Estimate Submit Order Deliver Install

Assemblies:

• Ball
• Pressure Independent
• Globe
• Retrofit Linkages
• Unitary
• Accessories

The smart, simple way to stay on time and under budget

Easy:

• Estimating
• Bidding
• Ordering
• Delivery Tracking
• Installation

Smart Tags

live up to their name

Quick Start

Project/Customer Information Save, Export, Print, Open, Order, Update Pricing

1 9

customer.honeywell.com/go/fasttrack

Install and Run

• Pricing Effective Date
• To accept, select “Go to App”
• Version of app shown below

buttons

Enter Project Information

• Select “Change”
• Enter customer information
• Enter project information
• Select “Save”
• Select “Canadian Pricing” if

desired

Quick Search

• Search text can be entered

to quickly find specific valves

• r actuators
• Valve can be selected and

list of compatible actuators will be shown

• VBN product family search is

shown here

System Parameters

• Medium
• Water or Steam
• Pressure

Dependent/Independent

• Control Type
• Modulating
• On/Off
• Line Size
• 1/2″ to 24″

Cv Calculator

• Water
• Differential Pressure (PSI)
• Required Flow Rate (GPM)
• Select “Calculate”
• Steam
• Inlet Pressure (PSI)
• Required Flow Rate (lbs/Hour)
• Select “Calculate”
• Cv calculated
• Direct entry of desired Cv is also

possible

• Filters to eight closest valves of

calculated or entered Cv

• Limited to two valve sizes below entered

line size value if line size is entered

• Calculated design values will also

show in the valve schedule

Valve Parameters

• Valve Type
• Ball, Globe, Unitary, Pressure

Independent

• Body Pattern
• 2-Way, 3-Way Mixing, 3-Way Diverting
• Body Size (in)
• Flow Characteristic
• Linear, Equal%
• Trim
• Brass, Stainless Steel

Select Valve

• A list of valves that meet the

entered parameters will appear in the Valve screen

• Highlight the valve you would like

to select

• To add only the valve to the

schedule select “Add Valve” or:

• Select compatible actuator from list of

actuators

Select Actuator

• A list of actuators that are

compatible with the selected valve will appear in the Actuator screen

• Highlight the actuator you would

like to select

• To add only the actuator to the

schedule select “Add Actuator”

• r:
• Enter tagging and “Add Assembly”

Enter Tag Information

• Double click tag information to

edit

• Enter tag information as you

would like it to be printed

• Can be added only to assemblies

Update Schedule

• Valves and Actuators can be

added to the schedule by selecting:

• “Add Assembly” – valve and actuator
• “Add Valve”- valve only
• “Add Actuator” – actuator and required

linkage

• Select the check box to the left of

any line on the schedule to:

• Duplicate a line to the next line
• Edit and replace the line with a

different product

• Delete the line

Save, Export, Email ,Open

• Save Project
• Saves project in its current format to

be opened later for editing

• Default save location is on the c-drive,

but can map to a folder or desktop

• Export Schedule
• Exports schedule as .csv file for use

with Excel

• Email Project
• Generate an email to send project or

schedule files to colleagues

• Open Project
• Open a previously saved project file, or

a received project file

Place Order

• Be sure to save the project first
• Select Email preference
• Email your Honeywell Distributor
• Email Honeywell (authorized

customers only)

• Email Now
• Generate an email
• Attach saved schedule to the email

Quick Order Form

• For use when placing orders on

https://customer.honeywell.com

• Enter desired delivery date
• This is optional
• Quick order form is generated for

upload onto B2B site

Update Pricing

• Upon opening a new project file,

Fast Track will check schedule pricing to see if it matches current year pricing

• The pricing can be updated, if

desired, by clicking on the “Update Price” button

• Previous pricing can be reviewed

and will remain in the schedule until an update occurs.

Retrofit Linkages

• Retrofit linkage products can

be selected based on competitor valves

• Sorting parameters includes

Manufacturer and valve Size

• Compatible Honeywell

actuators and close-off value will be shown when linkage is selected

• Linkage (and bonnet adapter

if required) and actuator can be added to schedule

customer.honeywell.com/go/fasttrack
