eGATE Smart Building Innovation

Sensor network technology based (IoT) condition monitoring and analysis of condition data for higher quality conditions

• n construction sites and completed

buildings.

Background

• Utilizing sensor network technology (IoT) in business

development

• Years of experience of the key personnel as a

subcontractor in managing construction site conditions and the utilization of digitalization to develop value chains and business processes

• How to produce added value to your customers in

construction projects and in the life cycle management of completed buildings?

• From a construction project to an end-user-focused

and administrator-focused maintenance of a completed property

Background in Brief

• Business Finland project part 1 (2015-2016)
• Business Finland project part 2 (2016-2020)
• eGate service production-ready: 1/2018
• 12/2018 Establishment of eGate Smart Building

Innovation Oy

• Internationalization: 2019à

Building Life Cycle Condition Monitoring

• Wireless sensors and measuring devices measuring

multiple variables integrated into a cloud-based platform

• Conditions of structures and air
• E.g. air temperature and relative humidity, carbon

dioxide concentration, particles, VOC, concrete moisture/temperature, structure RH-T, differential pressure

• Wireless, reliable, accurate

Measuring Device Configurations (situation in 5/2019)

• Concrete coating capability:
• RH-T
• Measurements from structures:
• RH-T
• Measurements from air:
• RH-T
• RH-T-CO2
• RH-T-TVOC
• RH-T-DUST PM 0.35-40
• DP

eGate Measuring Device Features

• 100% wireless (no coverage problems)
• Used by, i.e., all major building constructors
• Real-time (10-15 min transfer interval)
• Extremely accurate
• Cloud-based service (SaaS)
• Made in Finland
• The number of measured variables increases

constantly, i.e. according to customer needs (Radon, brightness, noise…)

Transparent and Accessible Information for Different Stakeholders

• Cloud-based service automatically generates visualizations and "monitoring

desktops" on customer data

• The service enables transparency and efficient utilization of data on the conditions
• f the contractors, building constructors, operators monitoring/assuring the

conditions, and ultimately the end-users of the buildings

• Intuitive and easy to use
• API Strategy: Data can be transferred to another platform, for example, as part of a

building automation system or other existing service/platform.

Terminal Independent and in Real-time

• Real-time data transfer
• Reporting feature
• All data is retained, and can be retrieved, stored

and printed for any period of time for any site or measurement point at any time

• All data can be imported to, e.g., Excel, as PDF…
• Also accessible with mobile devices
• E.g. on site foreman's smart phone, supervisor's

monitors, or info screens on construction site / schools / office buildings / temporary facilities

Versatile Visualizations and Reporting Options to Perceive the Situation

Pilot case, Cast Sensing

• RH-T sensing at site x at a real construction site
• On-site testing has demonstrated the functionality:

compared to a standard measurement method (Vaisala), the difference in the results was approximately 1.0-1.5 percentage points.

• The sensors were in the same holes during the testing >

2 months without any problems. The data remains reliable.

• Easy to monitor the coating capability situation -> ease
• f work management, work planning more efficient
• Reduces "site" visits, eliminates the need for drilling,
• Waiting time is reduced or completely eliminated ->

cost effectiveness -> better margin

SaaS Service Model

• The service cost for the customer consists of: Device purchase price + license costs +
• ther services (e.g. potential installation)
• eGate license
• Customer's own database for storing data of their sites
• Sensors/measuring devices with a 2 year warranty
• Service level is defined in the contract
• eGate Smart Building Innovation Oy continuously develops the service in cooperation

with key partners.

Measuring vs. Big Data: Current Situation

• Covering current measurement needs wirelessly, accurately, in-real time, transparently

(new construction, repair construction, life cycle projects..)

• Comparable and high-quality data stored in one place transparently and accessible to all

parties

• Better quality of construction
• Monitoring the conditions of completed buildings and early intervention, transparency

Measuring vs. Big Data: The Future!

• The data collected during the entire life cycle of the building must be achievable, further

process able and analyzable in order to develop the processes, quality and business

• perations.
• Development of construction processes based on data: From design to implementation.
• Condition data as part of Smart City projects / data models (BIM)
• Condition data to contribute to the control of building automation systems
• Data mining / research as an integral part of the organization's operations
• = SUPERIOR COMPETITIVE EDGE!

References - CRAMO

Cramo Finland's Condition Monitoring Project Manager Mika Aalto says, that the solutions and devices for protection against moisture, drying and heating exist. Cramo's condition management service is now packed into

• ne single entity.

References - KOTKA HOSPITAL

Cramo's condition monitoring expert, Project Manager Mika Aalto says, that real-time measurement accurately describes how drying progresses and when the structures are close to being ready for coating. Janita Ojala, Skanska Talonrakennus Oy's Trainee Supervisor, also considers the eGate system useful. Se actively monitors the results on a daily basis. “The screen tells you immediately if the concrete is not drying or if the temperatures are

• low. This way we can, for example, adjust heaters to quickly generate more heat.”

References - YIT RAKENNUS and CRAMO

Moisture management, weather protection and indoor air quality were managed by utilizing the Cramo Dry Chain10 (Kuivaketju 10) entity at an expansion site of YIT Rakennus Oy in Jyväskylä. In the picture: Account Manager Anne Forsman of Cramo and Juha Mäkelä of YIT Rakennus Oy.

References - SRV CENTRAL FINLAND HOSPITAL

eGate condition monitoring aboard in the SRV Central Finland Hospital Nova project SRV has deployed the eGate Smart Building Innovation service in the Central Finland Hospital Nova project. The aim is to measure the relative humidity and temperature of the building in different sections of the construction site during the construction phase.

Abbreviations and Concepts

• T = Temperature
• RH= Relative humidity
• CO2 = Carbon dioxide
• DP = Differential pressure
• DUST PM 0.35-40 = dust particles
• The sensor measures, and the application calculates the quantity of particles of 0.35-40 micrometers
• Quantity per cubic meter of air or micrograms per m3 of air.
• Particles are, for example, small emissions of traffic, etc. (the most harmful to humans because they are partly

emanated to the alveolus, bloodstream, etc.)

• VOC = Volatile organic compounds
• Smog factor, as they react with nitrogen oxides in the presence of sunlight, thus forming troposphere ozone
• Ozone in the troposphere is harmful to humans, animals and vegetation
• TVOC = total voc concentration
• Does not specify what and how much, but how much volatile organic compounds are in the air
• TVOC = total voc concentration

eGate Smart Building Innovation Oy Key Personnel

eGate Smart Building Innovation Oy

JARKKO HAUKIJÄRVI CEO, Partner, Board Member

I have been an entrepreneur and an employer since 2002. Between 2002 and 2008, I was involved in manufacturing business when I was involved in the founding and development of Finnish Water Group Oy (currently Polar Spring Oy). Since 2006, I have been involved in the service business developing services related to the building purity management during construction and use and P1 consulting. Since 2015, I have focused heavily on the eGate project, aiming in creating a service that helps to achieve and maintain a good and high-quality conditions in the building throughout its life cycle. Founding of eGate Smart Building Innovation Oy and the fact that the company was able to acquire top-notch key personnel, provide the best possible prerequisite for the success of the project.

eGate Smart Building Innovation Oy

MARKKU MOISIO Partner, Board Chairman

I have worked in various management positions in Kesko Oy in the 80's and in Polar Group in the 90's. From 1995 to 2001, I was the CEO of Pirkan OP-Kiinteistökeskus. After that, I transferred as the Vice CEO of Rakennustoimisto Palmberg Oy and later to the CEO and Management Team member of Lemminkäinen Talo Oy. Since 2011, I have worked in Akkumo Oy as an entrepreneur and an investor, and as a professional board member in several companies. I have extensive knowledge and experience in the fields of wholesale, construction, real estate and business development. I hold a Master of Economic Sciences degree.

eGate Smart Building Innovation Oy

PAULI MÄKELÄ Partner, Board Member

I have made my working career in Lemminkäinen Group in various

• positions. Since 2014, I ran the building construction segment of

Lemminkäinen. Lemminkäinen and YIT merged at the end of January 2018 and I was involved in supporting the merger until the end of September

• 2018. Now I am retired.

I got the opportunity to become an eGate partner. eGate represents high- quality measurement technology and data transfer for monitoring indoor

• conditions. I want to witness eGate's services find their way to

responsible construction builders and property owners.

eGate Smart Building Innovation Oy

PIRKKA LÄHTEINEN Partner, Board Member

I am the Regional Manager of Consti Korjausurakointi Oy in the capital region. I have worked with repair construction my entire career.

eGate Smart Building Innovation Oy

LARI MAASALO Partner, Board Member

I work full time in Nokeval Oy, where I have worked for more than 16 years in various product development positions. My job has included both hardware and software design, as well as sales and administrative tasks. For the recent years, I have led the change of the company from a device manufacturer into a service house and a multi-expert offering product development services. Since 2016, I have been developing a hardware and service entity for condition measuring together with eGate. I will continue this work now in eGate.

eGate Smart Building Innovation Oy

JANI VÄHÄSÖYRINKI Partner, Board Member

I have been designing IoT-measuring devices already in the early 2000's after I graduated as an electronics engineer, and continued to study automation and measuring technology in TTY's Master of Science

• programme. I started my career with wireless devices in Abb Corporate

Research, from where I continued through the Air Force Signaler School and the Reserve Officer Training Corps to Nokeval to design measuring

• devices. My career with Nokeval has lasted for over ten years and

nowadays I am the CEO of Nokeval Oy. Measurement techniques and knowledge management have always been close to my heart, and the eGate concept makes me believe that through the life cycle-long monitoring of buildings we get better indoor air for us Finns as well as the entire Europe.

eGate Smart Building Innovation Oy

ILKKA HAUKIJÄRVI Partner

I have 10 years of experience in the digitization change in different key

• roles. My latest position held was a Project Development Manager

responsible for business development portfolio entity and project management in the most extensive reform of Finnish higher education, Tampere-3 project, as well as the Lead Expert of innovation culture development of Tampere University.

Contact

Jarkko Haukijärvi, MBA CEO eGate Smart Building Innovation Oy +358 44-5833410 jarkko.haukijarvi@e-gate.fi www.e-gate.fi fi.linkedin.com/in/jarkkohaukijarvi/
