Earthquake Resistant Design & Construction (Gujarat Institute of Disaster Management) (28-07-2020) by Professor APPLIED MECHANICS DEPARTMENT L D COLLEGE of ENGINEERING Ahmedabad Earthquake Engineering Practice Concept of Earthquake

slide-1
SLIDE 1

by Professor APPLIED MECHANICS DEPARTMENT L D COLLEGE of ENGINEERING Ahmedabad

Earthquake Resistant Design & Construction

(Gujarat Institute of Disaster Management) (28-07-2020)

slide-2
SLIDE 2

.

Earthquake Engineering Practice

Concept of Earthquake Resistant Design of RC structures Actual Construction Practice Construction practice - Beam, column, foundation, walls and roofs Geotechnical considerations

slide-3
SLIDE 3

– Earthquakes do not kill, unsafe buildings do – Earthquake is a manmade disaster – Solution lies in “buildings” & not in “earthquakes”

Challenge : Understanding

slide-4
SLIDE 4

2005 NPEEE Earthquake Design Concept : Lecture 1: Impact of Earthquakes 4/29

slide-5
SLIDE 5

Destruction of Human life.

slide-6
SLIDE 6
slide-7
SLIDE 7
slide-8
SLIDE 8

Structural Design

  • Life of Structures
  • Loads acting on civil engineering structures

Design Loads

  • Dead Load
  • Live Load
  • Wind Load
  • Earthquake Load
  • Many other types of loads
slide-9
SLIDE 9

Structural Design

  • Design for Gravity Loads : (DL+LL)
  • 1. Permanent load
  • 2. Factor of Safety
  • 3. No damage
  • Design for Lateral Load: (Wind + EQ)

Lateral forces create discomfort to structures

  • 1. Wind Force – frequent - No damage
  • 2. EQ Force - ??? (Max effective time 2 minutes)
slide-10
SLIDE 10

Dead Load + Live Load +Wind or EQ Load

DL + LL + WL or EQ

Earthquake Force F = mass x acceleration = ma Wind Force F = Intensity of wind x Area of Obstruction

slide-11
SLIDE 11
slide-12
SLIDE 12

Cyclone Resistant Design

  • No damage condition

Earthquake Resistant Design - ???????

slide-13
SLIDE 13

Design Philosophy for Earthquake

Which design philosophy should we follow? Earthquake Proof Design OR Earthquake Resistant Design

slide-14
SLIDE 14

Philosophy of earthquake resistant structure

slide-15
SLIDE 15

During an earthquake, lighter the building and the roof, the better is the performance of the house. Lighter roof would not induce as much load on the walls, and the walls would be able to transfer the loads easily during an earthquake. On the other hand, during a cyclone, heavier the roof, the better is the performance of the house. It would resist strong loads due to the wind pressure, hold itself and the house in place.

slide-16
SLIDE 16

Cyclone Resistant Design

  • No damage allowed

Earthquake Resistant Design

  • Damages allowed but no collapse
  • We heavily rely on ductility
slide-17
SLIDE 17

IS 13920 – 2016 – Ductile Design & Detailing

  • f RC Structures subjected to Seismic Forces

– Code of Practice Ductility is defined as the ability

  • f

a structure to undergo inelastic deformations beyond the initial yield deformation without decrease in strength & stiffness

slide-18
SLIDE 18

Elastic Response Vs Inelastic Response

slide-19
SLIDE 19

Advantages of Ductility

  • 1. Absorbs lots of energy, therefore good performance

during

  • load reversals,
  • Impact
  • secondary stresses due to differential settlement
  • f foundation.
  • 2. Enough warning by showing large deformation

before failure - loss of life is minimized

  • 3. Yielding of steel reinforcement - assumptions in the

design of reinforced concrete structures by limit state method.

slide-20
SLIDE 20

WHY IS DUCTILTY REQUIRED?

TO PREVENT BRITTLE FAILURES.

  • SHEAR FAILURE
  • BOND FAILURE
  • COMPRESSION FAILURES (OVER REINFORCED

SECTIONS)

slide-21
SLIDE 21

VARIOUS CONVETIONAL LATERAL LOAD RESISTING SYSTEMS

  • COLUMNS
  • SHEAR WALLS
  • BRACING SYSTEMS
  • MOMENT RESISTING FRAME
  • TUBES
slide-22
SLIDE 22

2005 NPEEE Earthquake Design Concept : Lecture 9: Overview

  • f EQ resistant Structural

Systems 22/23

slide-23
SLIDE 23

2005 NPEEE Earthquake Design Concept : Lecture 9: Overview

  • f EQ resistant Structural

Systems 23/23

slide-24
SLIDE 24

2005 NPEEE Earthquake Design Concept : Lecture 9: Overview

  • f EQ resistant Structural

Systems 24/23

slide-25
SLIDE 25

2005 NPEEE Earthquake Design Concept : Lecture 9: Overview

  • f EQ resistant Structural

Systems 25/23

slide-26
SLIDE 26

2005 NPEEE Earthquake Design Concept : Lecture 9: Overview

  • f EQ resistant Structural

Systems 26/23

slide-27
SLIDE 27

2005 NPEEE Earthquake Design Concept : Lecture 9: Overview

  • f EQ resistant Structural

Systems 27/23

slide-28
SLIDE 28

2005 NPEEE Earthquake Design Concept : Lecture 9: Overview

  • f EQ resistant Structural

Systems 28/23

slide-29
SLIDE 29

2005 NPEEE Earthquake Design Concept : Lecture 9: Overview

  • f EQ resistant Structural

Systems 29/23

slide-30
SLIDE 30

2005 NPEEE Earthquake Design Concept : Lecture 9: Overview

  • f EQ resistant Structural

Systems 30/23

slide-31
SLIDE 31

2005 NPEEE Earthquake Design Concept : Lecture 9: Overview

  • f EQ resistant Structural

Systems 31/23

slide-32
SLIDE 32

Learning from failures DEFICIENCIES IN BUILDINGS

  • LOCAL DEFICIENCIES
  • GLOBAL DEFICIENCIES
slide-33
SLIDE 33

LOCAL DEFICIENCIES IN BUILDINGS Failures of Flexural Members

slide-34
SLIDE 34

2005 NPEEE Earthquake Design Concept : Lecture 14: Ductility

  • f MRFs

34/37

slide-35
SLIDE 35

2005 NPEEE Earthquake Design Concept : Lecture 14: Ductility

  • f MRFs

35/37

slide-36
SLIDE 36
slide-37
SLIDE 37

Confinement & Anchorage

slide-38
SLIDE 38

Confinement to increase strength Continuity & Anchorage for integral action

slide-39
SLIDE 39

Confinement to increase strength Continuity & Anchorage for integral action

slide-40
SLIDE 40

Anchorage for integral action

slide-41
SLIDE 41

135 degree bend

slide-42
SLIDE 42

LOCAL DEFICIENCIES IN BUILDINGS Failures of MEMBERS SUBJECTED TO BENDING & AXIAL LOAD

slide-43
SLIDE 43

Hinges

slide-44
SLIDE 44

FAILURES DUE TO INADEQUATE LINKS

slide-45
SLIDE 45

FAILURES DUE TO INADEQUATE LINKS

slide-46
SLIDE 46
slide-47
SLIDE 47
slide-48
SLIDE 48

When a column terminates into a footing or mat

slide-49
SLIDE 49

2005 NPEEE Earthquake Design Concept : Lecture 14: Ductility

  • f MRFs

49/37

slide-50
SLIDE 50

Thanks to well detailed confining reinforcement (Taiwan 1999)

slide-51
SLIDE 51

IS 13920 -2016

  • Design of Beam Column Joint
  • Design of shear wall
slide-52
SLIDE 52

MITIGATING GEOLOGICAL HAZARDS

  • Ground collapse
  • Liquefaction
  • Differential compaction
  • Landslide
  • Earthquake-induced flood
slide-53
SLIDE 53

ASSESS THE POTENTIAL FOR SOIL LIQUEFACTION

slide-54
SLIDE 54

The building sank evenly about 1 m due to soil

  • liquefaction. The

displaced soil caused a bulge in the road.

slide-55
SLIDE 55

This inclined building sank unevenly and leans against a neighbouring building

slide-56
SLIDE 56

The solid building tilted as a rigid body and the raft foundation rises above the ground. The building itself suffered only relatively minor damage.

slide-57
SLIDE 57

This tank is also tilted due to the liquefaction of the sandy artificial landfill.

slide-58
SLIDE 58

Mitigating Liquefaction

  • Foundation on bed rock
  • Vibro-floatation
  • Soil with stabilizing materials
  • Provision of drainage to release pore

pressure

slide-59
SLIDE 59

Factors for Good Seismic Performance

  • Architectural configuration
  • Simple and regular configuration
  • Structural design
  • Adequate lateral strength
  • Adequate stiffness
  • Adequate ductility
  • Integral Action
  • Non-structural elements
  • Quality of construction
slide-60
SLIDE 60

CONCLUSION For safety in future earthquakes, all provisions

  • f the codes should be followed in design &
  • construction. This should be a mandatory

provision in the Building Bylaws.

slide-61
SLIDE 61
slide-62
SLIDE 62

Wish U All the Best

slide-63
SLIDE 63

Courtesy: Dr S K Jain Dr C V R M Murthy
