SLIDE 1
Engineering Utilities Master Plans
Executive Committee October 2, 2017
AGENDA
- Overview
- Progress
- Engagement
- Utilities Master Plans/Study:
– Drainage – City Sewer – City Water
- Questions/Comments?
Engineering Utilities Master Plans Executive Committee October 2, - - PowerPoint PPT Presentation
Engineering Utilities Master Plans Executive Committee October 2, - - PowerPoint PPT Presentation
Engineering Utilities Master Plans Executive Committee October 2, 2017 AGENDA Overview Progress Engagement Utilities Master Plans/Study: Drainage City Sewer City Water Questions/Comments? Overview Financial
SLIDE 2
SLIDE 3
Overview
CSP OCP Master Plans Financial Plans DCC
SLIDE 4
Progress
Master Plans Stage 1 Stage 2 Stage 3 Stage 4
June 2018
BACKGROUND REVIEW AND DATA ASSESSMENT ANALYSIS AND EVALUATION
Fall/Winter 2017 Spring 2018
Surveys in Winter 2017/ Spring 2018
SLIDE 5
Engagement
May
- Taste of Abby
June
- Seven Oaks Mall
- ARC
- MRC
July
- Canada Day,
- Kalgidhar Park and
Temple
- Berry Beat
- Abbotsford’s Farmers
Market
Public Events
Engaged approximately 650 people to date
Focus Groups
- Internal Stakeholder Workshop
- Chamber of Commerce
- Committee of the Whole (May 15)
- Council Committee Workshop (May 25)
- Report to Council on Stage 1 (Oct 2)
Council
SLIDE 6
- Purpose
- Background
- System Overview
- Issues and Opportunities
- Guiding principles
- Assumptions
- Next steps
Utilities Outline
SLIDE 7
DRAINAGE MASTER PLAN
SLIDE 8
Purpose
Identify impacts
- n the drainage
system Review existing stormwater policy & criteria Review best practices for stormwater utilities Develop a prioritized long- term capital program
Affordable Expandable Phasable
SLIDE 9
Stage 1 Stage 2 Stage 3 Stage 4
June 2018
BACKGROUND REVIEW AND DATA ASSESSMENT ANALYSIS AND EVALUATION
Fall/Winter 2017 Spring 2018 April 2017
Background
- Drainage Issues
- GIS Data
- OCP Land Use Plan
- Finished Projects
- ISMPs
- Reports
- Hydraulic Model
- Drainage Capital Plan
SLIDE 10
- Drainage area is 37,000
ha
- Over 10 watersheds
Matsqui Prairie Sumas Prairie McLennan PS Barrowtown PS Sumas River Dyke Vedder Dyke Matsqui Dyke Matsqui Slough PS
Area A Area B Area C Area D
Urban Development Bdy
Watershed Overview
SLIDE 11
System Overview
Asset 526 Asset
380 1,300
culverts
31,000
SLIDE 12
Drainage Conveyance System
SLIDE 13
System Condition
PS Useful Life: 20-50 Years
Pump Station Physical Age
Barrowtown 32 Matsqui Slough 42-44 McLennan Creek 44
10.9% 19.0% 25.7% 25.7% 13.1% 1.4% 0.4% 3.7% 0.05 0.1 0.15 0.2 0.25 0.3 0-10 11-20 21-30 31-40 41-50 51-60 61-70 71-80
Storm Mains by Physical Age
30% 25% 20% 15% 10% 5%
- Over 60% of pipes were CCTV inspected
- 0.2% in critical condition/ under emergency repair program
Pipe average age: 27 years Detention facility average age: 12 years Useful Life: 75 Years Useful Life: 75 Years
SLIDE 14
Issues and Opportunities
Localized flooding Past practices - runoff volume & quality control Erosion Sediment deposition Low dyke level Capacity
- f system
& pump stations Climate change Stormwater utilities
Resiliency
SLIDE 15
Funding Areas
Matsqui Prairie Sumas Prairie
Urban Development Boundary
Glen Valley
Sub-Drainage Area Urban Development Area Matsqui Prairie Sumas Prairie Upland Rural Glen Valley Drainage & Dyking Rate $/ acre Sumas Lake Bottom Drainage & Dyking Rate $/ acre Outside Lake Bottom Drainage & Dyking Rate $/ acre Drainage fee Based on Land Value (Mill Rate) No Drainage Fee Collect $/ year for Dyking District No Drainage Fee No Drainage Fee
SLIDE 16
Guiding Principles
Best Management Practices Environmental/ Aquifer Protection Streamside Protection Bylaw & Source Control Bylaw Flood and Erosion Protection Criteria & Development Bylaw DFO Guidelines & Water Sustainability Act
SLIDE 17
Assumptions
Rural upland area in a future study Maximum allowable release rate of detention: 5L/s/ha Dyke design level: 1 in 500 year events Climate Change Factor: 10%
SLIDE 18
Next Steps
Stage 1 Stage 2 Stage 3 Stage 4
June 2018
BACKGROUND REVIEW AND DATA ASSESSMENT ANALYSIS AND EVALUATION
Fall/Winter 2017 Spring 2018 April 2017
- Prioritize project list
- Detention & Infiltration
assessment
- Recommendation on
stormwater policy/ criteria
- Review Best Practices for
Stormwater Utilities
SLIDE 19
CITY SEWER MASTER PLAN
SLIDE 20
Purpose
Identify impact due to 200K population growth Identify impact due to commercial, industrial and institutional growth Develop long- term capital program (costs, timing and upgrade priority)
SLIDE 21
Stage 1 Stage 2 Stage 3 Stage 4
June 2018
BACKGROUND REVIEW AND DATA ASSESSMENT ANALYSIS AND EVALUATION
Fall/Winter 2017 Spring 2018 April 2017
- Reviewed GIS Data
- Reviewed current and
future population
- Reviewed infiltration & inflow rates
- Reviewed sewer loads & flow
patterns
- Built sewer model
Background
SLIDE 22
System Overview
- Services 132,000 people in Abbotsford, including Matsqui
& Sumas FN
- Services City of Sumas, WA (~1000 people)
- Sewer flows north to the JAMES plant
- 80% of pipes are CCTV inspected
– 94% in good condition; – 4% approaching critical condition; and – 2% in critical condition
34
33
SLIDE 23
City Sewer Collection System
SLIDE 24
System Condition
Optimize infrastructural renewal and growth related projects Average age of pipe is 30 Years. Useful Life is 75 Years
SLIDE 25
Issues and Opportunities
Dry vs Wet industry (e.g. food processing)
Warehouse (50 eq. ppl) Food processor (2,000 eq. ppl) Wet industry – 15% of total Abbotsford flows
Infrastructure Upgrades
Maximize sewer capacity & mitigate risks (350 to185 L/cap/d) Sewer Odour Corrosion
- f pipes
and manholes Upgrades
- r
relocation
- f sewers
in Right of Ways Climate change & Sewer
- verflows
Resiliency
SLIDE 26
Guiding Principles
Municipal Wastewater Regulations Sewer Regulations Bylaw* & Development Bylaw*
* Design criteria in bylaws will be reviewed in the master plan
SLIDE 27
Assumptions
Keep current Sewer Service Area the same Lands outside Sewer Service Area to remain
- n private onsite
treatment* Residential growth will follow OCP projections Industrial, Commercial and Institutional (ICI) sector also grows with residential sector
* Unless approached by Province due to public health reasons
SLIDE 28
Next Steps
Stage 1 Stage 2 Stage 3 Stage 4
June 2018
BACKGROUND REVIEW AND DATA ASSESSMENT ANALYSIS AND EVALUATION
Fall/Winter 2017 Spring 2018 April 2017
- Run sewer model
- Optimize sewer system
- Identify infrastructure upgrades and their
timing
- Prioritize upgrades
- Integrate Neighborhood Servicing Plans into
masterplan (U District, City Centre, Downtown)
SLIDE 29
CITY WATER MASTER PLAN
SLIDE 30
Identify impact due to 200K population growth
Purpose
Identify Impact
- n Water
infrastructure for commercial industrial, institutional and agricultural growth
Long-term capital program with costs, timing and upgrade priority
SLIDE 31
Background
Stage 1 Stage 2 Stage 3 Stage 4
June 2018
BACKGROUND REVIEW AND DATA ASSESSMENT ANALYSIS AND EVALUATION
Fall/Winter 2017 Spring 2018 April 2017
- Reviewed GIS Data
- Reviewed AMI Data
- Reviewed current and Future
Population
- Aligned with Water Source Supply
Study and Joint Water Masterplan
- Updated Water Model
SLIDE 32
City Water Overview
Services 132,000 people in Abbotsford including Matsqui First Nation
SLIDE 33
City Water System
SLIDE 34
System Condition
- Plan for infrastructural renewal and how that
renewal can happen with growth
(note pipes aged 71-80 are defaulted to 1945 as there are no record Drawings)
13.0% 13.8% 20.8% 30.9% 16.8% 4.1% 0.0% 0.6% 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0-10 11-20 21-30 31-40 41-50 51-60 61-70 71-80
Distribution Mains by Physical Age
Total
Average age of pipe is 29 Years. Useful Life is 75 Years
30% 25% 20% 15% 10% 5% 35%
SLIDE 35
Demand Projections
20 40 60 80 100 120 140 1990 1995 2000 2005 2010 2015 2020 2025 2030 2035 2040 Max Day Demand (MLD) Year
Abbotsford Actual and Projected Max Day Demand
Actual MDD Future MDD
Demand Type Percentage
Residential 43% Commercial 7% Industrial 16% Institutional 4% Agricultural 15% Non-Revenue 15%
SLIDE 36
Issues and Opportunities
Agricultural Water use (25mm diameter service)
Asset Renewal Program (AC water main replacement 80 km remaining)
Dry vs Wet industry (e.g. food processing) Fire protection
Infrastructure Upgrades to Meet Future Demands
Optimizing existing system to improve distribution and water quality
Resiliency of the Water Distribution System
SLIDE 37
Guiding Principles
Canadian Drinking Water Guidelines
Current Waterworks Regulation Bylaw, 2017 and Development Bylaw
Drinking Water Protection Act and Regulation
SLIDE 38
Assumptions
Services in the Rural Area will, remain limited to one service at 25mm (1inch) 75% growth in agricultural use (AgRefresh). Includes growth and climate change Industrial, Commercial and Institutional (ICI) sector also grows with residential sector Residential Growth will follow the OCP Model Water Boundary to remain the same Urban Fire Flows follow FUS Rural Fire Flows is what is available
SLIDE 39
Next Steps
Stage 1 Stage 2 Stage 3 Stage 4
June 2018
BACKGROUND REVIEW AND DATA ASSESSMENT ANALYSIS AND EVALUATION
Fall/Winter 2017 Spring 2018 April 2017
- Run water model
- Optimize water system
- Identify infrastructure upgrades
and their timing
- Prioritize upgrades
- Integrate Neighborhood Servicing
Plans into masterplan
SLIDE 40
Summary of Progress
Master Plans Stage 1 Stage 2 Stage 3 Stage 4
June 2018
BACKGROUND REVIEW AND DATA ASSESSMENT ANALYSIS AND EVALUATION
Fall/Winter 2017 Spring 2018
Surveys in Winter 2017/ Spring 2018
SLIDE 41
