost

Consu mpt…
