EE E6820: Speech & Audio Processing & Recognition

Lecture 4: Auditory Perception

Motivation: Why & how Auditory physiology Psychophysics: detection & discrimination Pitch perception Auditory organization & scene analysis Speech perception

Dan Ellis <dpwe@ee.columbia.edu> http://www.ee.columbia.edu/~dpwe/e6820/

1 2 3 4 5 6

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 2

Why study perception?

• Perception is messy: Can we avoid it?

No!

• Audition provides the ‘ground truth’ in audio
• what is relevant and irrelevant
• subjective importance of distortion (coding etc.)
• (there could be other information in sound...)
• Some sounds are ‘designed’ for audition
• co-evolution of speech and hearing
• The auditory system is very successful
• we would do extremely well to duplicate it
• We are now able to model complex systems
• faster computers, bigger memories

1

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 3

How to study perception?

Three different approaches:

• Analyze the example: physiology
• dissection & nerve recordings
• Black box input/output: psychophysics
• fit simple models of simple functions
• Information processing models
• investigate and model complex functions
• e.g. scene analysis, speech perception

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 4

Outline

Motivation Physiology

• Outer, middle & inner ear
• The Auditory Nerve and beyond
• Models

Psychophysics Pitch perception Scene analysis Speech perception 1 2 3 4 5 6

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 5

Physiology

• Processing chain from air to brain:
• Study via:
• anatomy
• nerve recordings
• Signals flow in both directions

2

Outer ear Middle ear Inner ear Auditory nerve Midbrain Cortex

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 6

Outer & middle ear

• Pinna ‘horn’
• complex reflections give spatial (elevation) cues
• Ear canal
• acoustic tube
• Middle ear
• bones provide impedance matching

Pinna Ear canal Eardrum (tympanum) Middle ear bones

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 7

Inner ear: Cochlea

• Mechanical input from middle ear starts

traveling wave moving down Basilar Membrane

• Varying stiffness and mass of BM gives results

in continuous variation of resonant frequency

• At resonance, traveling wave energy is

dissipated in BM movement → Frequency (Fourier) analysis

Cochlea Oval window (from ME bones) Basilar Membrane (BM) Travelling wave Resonant frequency Position

16 kHz 50 Hz 35mm

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 8

Cochlea hair cells

• Ear converts sound in BM motion;

Each point on BM corresponds to a frequency

• Hair cells on BM convert motion into nerve

impulses (firings)

• Inner Hair Cells detect motion
• Outer Hair Cells? Variable damping?

[Allen simulation] Cochlea Basilar membrane Tectorial membrane Inner Hair Cell (IHC) Outer Hair Cell (OHC) Auditory nerve

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 9

Inner Hair Cells

• IHCs convert BM motion into nerve firings
• Human hear has ~3500 IHCs;

Each IHC has ~7 connections to Auditory Nerve

• Each nerve fires (sometimes) near peak

displacement:

• Histogram to get firing probability:

Local BM displacement Typical nerve signal (mV) time / ms

50

Firing count Cycle angle

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 10

Auditory nerve (AN) signals

• Single nerve measurements:
• Hard to measure: probe living ANs

(log) frequency 100 Hz 1 kHz 10 kHz 20 40 60 80 dB SPL

Tone burst histogram Frequency threshold

Spike count Time

100 100 ms

Tone burst

Spikes/sec Intensity / dB SPL 300 200 100 20 40 60 80 100 One fiber: ~ 25 dB dynamic range Hearing dynamic range > 100 dB

Rate vs. intensity (approx. constant-Q)

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 11

AN population response

• All the information the brain has about sound:
• average rate & spike timings on 30,000 fibers
• Not unlike a (constant-Q) spectrogram?

time / ms freq / 8ve re 100 Hz ( ) 1 2 3 4 5 10 20 30 40 50 60

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 12

Beyond the auditory nerve

• Ascending

and descending

• Tonotopic x ?
• modulation - position - source??

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 13

Periphery models

• Modeled aspects:
• outer/middle ear
• cochlea filtering
• hair cell transduction
• efferent feedback?
• Result: ‘neurogram’ / ‘cochleagram’

Outer/middle ear filtering Sound Cochlea filterbank IHC IHC

time / s channel SlaneyPatterson 12 chans/oct from 180 Hz, BBC1tmp (20010218) 0.1 0.2 0.3 0.4 0.5 10 20 30 40 50 60

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 14

Outline

Motivation Physiology Psychophysics

• Detection theory modeling
• Intensity perception
• Masking

Pitch perception Scene analysis Speech perception 1 2 3 4 5 6

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 15

Psychophysics

• Physiology

looks at the implementation; Psychology looks at the function/behavior

• Analyze audition as

signal detection :

• psychological tests reflect internal decisions
• assume optimal decision process
• infer nature of internal representations, noise, ...

→ lower bounds on more complex functions

• Different aspects to measure
• time, frequency, intensity
• tones, complexes, noise
• binaural
• pitch, detuning

3

p ω O ( )

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 16

Basic psychophysics

• Relate

physical and perceptual variables

• e.g. intensity

→ loudness frequency → pitch

• Methodology: subject tests
• just noticeable difference (jnd)
• magnitude scaling e.g. ‘adjust to twice as loud’
• Results for Loudness vs. Intensity:

Weber’s law

∆I α I → log(L) = k·log(I)

• 20
• 10

10 1.4 1.6 1.8 2.0 2.2 2.4 2.6 Sound level / dB Log(loudness rating) Hartmann(1993) Classroom loudness scaling data Power law fit:

L α I 0.22

Textbook figure:

L α I 0.3

L ( )

2

log 0.3 I ( )

2

log = 0.3 I

10

log 2

10

log

• ⋅

= 0.3 2

10

log

• dB

10

• ⋅

= dB 10 ⁄ =

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 17

Loudness as a function of frequency

• Fletcher-Munson equal-loudness curves:
• Hearing impairment: exaggerates

freq / Hz Intensity / dB SPL

40 20 60 100 80 120 1000 100 10,000

Intensity / dB Equivalent loudness @ 1kHz 40 40 80 80 100 60 20 20 60 20 60 100 60 20 Intensity / dB Equivalent loudness @ 1kHz 40 40 80 80

rapid loudness growth

100 Hz 1 kHz

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 18

Loudness as a function of bandwidth

• Same total energy, different distribution:
• e.g. 2 chans at -6 dB (not -10 dB)
• Critical bands: independent freq. channels
• ~ 25 total (4-6 / octave) [sndex]

time freq

freq mag freq mag

Same total energy I·B ... but wider perceived as louder I0 I1 B0 B1

Bandwidth B

‘Critical’ bandwidth

Loudness

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 19

Simultaneous masking

• A louder tone can ‘mask’ the perception of a

second tone nearby in frequency:

• Suggests an ‘internal noise’ model:

masked threshold

log freq

absolute threshold masking tone

Intensity / dB

decision variable

x

internal noise p(x | I)

p(x | I) p(x | I+∆I) σn I

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 20

Sequential masking

• Backward/forward in time:
• suggests temporal envelope of decision var.

→ Time-frequency masking ‘skirt’:

time Intensity / dB masker envelope masked threshold simultaneous masking ~10 dB backward masking ~5 ms forward masking ~100 ms

time freq intensity Masking tone Masked threshold

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 21

What we do and don’t hear

• Timing: 2ms attack resolution, 20ms discrim
• but: spectral splatter
• Tuning: ~ 1% discrimination
• but: beats
• Spectrum: profile changes, formants
• variable time-frequency resolution
• Harmonic phase
• Noisy signals & texture
• (Trace vs. categorical memory)

A B X X = A or B? “two-interval forced-choice”:

time

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 22

Outline

Motivation Physiology Psychophysics Pitch perception

• ‘Place’ models
• ‘Time’ models
• Multiple cues & competition

Scene analysis Speech perception 1 2 3 4 5 6

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 23

Pitch perception: A classic argument in psychophysics

• Harmonic complexes are a pattern on AN
• .. but give a fused percept (ecological)
• What determines the pitch percept?
• not the fundamental
• How is it computed?

Two competing models: place and time

4

10 20 30 40 50 60 70 0.05 0.1 time/s

• freq. chan.

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 24

Place model of pitch

• AN excitation pattern shows individual peaks
• ‘Pattern matching’ method to find pitch:
• Support:

Low harmonics are very important

• But: Flat-spectrum noise can carry pitch

frequency channel frequency channel AN excitation

Pitch strength resolved harmonics broader HF channels cannot resolve harmonics Correlate with harmonic ‘sieve’:

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 25

Time model of pitch

• Timing information is preserved in AN

up to ~ 1ms scale

• Extract periodicity by e.g. autocorrelation

& combine across frequency chans:

• But: HF channels give weak pitch

lag / ms time freq per-channel autocorrelation autocorrelation Summary autocorrelation 10 20 30

common period (pitch)

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 26

Alternate & competing cues

• Pitch perception could rely on various cues
• average excitation pattern
• summary autocorrelation
• more complex pattern matching
• Relying on just one cue is brittle
• e.g. missing fundamental

→ Perceptual system appears to use a flexible,

• pportunistic combination
• Optimal detector justification?

if o1 and o2 are conditionally independent

p ω o ( ) ω argmax p o ω ( ) p ω ( ) ⋅ p o ( )

• ω

argmax = p o1 ω ( ) p o2 ω ( ) p ω ( ) ⋅ ⋅ ω argmax =

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 27

Outline

Motivation Physiology Psychophysics Pitch perception Scene analysis

• Events and sources
• Fusion and streaming
• Continuity & restoration

Speech perception 1 2 3 4 5 6

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 28

Auditory Organization

• Detection model is huge simplification
• Real role of hearing is much more general:

Recover useful information from outside world → Sound organization into events and sources:

• Research questions:
• what determines perception of sources?
• how do humans separate mixtures?
• how much can we tell about a source?

5

2 4 time/s frq/Hz 2000 4000

Voice Stab Rumble

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 29

Auditory scene analysis: Simultaneous fusion

• Harmonics are distinct on AN,

but perceived as one sound (“fused”):

• depends on common onset
• depends on harmonicity (common period)
• Methodologies:
• ask subject how many ‘objects’
• match attributes e.g. object pitch
• manipulate higher level e.g. vowel identity

time freq

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 30

Sequential grouping: streaming

• Pattern / rhythm: property of set of objects
• subsequent to fusion

employs fused events?

• Measure by relative timing judgments
• cannot compare between streams
• Separate ‘coherence’ and ‘fusion’ boundaries
• Can interact and compete with fusion

[sndex]

∴

–2 octaves TRT: 60-150 ms

time frequency

∆f:

1 kHz

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 31

Continuity & restoration

• Tone is interrupted by noise burst:

What happened?

• masking makes tone undetectable during noise
• Need to infer most probable real-world events
• observation equally likely for either explanation
• prior on continuous tone much higher → choose
• Top-down influence on perceived events...

pulsation threshold [sndex]

time freq + + +

?

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 32

Models of auditory organization

• Psychological accounts suggest bottom-up:
• (Brown 1991)
• Complications in practice:
• formation of separate elements
• contradictory cues
• influence of top-down constraints (context,

expectations) ...

input mixture signal features (maps) discrete

• bjects

Front end Object formation Grouping rules Source groups

• nset

period frq.mod time freq

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 33

Outline

Motivation Physiology Psychophysics Pitch perception Scene analysis Speech perception

• The sounds of speech
• Phoneme perception
• Context and top-down influences
• Simultaneous vowels

1 2 3 4 5 5

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 34

Speech perception

• Highly specialized function
• subsequent to source organization?
• .. but also can interact
• Kinds of speech sounds:
• vowels
• glides
• nasals
• stops
• fricatives

...

6

20 30 40 50 60 1.4 1.6 1.8 2 2.2 2.4 2.6

time/s level/dB freq / Hz

1000 2000 3000 4000

watch thin as a dime a has

stop burst fricative vowel nasal glide

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 35

Cues to phoneme perception

• Linguists describe speech with phonemes:
• phonemes define minimal word contrasts
• Acoustic-phoneticians describe phonemes by:

watch thin as a dime a has

m d n c tcl

^

θ z w z h e

I I I

a

y

ε

• formants

& transitions

• bursts

& onset times

time freq

vowel formants transition stop burst voicing onset time

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 36

Categorical perception

• (Some) speech sounds perceived categorically

rather than analogically

• e.g. stop-burst & timing:
• tokens within category are hard to distinguish
• category boundaries are very sharp
• Categories are learned for native tongue
• “merry” / “mary” / “marry”

T P K P P i e a c

• u

ε

following vowel burst freq fb / Hz 1000 2000 3000 4000 time freq stop burst vowel formants fb

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 37

Where is the information in speech?

• ‘Articulation’ of high/low-pass filtered speech:
• sums to more than 1...
• Speech message is highly redundant
• e.g. constraints of language, context

→listeners can understand with very few cues

Articulation / % 1000 20 40 60 80 2000 3000 4000 freq / Hz

high-pass low-pass

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 38

Top-down influences: Phonemic restoration

(Warren 1970)

• What if a noise burst obscures speech?
• auditory system ‘restores’ the missing phoneme

... based on semantic context ... even in retrospect!

• Subjects are typically unaware of which

sounds are restored

1.4 1.6 1.8 2 2.2 2.4 2.6 time / s freq / Hz 1000 2000 3000 4000

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 39

A predisposition for speech: Sinewave replicas

(Remez et al. 1994)

• Replace each formant with a single sinusoid:
• speech is (somewhat) intelligible
• people hear both whistles and speech (“duplex”)
• processed as speech despite un-speech-like
• What does it take to be speech?

1000 2000 3000 4000 5000 0.5 1 1.5 2 2.5 3 1000 2000 3000 4000 5000 time / s freq / Hz freq / Hz

Speech Sines

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 40

Simultaneous vowels

• Mix synthetic vowels with different f0s:
• Pitch difference helps (though not necessary):

freq

+ =

dB

/iy/ @ 100 Hz /ah/ @ 125 Hz

% both vowels correct

∆f0 (semitones)

1

1/4 1/2

2 4 25 50 75

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 41

Computational models of speech perception

• Various theoretical - practical models of speech

comprehension, e.g. :

• Open questions:
• mechanism of phoneme classification
• mechanism of lexical recall
• mechanism of grammar constraints
• ASR is a practical implementation (?)

Phoneme recognition Lexical access Grammar constraints Speech Words

E6820 SAPR - Dan Ellis L04 - Perception 2002-02-18 - 42

Summary

• Auditory perception provides the ‘ground truth’

underlying audio processing

• Physiology specifies information available
• Psychophysics measures basic sensitivities
• Sound sources requires further organization
• Strong contextual effects in speech perception

Transduce Scene analysis Multiple represent'ns High-level recognition Sound
