Diatomix A Natural Way to Control Algae Blooms Diatomix is a natural solution to control nutrient levels as well as managing problem and toxic algae. Diatomix is a non-toxic, leading-edge nano-technology for water managing waterbodies. Before

SLIDE 1

Diatomix

SLIDE 2

A Natural Way to Control Algae Blooms

Diatomix is a natural solution to control nutrient levels as well as managing problem and toxic algae. Diatomix is a non-toxic, leading-edge nano-technology for water managing waterbodies. After Before

SLIDE 3

How Does It Work?

By boosting diatom growth, Diatomix

moves nutrients into the food chain

Diatoms can out-compete blue-green

algae and other problem plant life for the Nitrogen and Phosphorus (N and P) in the water

N and P in the water are converted into

zooplankton, invertebrates and fish biomass, so a healthy balance is restored to the waterbody

SLIDE 4

What are Diatoms?

At the bottom of the food chain,

diatoms are a diverse group of algae and are one of the most common types

f organism found in oceans, lakes

and freshwater ecosystems

Diatoms are a major food source for

zooplankton which in turn are the primary food for invertebrates, fish, and other organisms.

SLIDE 5

Diatomix is a nano-silica based micro-nutrient liquid solution
1 litre of Diatomix promotes the growth of 200 to 1,000 kg of diatoms

and can convert up to 80 kg of Inorganic Nitrogen into animal biomass (zooplankton, insects, fish, eels, birds, etc.)

Diatomix contains: Nano-silica and ten micronutrients:

Iron, Manganese, Cobalt, Molybdenum, Calcium, Boron, Copper, Magnesium, Zinc and Potassium

SLIDE 6

Council Trial

STP site - Started 8 Feb 2016 Finished on 3 June 2016

Dosing rate for the trial was 0.1 mL/m2/week
Total Blue Green Algae reduction was 99.4% by end of trial

SLIDE 7

0.02 0.04 0.06 0.08 0.1 0.12 0.14

500,000

1,000,000 1,500,000 2,000,000 2,500,000 3,000,000 31/01/2016 20/02/2016 11/03/2016 31/03/2016 20/04/2016 10/05/2016 30/05/2016

Diatomix dose added (mL/m2/week) Cells/mL Total BGA Total Cells Diatomix Dose

Council Trial

STP site

SLIDE 8

Council Trial

STP site

SLIDE 9

10 February 11 February 12 February 14 February 29 February 4 March

Council Trial

STP site

SLIDE 10

4 March 10 February

Council Trial

STP site

SLIDE 11

The New Plan

Controlling Blue Green Algae

(BGA) with Diatomix works

Started dosing in winter

before the problem arises, for easier control

Automated dosing station

reduces OPEX and operator time

Council Trial

STP site

SLIDE 12

Site 1 - Prior to trial start Four months into trial

Utility Trial

Trialled at three of their sites Dosing rates for trials ranged from 0.08 to 1.0 mL/m2/week depending upon the nitrogen concentration of the lagoon (11 to 37 mg/L Total Nitrogen)

SLIDE 13

0.00 0.05 0.10 0.15 0.20 0.25

500,000

1,000,000 1,500,000 2,000,000 2,500,000 3,000,000 3,500,000 4,000,000

6/04/2015 15/07/2015 23/10/2015 31/01/2016 10/05/2016

Diatomix Dose (mL/m2/week) Cells/mL Total BGA Total Cells Diatomix dose

< Cell Count peaked at 9.2 million cells/mL. Several large blooms over Autumn. Large Rain Event -> First bloom after starting dosing -> Settled activity over Summer <- Large Rain Event

Utility Number 1

Trial Site 1

SLIDE 14

0.2 0.4 0.6 0.8 1 1.2

1,000,000

2,000,000 3,000,000 4,000,000 5,000,000 6,000,000 7,000,000 8,000,000 26/04/2015 15/06/2015 4/08/2015 23/09/2015 12/11/2015 1/01/2016 20/02/2016

Diatomix Dose (mL/m2/week) Cells/mL Lagoon 1 Total BGA Lagoon 3 Total BGA Lagoon 1 Total Cells Lagoon 3 Total Cells Lagoon 1 Diatomix dose Lagoon 3 Diatomix dose

Utility Number 1

Trial Site 2

SLIDE 15

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 500,000 1,000,000 1,500,000 2,000,000 2,500,000 3,000,000 3,500,000 4,000,000 8/10/2015 17/11/2015 27/12/2015 5/02/2016 16/03/2016

Diatomix dose (mL/m2/week) Cells/mL Lagoon 1 Total BGA Lagoon 2 Total BGA Lagoon 3 Total BGA Lagoon 1 Total Cells Lagoon 2 Total Cells Lagoon 3 Total Cells L2 Diatomix dose L3 Diatomix dose

Utility Number 1

Trial Site 3

SLIDE 16

6 6.5 7 7.5 8 8.5 9 9.5 10 10.5 11

17/05/2011 3/07/2012 30/07/2013 7/10/2014 1/12/2015

pH Winter Summer Diatomix Winter Diatomix Summer

Utility Number 2

Trial Site 1

SLIDE 17

Site 2 - Storage Dam Changes in Appearance

Start Trial 2 29 September 2015 Mid Trial 2 3 November 2015

SLIDE 18

Site 2 - Algae Counts during two trial periods

1 2 3 4 5 6 7 8 4 5 6 7 8 9 10 11 05 May 19 May 02 Jun 16 Jun 30 Jun 14 Jul 28 Jul 11 Aug 25 Aug 08 Sep 22 Sep 06 Oct 20 Oct 03 Nov 17 Nov 01 Dec 15 Dec

Blue Green Algae Counts (cells/mL) Millions pH 2015 pH Blue Green Algae

Operational Dosing Post Trial Sampling Operational Dosing Background Sampling

STP failed during this period

SLIDE 19

Site 2 - STP Improvement Options

Improvements Cost Includes Full Upgrade Capital Cost: $15 million Two parallel decant tanks, dosing unit + pH correction + increasing sludge removal Increase Land Disposal Area Available Capital Cost: $2 to 5 million Land cost (if available) + cost

f pipes and irrigation set up

STP Chemical Phosphorus Removal Capital Cost: $1 to 2 million Dosing unit + pH correction + increasing sludge removal Diatomix Dosing Capital Cost: $2,800 Operational Cost: $5,200 Diatomixer unit + 40 litres of Diatomix

SLIDE 20

Contact Details

Dr Simon Tannock is the Director of AlgaEnviro

Mobile: 0406 506 536 Email: simon@algaenviro.com.au

For more information please visit our website: www.algaenviro.com.au
