" Digigram meets our most stringent criteria for developing high quality, reliable audio-over-IP solutions that we can present to our clients with complete confidence."

Jean-Louis Degoul, Head End Lead Buyer, TDF Group, France

AUDIOWAY BRIDGE

Preliminary

Presentation summary

• Workflow overview and main use cases
• Assets and Key features
• Targets and product’s benefits
• Competition and pricing

Workflow overview

Full Digigram workflow overview

6

What is AUDIOWAY BRIDGE for?

7

“Input MADI, AES67, RAVENNA, Dante/AES67, or AES/EBU and route audio to output in any one of these formats”

Bridge Legacy / IP audio inside studio

Legacy audio

AES/EBU MADI

AoIP streams

Main use cases

Route audio from/to AoIP islands

AES/EBU MADI MADI MADI

Studio-to-Studio highway

Managed network Studio A

GPS/PTP Sync master

Studio B

MADI MADI

GPS/PTP Sync master

Remote studio

Managed network Remote studio

MADI or AES/EBU

GPS/PTP Sync master

Studio

MADI

GPS/PTP Sync master

Network audio firewall

13

Guest AoIP network Studio AoIP network

Eth 0 Eth 1 Wordclock Master PTP

• r Wordclock

Assets and key features

Ultra-low latency routing Open discovery and control Full clocks synchronization 24/7/365 operation

Assets

Ultra-low latency routing

16

MADI In / Out (optical) AES/EBU In / Out AES67/RAVENNA ETH 0 AES67/RAVENNA ETH 1 64/64 64/64 64/64 8/8 All I/O are Mono I/O Headphone monitoring 2

Full AES67 (ST 2110-30) compliance

All streams are Mono

Full clocks synchronization

17

All I/O are Mono I/O

• MADI In / Out (optical)

AES/EBU In / Out AES67/RAVENNA ETH 0 AES67/RAVENNA ETH 1 Headphone monitoring

Open Discovery & Control

18

• All I/O are Mono I/O
• MADI In / Out (optical)

AES/EBU In / Out AES67/RAVENNA ETH 0 AES67/RAVENNA ETH 1 Headphone monitoring

• Manual (raw AES67)

Hands on Discovery

• Advertized with RAVENNA (mDNS)

19

• Advertized with Dante (SAP)

1 - Select the available streams, Rx side 2 - AUDIOWAY automatically decodes the selected streams

Example :

• OB1, Studio 1, Studio 2 are stereo

streams

• OB2 is a 7.1 multichannel stream

24/7/365 operation

• Dual power supply
• FPGA technology, derived from Digigram’s

sound cards

20

Connectivity

21

AES/EBU IN 1/2 to 7/8 AES/EBU OUT 1/2 to 7/8 Ethernet 0/1 + CRL Optical MADI I/O Wordclock IN Wordclock OUT Dual power supply Headphone monitoring Ethernet configurations

Targets and benefits of the product

Who will use AUDIOWAY BRIDGE?

23

Target Persona Needs Radio or TV studios

Audio technician Simplicity, reliability Studio administrator Security, Control with open protocol Interoperability CTO Procurement AES67 architecture expertise References Interoperability (Audio AND control)

VARs & integrators

Architect Interoperability (Audio AND control)

OEM partners

Product manager Label customization AES67 architecture expertise

Benefits Proven by

Ease your migration to IP

• Takes care of all the audio and clock synchronization to

bridge Legacy audio and AoIP low latency streams

• Provides for PTP master clock, no costly investment

Protects your investment

• Compatible with open source EMBER+ managers
• Full AES67 (ST 2110-30) interoperability (IP showcase)
• Dante/AES67 streams managed by Dante Controller

Performs mission critical

• perations
• High reliability of Dual Power Supply
• Proven Digigram sound card reliability (FPGA technology)

Same low latency as digital audio

• RAVENNA allows Ultra-low latency, down to 1 sample per

packet

Benefits

24

Competition and pricing

Competition and pricing

AoIP + Analog AoIP + AES/EBU AoIP + MADI

AUDIOWAY BRIDGE List price: 3450 €

Expected schedule

• IBC 2017: prototype
• Dec 2017: Q=5 Beta
• March 2018: shipping

27

Addendum Market introduction survey

Survey

29

Digigram references

And many more...

Some clients testimonials

32

"In a nutshell: The IQOYA offers a good price/performance ratio. Furthermore we appreciate the quick response and fantastic support of Digigram.” Sandra Müller, Product Manager, Media Broadcast, Germany “ Digigram meets our most stringent criteria for developing high quality, reliable audio-over-IP solutions that we can present to our clients with complete confidence." Jean-Louis Degoul, Head End Lead Buyer, TDF Group, France “The Digigram sound cards integrate very smoothly with our preferred broadcast systems. We are confident that Digigram will provide the quality and stability essential for the creation of a top-tier broadcast solution.” Yun Seong Lee, Manager, Radio Technology Department, Korean Broadcasting Systems, Korea

Thank you for your attention!

Pascal Malgouyard malgouyard@digigram.com
