DX 3 offer Accessories MCB Isolators RCCB RCBO Measure Time- - - PowerPoint PPT Presentation

C.Tamhankar/Marketing

DX3 offer

2

Accessories

Measure

Power Multi power

Time- Switch

Digital Astro

Contactor MCB

AC DC RDSO

Isolators RCCB

AC A HPI

RCBO

AC HPI

C.Tamhankar/Marketing

DX3 – a global offer

• Global range
• R&D in France, Italy & India
• Launched in France, Spain, Portugal, Italy, Chili,

central America, Russia and CEI countries, whole Africa, Arabic countries

• Next launch in China, Brazil, Peru, Northern and

Eastern Europe and the remaining Asian countries

• India 13th country to launch DX3

3

C.Tamhankar/Marketing

Time switches

• AlphaRex3
• AstroRex3
• MocroRex

C.Tamhankar/Marketing

AlphaRex3

• New look
• New functions
• Improved display

AlphaRex 3

Data key „+/-“ Select programming menus and -steps „MENU“ – Start programming mode „OK“ button – For programming - menus and -steps Operating mode Operating date and time Weekly switching steps overview

C.Tamhankar/Marketing

AlphaRex3

AlphaRex3 D21, D22 AlphaRex3 D21, D22 astro AlphaRex3 DY21, DY22, DY64 astro Weekly time switch 1- and 2-channel Weekly time switch with astronomical functions 1- and 2-channel Yearly time switch with astronomical functions 1- and 2-channel

C.Tamhankar/Marketing

AlphaRex3

• Preset date and time
• Only one data key for all devices
• Terminal block with high torque
• New design and graphic on display
• PIN-Code also for weekly device

No adjustment necessary Simply and easy Safety Improved visibility Security for program

C.Tamhankar/Marketing

AlphaRex3

• Changeable battery
• EMI stability ->
• Zero-crossing-switching

Environmental friendly Better EMI immunity Specially adapted for energy- saving (lamps)

C.Tamhankar/Marketing

AlphaRex3

• Expanded offset programming for

astronomical functions

• Expanded cycles functions
• Correction function Summer/Winter

(OnlyAstro clocks) Special features for street lighting and similar markets More possibilities for different needs Additional customer savings possible

C.Tamhankar/Marketing

AlphaRex3

• Improved handling
• Expanded offset programming

for astronomical functions

• 15 programming languages in
• ne device
• 0,1 sec clock precision
• Program backup via datakey

possible Easy button access More flexibilities and additional savings for customer possible One reference for almost the whole world Highest precision on market Exclusive Legrand patent

C.Tamhankar/Marketing

AlphaRex3

• 1. Programming via

push buttons

• 2. Programming

via data key

PC include AlphaSoft 4.0 software USB Data key USB Adapter for programming

• 3. Programming via data key

for different devices

• 3. Programming of logic

module via data key

412 873 412 872 412 872 412 872

C.Tamhankar/Marketing

AlphaRex3

AlphaSoft 4.0

data files

C.Tamhankar/Marketing

AlphaRex3

• Maintenance is much easier now

13

C.Tamhankar/Marketing

AlphaRex3

• Daily and weekly time switch
• Quick and easy programming due to the option to select day blocks
• Programming with precision to the second
• Switch times visible in weekly overview on display
• Holiday program
• Random function
• Operating hours counter, counting range of up to 65,535 h
• switch-off delay can be set from 0 s to 23 h 59 min 59 s
• 1h test
• PIN code input lock
• Expert mode for additional functions:
• Cycle function, switch-on time can be set between 1 s and 1 h 59 min 59 s
• Backlight

14

C.Tamhankar/Marketing

AlphaRex3

Yearly function

• Yearly and weekly time switch with additional astronomical function for all

channels

– 84 switching programs per channel, comprising: – 28 weekly programs – 28 yearly programs – 28 special programs (priority program)

• Astronomical function (sunrise/sunset times) can be combined with time switch

function

• Offset can be set to either +/– 120 min or -/+ 12°00´
• Random function
• Operating hours counter, counting range of up to 65,535 h
• 1 h test
• PIN code input lock
• Cycle function, switch-on time can be set between 1 s and 1 h 59 min 59 s

15

C.Tamhankar/Marketing

AstroRex3

• For switching on/off lights and other electric devices according to the

rising/setting of the sun

• Devices are switched according to astronomical time and/or fixed preset

times

• Daily astronomical calculation of the sunrise/ sunset times based on the

entered location or location coordinates

• Offset for sunrise and sunset - adjusted up to +/– 120 min
• Time differentials are set separately for sunrise and sunset
• Controlled directly by the distribution board
• No separate light sensor required

16

C.Tamhankar/Marketing

AstroRex3

• Time offset

18

C.Tamhankar/Marketing

MicroRex

• Extremely easy plug-and-play

installation

• Automatic setting of the time using
• fast-run mode
• Automatic switching for summer/

winter time (daylight saving time)

• LED status indicator
• Precision clockwork:

+/- 0.2 s/day clock precision

• Captive switching segments

19

C.Tamhankar/Marketing

MicroRex

• Manual switching: ON/automatic/OFF
• Sealable cover
• Changeover contact as switch output
• Normally open contact as switch output

(single-module time switches)

• Removable battery

20

C.Tamhankar/Marketing

MicroRex T31/W31 Su/Wi

• Automatic setting of the time during startup
• Automatic switching for summer/winter time

(daylight saving time)

• Automatic time reset after a power failure
• With the highest clock precision and a running reserve
• f 6 years

21

C.Tamhankar/Marketing

MicroRex

• Single channel unit
• Direct load of 1000 W

22

C.Tamhankar/Marketing

Luxo switch

• The outdoor unit to be connected to DIN rail mounting unit
• Maximum length 50 meters

23

C.Tamhankar/Marketing

Luxo switch

• The knob on the front face to be

adjusted for the Lux level setting

24

C.Tamhankar/Marketing

Contactor

• 16 A to 63 A
• DP, TP & FP
• NO & NC functions
• 1,00,000 operating cycles

25

C.Tamhankar/Marketing

Conformity and approvals

• In accordance with RoHS / Reach
• CE and VDE approved (Others on request)
• Eco-conception
• Recyclability: 80%
• PEP available

C.Tamhankar/Marketing

Applications

• Advertising hoardings
• Shop windows
• Street lighting
• Sport facilities
• Outdoor lighting

28
