Differentiated Storage Services

Presentation by Szymon Bachnij

• M. Mesnier, J.B. Akers, F. Chen, T. Luo

Introduction

• DSS is a proposition of I/O classification

architecture

• we want to define the separate classes of I/O
• our goal is to assign the storage system policy

to each of those classes to efficently manage data and I/O requests

Challenges:

• Computer system performance depends
• n storage system
• Storage systems are becoming more

and more complex

• Storage system need some information

to provide any optimazation

• ... but too much information is not a good idea

Requirements

Operating system:

• classifier assosiated with every I/O request
• new field must be added to each OS structure

describing I/O which is always copied to actual I/O command (SCSI, ATA)

• OS scheduler need to be changed

Filesystem:

• must have its own classification scheme
• each class have its own policy
• I/O can change the classification class

(ex. file changes its size)

Storage system:

• must exctract the classifier, find the appropriate

policy and enforce it

• don’t need to remember the class
• f each data block
• have to inform about changing the location of

block

Application:

• O_CLASSIFIED needed to use DSS

while opening the file

• POSIX gather/scatter operations

are overloaded

• changes in VFS are essential in order

to handle DSS features

Implementation

Operating system

• interface for classifying I/O requests

Operating system

• then we copy from the BIO to the 5-bit

vendor-specific Group Number field in byte 6 of the SCSI CDB

SCpnt->cmnd[6] = SCpnt->request->bio->bi_class;

• adding I/O classification is a matter of tracking

an I/O from filesystem to device drivers through block layers

File system

• Goal: provide

the storage system information which blocks should be cached and the order of eviction

• f cached blocks

File system

• class id and priority

may change

• we using 19 out of 32

available ID’s

• the less numer

the higher priority is

File system

• provided POSIX interface for user-level I/O

File system

• example for PostgreSQL

Storage system

Baseline algorithm:

• at the beginning we have ‘free list’
• f allocations
• when the data block is cached the allocation is

moved to ‘dirty list’

• when the ‘free list’ drops below some level

‘syncer deamon’ begins to clean the ‘dirty list’

Storage system

Selective allocation:

• decision about caching is not based
• n request size
• metadata and small files are always cached
• large files are cached conditionally

(it depends on ‘syncer deamon’ state)

Storage system

• Selective eviction:
• is not a LRU algorithm
• first are evicted entries with lowest priority
• If this is not enough we evict next lowest entries
• metadata and small files rarely leave cache
• large files are usually moved out

because of priority, but also its size

Evaluation

Environment

• single Linux machine (Fedora 13)
• kernel version: 2.6.34
• 8-core system with 8GB of RAM
• file system: Ext3
• storage device: 5-disk LSI RAID-1E array
• cache: Intel 32GB X25-E SSD

Test methodology

• Workload generator

which on input takes: file size distribution, request file size, read/write ratio, number

• f subdirectories

File server

• file server worload based on SPECsfs2008
• over 262,000 files

and 8,500 directories created

• over 262,000 transactions performed
• read/write ratio is 2:1
• 184GB of memory used
• 18GB cache

E-mail server

• e-mail server worload based on a study
• f e-mail server file sizes
• 1 milion files 1,000 directories
• 1 milion transactions performed
• read/write ratio is 2:1
• 204GB memory used
• 20GB cache

Results

Database

• used database: PostgreSQL
• highest priority for: metadata, user tables, log

files and temporary tables (all in one class)

• index files have lower priority
• 8GB cache

Database results

The end
