As Sea Level Rises Groundwater Does Too What is at Risk when Groundwater Rises? Jayne F. Knott and Jennifer M. Jacobs University of New Hampshire Department of Civil and Environmental Engineering Hosted by NH Coastal Adaptation Workgroup

slide-1
SLIDE 1

Short title; Author(s), Date

As Sea Level Rises Groundwater Does Too – What is at Risk when Groundwater Rises?

Jayne F. Knott and Jennifer M. Jacobs University of New Hampshire Department of Civil and Environmental Engineering Hosted by NH Coastal Adaptation Workgroup (NH CAW)

April 26, 2018

slide-2
SLIDE 2

Short title; Author(s), Date

Outline

  • Introduction - Groundwater
  • Sea level rise (SLR) and coastal groundwater
  • SLR in coastal New Hampshire (NH)
  • Simulated SLR-induced groundwater rise
  • Potential impacts of groundwater rise
  • What can we do?

2

slide-3
SLIDE 3

Short title; Author(s), Date

Introduction - Groundwater

3

slide-4
SLIDE 4

Short title; Author(s), Date

4

Water Volumes (km3)

96% 2% 1%

Fresh

Charles Harvey, CEE-1.72 Groundwater Hydrology, Fall 2005. (Massachusetts Institute of Technology: MIT OpenCourseWare), http://ocw.mit.edu (Accessed April 2, 2018). License: Creative Commons BY-NC-SA

slide-5
SLIDE 5

Short title; Author(s), Date

5

Hydrologic Cycle with Annual Volumes (thousand km3/year)

Charles Harvey, CEE-1.72 Groundwater Hydrology, Fall 2005. (Massachusetts Institute of Technology: MIT OpenCourseWare), http://ocw.mit.edu (Accessed April 2, 2018). License: Creative Commons BY-NC-SA

slide-6
SLIDE 6

Short title; Author(s), Date

Sea level rise and coastal groundwater

6

slide-7
SLIDE 7

Short title; Author(s), Date

7

Sea level is rising

Griggs, David. Climate Change 2001, Synthesis report, Contribution of working groups I, II, and III to the Third Assessment Report of the Intergovernmental Panel on Climate Change, Cambridge University Press, 2001

slide-8
SLIDE 8

Short title; Author(s), Date

8

Union of Concerned Scientists, 2015; www.ucsusa.org/sealevelrisescience

Surface water impacts of sea level rise What’s happening UNDERGROUND?

slide-9
SLIDE 9

Short title; Author(s), Date

A more complete picture

9

http://www.skagitclimatescience.org/skagit-impacts/sea-level-rise/ Seattle, Washington

slide-10
SLIDE 10

Short title; Author(s), Date

10

Can a sea wall really keep the water out? Groundwater flow

Charles Harvey, CEE-1.72 Groundwater Hydrology, Fall 2005. (Massachusetts Institute of Technology: MIT OpenCourseWare), http://ocw.mit.edu (Accessed April 2, 2018). License: Creative Commons BY-NC-SA

slide-11
SLIDE 11

Short title; Author(s), Date

Has Groundwater Rise been Recorded? Yes - Cape Cod

11

McCobb and Weiskel (2003)

2.1 mm/yr. average GW rise in a well 300 m from coast in Truro, Cape Cod 2.5 mm/yr. average sea-level rise at the Boston tide gage.

slide-12
SLIDE 12

Short title; Author(s), Date

Groundwater will rise with sea level rise – Why do we care?

12

Source: U.S. Geological Survey

slide-13
SLIDE 13

Short title; Author(s), Date

Groundwater contamination from septic tanks

13

Source: https://www.mass.gov/service-details/smart-growth-smart-energy-toolkit- modules-wastewater-alternatives Vertical separation between the bottom of leaching field and groundwater decreases – total treatment decreases because there is less vertical passage.

slide-14
SLIDE 14

Short title; Author(s), Date

Groundwater rise and septic systems: North Carolina

14

Source: Manda et al. (2015)

Current seasonal high water table Seasonal high water table with 1.0 m SLR RED - Simulated GW is above the leaching field trench

slide-15
SLIDE 15

Short title; Author(s), Date

Rising groundwater can mobilize contamination from disposal sites

15 15

Plummer, McGeary, Carlson. Physical Geology, 8th ed., McGraw-Hill Companies, Inc., 1999

slide-16
SLIDE 16

Short title; Author(s), Date

What will happen to the freshwater/saltwater interface? Will it move inland?

Source: U.S. Geological Survey

16

slide-17
SLIDE 17

Short title; Author(s), Date

Saltwater Intrusion into Drinking Water Wells

17

2007 Thompson Higher Education; https://www.slideshare.net/prashantpkatti/sea-water-intrusion

slide-18
SLIDE 18

Short title; Author(s), Date

Sea-Level Rise in Coastal New Hampshire

18

slide-19
SLIDE 19

Short title; Author(s), Date

NH Sea-Level Rise Situational Awareness

NH Coastal Risk and Hazards Commission NH Dept. of Environmental Services NH Coastal Adaptation Workgroup

Photo Credit: Peter Digeronimo

CAW King Tide Photo Competition November 5-7, 2017

19

slide-20
SLIDE 20

Short title; Author(s), Date

NH Sea-Level Rise – Projected Tidal Flooding

20

Note: Storm surge = flood extent from a 100-year/1% chance storm event Tidal water inundation with SLR Green shading = 0.5 m, 1.2 m, and 1.9 m of SLR Tidal water inundation with SLR and storm surge Pink shading = 0.5 m, 1.2 m, and 1.9 m of SLR

Map credit: Tides to Storms, Rockingham Planning Commission (2015)

slide-21
SLIDE 21

Short title; Author(s), Date

New Hampshire Seacoast What is coastal and what is inland?

21

How far inland will the effects of SLR be felt?

slide-22
SLIDE 22

Short title; Author(s), Date

Simulated SLR-Induced Groundwater Rise in Coastal New Hampshire

22

slide-23
SLIDE 23

Short title; Author(s), Date

Modeling Groundwater Rise with SLR

23

Groundwater (GW) model:

  • Existing 3D model

(Mack, 2009) - modified for this study

  • USGS MODFLOW
  • Ran in steady

state – no seasonal effects

  • Grid – 200 ft. x

200 ft.

slide-24
SLIDE 24

Short title; Author(s), Date

Sea Level Rise - Scenarios

24

Sea-Level Rise (SLR) High Emissions Scenario:

  • 1.0 ft. SLR (Y: 2030)
  • 2.7 ft. SLR (Y: 2060)
  • 5.2 ft. SLR (Y: 2090)
  • 6.6 ft. SLR (Y: 2100)

From: NOAA (Parris et al., 2012)

slide-25
SLIDE 25

Short title; Author(s), Date

Model Results: Groundwater-Rise Zone (GWRZ)

25

Groundwater rise

(% of sea-level rise):

  • GW Rise: 4–5 km

inland

  • Tidal surface-water

flooding: 1.5 km inland

  • GW Rise is reduced

near streams

  • Affected by:
  • geology
  • coastal

geometry

  • GW pumping
  • Can result in

GWI of the land surface

slide-26
SLIDE 26

Short title; Author(s), Date

Potential Impacts from SLR-Induced Groundwater Rise in Coastal New Hampshire

26

slide-27
SLIDE 27

Short title; Author(s), Date

Will drinking water supplies in the seacoast region be harmed by saltwater intrusion?

27

Area where GW is predicted to rise the most with SLR Areas potentially at risk from saltwater intrusion

Red: Overburden wells Grey: Bedrock wells

Areas potentially at risk from saltwater intrusion

slide-28
SLIDE 28

Short title; Author(s), Date

Where might rising groundwater impact marine and freshwater wetlands?

28 28

City of Portsmouth: Approximately 9 km2 (21%) is occupied by freshwater wetlands. The depth of water in wetlands may increase – wetland type transition Freshwater wetland area will increase:

  • 3% by 2030;
  • 10% by mid-century;
  • 19 to 25% by the end
  • f century.
slide-29
SLIDE 29

Short title; Author(s), Date

Where might rising groundwater contact contaminated soils?

29

The red triangles are/were active remediation sites

Depth to GW with 6.6’ (2.0 m) of SLR Pease Tradeport, Portsmouth, NH

slide-30
SLIDE 30

Short title; Author(s), Date

Which pavements may fail prematurely due to rising groundwater?

30

Roads in the zone of groundwater rise where groundwater is already close to the ground surface will be the most vulnerable.

slide-31
SLIDE 31

Short title; Author(s), Date

Vulnerable sections of roadway

31

Vulnerable Roads –

Roads within the GWRZ with GW less than 1.5 m below the road surface.

  • 1022 km of roads are in

the study area

  • 783 km of roads (77% of

the region’s roads) are in the GWRZ.

  • 235 km of the region’s

roads (23%) are vulnerable or 30% of the roads in the GWRZ.

slide-32
SLIDE 32

Short title; Author(s), Date

What happens when the underlying, supporting soils become saturated?

32

slide-33
SLIDE 33

Short title; Author(s), Date

33

Fatigue cracking

Pavement life decreases when GW moves into the underlying layers and increased temperature weakens the AC

Rutting

slide-34
SLIDE 34

Short title; Author(s), Date

Pavement evaluation

34

Pavement evaluation sites

  • Spaulding turnpike (Divided

highway)

  • Gosling Road (Local road)
  • Route 101 (Statewide

corridor)

  • Route 286 (Regional corridor)
  • Middle St. (Local road)
slide-35
SLIDE 35

Short title; Author(s), Date

Spaulding Turnpike and Gosling Road

35

slide-36
SLIDE 36

Short title; Author(s), Date

Spaulding Turnpike (divided highway)

36

Road surface elevation = 64.9 feet (NAVD88)

slide-37
SLIDE 37

Short title; Author(s), Date

Gosling Road – Pavement profile and analysis

37

Road surface elevation = 49 feet (NAVD88)

Road is flooded

Fatigue cracking controls pavement failure

slide-38
SLIDE 38

Short title; Author(s), Date

What can we do?

38

slide-39
SLIDE 39

Short title; Author(s), Date

There are many options – we have some time . . .

1. Adopting adaptation actions now may save money in increased maintenance, emergency repairs, and environmental harm.

  • 2. Ensuring that our natural systems remain healthy will enable them to

continue performing essential protective functions.

  • 3. Where infrastructure adaptation is extremely costly, a wait and see

approach may be best.

  • 4. Staged adaptation planning: what you do now can influence or constrain

future options.

39

slide-40
SLIDE 40

Short title; Author(s), Date

40

Example Adaptation Strategies – Local Road (Gosling Road)

Pavement Life (Nfn/Nfe) Adaptation Costs ($/yd2) Pavement Options

slide-41
SLIDE 41

Short title; Author(s), Date

Concluding Remarks

41

slide-42
SLIDE 42

Short title; Author(s), Date

SLR, Rising GW, and Coastal NH Summary

42

1. The Groundwater Rise Zone (GWRZ) caused by sea-level rise was identified in coastal NH with a regional groundwater-flow model.

  • 2. Vulnerable assets, within the GWRZ, are those where groundwater is

already close to the base of the structure, i.e. within the range of projected groundwater rise.

  • 3. Detailed asset-specific vulnerability studies are required to account for

local conditions and to assess the asset’s resiliency to groundwater and temperature rise from climate change.

  • 4. Adoption of adaptation strategies now will avoid expensive emergency

repairs, groundwater contamination, and harm to natural resources.

slide-43
SLIDE 43

Short title; Author(s), Date

Acknowledgements

43

  • Co-authors and advisors:
  • Jennifer Jacobs, Ph.D., University of New Hampshire
  • Jo Sias Daniel, Ph.D., University of New Hampshire
  • Paul Kirshen, Ph.D., University of Massachusetts Boston
  • Advisors: David Burdick, Ph.D., University of New Hampshire; Eshan Dave,

Ph.D., University of New Hampshire

  • New Hampshire Sea Grant for funding this work
  • UNH Center for Infrastructure Resilience to Climate (UCIRC)
  • The Infrastructure and Climate Network (ICNet)
  • NH Department of Transportation (NHDOT)
  • NH Department of Environmental Services (NHDES)
  • NH Seacoast Transportation Climate Working Group (NHS TCWG)
  • NH Coastal Adaptation Workgroup (NHCAW)
slide-44
SLIDE 44

Short title; Author(s), Date

Thank you for your interest. Questions?

44

Jayne F. Knott and Jennifer M. Jacobs University of New Hampshire e-mails: jfk1011@wildcats.unh.edu Jennifer.Jacobs@unh.edu

Source: www.huffingtonpost.com

slide-45
SLIDE 45

Short title; Author(s), Date

Route 286 (regional corridor)

45

slide-46
SLIDE 46

Short title; Author(s), Date

Route 286 - Pavement profile and analysis

46

Road surface elevation = 13.9 feet (NAVD88)

Road is flooded

Rutting controls pavement failure

slide-47
SLIDE 47

Short title; Author(s), Date

47

Adaptation Strategies – Regional Corridor (Rte. 286)

Pavement Options Adaptation Costs ($/yd2) Pavement Life (Nfn/Nfe)
