A Data Network for Emergency Communication Tucker Dunham, KD2JPM Abbie Heim, KD2PUA 1 About Me Tucker KD2JPM Licensed: October 2016 Warren County, NJ Eagle Scout Junior at Warren County Technical School-

slide-1
SLIDE 1

A Data Network for Emergency Communication

Tucker Dunham, KD2JPM Abbie Heim, KD2PUA

1

slide-2
SLIDE 2

About Me

  • Tucker – KD2JPM
  • Licensed:

October 2016

  • Warren County, NJ
  • Eagle Scout
  • Junior at Warren

County Technical School- Electronics

  • Certified Electronics

Technician Associate

  • Placed 2nd in NJ

SkillsUSA for Electronics Technology.

2

slide-3
SLIDE 3

About Abbie

3

slide-4
SLIDE 4

Cellphone Service in Puerto Rico after Hurricane Maria

Source: FCC Communications Status Report September 28, 2017

4

slide-5
SLIDE 5

Communication During Emergencies

During Emergencies passing accurate information is key:

 Location of Shelters  Medical Assistance  Rescue Operations  Food and Water  Health and Welfare

During Hurricane MARIA in the Puerto Rico, MOST communications systems were OFFLINE

5

slide-6
SLIDE 6

Challenges

Cannot rely on commercial power at all! Generators become useless when fuel cannot be obtained!

6

slide-7
SLIDE 7

Inspiration

7

slide-8
SLIDE 8

Requirements

  • Made with readily available materials
  • Easily manufactured and reproduced
  • Self Sustaining
  • Simple
  • Effective
  • Versatile
  • Portable
  • Low Cost

8

slide-9
SLIDE 9

The Solution

Portable Solar Powered Digipeater

9

slide-10
SLIDE 10

Field Research

When communicating information TEXT wins over VOICE “Text me the movie times ….” “Text me your address …..” “Text me where we should meet …..” As opposed to: “Wait let me find a pencil and paper …...” “How do you spell that?? P-E-R-R-I-E or with a Y ??”

10

slide-11
SLIDE 11

Which Digital Mode?

MESH networking uses 2.4, 3.4 and 5.8 GHz Bands Very unforgiving to path loss like trees and buildings Alignment is critical Typical Emergency traffic doesn’t require high- speed data or multimedia AX.25 1200 baud packet is sufficient for “text messages”

11

slide-12
SLIDE 12

Packet Radio??? But that’s so 80s!!

12

slide-13
SLIDE 13

What is Packet Digipeating Connect computers to radios with Terminal Node Controller (TNC) That forms the packets and modulates AND DEMODULATES DATA. Packet Framing and addressing

13

slide-14
SLIDE 14

14

System Overview

slide-15
SLIDE 15

Antenna

Twin-Lead Half-Wave “J pole” inside of 1/2” PVC

15

slide-16
SLIDE 16

3D Printed Parts

16

slide-17
SLIDE 17

Solar panel holders Radio holders Threaded base Vertical mount for PI

17

slide-18
SLIDE 18

Sketchup

  • Easy to use and free CAD software

18

slide-19
SLIDE 19

Printer

19

  • Creality CR-10 3D printer
slide-20
SLIDE 20

Container

What shapes you considered What was the goals ….. Fit Good for solar panels Mechanical flow Weatherized Folding solar panel mounts The project was built to fit inside a cylinder because PVC is readily available, cheap and can be cut to size.

  • Solar panels can moved easily to

follow the sun when mounted on a cylinder

20

slide-21
SLIDE 21

Solar Panel Mounts

Cylinder makes good platform for mounting solar panels

21

slide-22
SLIDE 22

Power Supply

Solar panels power radio, Raspberry Pi, and charge batteries during the day. Batteries power the system by night.

22

slide-23
SLIDE 23

Block diagram of the power

23

slide-24
SLIDE 24

Shape Why SLA batteries

24

  • SLA was used for their large energy density and how easy it is to charge.
  • Lithium-ion was considered, but the complexity required to charge them was not

practical when using solar panels.

  • Liquid batteries could leak if the unit was knocked over.
  • Can survive being undercharged and overcharged more forgivingly than lithium

batteries.

slide-25
SLIDE 25

Voltage converters Describe them What each one does Why their different

25

  • The first voltage converter (buck/boost) that is wired directly to the solar panels

steps down the voltage from the solar panels to the correct voltage to charge the batteries, keep them on standby during the day, and provide power to the second converter.

  • The second converter is a buck converter that steps the 13.8 volts from the first to

the 7.6 volts required to power the Yaesu radio,

  • The third and provide power to the raspberry pi 5 volt power supply.
slide-26
SLIDE 26

Solar panels How many …. Why these Size … voltage … current

26

  • The panels we chose claimed to be able to provide 500mA at 5V, but after

testing them under load, we learned that was not possible. (what was the actual performance)

  • The size of the panels was small enough that it could be mounted to almost

any surface, such as an ammo box, PVC pipe, or a custom 3d printed enclosure.

  • There were also solder pads on the back to allow us to arrange the panels

in any configuration, high current at low voltage or high voltage at low current.

  • Originally, we purchased twelve believing that we only need six to power the

project, leaving us enough to build two units. All twelve eventually ended on the final design to compensate for the lack of performance and to provide power to charge the batteries more to make up for cloudy days

slide-27
SLIDE 27

Computer platform Why a raspberrypi

27

  • The raspberry pi was chosen because it ease of use
  • It is a full single board computer running the popular linux operating system
  • The raspberry pi was also the most economic solution, price-wise and in terms of

power consumption.

  • The raspberry pi also has many GPIO pins on it to allow the user to connect a

multitude of sensors that can provide data that can be transmitted as its own message or along with the intended data.

slide-28
SLIDE 28

Tncpi What is it How does Read the docs

28

slide-29
SLIDE 29

Local networking RaspberryPi acts as a wifi access point for easy local access with a computer or smartphone Could be used as a communication end point in addition to a repeater

29

slide-30
SLIDE 30

Radio Why this radio It worked better than the baofengs Talk about the problems 3d printed radio holder

30

  • Originally, we had chosen to use Chinese made Baofeng radios with the intent to

keep each unit as cost effective as possible.

  • After hours of testing and troubleshooting, it was determined that the poorly designed

receiver of the Baofeng was distorting the incoming data signal and not allowing the data to be recognized by the receiving unit.

  • After finding an economical, better engineered radio, we built a new interface cable

and tested the new radio’s capabilities.

  • With a new receiver that was designed under higher quality control, the data was

transmitted and received perfectly clear.

slide-31
SLIDE 31

Interface cable Diagram How it works

31

slide-32
SLIDE 32

Final Overview

Portable Solar Powered Digipeater

 RaspberryPi with TNC-PI  2 Meter Handi-Talkie  Voltage Regulators  Charge Control  Batteries  Solar Panels  Antenna  Portable / Transportable Enclosure  3D Printed Parts

32

slide-33
SLIDE 33

Compact

33

6V SLA Batteries Power Management Circuits Raspberry Pi 2M Handie Talkie

slide-34
SLIDE 34

Final Product

34

slide-35
SLIDE 35

Video Demonstration Note: unfortunately the size of the video precluded it from being loaded

  • nto the RCA site.

35

slide-36
SLIDE 36

Expandability - Enhancements

APRS Repeater Weather station Message Post Office Alternate Antenna Configuration RaspberryPi Base allows for almost infinite software

  • r sensor expansion

36

slide-37
SLIDE 37

APRS repeater Add GPS module for self position reporting Change repeater soft

37

slide-38
SLIDE 38

Weather Station

38

slide-39
SLIDE 39

Post office

39

slide-40
SLIDE 40

Thanks to all that helped …..

 Carole Perry, WB2MGP, for the opportunity to present  Abbie Heim, KD2PUA, enclosure top & bottom and

antenna

 Caleb Lee, KD2NUC, RaspberryPi research, held SD

cards

 John Metroke, WA2SME, Electronics Instructor at WCTS  Bob Oppen, NE2C, Antenna materials and guidance  The 721

st

Mechanized Contest Battalion, for what they do best

40

slide-41
SLIDE 41

The End!

Thank you for your time. If any one has any questions feel free to ask.

41

WC2FD.COM
