SLIDE 1

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 1

EE E6820: Speech & Audio Processing & Recognition

Lecture 8: Spatial sound

Spatial acoustics Binaural perception Synthesizing spatial audio Extracting spatial sounds

Dan Ellis <dpwe@ee.columbia.edu> http://www.ee.columbia.edu/~dpwe/e6820/

1 2 3 4

SLIDE 2

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 2

Spatial acoustics

Received sound = source +

channel

so far, only considered ideal source waveform
Sound carries information on its spatial origin
e.g. “ripples in the lake”
great evolutionary significance
The basis of scene analysis?
yes and no - try blocking an ear

1

SLIDE 3

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 3

Ripples in the lake

Effect of relative position on sound
delay =

∆ r/c

energy decay ~ 1/r

2

absorption ~ G(f)

r

direct energy plus reflections
Give cues for recovering source position
Describe wavefront by its normal

Source Source Listener Wavefront (@ c m/s) Energy ∝ 1/r2

SLIDE 4

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 4

Recovering spatial information

Source

direction as wavefront normal

moving plane found from timing at 3 points
need to solve

correspondence

Space: need 3

parameters

e.g. 2 angles and range

wavefront A B C

time pressure ∆t/c = ∆s = AB·cosθ θ range r azimuth θ elevation φ

SLIDE 5

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 5

The effect of the environment

Reflection causes additional wavefronts
+ scattering, absorption
many paths

→ many echoes

Reverberant

effect

causal ‘smearing’ of signal energy

reflection diffraction & shadowing

time / sec freq / Hz time / sec freq / Hz 0.5 1 1.5 2000 4000 6000 8000 0.5 1 1.5 2000 4000 6000 8000 Dry speech airvib16 + reverb from hlwy16

SLIDE 6

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 6

Reverberation impulse response

Exponential decay of reflections:
Frequency-dependent
greater absorption at high frequencies

→ faster decay

Size-dependent
larger rooms

→ longer delays → slower decay

Sabine’s equation:
Time constant as size, absorption

t hroom(t) ~e-t/T

time / s freq / Hz

hlwy16 - 128pt window

0.1 0.2 0.3 0.4 0.5 0.6 0.7 2000 4000 6000 8000

70
60
50
40
30
20
10

RT60 0.049V Sα

=

SLIDE 7

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 7

Outline

Spatial acoustics Binaural perception

The sound at the two ears
Available cues
Perceptual phenomena

Synthesizing spatial audio Extracting spatial sounds 1 2 3 4

SLIDE 8

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 8

Binaural perception

What is the information in the 2 ear signals?
the

sound

f the source(s) (L+R)
the

position

f the source(s) (L-R)
Example waveforms (ShATR database)

2

path length difference path length difference head shadow (high freq) source L R

2.2 2.205 2.21 2.215 2.22 2.225 2.23 2.235

0.1
0.05

0.05 0.1 time / s shatr78m3 waveform Left Right

SLIDE 9

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 9

Main cues to spatial hearing

Interaural time difference (ITD)
from different path lengths around head
dominates in low frequency (< 1.5 kHz)
max ~ 750

µ s → ambiguous for freqs > 600 Hz

Interaural intensity difference (IID)
from head shadowing of far ear
negligable for LF; increases with frequency
Spectral detail (from pinna relfections)

useful for elevation & range

Direct-to-reverberant useful for range

SLIDE 10

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 10

Head-Related Transfer Fns (HRTFs)

Capture source coupling as impulse responses
Collection: (

http://phosphor.cipic.ucdavis.edu/ )

Highly individual!

lθ φ R

, ,

t ( ) rθ φ R

, ,

t ( ) , { }

0.5 1 1.5

45

45 0.5 1 1.5 1 0.5 1 1.5

1

1

time / ms time / ms HRIR_021 Left @ 0 el HRIR_021 Left @ 0 el 0 az HRIR_021 Right @ 0 el 0 az HRIR_021 Right @ 0 el

LEFT RIGHT Azimuth / deg

SLIDE 11

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 11

Cone of confusion

Interaural timing cue dominates (below 1kHz)
from differing path lengths to two ears
But: only resolves to a cone
Up/down? Front/back?

azimuth θ

Cone of confusion (approx equal ITD)

SLIDE 12

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 12

Further cues

Pinna

causes elevation-dependent coloration

Monaural perception
separate coloration from source spectrum?
Head motion
synchronized spectral changes
also for ITD (front/back) etc.

SLIDE 13

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 13

Combining multiple cues

Both ITD and ILD influence azimuth;

What happens when they disagree?

trading @ around 0.1 ms / dB

t t r(t) 1 ms l(t) t t r(t) l(t)

Identical signals to both ears → image is centered Delaying right channel moves image to left

t t r(t) l(t)

Attenuating left channel returns image to center

SLIDE 14

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 14

Binaural position estimation

Imperfect results: (Arruda, Kistler & Wightman 1992)
listening to ‘wrong’ hrtfs → errors
front/back reversals stay on cone of confusion
180
120
60

60 120 180

Target Azimuth (Deg)

180
120
60

60 120 180

Judged Azimuth (Deg)

SLIDE 15

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 15

The Precedence Effect

Reflections give misleading spatial cues
But: Spatial impression based on 1st wavefront

then ‘switches off’ for ~50 ms

.. even if ‘reflections’ are louder
.. leads to impression of room

t l(t) t R/c

R

r(t) direct reflected

SLIDE 16

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 16

Binaural Masking Release

Adding noise to reveal target
why does this make sense?
Binaural Masking Level Difference up to 12dB
greatest for noise in phase, tone anti-phase

t t

Tone + noise to one ear: tone is masked +

t t

Identical noise to other ear: tone is audible

t

+

SLIDE 17

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 17

Outline

Spatial acoustics Binaural perception Synthesizing spatial audio

Position
Environment

Extracting spatial sounds 1 2 3 4

SLIDE 18

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 18

Synthesizing spatial audio

Goal: recreate realistic soundfield
hi-fi experience
synthetic environments (VR)
Constraints
resources
information (individual HRTFs)
delivery mechanism (headphones)
Source material types
live recordings (actual soundfields)
synthetic (studio mixing, virtual environments)

3

SLIDE 19

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 19

Classic stereo

‘Intensity panning’:

no timing modifications, just vary level ±20 dB

works as long as listener is equidistant
Surround sound:

extra channels in center, sides, ...

same basic effect - pan between pairs

L R

SLIDE 20

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 20

Simulating reverberation

Can characterize reverb by impulse response
spatial cues are important - record in stereo
IRs of ~ 1 sec → very long convolution
Image model: reflections as duplicate sources
‘Early echos’ in room impulse response:
Actual reflection may be href(t), not δ(t)

source listener virtual (image) sources reflected path t hroom(t) direct path early echos

SLIDE 21

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 21

Artificial reverberation

Reproduce perceptually salient aspects
early echo pattern (→ room size impression)
overall decay tail (→ wall materials...)
interaural coherence (→ spaciousness)
Nested allpass filters (Gardner ’92)

z-k + +

g

g g,k x[n] y[n] n

k 2k 3k

g

1-g2 g(1-g2) g2(1-g2)

h[n] z-k - g 1 - g·z-k H(z) = 20,0.3

Allpass Nested+Cascade Allpass Synthetic Reverb

30,0.7 50,0.5 AP0 + AP1 AP2 LPF g a0 a1 a2 + +

SLIDE 22

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 22

Synthetic binaural audio

Source convolved with {L,R} HRTFs gives

precise positioning

...for headphone presentation
can combine multiple sources (by adding)
Where to get HRTFs?
measured set, but: specific to individual, discrete
interpolate by linear crossfade, PCA basis set
or: parametric model - delay, shadow, pinna
Head motion cues?
head tracking + fast updates

Source Delay Shadow Pinna z-tDL(θ) 1 - azt 1 - bL(θ)z-1 z-tDR(θ) 1 - azt 1 - bR(θ)z-1

Σ pkL(θ,φ)·z-tPkL(θ,φ) Σ pkR(θ,φ)·z-tPkR(θ,φ)

Room echo KE·z-tE

+ +

(after Brown & Duda '97)

SLIDE 23

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 23

Transaural sound

Binaural signals without headphones?
Can cross-cancel wrap-around signals
speakers SL,R, ears EL,R, binaural signals BL,R.
Narrow ‘sweet spot’
head motion?

SL HLL

1 –

BL HRLSR – ( ) = SR HRR

1 –

BR HLRSL – ( ) =

EL ER HRR HRL HLR HLL SL BL SR BR M

SLIDE 24

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 24

Soundfield reconstruction

Stop thinking about ears

just reconstruct pressure + spatial derivatives

ears in reconstructed field receive same sounds
Complex reconstruction setup (ambisonics)
able to preserve head motion cues?

p(x,y,z,t) ∂p(t)/∂z ∂p(t)/∂x ∂p(t)/∂y

SLIDE 25

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 25

Outline

Spatial acoustics Binaural perception Synthesizing spatial audio Extracting spatial sounds

Microphone arrays
Modeling binaural processing

1 2 3 4

SLIDE 26

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 26

Extracting spatial sounds

Given access to soundfield, can we recover

separate components?

degrees of freedom:

>N signals from N sensors is hard

but: people can do it (somewhat)
Information-theoretic approach
use only very general constraints
rely on precision measurements
Anthropic approach
examine human perception
attempt to use same information

4

SLIDE 27

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 27

Microphone arrays

Signals from multiple microphones can be

combined to enhance/cancel certain sources

‘Coincident’ mics with diff. directional gains
Microphone arrays (endfire)

m1 s1 m2 s2 a21 a22 a12 a11

m1 m2 a11 a12 a21 a22 s1 s2 ⋅ = s1 ˆ s2 ˆ ⇒ A 1

–

m ⋅ =

D D + D + +

40
20

λ = 4D λ = 2D λ = D

SLIDE 28

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 28

Adaptive Beamforming & Independent Component Analysis (ICA)

Formulate mathematical criteria to optimize
Beamforming: Drive interference to zero
cancel energy during nontarget intervals
ICA: maximize mutual independence of outputs
from higher-order moments during overlap
Limited by separation model parameter space
only NxN?

m1 m2 s1 s2 a11 a21 a12 a22

x

−δ MutInfo δa

SLIDE 29

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 29

Binaural models

Human listeners do better?
certainly given only 2 channels
Extract ITD and IID cues?
cross-correlation finds timing differences
‘consume’ counter-moving pulses
how to achieve IID, trading
vertical cues...
6
4
2

2 4 6 lag / ms 100 200 400 800 1600 3200 Center freq / Hz

Interaural cross-correlation Target azimuth

SLIDE 30

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 30

Nonlinear filtering

How to separate sounds based on direction?
estimate direction locally
choose target direction
remove energy from other directions
E.g. Kollmeier, Peissig & Hohman ’93
IID from |Lw|/|Rw|; ITD (IPD) from arg{LwRw

*}

match to IID/IPD template for desired direction
also reverberation?

time frequency

Xw(mH,2 πk/NT)

FFT analysis Modulus l L w |L w| 2 FFT analysis r R w Modulus |R w| 2 Cross- correlation LwR*w Smooth (1-a) (1-az-1) SLL Smooth (1-a) (1-az-1) Smooth (1-a) (1-az-1) SLR SRR Gain factor calc l' OLA- FFT synthesis r' OLA- FFT synthesis

g

SLIDE 31

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 31

Summary

Spatial sound
sampling at more than one point gives

information on origin direction

Binaural perception
time & intensity cues used between/within ears
Sound rendering
conventional stereo
HRTF-based
Spatial analysis
optimal linear techniques
elusive auditory models

SLIDE 32

E6820 SAPR - Dan Ellis L08 - Spatilal sound 2002-04-01 - 32

References

B.C.J. Moore, An introduction to the psychology of hearing (4th ed.) Academic, 1997.

J. Blauert, Spatial Hearing (revised ed.), MIT Press, 1996.
