El. devices fabrication (2) [Hastings] Production of silicon Crystal growth - starting from electronic grade Si, obtained by distillation from metallurgical grade Si - Czochralski method -> ingots (height ~ 1m) Then: - cut -> wafers


slide-1
SLIDE 1
  • El. devices fabrication (2)

[Hastings]

slide-2
SLIDE 2

Production of silicon

Crystal growth

  • starting from electronic

grade Si, obtained by distillation from metallurgical grade Si

  • Czochralski method ->

ingots (height ~ 1m) Then:

  • cut -> wafers (diam. 6 - 12 inches, 0.150-0.300 mm)
  • polishing (mechanical (abrasive) + chemical)

Orientation (100) or (111)

slide-3
SLIDE 3

Oxide growth/deposition

  • Oxide: SiO2
  • easy growth/deposition
  • mechanically rugged; readily dissolves in HF
  • excellent isolator -> also for MOS
  • Growth
  • dry: Si + O2 -> SiO2
  • wet (not so good (superficial charge) but faster):

Si + 2H2O -> SiO2 + 2H2

  • T ~ 1000 oC
  • thickness: ~ 2x wrt Si (see LOCOS later)
  • Alternatively: deposition (not so good!). E.g.:

SiH4 + 2NO2 -> N2 + 2H2O + SiO2 This is an example of chemical vapor deposition (CVD)

slide-4
SLIDE 4

Masks

  • If selective processing is needed, a patterned material

can be used as a mask

  • the patterning is done via photolithography (see later)
  • materials:
  • low T: photoresist (soft mask)
  • high T: SiO2 o Si3N4 (hard mask), which, of course,

are patterned using photoresist)

slide-5
SLIDE 5

Photolithography (1/3)

◼ Photoresist (deposited via

spinning)

  • negative (polymerize with UV)
  • positive (depolymerize with UV)
slide-6
SLIDE 6

Photolithography (2/3)

  • Photomasks (reticles)
  • normally 5x or 10x (with

stepper -> several exposures (each normally for more than one die)

  • or, mask 5x or 10x ->

stepped working plate ->

  • nly one exposure, 1x
  • very expensive; normally
  • btained via direct writing

(electron beam lithography)

  • r (photo)reticle
slide-7
SLIDE 7

Photolithography (3/3)

  • Then, development (with organic solvents) to remove

the non-polymerized photoresist

  • Then, after the selective processing (deposition or

etching), the photoresist is removed

  • chemically (with solvents), or with
  • reactive ion etching (ashing): plasma with oxygen
slide-8
SLIDE 8

Oxide removal

  • wet etching (with

HF, isotropic)

  • dry etching (e.g.

with reactive ion etching, e.g. trichloroethane + Ar; anisotropic -> better control on the widths)

slide-9
SLIDE 9

Oxide…

Reactive ion etching

slide-10
SLIDE 10

LOCOS; silicon nitride

LOCOS (local

  • xidation of

silicon): selective growth

  • f a very thick
  • xide: normally

for field oxide For Si3N4: CVD 3SiH4+4NH3 -> Si3N4+12H2

slide-11
SLIDE 11

Diffusions

Diffusion:

  • (pre)deposition
  • drive(-in)

T ~ 800-1250 oC Dopants: Si-p: B (B2H6) Si-n: P (POCl3, PH3), As, Sb Poor horizontal control: isotropic process! E.g.: 4POCl3+3O2 -> 2P2O5+6Cl2 P2O5 builds a glass on Si 2P2O5 +5Si -> 4P+5SiO2

slide-12
SLIDE 12

Diffusions

Main parameters of the dopant:

  • diffusion coeff.
  • solid solubility

NB: As, Sb have low diff. coeff.

slide-13
SLIDE 13

Diffusions

Ion implantation (actually, it is not a diffusion...)

◼ Ions are launched into the silicon ◼ then, short annealing (T ~ 800 oC)

and, possibly, high T drive

◼ high T not needed (-> photoresist

as mask)

◼ better control; expensive and slow ◼ self-alignment (apart from straggle

and small diffusion)

◼ depth depends on V (and by the

drive, if present)

slide-14
SLIDE 14

Deposition of silicon (mono)

To have a single crystal: epitaxy

  • (rare: liquid phase (with melted Si ))
  • low pressure chemical vapor deposition (LPCVD),

SiH2Cl2 -> Si + 2HCl (with H2 as carrier), or SiCl4+2H2 -> Si + 4HCl or SiH4 -> Si + 2H2 possibly with PH3 o B2H6 o AsH3 to dope

  • slow (~1 mm/min) and expensive
  • T ~ 1100 oC
slide-15
SLIDE 15

Deposition of silicon (polysilicon or “poly”)

For polysilicon: CVD SiH4 -> Si + 2H2 e.g. on SiO2 used

  • normally for MOS gates (withstands larger T wrt

Al, and VT is better controlled)

  • also for resistors (instead of diffused resistors)
  • also as a layer for (short) routing

apparatus similar to the one for epitaxy

slide-16
SLIDE 16

Metallizations (1/3)

Al deposition:

  • e.g via evaporation (this is an

example of physical vapor deposition, PVD) Some % of Si in Al reduces the contact spiking (o emitter punchthrough) Some % of Cu in Al reduces electromigration Patterning:

  • normal
  • lift-off (metal on the photoresist)

On the contacts, Al dopes Si:

  • ok for Si-p
  • for Si-n, Si-n+ is needed (see

Schottky junction)

slide-17
SLIDE 17

Metallizations (2/3)

To improve lateral coverage:

  • reflow (before Al): high T, with P and B added to SiO2
  • refractory barrier metals (Mo, W (tungsten), Ti)

Deposited via sputtering (they melt at too large T for evaporation) Also reduce contact spiking (and electromigration) But have poor conductance -> sandwich with Al -> e.g.. refractory metal, and Al with Cu (Si not needed)

slide-18
SLIDE 18

Metallizations (3/3)

Silicides: Si + metal (PtSi, Pd2Si, TiSi…)

  • good ohmic contacts, or Shottky diodes; moreover
  • low resistivity -> for low resistivity poly (clad poly), e. g.

for high speed MOS Ex of final sandwich: PtSi + refractory + Al with Cu

◼ Also poly layers are often called “metallizations”

slide-19
SLIDE 19

And then...

Between poly and metal1: multilevel oxide (MLO), with contact openings between metal1 and Si or Poly Between the various metals: interlevel oxide (ILO), with vias between the various metals Above all: protective overcoat (PO), or overglass, tipically Si3N4 (more resistent than SiO2), with openings for the pads

slide-20
SLIDE 20

Assembly and testing

Often made in another facility (easy step -> e.g. in the far east) Process control structures: transistors, R, C, contacts… Test dice: variants of the IC, or to test subcircuits… Test (wafer probing):

  • f the wafer
  • f each IC (t ~ s; yield ~ 80%)
slide-21
SLIDE 21

Assembly…

Then

  • cut
  • mounting on the leadframe (also for thermal exchange)
  • epoxy resin
  • soldering (also to have a substrate contact)
slide-22
SLIDE 22

Assembly…

Bonding (from bondpads to leadfingers)

  • Normally, 1 mil

gold wire and ball bonding

  • for Al: wedge

bonding (similar, but the wire is snapped)

  • 10 per second!
slide-23
SLIDE 23

Assembly…

An IC with many leads...

slide-24
SLIDE 24

Assembly…

An IC with many leads...

slide-25
SLIDE 25

Assembly…

An IC with many leads...

slide-26
SLIDE 26

Packaging

In plastic (normally injected from the bottom)…

slide-27
SLIDE 27

Packaging

In plastic (normally injected from the bottom)…

slide-28
SLIDE 28

Packaging

... or ceramic…

slide-29
SLIDE 29

Finally…

◼ further tests ◼ final packaging (tubes, reels…)
