ELECTRONIC WATER CONDITIONER

U K Systems is at your service since 1993

&

incorporated with UB’CAL water conditioner in the year 2004.

UB’CAL treats hard water with

Recently in the market numerous devices are used to treat hard water that are permanent magnets, electromagnetic, catalytic, resonators,

• etc. Most of the devices are not reliable or work

according to the principle of fundamental physics and chemistry, so the performance of these devices will not be up to the mark.

ü Scale Elimination.

ü No salt or chemicals needed ü Retains healthy minerals. ü Little space required and safe. ü Low running cost, negligible power Consumption. ü Effective on PVC,HDPE,Copper or Steel pipe. ü Mains pressure unaffected & No waste water. ü No maintenance, no plumbing & easy to install.

UB’CAL

TM

E L E C T R O N I C

WATER CONDITIONER

Rain water is somewhat acidic because it falls through the atmosphere it encounters carbon dioxide (CO2) with which it reacts to from carbonic acid as follows

H2O + CO2 = H2CO3 water + carbon dioxide = carbonic acid

Rain water combines with gases in air & becomes slightly acidic and the following reaction takes place .

The slightly acidic water dissolves rock and forms hardness. The hardness in the water comes from the water passes over and permeates through rocks such as lime stone, seashells or marble forming soluble calcium ions and bicarbonate ions that dissolved into the water from soluble rocks through which the rain water flows.

CaCO3 + H2CO3 = Ca++ + 2HCO3

(Calcium Carbonate) (Carbonic Acid) (In Solution)

Scale is the deposition of mineral accumulation on the surface that are in contact with hard water. The most common scale is calcium carbonate and occurs naturally as an ingredient of chalk, limestone or marble. Especially in hard water area the hard water affects almost everything i.e.

In residential zone scaling in pipe, stains

• n showerheads, basins, sinks, taps, etc.

The scales are formed due to the electrostatic attraction between pipe surface and the scale causing minerals.

Do you know the gravity plays

The unique property of scaling in pipe is that the deposition of the scale is in uniform.

No role in scale formation.

factors affects the solubility of calcium carbonate & cause scale.

Solubility of Calcium decreases with increase in pH. Lower the pH higher the acid content this will dissolve more calcium carbonate. As the temperature increase the solubility of the calcium decreases and property of scaling increases. A change in water pressure also affects the scale formation lower the pressure higher the chances of scale buildup in pipe.

Research showed that these salts combine with each other to form crystals & attaching themselves to other surface in the form of scale. Further research proved that a rapidly changing electronic wave form would neutralize these bonds but that a different wave form was needed for each mineral which should be generated accurately & with controlled speed.

ü Scale Elimination. And resolve issue of Hard Water. ü Improves Water Quality. ü UB’CAL – Helps To Control Biological Impurities. ü Reducing Bacteria Growth. ü Low Running Cost, Negligible Power Consumption. ü Effective On PVC,HDPE,COPPER Or Steel Pipe. ü No Salt ,Chemical Or Maintenance Is Needed. ü Easy To Install And Mains Pressure Is Unaffected.

UB’CAL

TM

E L E C T R O N I C

WATER CONDITIONER

The UB'CAL uses a series of controlled complex modulating high frequency waveform that neutralizes the bonding ability of minerals that are contained in our water. This field effectively agitates different size molecules likely to form scale & to break the bonds between molecules & the water. This results the break down of large mineral crystals into tiny mineral particles & then prevent them from reacting with other minerals or bonding to any surface to from scales. The process is so effective that existing scales are progressively broken down & flushed away in due course of time. The conditioned gaseous ions results in non-corrosive & better tasting water. It also helps the plants to grow well & healthy.

S Two coiled antennas wrapped around the water pipe broadcast & induce a

series of controlled complex modulated signal field into the water pipe. When water passes rapidly from the complex signal field, it changes the behavior of the mineral particles in the water.

It means UB’CAL has a unique processes of variable frequency modulation technology, in this processes the variable frequencies are programmed in nano and micro seconds, these frequencies are induced into the water through alternate coiling mechanism. This unique mechanism of UB’CAL water conditioner achieved great success in water industry. The UB’CAL does not rely on the strength of the magnetic field at all, the strength of the magnetic field produced by UB’CAL is less than 1000 time that of a simple refrigerator magnet used in kitchen.

ü Removes existing lime scales & descales the plumbing system. ü Prevents fresh deposits of lime scale forming on baths sinks, shower heads, shower screens & lavatories. ü Provides softer water so that soaps, shampoos & detergents lather better & scum is reduced. ü Conditioned water is better for skin & hair. ü Helps to keep wall tiles, toilet mirrors, etc. clean. ü Car washing is made easy & cheerful. ü For swimming pools reduces the need of chemicals. ü Extends life of water filters & RO membranes

ü Water with high salinity & T.D.S. level can be effectively used. ü Reduce the effect of salts & basic elements are made available to root zone, it also enhances nutrients uptake. ü Reduce the tip burn problem in leaves. üFewer pesticides & effective use of fertilizers.. ü Crop production & crop quality increases. üIncreases milk production & fat content in milk. üIn poultry egg laying capacity increases & problem of thin shelled eggs in minimized.

ü Used for Boilers, Cooling Tower, Heat Exchangers etc. üStops scale deposition and corrosion. üSaves fuel and energy by removing heat wasting scales. üMore efficient Cooling and Heating. üKeeps cooling towers, piping and condensers clean. üSaves money by avoiding maintenance and replacement cost. üLonger life for hot water equipments. üAvoids expenses on chemicals and soft water treatment.

In Industrial sector scaling is the major problem such as loss in production , quality of the product, maintenance, early replacement of capital equipment and increase energy usage.

Scale Thickness in mm Loss of energy in % 1.60 13% 3.18 25% 6.35 40% 9.00 55%

SUPPLY VOLTAGE : 230 V/AC. CURRENT CONSUMPTION : LESS THAN 10 WATT. OUTPUT POWER : DESISGED TO CONTROL DESCALING RATE MAXIMUM SIGNAL CABLE : DUAL 2 X 13 TURNS. ENCLOSURE MATERIAL : ABS DIMENSION : 33 CM. X 27 CM. X 10 CM. WEIGHT :

• APPROX. 4.8 K.G.

MAHARASTRA OFFICE:- U.K.SYSTEMS 6, Rahul Complex, Opposite of TATA Petrol Pump, Miraj Road,Sangli - 416416 Maharashtra, India GUJARAT OFFICE:- Tattva Tech B-504, Shilp Aaron, Sindhubhavan Road, Nr. Pakwan Circle, Bodakdev, Ahmedabad – 380054 Gujarat, India.

Contact Numbers : +91 9558 314 111 +91 8140 314 111 Email:- info.tattvatech@gmail.com Website :- www.tattvatech.in www.ubcalindia.com

Please Feel Free To Ask Any Query Regarding

UB’CAL

• r visit

www.ubcalindia.com www.tattvatech.in

UB’CAL

ELECTRONIC WATER CONDITIONER TATTVA TECH
