Dropped Objects Who’s Responsible

Presented by Bob Thompson, Chevron Indonesia

Dropped Objects Who’s Responsible

Responsibilities Through the Supply Chain

Dropped Objects Who’s Responsible

Responsibilities Through the Supply Chain

• A bolt attaching the gripper head to the upper

racking arm came loose and fell to the drillfloor during a tripping operation

• All personnel were outside the danger area.

Causes:

• 1. Incorrect material in manufacture
• 2. Bolt had the incorrect part number
• 3. Faulty design - should not have been with

welded head

• 4. New design bolt in 2000 - not changed out.

Design - Bolt fell from URA to Drillfloor - 1.6kg x 25m

Dropped Objects Who’s Responsible

Responsibilities Through the Supply Chain

• Bar holding skid rubber

in place fell 30m to cargo deck.

Manufacture - Bar fell 30m to Cargo Deck

Causes:

• 1. Poor design
• 2. Poor manufacture
• 3. Poor maintenance.

Dropped Objects Who’s Responsible

Responsibilities Through the Supply Chain

• Compressor delivered with

broken Weco coupling inside skid

• Coupling had been sheared
• ff during transit.

Packaging - Coupling sheared off during transit

Causes:

• 1. Poor design
• 2. Poor packaging
• 3. Lack of awareness.

Dropped Objects Who’s Responsible

Responsibilities Through the Supply Chain

• Hammer and Chisel

found on the top of container prior to lifting.

Transport - Items found on the top of container

Causes:

• 1. Carelessness of

persons using tools

• 2. Failure to check loads

prior to despatch.

Dropped Objects Who’s Responsible

Responsibilities Through the Supply Chain

• Rubble found in the

Forklift Pockets.

Quayside - Rubble found in the Forklift Pockets

Causes:

• 1. Poor storage facility
• 2. Failure to check loads

prior to despatch.

Dropped Objects Who’s Responsible

Responsibilities Through the Supply Chain

Transport by Sea - Item left on top of a unit

Causes:

• 1. Lack of awareness of

maintenance staff

• 2. Failure to check loads

prior to despatch.

• A temperature gauge

used to check exhaust temperature was left on top of a unit

• The gauge weighed

approximately 0.25kg.

Dropped Objects Who’s Responsible

Responsibilities Through the Supply Chain

• Air regulator fitted to wireline

hoist.

• Not designed for use at

height

• Securing dogs not engaged
• When energised cover and

internals (230gm) blew off and fell 10m to drillfloor

• No injuries were sustained.

Installation / Commission - Item not designed for use at height

Cause:

• 1. Equipment unsuitable for

use at height.

Dropped Objects Who’s Responsible

• A bolt was observed laying on drill

floor 3m from personnel

• Investigation showed that a bolt for a

roller on pipe handler had come loose, the nut and bolt had

• disassembled. Roller (750gr) was

found loose on roller gripper head. Causes:

• 1. Failure of lock washer
• 2. Poor design.

Operations - Bolt fell 24m to Drillfloor

Responsibilities Through the Supply Chain

Dropped Objects Who’s Responsible

Responsibilities Through the Supply Chain

• Pin fell 6m from Bail Retainer

to Drillfloor, the pin weighed 0.5kg.

Operations - Pin fell 6m to Drillfloor

Causes:

• 1. Poor design of cotter pin

security

• 2. Cotter pin safety spring was

flicked-up and fell out. Considerations:

• 1. Secure pins with ty-wraps
• 2. Re-design pin security.

Dropped Objects Who’s Responsible

• While running riser a flange on the riser knocked

loose a part of the grating on a work platform.

• The grating fell to a lower level landing 2m from a

person.

• There were people on all levels observing to make

sure the riser was not hitting obstructions.

Causes:

• 1. Roughneck changes level without notifying

the Driller and has his focus on the guide lines

• 2. Failure to follow procedures - Work platform

was not fully retracted

• 3. Person was inside closed area.

Operations - Grating (20kg) fell 8m

Responsibilities Through the Supply Chain

Dropped Objects Who’s Responsible

• Hammer (0.4kg) fell 33m

from work platform following maintenance

• perations.
• No personnel were working

in the vicinity.

Maintenance / Repair - Hammer fell 30m

Causes:

• 1. Insufficient Risk

Assessment

• 2. No securing of tools at

height.

Responsibilities Through the Supply Chain

Dropped Objects Who’s Responsible

Responsibilities Through the Supply Chain

Decommission / Dismantle - Spike fell 7 - 8 feet

• Spike, hidden inside scaffolding

tube fell 7 - 8 feet to the deck narrowly missing Scaffolder.

Causes:

• 1. Insufficient Risk Assessment
• 2. No securing of tools at height
• 3. Bad habits.

Recommendations:

• 1. Cap tube ends
• 2. Secure tools at height.

Dropped Objects Who’s Responsible

Responsibilities Through the Supply Chain

• Container back loaded from
• ffshore. Door opened and fell off.
• Further investigation revealed door

hinges were unsatisfactory and container had made substantial contact with solid object.

Packing - Door fell off during backloading

Causes:

• 1. Poor maintenance and fabrication
• f containers
• 2. Poor standards of inspection
• 3. Poor handling of loads.

Dropped Objects Who’s Responsible

Responsibilities Through the Supply Chain

www.droponline.org Developed in association with

Everyone is Responsible Dropped Objects
