Embracing Noopur Gupta Eclipse JDT co-lead IBM India with noopur_gupta@in.ibm.com @noopur2507 1 EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM JUnit Framework JUnit 4.0 Released in 2006 JUnit 5.0

slide-1
SLIDE 1

Noopur Gupta Eclipse JDT co-lead IBM India noopur_gupta@in.ibm.com

Embracing with

1

@noopur2507

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-2
SLIDE 2

 JUnit 4.0

Released in 2006

 JUnit 5.0

Released in September 2017

2

Source: http://blog.takipi.com/the-top-100-java-libraries-in-2017-based-on-259885-source-files/

JUnit Framework

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

The top 20 Java libraries on GitHub in 2017

slide-3
SLIDE 3

Modularity (single JAR) Developers accessing internals and duplicating code Maintainability Extensibility

(via Runners and Rules)

Java 8 support

(Lambdas, Streams, Default Methods etc.)

JUnit 4 Architecture

3

junit.jar (Single JUnit 4 JAR) Testing frameworks developers Build tools developers IDEs developers @Test developers

Problems

(+ org.hamcrest.core.jar)

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-4
SLIDE 4

4

JUnit 5 Architecture

JUnit 5 = Platform + Jupiter + Vintage

5th planet in Solar System!

Source: http://junit.org/junit5/docs/current/user-guide/#dependency-diagram

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-5
SLIDE 5

5

 JUnit Platform

▪ junit-platform-launcher Launcher APIs used by IDEs and build tools to launch the framework. Finds test engines via Java’s ServiceLoader mechanism. ▪ junit-platform-engine TestEngine APIs for integration of any testing framework that runs on platform.

 JUnit Jupiter

▪ junit-jupiter-api APIs for the new programming and extension model. ▪ junit-jupiter-engine JupiterTestEngine - To discover and execute Jupiter tests.

 JUnit Vintage

▪ junit-vintage-engine To discover and execute JUnit 3 and JUnit 4 tests on JUnit 5 platform.

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

JUnit 5 Architecture

slide-6
SLIDE 6

A sneak peek into the major interesting features of JUnit Jupiter with Eclipse support for JUnit 5.

6 EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-7
SLIDE 7

Eclipse support for JUnit 5

7

Eclipse Oxygen.1a (4.7.1a)

https://www.eclipse.org/downloads/eclipse-packages

Eclipse Photon (4.8) M2 onwards

http://download.eclipse.org/eclipse/downloads

Software site repository to update Eclipse Oxygen (4.7 and 4.7.1):

http://download.eclipse.org/releases/oxygen/

Demo: Eclipse Photon (4.8) M2 milestone build

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-8
SLIDE 8

Demo

JUnit Jupiter - Programming Model

8 EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-9
SLIDE 9

Create a new JUnit Jupiter test

Create a new JUnit Jupiter test in Eclipse with lifecycle method stubs for a class and its methods under test:

9

New JUnit Test Case wizard

  • > New JUnit Jupiter test

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-10
SLIDE 10

Add JUnit 5 library to the build path

10

New JUnit Test Case wizard offers to add it while creating a new JUnit Jupiter test. Quick Fix (Ctrl+1) proposal on @Test. Add library (JUnit) in Java Build Path dialog.

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-11
SLIDE 11

11

Visibility

Test classes and methods can have any access modifier (other than private).

Annotations

JUnit 4 JUnit Jupiter @org.junit.Test @org.junit.jupiter.api.Test

(No expected and timeout attributes)

@BeforeClass @BeforeAll @AfterClass @AfterAll @Before @BeforeEach @After @AfterEach @Ignore @Disabled

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-12
SLIDE 12

Create a JUnit Jupiter test method in Eclipse with the new template:

12

test_jupiter

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

Create a new JUnit Jupiter test method

slide-13
SLIDE 13

13

Assertions

(org.junit.jupiter.api.Assertions class)

  • Failure message comes at the end of arguments list.
  • Failure message can be retrieved lazily.
  • Grouped assertions to execute all assertions first

and then report all failures together.

  • Exception testing to assert and evaluate a thrown exception.
  • Asserting that the given task completes before the given timeout.

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-14
SLIDE 14

14

(org.junit.jupiter.api.Assumptions class)

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

Assumptions

slide-15
SLIDE 15

JUnit Jupiter’s Assertions, Assumptions, DynamicContainer & DynamicTest classes are now added to Eclipse Favorites by default.

15

Preferences

  • > Java -> Editor
  • > Content Assist
  • > Favorites

Import static methods in your code from favorite classes via Content Assist (Ctrl + Space) and Quick Fix (Ctrl + 1). Configure the number of static member imports needed before type.* is used.

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

Eclipse Favorites

slide-16
SLIDE 16

16

@DisplayName

Provide custom display names for test classes and test methods - with spaces, special characters, and even emojis! Use Go to File action or just double-click to navigate to the test from JUnit view.

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-17
SLIDE 17

17

@Nested test classes

Non-static nested classes (i.e. inner classes) can serve as @Nested tests for logical grouping of test cases.

(Re-)Run a single @Nested test class by using the Run action in JUnit view or Outline view. You can even right-click on a nested test class name in the editor and use the Run As action.

Example: TestingAStackDemo in JUnit 5 user guide.

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-18
SLIDE 18

18

Test interfaces and default methods

  • Default test methods can be inherited by implementing test classes.
  • Enables multiple inheritance in tests classes.

Example: StringTests in JUnit 5 user guide.

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-19
SLIDE 19

19

Tagging and Filtering

  • Tag test classes and test methods with @Tag.
  • Tags can later be used to filter test execution.

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

Provide tags to be included in

  • r excluded from a test run

via Configure Tags dialog in its JUnit launch configuration.

slide-20
SLIDE 20

20

Meta-annotations and composed annotations

  • JUnit Jupiter annotations can be used as meta-annotations.
  • Create custom composed annotation inheriting semantics of its meta-annotations.

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-21
SLIDE 21

21

Dynamic Tests

  • Dynamic tests are generated at runtime by a @TestFactory method.

Create a @TestFactory method in Eclipse with the new template:

  • Dynamic container is composed of a display name and a list of dynamic nodes.
  • Dynamic test is composed of a display name and an Executable.

test_factory

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

There are no lifecycle callbacks for individual dynamic tests.

slide-22
SLIDE 22

22

Navigate to failing source location

Double-click an entry in JUnit view’s failure trace to jump to the corresponding source location. Click "Show Stack Trace in Console View" button and use the hyperlinks. It can also be used to copy parts of the stack trace.

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-23
SLIDE 23

23

Dependency Injection

  • Test constructors and methods are now permitted to have parameters enabling

Dependency Injection.

  • ParameterResolver is the extension API to provide a parameter resolver which

dynamically resolves a parameter at runtime.

  • A parameter resolver can be registered via @ExtendWith(…) annotation.
  • JUnit Jupiter provides some built-in resolvers which are registered automatically:
  • TestInfo (resolved by TestInfoParameterResolver) to access information about the

currently executing test:

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-24
SLIDE 24

24

Dependency Injection

  • TestReporter (resolved by TestReporterParameterResolver) to publish additional data

from the currently executing test which can be seen in the Console view in Eclipse:

  • To support overloaded test methods, the Test Method Selection dialog in JUnit

launch configuration now shows the method parameter types also:

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-25
SLIDE 25

25

Repeated Tests

Repeat a test by annotating the method with @RepeatedTest and specifying the number of repetitions.

  • name attribute: to optionally specify a custom display name for each repetition.
  • RepetitionInfo: as test method parameter to get information about the current

repetition.

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-26
SLIDE 26

26

Parameterized Tests

Run a test multiple times with different arguments by:

  • annotating the method with @ParameterizedTest
  • and declaring at least one source to provide the arguments.
  • name attribute: to optionally specify a custom display name for each invocation.
  • Test method may have additional parameters to be resolved by other

ParameterResolvers at the end of the method's parameter list.

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-27
SLIDE 27

27

Test Instance Lifecycle

  • By default, JUnit Jupiter creates a new instance of the test class before

executing each test method.

  • To execute all test methods on the same instance of the test class, you can

annotate the test class with @TestInstance(Lifecycle.PER_CLASS).

  • The per-class mode makes it possible to use @BeforeAll and @AfterAll

annotations on:

  • Non-static methods
  • Interface default methods
  • Methods in @Nested test classes

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-28
SLIDE 28

JUnit Jupiter - Extension Model

See the JUnit 5 User Guide for more details.

28

 Provides extension points as interfaces in org.junit.jupiter.api.extension package to be implemented by extension providers.  Register one or more extensions declaratively on a test class, test method,

  • r composed annotation with @ExtendWith(…).

 JUnit Jupiter also supports global extension registration via Java’s ServiceLoader mechanism.

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-29
SLIDE 29

In summary…

29

 Modular architecture  Modern programming model  Powerful extension model  Gentle migration path  Eclipse IDE support

EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-30
SLIDE 30

References & Resources

Eclipse support for JUnit 5

https://www.eclipse.org/community/eclipse_newsletter/2017/october/article5.php Download Photon (4.8) M2 & above: http://download.eclipse.org/eclipse/downloads Download Oxygen.1a (4.7.1a): https://www.eclipse.org/downloads/eclipse-packages Software site to update Oxygen (4.7 & 4.7.1): http://download.eclipse.org/releases/oxygen/ Report bugs/enhancements: https://bugs.eclipse.org/bugs/enter_bug.cgi?product=JDT

30 EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-31
SLIDE 31

References & Resources

JUnit 5 Project

http://junit.org/junit5 User Guide http://junit.org/junit5/docs/current/user-guide Javadoc http://junit.org/junit5/docs/current/api GitHub https://github.com/junit-team/junit5 Gitter https://gitter.im/junit-team/junit5 Q&A http://stackoverflow.com/questions/tagged/junit5

31 EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-32
SLIDE 32

32 EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-33
SLIDE 33

33 EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM

slide-34
SLIDE 34

Eclipse Converge 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM 34 EclipseCon Europe 2017 | Embracing JUnit 5 with Eclipse | Noopur Gupta, IBM
