DLL design

Herve Grabas

4/28/2010

1

3rd Chip Review

Overall presentation

• The DLL will allow us to have a controlled

sampling rate.

• Provide us a cleaner sampling window
• No dead zone of sampling ( if the effective delay

free running delay line is less than the period of the input clock -> dead time)

4/28/2010 3rd Chip Review

2

CMOS design

• Cell design

Phase detector Charge pump Delay line Some control logic

• Simulation

Complicated: long locking time, small time steps. The use of VerilogA language and mixed signal simulation saves you.

4/28/2010 3rd Chip Review

3

DLL simulation

• Difficult because:

 DLL function with 40ps delays. Locking take up to 100us.

• Therefore, there is more than 7 orders of

magnitude of difference between the smallest time step and the biggest one.

• Solution : not simulating the internal function of

the delay line.

4/28/2010 3rd Chip Review

4

Delay line simulation model (1)

• Delay line structure: chain of small delays.

4/28/2010 3rd Chip Review

5 Generates a sampling frequency equals to

Delay 1

Delay line simulation model (2)

• From its input and output the delay line is however nothing

else than a big delay adjustable by to voltages : VCN and VCP.

4/28/2010 3rd Chip Review

6

Delay line simulation (3)

• VerilogAMS description of the VCDL:

Allow us to describe a variable delay.  Description uses post layout results from Eric

4/28/2010 3rd Chip Review

7

DLL simulation success

4/28/2010 3rd Chip Review

8

Delay Locked Loop principle

1. VCN and VCP are set to their max value (1.2 & 0 resp.).

 The propagation delay in the DLL is then the smallest -> 11ns.

2. The delay is increased until it reaches the delay of one clock cycle. 3. The phase comparator locks then the delay of the delay line at one clock cycle

4/28/2010 3rd Chip Review

9

Delay locked loop control logic

• In a delay locked loop the generated delay of the delay line cannot

reach 0. It is always minored by the smallest delay of the line. Here 11ns.

• Therefore, the DLL can never lock on the first edge of the clock. (See

Fig.)

• However the phase comparator work at ±180° around a clock edge.

And in some case this can result in the DLL trying to lock on the first edge of the clock (See Fig.)

• This has to be taken care of. Some simple logic is sufficient.

4/28/2010 3rd Chip Review

10

DLL control logic (2)

• The control logic outputs 1

if VDLL is in the wrong pull-in range.

• After having being active

the pull-out logic is

• inactivated. (The DLL can
• nly be in the wrong pull-in

range once).

• The control logic operates

directly on the phase comparator to preserve its speed.

4/28/2010 3rd Chip Review

11

Dynamic phase comparator

4/28/2010 3rd Chip Review

12

• It is a dynamic phase

comparator so it is extremely fast. Therefore it gives us very accurate jitter correction.

• Adjusted to give us

directly the right control signal for the charge pump. (No extra inverted needed).

• Shift logic integrated.

Charge pump

4/28/2010 3rd Chip Review

13

• High performance charge

pump.

• 1uA external current

source.

• Cascode current mirror

to increase output resistance, so that charging and discharging current are not disturbed by the state of the output. (Better current matching).

Delay locked loop

4/28/2010 3rd Chip Review

14

• Whole schematic circuit with the control logic.

Layout: Charge pump & Phase detector

4/28/2010 3rd Chip Review

15

• Layout of the

charge pump and phase detector done together for better matching and smallest wiring capacitances.

• 16um x 18um

Layout Control logic

4/28/2010 3rd Chip Review

16

Results

• Successful simulation and locking pre and post

layout.

• Lock time ~ 10 us.
• Simulation time ~10 min.
• Measured jitter in schematic simulation : 8as

(not legitimate!)

• 300fs in post-layout simulation with the

behavioral model of the DLL.

• DLL system is stable and precise.

4/28/2010 3rd Chip Review

17

Results (2): The pull-out

4/28/2010 3rd Chip Review

18 Pull-out control signal Decrease in VCN -> Increase in delay.

Results (3) : The locking

4/28/2010 3rd Chip Review

19 Small UP and DOWN control signal. Locking almost complete.

Results (4) : The jitter

4/28/2010 3rd Chip Review

20 Very low delay variations at the output of the delay line
