Does sustainable remediation passes on risks and burdens to future generations? 4th International Conference on Sustainable Remediation April 26 th , 2016 - Montral Griet Van Gestel OVAM The image cannot be displayed. Your computer may

slide-1
SLIDE 1

Griet Van Gestel – OVAM

Does sustainable remediation passes on risks and burdens to future generations?

4th International Conference on Sustainable Remediation April 26th, 2016 - Montréal

slide-2
SLIDE 2

Introduction

16-05-04 │ 2

The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file again. If the red x still appears, you may have to delete the image and then insert it again. The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file again. If the red x still appears, you may have to delete the image and then insert it again.
slide-3
SLIDE 3

How much soil/groundwater contamination can be left behind?

16-05-04 │ 3

slide-4
SLIDE 4

How do we deal with it in Flanders?

16-05-04 │ 4

slide-5
SLIDE 5

How do we deal with it in Flanders?

  • 1. Information on soil and groundwater contamination
  • 2. Evaluation of sustainability of residual contamination

16-05-04 │ 5

slide-6
SLIDE 6

1.

Information on soil and groundwater quality will be expanded with information on possible land uses

16-05-04 │ 6

slide-7
SLIDE 7

Present legislation: soil certificate and database

A soil certificate is delivered whenever a piece of land is sold Database containing data on soil and groundwater quality: ‘land information register’ Database is supplied by soil investigation reports

16-05-04 │ 7

slide-8
SLIDE 8

Need for improvement

New evolutions emphases stakeholder involvement Rethink: Which information, and how will it be represented? Data management systems of OVAM are screened also quality standards for soil investigation reports focus on residual contamination

16-05-04 │ 8

slide-9
SLIDE 9

Two improvements proposed

  • 1. Information given in reports will be expanded

with consequences when soil will be excavated, with consequences for risks when land uses are changed.

  • 2. Information will be represented in a visually clear and

appealing format

16-05-04 │ 9

slide-10
SLIDE 10

16-05-04 │ 10

slide-11
SLIDE 11

Usage information

16-05-04 │ 11

Code ¡ Action ¡ Risks / impacts ¡ Measures ¡ ¡ ¡ ¡ ¡ GI 1 ¡ Excavation of soil ¡ Direct exposure ¡ e.g. soil removal and treatment ¡ GI 2 ¡ Excavation of soil for infrastructure ¡ Direct exposure ¡ e.g. soil removal and treatment ¡ GI 3 ¡ Drainage for infrastructure ¡ Spreading of contamination ¡ e.g. installation of water purification ¡ GI 4 ¡ Removal of pavement ¡ Direct exposure ¡ …… ¡ GI 5 ¡ Vegetable garden ¡ Exposure by consumption of vegetables ¡ …… ¡ GI 6 ¡ Pumping and use of groundwater ¡ Exposure (dermal and oral) ¡ new risk evaluation ¡ GI 7 ¡ Redevelopment with change of use ¡ Risks due to change of land use ¡ new risk evaluation ¡ GI 8 ¡ …… ¡ ……. ¡ ¡ ¡ ¡ ¡ ¡

slide-12
SLIDE 12

16-05-04 │ 12

slide-13
SLIDE 13

2.

Sustainability evaluation of residual contamination is integrated in a Sustainability Assessment Tool

16-05-04 │ 13

slide-14
SLIDE 14
  • Cfr. Presentation by Johan Ceenaeme and Peter Van den

Bossche in stream 1B at 2:30pm ‘Sustainability Assessment Tool of Soil Remediation and Redevelopment Projects’

16-05-04 │ 14

slide-15
SLIDE 15

Sustainability of residual contamination is related to (1) the potential for redevelopment (2) locational factors & properties of residual contamination

Approach in two steps: Step A (potential for redevelopment) Step B (properties of residual contamination)

16-05-04 │ 15

slide-16
SLIDE 16

Approach in two steps: Step A (potential for redevelopment)

  • 1. external decisions leading to land use changes (in next 100 years)
  • 2. intrinsical factors (in the next 100 years)

Step B (properties of residual contamination)

  • 3. depth soil contamination
  • 4. depth of groundwater contamination
  • 5. persistence and evolution (mobility)
  • 6. impact on uses of the site (advices and restrictions on land use)
  • 7. impact on surrounding areas (of contamination in groundwater)
  • 8. impact on costs for excavation
  • 9. impact on costs for groundwater pumping
  • 10. benefits of integration of redevelopment & residual contamination

16-05-04 │ 16

slide-17
SLIDE 17

Case: Forges de Clabecq – coking plant

16-05-04 │ 17

slide-18
SLIDE 18

Case: Forges de Clabecq – coking plant

Soil contamination: mineral oil, HM, PAH, BTEX, cyanides Two options :

  • 1. Remediation integrated in the redevelopment : including

residential and recreational area

  • 2. Remediation as required by regulations

16-05-04 │ 18

slide-19
SLIDE 19

16-05-04 │ 19

Criterion Option 1 Option 2 Step A

  • 1. external decisions leading to land use changes (in next 100 years)

0.5 0.5

  • 2. intrinsical factors (in the next 100 years)

0.5 0.5

Total step A 1 1 Step B

  • 3. depth soil contamination

5 5

  • 4. depth of groundwater contamination
  • 5. persistence and evolution (mobility)

3 3

  • 6. impact on uses of the site (advices and restrictions on land use)

3

  • 7. impact on surrounding areas (of contamination in groundwater)
  • 8. impact on costs for excavation

1 7

  • 9. impact on costs for groundwater pumping
  • 10. benefits of integration of redevelopment & residual contamination
  • 5

Total step B 4 18 Final score (Step A X step B) 4 18

slide-20
SLIDE 20

16-05-04 │ 20

Criterion Option 1 Option 2 Step A

  • 1. external decisions leading to land use changes (in next 100 years)

0.5 0.5

  • 2. intrinsical factors (in the next 100 years)

0.5 0.5

Total step A 1 1 Step B

  • 3. depth soil contamination

5 5

  • 4. depth of groundwater contamination
  • 5. persistence and evolution (mobility)

3 3

  • 6. impact on uses of the site (advices and restrictions on land use)

3

  • 7. impact on surrounding areas (of contamination in groundwater)
  • 8. impact on costs for excavation

1 7

  • 9. impact on costs for groundwater pumping
  • 10. benefits of integration of redevelopment & residual contamination
  • 5

Total step B 4 18 Final score (Step A X step B) 4 18

slide-21
SLIDE 21

Evaluation

Score: < 5 sustainable Score: > 10 not sustainable

16-05-04 │ 21

slide-22
SLIDE 22

Conclusions

Providing more information on residual contamination in soil and groundwater in a clear and visually appealing format contributes to sustainable remediation.

The evaluation of sustainability of residual contamination

in soil and groundwater should be part of a sustainable remediation assessment.

16-05-04 │ 22

slide-23
SLIDE 23

Thanks for your attention Are there any questions?
