Energy in Your Home Jake Mathias Private Sector Housing Manager, Housing Department, Westminster Council Energy in Your Home Westminster Profile 115,000 Homes Average home in London = 5.3 tonnes of Carbon Social Housing - 29%

slide-1
SLIDE 1

Energy in Your Home Jake Mathias – Private Sector Housing Manager, Housing Department, Westminster Council

slide-2
SLIDE 2

Energy in Your Home

Westminster Profile

  • 115,000 Homes
  • Average home in London = 5.3 tonnes of Carbon
  • Social Housing - 29%
  • Private Renting - 36%
  • 55 Conservation Areas
  • 90% of dwellings are flats
  • 63% of private dwellings built pre 1919
  • At least 63% of dwellings have solid walls
slide-3
SLIDE 3

Energy in Your Home

Energy Efficiency: Easy Measures

slide-4
SLIDE 4

Energy in Your Home

  • Turn your thermostat down by 1 C
  • can reduce heating bills by approx 10%
  • use your programmer to turn on heating when

needed

slide-5
SLIDE 5

Date

Energy in Your Home

  • Only boil as much water as you need
  • but remember to cover the elements if you're using

an electric kettle

  • Eco kettle – EST recommended
slide-6
SLIDE 6

Date

Energy in Your Home

  • Turn appliances off at the wall when not in use
  • cut electricity to all selected appliances using one

switch - Bye Bye Standby

slide-7
SLIDE 7

Date

Energy in Your Home

  • Use energy efficient light bulbs
  • last up to 10 times longer than normal bulbs
  • use up to 80% less electricity than a normal bulb
  • Government phasing out normal bulbs by 2012
slide-8
SLIDE 8

Date

Energy in Your Home

  • Install Energy / Smart Meters
  • Energy meter – shows energy

used by different appliances

  • Smart meter – two-way

communication system, displays real-time energy use

slide-9
SLIDE 9

Date

Energy in Your Home

  • Buy energy efficient appliances
  • Energy Saving recommended fridges use up to 60%

less electricity

  • Energy Saving recommended dishwashers use up to

20% less electricity and less water

  • Integrated Digital TV
slide-10
SLIDE 10

Date

Energy in your Home

  • Install a hot water tank jacket

Hot water Tank Jacket DIY Cost £12 Annual Saving £35 DIY Payback under 6 months Annual CO2 savings 190kgs

slide-11
SLIDE 11

Date

Energy in Your Home

  • Install Curtains and Shutters
  • Draw curtains at dusk to keep the

heat in

  • Shutters reduce heat loss and

provide privacy

slide-12
SLIDE 12

Date

Energy in Your Home

  • Install low flow Shower heads
  • aerated shower heads
  • non-aerated shower head
slide-13
SLIDE 13

Date

Energy in Your Home

  • Install a chimney

balloon

  • Stops chimney

draughts

  • Reduces heat loss
  • Reduces noise
slide-14
SLIDE 14

Date

Energy in Your Home

  • Maintenance
  • Bleed radiators and power flush the system
  • Service the boiler
  • Defrost the freezer
  • Sealing gaps in floorboards
slide-15
SLIDE 15

Date

Energy in Your Home

Energy Efficiency: Major Measures

slide-16
SLIDE 16

Date

35% WALLS 15% DRAUGHTS 25% ROOF 10% WINDOWS 15% FLOOR

Energy in Your Home

slide-17
SLIDE 17

Date

Energy in Your Home

Heating System

Condensing boiler upgrade (G rated to A rated) Installed cost £2,000 Annual saving £235 Payback Period 9 years Annual CO2 savings 1,300kg

slide-18
SLIDE 18

Date

Energy in Your Home

Draught Proofing

Draught Proofing Installed Cost £200 Annual Saving £25 Payback period 8 years Annual CO2 savings 130kg

slide-19
SLIDE 19

Date

Energy in Your Home

Loft Insulation

Loft Insulation top-up from 0 to 270mm Installed cost £300 Annual saving £150 Payback Period 2 years Annual CO2 savings 620kg

slide-20
SLIDE 20

Date

Energy in Your Home

Wall Insulation

Internal Solid Wall Insulation Material cost £35/m2 - £100/m2 Annual saving £380 Annual CO2 saving 2 tonnes

slide-21
SLIDE 21

Date

Energy in Your Home

Wall Insulation

Cavity Wall Insulation Installed cost £415 Annual saving £145 Payback Period 3 years Annual CO2 saving 600kg

slide-22
SLIDE 22

Date

Energy in Your Home

Double Glazing

Sash Window Double Glazing Installed cost £8,000? Annual saving £135 Payback Period 59 years Annual CO2 saving 720kg

slide-23
SLIDE 23

Date

Energy in Your Home

Secondary Glazing

Secondary Glazing DIY Installed cost £2,000 Annual saving £50 Payback Period 40 years Annual CO2 saving 140kg

slide-24
SLIDE 24

Date

Energy in Your Home

  • Solar Thermal – provides

hot water

  • Solar PV – provides

electricity

  • Wind turbine – provides

electricity

  • Biomass – provides

heating

  • Heat Pumps – provides

heating

Renewable Energy

slide-25
SLIDE 25

Date

“Retrofit & Replicate”

  • exemplar terraced house refurbishment
slide-26
SLIDE 26

Date

  • Government had am 80% reduction CO2,

based on a ‘whole house’ approach

  • Energy breakdown for dwellings

− 61% space heating − 23% hot water − 13% lighting and appliances − 3% cooking

  • The priorities are:

− to minimise heat losses from the building fabric; − to install an easily replicable, efficient form of space and water heating; − to reduce the energy requirements for lighting; − to utilise the most appropriate renewable forms of micro-generation

Case study

slide-27
SLIDE 27

Date

The Proposals

slide-28
SLIDE 28

Date

Insulation

  • Kingspan Kooltherm phenolic

foam lining boards

  • Web Dynamics TLX Gold

breathable multifoil – world’s first application

  • Kingspan Thermapitch

polyurethane

  • U value = 0.15 W/m²K walls
  • U value = 0.10 W/m²K roof
slide-29
SLIDE 29

Date

Windows and Doors

  • Nordan NTech Passive

windows – triple-glazed, – frame insulated

  • U value = 0.7 W/m²K !
slide-30
SLIDE 30

Date

MV Heat Recovery

Vaillant recoVAIR 275

  • 85% efficient heat

recovery

slide-31
SLIDE 31

Date

Lighting

  • 100% LED fittings
  • GreenLED 3.7w

‘Antares’ GU10

  • 180W for whole

house

  • 50,000 hrs lifespan =

20 years before replacement

slide-32
SLIDE 32

Date

Solar Thermal Collectors

Dual east/west-facing panels giving combined area of 3.68m2

  • Controls intelligently favour

the better performing panel

  • Generates 1240 kWh heat per

year, around 70% of annual need

  • Heat stored in 250 litre Range

twin coil thermal store, located directly beneath panels

  • Backed up by conventional

condensing gas boiler

slide-33
SLIDE 33

Date

Solar Photovoltaics

  • 8 x 170w polycrystalline panels

(10m2) located on extension flat roof

  • Supplied and installed by Solar

Technologies under British Gas framework with 50% grant funding anticipated from LCBP

  • Tilted due south at 5 deg pitch,

generating 1088 kWh/yr (618 kgCO2/yr offset)

  • Low profile installation to

remove impact on neighbours and planning considerations

  • 1no. inverter located in meter

cupboard, cable penetrates roof via local upstand

  • Installed cost to client - £4460

(with grant) = £446/m2 or £3280/kWp

slide-34
SLIDE 34

Date

Achieving the Target

slide-35
SLIDE 35

Date

Achieving the Target

Fabric insulation - £8900 or £4.38/kgCO2/yr saved Triple-glazed windows/doors - £9640 or £21.34/kgCO2/yr saved Condensing boiler/central heating - £5000 or £3.16/kgCO2/yr saved MVHR/airtight measures /testing - £3200 or £2.83/kgCO2/yr saved Solar collectors and storage - £5300 or £7.49/kgCO2/yr saved Replacement LED Lighting - £2505 or £8.32/kgCO2/yr saved Photovoltaics - £4950 (with 50% LCBP grant) or £9.39/kgCO2/yr saved Total - £39,495 or £6.10/kgCO2/yr saved Average tenant fuel bill reduced by over £600/yr

slide-36
SLIDE 36

Date

The completed project

slide-37
SLIDE 37

Date

The completed project

slide-38
SLIDE 38

Date

The completed project

slide-39
SLIDE 39

Date

The completed project

slide-40
SLIDE 40

Date

The completed project

slide-41
SLIDE 41

Date

The completed project
