Embracing the Environment

Whau Symposium – Our River Our Future 25 September 2013

Agenda

• Introduction
• Western Ring Route - context and overview
• Causeway Upgrade Project - overview
• Environmental monitoring and mitigation
• Find out more, and Causeway News
• Discussion

Western Ring Route – SH 6

• Improved and more reliable

journey times

• Direct motorway access to

the airport

• An alternative route to SH1

around Auckland

• Co-ordinated with Auckland

Transport and public transport improvements

• One of the ‘Roads of

National Significance’

Waterview to Te Atatu

Western Ring Route – SH16

Body text style ○ Bullet point style level 1

○ Bullet point style level 2

○ Bullet point style level 3

Body text style tinci ent et loborer ciduipsum il ullaor iriustio consectet. Rud dolor sustis dolor si tat lorperaesed modolore tie verostrud eliquis eu feuisi tat ut luptate te tat, quat inciduis.

HEADING TWO STYLE

Programme update

• Causeway Alliance of the NZ Transport Agency, AECOM,

Coffey, Fulton Hogan, Leighton Contractors and Sinclair Knight Merz are delivering the project for the Transport Agency

• Sept 2013 - Causeway construction continues
• October 2013 to Sept 2015 – Whau bridge widening
• Late 2016 – Causeway upgrade due to be completed
• Early 2017 - Waterview tunnels open

Causeway Alliance

• NZ Transport Agency
• AECOM
• Fulton Hogan
• Leighton Contractors
• Sinclair Knight Merz
• Coffey

A collaborative approach to our work gives better value for money and greater benefits for our customers

Causeway – storms and tides

Causeway Upgrade - scope

Existing SH16 Causeway New SH16 Causeway

3 lanes westbound 5 lanes Waterview to Rosebank 4 lanes Rosebank to Te Atatu 3 lanes eastbound 4 lanes eastbound Inadequate bus shoulders Extended and widened bus shoulders both sides of motorway Pedestrian/cycleway

Enhanced pedestrian/cycleway

Flooding occurrences

Raised 1.5m for flood protection

Existing Causeway

Causeway improvements

(progressively from 0 months to -/+ 2 years)

Causeway improvements

Causeway improvements

(2 to 2.5 years)

Causeway improvements

(2.5 - 3 years)

Causeway – final layout

Whau river and Te Atatu site offices (Taupuni)

Te Atatu site offices & Whau bridge

Kaumatua Eru Thompson and Pita Pou

Whau bridge - access

Whau bridge – ground improvements

Whau bridge to Rosebank Domain

Whau bridge widening – cross section

• Broad range of experts review construction activities
• Pre-clearance and ongoing inspections for lizards,

vegetation, trees and archaeology

• Stormwater, erosion/sediment control, coastal area

protection established before works begin and regular inspections

• Ongoing monitoring of earthworks compliance,

contaminated soils, noise, air quality, marine ecology and birds

• Monitoring results to be issued to CLG

Whau bridge – shared path widening

Planting and trees

• Coastal experience -

native coastal species

• Eco-sourced from

Tamaki Ecological District

• Appropriate ecotypes
• Reference to existing

vegetation

• Pohutukawa at gateway

locations

Environmental monitoring - overview

• Broad range of experts review construction activities
• Pre-clearance and ongoing inspections for lizards,

vegetation, trees and archaeology

• Stormwater, erosion/sediment control, coastal area

protection established before works begin and regular inspections

• Ongoing monitoring of earthworks compliance,

contaminated soils, noise, air quality, marine ecology and birds

• Monitoring results to be issued to Community Liaison

Group

Te Atatu Construction Yard - Bird life

• Dotterel nest found
• n earth stockpile in

Construction yard

• Fenced off to protect
• Advice being sought

from DOC

Environmental mitigation and legacy

• Runoff receives a high standard of stormwater treatment
• Landscape planting (grass swale & path edge, revetment)
• Further mitigation options/outcomes being considered, eg:
• Increased community awareness/education
• Improved access to marine reserve, under Whau bridge
• Viewing areas and seating along shared path
• Greater plant and animal pest control
• Celebration of heritage and culture
• Revegetation of Traherne Island

How to find out more

• Community Liaison Group (CLG) meetings
• Freephone 0800 444 449 | Mention “Causeway”
• Causeway News – regular project email updates
• Project website, Google: SH16causeway
• Info about upcoming work: media, advertising
• Separate meetings for site or issue specific details
• Communications and Stakeholder Manager, contact:
• elizabeth.collins@sh16causeway.co.nz

Summary

• Construction progressively moving along SH16 to

upgrade the corridor by late 2016

• Causeway Alliance is committed to working closely with

the community and monitoring works to minimise effects

• n environment
• Project outcome is to ‘tread lightly’ on the surrounding

environment and marine reserve

• Reviewing options for including further environmental

mitigation projects

Questions | Discussion
