Diagnosis and new classification Prof. Dr. Adriaan Voors University Medical Center Groningen the Netherlands Treatment of Diabetes in HF Disclosures AAV received consultancy fees and/or research grants from: Alere, AstraZeneca, Bayer,

slide-1
SLIDE 1

Diagnosis and new classification

  • Prof. Dr. Adriaan Voors

University Medical Center Groningen the Netherlands

slide-2
SLIDE 2

Treatment of Diabetes in HF

University Medical Center Groningen

Disclosures

  • AAV received consultancy fees and/or research grants from: Alere,

AstraZeneca, Bayer, BMS, Boehringer, Cardio3Biosciences, Merck/MSD, Novartis, Servier, Singulex, Sphingotec, Stealth, Trevena, Vifor.

  • AAV is supported by a grant from the European Commission: FP7-

242209-BIOSTAT-CHF

  • AAV is Clinical Established Investigator and supported by other

grants of the Dutch Heart Foundation

slide-3
SLIDE 3

www.escardio.org/guidelines

3

slide-4
SLIDE 4

www.escardio.org/guidelines

4

Now online available

http://www.escardio.org/Guidelines-&-Education/Clinical-Practice- Guidelines/Acute-and-Chronic-Heart-Failure

slide-5
SLIDE 5

www.escardio.org/guidelines

Key Points

  • Definition
  • New Classification HFrEF/HFpEF
  • Diagnosis of Heart Failure (general)
  • (NT-pro)BNP cut-offs
  • Diagnosis of HFpEF
  • Assessment of Diastolic Dysfunction

5

slide-6
SLIDE 6

www.escardio.org/guidelines

Definition

  • HF is a clinical syndrome characterized by typical

symptoms (e.g. breathlessness, ankle swelling and

fatigue) that may be accompanied by signs (e.g. elevated jugular venous pressure, pulmonary crackles and peripheral oedema) caused by a structural and/or

functional cardiac abnormality, resulting in a

reduced cardiac output and/or elevated intracardiac pressures at rest or during stress

6

slide-7
SLIDE 7

www.escardio.org/guidelines

Key Points

  • Definition
  • New Classification HFrEF/HFpEF
  • Diagnosis of Heart Failure (general)
  • (NT-pro)BNP cut-offs
  • Diagnosis of HFpEF
  • Assessment of Diastolic Dysfunction

7

slide-8
SLIDE 8

www.escardio.org/guidelines

Hands-up Question 1

  • Which LVEF cut-off to use for HFrEF?
  • A) ≤ 35%
  • B) ≤ 40%
  • C) ≤ 45%
  • D) ≤ 50%

8

slide-9
SLIDE 9

www.escardio.org/guidelines

Hands-up Question 2

  • Which LVEF cut-off to use for HFpEF?
  • A) ≥ 35%
  • B) ≥ 40%
  • C) ≥ 45%
  • C) ≥ 50%

9

slide-10
SLIDE 10

www.escardio.org/guidelines

10

“The middle child of HF deserves attention: available data suggest that it constitutes a sizeable proportion (10–20%) of the HF population, has a unique clinical, echocardiographic, haemodynamic, and biomarker profile compared with HFrEF and HFpEF, and carries a poor prognosis. Large gaps in evidence regarding its treatment warrant further study.”

slide-11
SLIDE 11

www.escardio.org/guidelines

  • TOPCAT:n=3444; EF≥45%;
  • spironolactone vs. placebo
  • Primary outcome: neutral
  • HFmrEF greater treatment

effect than HFpEF

11

Solomon et a;. EHJ 2016

slide-12
SLIDE 12

www.escardio.org/guidelines

Heart Failure with mid-range Ejection Fraction (HFmrEF)

Justification for the introduction of HFmrEF

  • Grey area between 40-50 %; HFpEF or HFrEF?
  • EF 40-49% different phenotype compared with EF>50%
  • Potentially differential treatment effects
  • “ Identifying HFmrEF as a separate group will stimulate

research into the underlying characteristics, pathophysiology and treatment of this group of patients”

12

slide-13
SLIDE 13

www.escardio.org/guidelines

New Classification of Heart Failure

13

slide-14
SLIDE 14

www.escardio.org/guidelines

Key Points

  • Definition
  • New Classification HFrEF/HFpEF
  • Diagnosis of Heart Failure (general)
  • (NT-pro)BNP cut-offs
  • Diagnosis of HFpEF
  • Assessment of Diastolic Dysfunction

14

slide-15
SLIDE 15

www.escardio.org/guidelines

Diagnostic algorithm for a diagnosis of heart failure of non- acute onset

slide-16
SLIDE 16

www.escardio.org/guidelines

Diagnostic algorithm for a diagnosis of heart failure of non-acute onset

slide-17
SLIDE 17

www.escardio.org/guidelines

17

Natriuretic Peptides: cut-offs for EXCLUSION

Roberts E, et al.. BMJ 2015; Zaphiriou A, et al. Eur J Heart Fail 2005; Fuat A, et al. Br J Gen Pract 2006;Yamamoto K, et al. J Card Fail 2000; Cowie MR, et al. Lancet 1997; Krishnaswamy P, et al. Am J Med 2001; Kelder JC, et al. J Card Fail 2011.

slide-18
SLIDE 18

www.escardio.org/guidelines

18

NT-proBNP cut-off in Non- Acute Setting

slide-19
SLIDE 19

www.escardio.org/guidelines

Natriuretic Peptides: cut-offs for EXCLUSION

  • “ At the mentioned exclusionary cut-points, the negative

predictive values are very similar and high (0.94–0.98) in both the non-acute and acute setting, but the positive predictive values are lower both in the non-acute setting (0.44–0.57) and in the acute setting (0.66–0.67).54,56 – 61

Therefore, the use of NPs is recommended for ruling-out HF, but not to establish the diagnosis.”

19

slide-20
SLIDE 20

www.escardio.org/guidelines

Key Points

  • Definition
  • New Classification HFrEF/HFpEF
  • Diagnosis of Heart Failure (general)
  • (NT-pro)BNP cut-offs
  • Diagnosis of HFpEF
  • Assessment of Diastolic Dysfunction

20

slide-21
SLIDE 21

www.escardio.org/guidelines

Definition

  • HF is a clinical syndrome characterized by typical symptoms

(e.g. breathlessness, ankle swelling and fatigue) that may be accompanied by signs (e.g. elevated jugular venous pressure, pulmonary crackles and peripheral oedema)

caused by a structural and/or functional cardiac abnormality, resulting in a reduced cardiac

  • utput and/or elevated intracardiac pressures at rest or

during stress.

21

slide-22
SLIDE 22

www.escardio.org/guidelines

New Classification of Heart Failure

22

slide-23
SLIDE 23

www.escardio.org/guidelines

Echocardiographic HFpEF/HFmrEF criteria for “structural and/or functional cardiac abnormality”

  • How? Which parameters? Which cut-offs?

23

Paulus WJ, et al. Eur Heart J 2007; Dokainish H, et al. Eur J Echocardiogr 2011; Caballero L, et al. Eur Heart J Cardiovasc Imaging 2015. Lang RM, et

  • al. Eur Heart J Cardiovasc Imaging 2015; Cohen GI, et al. J Am Coll Cardiol

1996; Gilman G, et al. J Am Soc Echocardiogr 2007; Nagueh SF, et al. Eur J Echocardiogr 2009; Nishimura RA, et al. J Am Coll Cardiol 1996; Ommen SR, et al. Circulation 2000;102:1788–1794.

slide-24
SLIDE 24

www.escardio.org/guidelines

24

Diagnosis of HFpEF/HFmrEF

  • Limited data (Unmet Need!)
  • Cut-offs arbitrary
  • More criteria; greater

certainty of diagnosis

  • Diastolic stress test?
  • Invasive hemodynamic

measurements? HFpEF: EF≥50% HFmrEF: EF 40-49%

Signs (± symptoms) of HF

Structural abnormalities Functional abnormalities

LAVI >34ml/m2 LVMI >115g/m2 (m) >95 g/m2 ( f ) E/e‘avg ≥ 13 e‘ average (lateral-septal) < 9 cm/s

+ +

slide-25
SLIDE 25

www.escardio.org/guidelines

Conclusions: Diagnosis and new classification

  • Definition: No symptoms, no heart failure
  • New Classification: Addition of HFmrEF
  • Diagnosis of Heart Failure: New diagnostic algorithm
  • (NT-pro)BNP cut-offs for exclusion
  • Diagnosis of HFpEF: structural (LAVI>34 mL/m2 or LVMI ≥115

g/m2 (m) ≥95 g/m2 (f) ) of functional (E/e′ ≥13 mean e’ < 9 cm/s) abnormalities

25
