Developing a Whole School Approach to Problem Solving and Word Problems Day 1 Dr Paul Swan and David Dunstan Dr Paul Swan and David Dunstan Developing a Whole School Approach www.drpaulswan.com.au | 1 Proficiency and Content Strands Dr Paul

slide-1
SLIDE 1

www.drpaulswan.com.au |

Developing a Whole School Approach to Problem Solving and Word Problems Day 1

Dr Paul Swan and David Dunstan

Dr Paul Swan and David Dunstan Developing a Whole School Approach 1

slide-2
SLIDE 2

www.drpaulswan.com.au |

Proficiency and Content Strands

Dr Paul Swan and David Dunstan Developing a Whole School Approach 2

slide-3
SLIDE 3

www.drpaulswan.com.au |

What is a problem?

  • A problem is a situation where there is no obvious method of solution.
  • There is no basic routine to follow in order to solve the problem.
  • Students need to think about it.

Dr Paul Swan and David Dunstan Developing a Whole School Approach 3

slide-4
SLIDE 4

www.drpaulswan.com.au |

Four Stages of Problem Solving

Dr Paul Swan and David Dunstan Developing a Whole School Approach 4

  • (See)
  • (Plan)
  • (Do)
  • (Check)
  • Understand the problem
  • Devise a plan
  • Carry out the plan
  • Look back

Polya It is better to solve one problem many ways, than many problems one way.

slide-5
SLIDE 5

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 5

Download the 16 page KenKen booklet from www.drpaulswan.com.au Go to the Resources section

slide-6
SLIDE 6

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 6

slide-7
SLIDE 7

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 7

A 4 by 4 grid. The digits 1, 2, 3 and 4 are used. The operation is Addition.

slide-8
SLIDE 8

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 8

Always fill the ‘Freebie’ cells. The ‘Target Number (TN)’ is given. For example, in the bottom LHC, the TN is 1.

3 1

slide-9
SLIDE 9

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 9

Look at the Green horizontal 2-cell Cage. A Cage is defined by the heavy outline and includes the TN and generally, the operation. Why must the top LHC be ‘2’? Each row and column must use the digits 1, 2, 3 and 4, with NO REPEATS. For a sum of 3, only 1 and 2 are used. In the first column, 1 cannot be repeated.

3 1 2

slide-10
SLIDE 10

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 10

Another Strategy! Why must the top LHC be ‘2’? Each row and column add to 10. So in the first column, 1 + 7 = 8 and 2 more makes 10 (or, 10 – 8 = 2).

3 1 2

slide-11
SLIDE 11

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 11

In the RED cage, the sum of 7 can only be made with 3 and 4,

  • r 4 and 3.

Due to the NO REPEAT rule, in row 3, the red cell must be a 4.

3 1 2 1 3 4

slide-12
SLIDE 12

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 12

Why is the bottom RHC = 2? 2 = 10 – (5 + 3) [each row and column adds to 10], or For two digits to make a sum of 5 (PINK cage), the possible number sets are (1,4), (4,1), (2,3) and (3,2). Thus the 2 must go in the bottom RHC.

3 1 2 1 3 4 2 4

slide-13
SLIDE 13

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 13

Remember, No Repeats; so ‘4’ goes in the Top RHC (1 cannot go there).

3 1 2 1 3 4 2 4 1 4

slide-14
SLIDE 14

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 14

Complete the top and bottom rows.

3 1 2 1 3 4 2 4 1 4 3 3

slide-15
SLIDE 15

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 15

Complete the remaining cells. Kengratulations!

3 1 2 1 3 4 2 4 1 4 3 3 1 2 4 2

slide-16
SLIDE 16

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 16

A 4 by 4 Grid. The digits 1, 2, 3 and 4 are used. The operation is Addition. No Freebies.

slide-17
SLIDE 17

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 17

To make a sum of 3, use 1 and 2. To make a sum of 4, use 1 and 3. So why must 3 be in the top LHC?

3 1

slide-18
SLIDE 18

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 18

Why MUST ‘4’ go in the bottom LHC? First column, 10 – (3 + 3) = 4

4 3 1

slide-19
SLIDE 19

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 19

Complete the PINK cage.

4 3 1 2 1 2

slide-20
SLIDE 20

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 20

Complete the RED cage. Remember, No Repeats of ‘1’ in the second row.

4 3 1 2 1 2 1 2

slide-21
SLIDE 21

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 21

Complete the YELLOW cage.

4 3 1 2 1 3 4 2 1 2

slide-22
SLIDE 22

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 22

Complete the GREY cage.

4 3 1 2 1 1 3 3 4 2 1 2

slide-23
SLIDE 23

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 23

Complete the remaining cages.

2 4 3 1 2 1 1 3 3 4 2 4 3 4 1 2

slide-24
SLIDE 24

www.drpaulswan.com.au |

Expe pert! Wher ere e is a s a st strateg egic st starting c cel ell?

slide-25
SLIDE 25

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 25

“Thinking Clouds” can be used to assess student reasoning. Students can also add in their

  • wn “Thinking Clouds” to

demonstrate their reasoning

  • ability. Dating these records will

assist teachers to monitor student progress.

slide-26
SLIDE 26

www.drpaulswan.com.au |

Partitions of 10

How many different ways can you partition (split) 10? 3 and 7 3 and 3 and 2 and 1 and 1

Dr Paul Swan and David Dunstan Developing a Whole School Approach 26

slide-27
SLIDE 27

www.drpaulswan.com.au |

42 Partitions of 10

Dr Paul Swan and David Dunstan Developing a Whole School Approach 27

slide-28
SLIDE 28

www.drpaulswan.com.au |

Decide what digits go in the boxes?

  • Can you find a solution?
  • How many solutions do you think there might be?
  • How will you know when you have found them all?

Dr Paul Swan and David Dunstan Developing a Whole School Approach 28

Hurst, C. (2011). Connecting with the Australian Curriculum: Integrating learning through the proficiency strands. In J. Clark, B. Kissane, J. Mousley, T. Spencer, &

  • S. Thornton (Eds.). Mathematics: Traditions and [New] Practices (Proceedings of the 34th annual conference of the Mathematics Education Research Group of

Australasia and the Australian Association of Mathematics Teachers), pp. 973-980. Adelaide: AAMT and MERGA.

slide-29
SLIDE 29

www.drpaulswan.com.au |

Questions

  • What sort of a number sentence do we have?
  • How big are the numbers?
  • What do we know about the numbers?
  • What digits could be in the ones place?
  • What numbers can we multiply together to make a number ending in 6?

Dr Paul Swan and David Dunstan Developing a Whole School Approach 29

slide-30
SLIDE 30

www.drpaulswan.com.au |

Hints

  • 1, 6 what about 6, 1?
  • 2, 3
  • 6, 6 Can you use a digit more than once?
  • 2, 8
  • 7, 8
  • 4, 4
  • 4, 9

Dr Paul Swan and David Dunstan Developing a Whole School Approach 30

slide-31
SLIDE 31

www.drpaulswan.com.au |

Open – Ended Tasks

Dr Paul Swan and David Dunstan Developing a Whole School Approach 31

Every school should buy at least one copy

slide-32
SLIDE 32

www.drpaulswan.com.au |

One example

  • I have three coins in my hand, How much money might I have?

Dr Paul Swan and David Dunstan Developing a Whole School Approach 32

  • From Open – Ended Maths Activities, Sullivan and Lilburn
slide-33
SLIDE 33

www.drpaulswan.com.au |

I have three coins in my hand. How much money do I have?

Some Prompts:

What is the lowest total? What is the highest total? Can any totals be made in more than one way? What are all the possible totals? How will you know when you have all of the solutions? (Parallel Problems)

Dr Paul Swan and David Dunstan Developing a Whole School Approach 33

slide-34
SLIDE 34

www.drpaulswan.com.au |

slide-35
SLIDE 35

www.drpaulswan.com.au |

Solve a simpler – related problem: 2 Coins

Dr Paul Swan and David Dunstan Developing a Whole School Approach 35

slide-36
SLIDE 36

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 36

slide-37
SLIDE 37

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 37

slide-38
SLIDE 38

www.drpaulswan.com.au |

Is it the Maths or Literacies that is the Problem?

Newman Analysis 5 Pr Prom

  • mpts
  • 1. Please read the question to me. If you don't know a word, leave it out

(Decoding)

  • 2. Tell me what the question is asking you to do (Comprehending)
  • 3. Tell me how you are going to find the answer (Transforming)

Dr Paul Swan and David Dunstan Developing a Whole School Approach 38

slide-39
SLIDE 39

www.drpaulswan.com.au |

Newman Analysis

cont

  • 4. Show me what to do to get the answer. "Talk aloud" as you do it, so that I

can understand how you are thinking (Applying)

  • 5. Now, write down your answer to the question (Encoding into required

format)

Dr Paul Swan and David Dunstan Developing a Whole School Approach 39

slide-40
SLIDE 40

www.drpaulswan.com.au |

Word Problems

  • “70% of errors made by students on standard

word problems could be attributed to lack of comprehension”(Clements, 2004)

  • However,

“There is significant research evidence that reveals that recognising words in isolation does not necessarily mean they will be recognised as quickly in connected text.”

(Ehri, 1997)

Dr Paul Swan and David Dunstan Developing a Whole School Approach 40

slide-41
SLIDE 41

www.drpaulswan.com.au |

Maths Literacies – Jigsaw

  • What do we mean by this term?
  • 1. Vocabulary and Comprehension;
  • 2. The Structure of Word Problems;
  • 3. Graphics in Mathematics; and
  • 4. Symbols in Mathematics.

Text organisation is also very significant in problem solving.

Dr Paul Swan and David Dunstan Developing a Whole School Approach 41

slide-42
SLIDE 42

www.drpaulswan.com.au |

Literacy and Mathematics

  • Classroom Discussion
  • Effect Size 0.82
  • Vocabulary Programs
  • Effect Size 0.67

Hattie et al (2017). Visible Learning for Mathematics

Dr Paul Swan and David Dunstan Developing a Whole School Approach 42

slide-43
SLIDE 43

www.drpaulswan.com.au |

Vocabulary

  • Vocabulary knowledge begets comprehension (and vice versa)
  • Students need 90-95% automatic word recognition to provide necessary

context to allow for comprehension to occur

Hi Hirs rsch an and Nat ation 19 1992

Dr Paul Swan and David Dunstan Developing a Whole School Approach 43

slide-44
SLIDE 44

www.drpaulswan.com.au |

Vocabulary

Worth Paying Attention To? Marzano (2004) found that teaching academic vocabulary could positively influence standardized test scores by as much as 33%.

  • Dr. Madeline Kovarik, Building Mathematics Vocabulary,

International Journal for Mathematics Teaching and Learning, Oct 2010

Dr Paul Swan and David Dunstan Developing a Whole School Approach 44

slide-45
SLIDE 45

www.drpaulswan.com.au |

Definitions: Help or Hindrance

Read

Annul nulus us

Explain Define

Dr Paul Swan and David Dunstan Developing a Whole School Approach 45

Swan, P ., (2018). The impact of vocabulary on numeracy. The Australian Primary Mathematics Classroom. 23, 4.

slide-46
SLIDE 46

www.drpaulswan.com.au |

Structure of Word Questions

Dr Paul Swan and David Dunstan Developing a Whole School Approach 46

First steps in Mathematics Number – Book 2 Pages 89 and 90. http://det.wa.edu.au/stepsresources/detcms/navigati

  • n/first-steps-mathematics/

First Steps in Number - Book 2: Understand Operations Calculate Reason About Number Patterns

slide-47
SLIDE 47

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 47

slide-48
SLIDE 48

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 48

slide-49
SLIDE 49

www.drpaulswan.com.au |

Graphic Help or Hinderance?

  • NAPLAN 2016 Yr5 q19

Dr Paul Swan and David Dunstan Developing a Whole School Approach 49

slide-50
SLIDE 50

www.drpaulswan.com.au |

Symbols

  • Simply recalling what a symbol says is often not enough. Students need

to understand what it actually means and the conceptual implications.

  • Consider the equal sign ( = ) as an example here.

Dr Paul Swan and David Dunstan Developing a Whole School Approach 50

slide-51
SLIDE 51

www.drpaulswan.com.au |

Critical Thinking Puzzles (rods)

  • Three rods
  • All different
  • Train is as long as blue
  • Longest rod is shorter than yellow

Dr Paul Swan and David Dunstan Developing a Whole School Approach 51

slide-52
SLIDE 52

www.drpaulswan.com.au |

Reasoning with Rods

  • For further puzzles see

Dr Paul Swan and David Dunstan Developing a Whole School Approach 52

slide-53
SLIDE 53

www.drpaulswan.com.au |

Can you make it an inquiry task?

Dr Paul Swan and David Dunstan Developing a Whole School Approach 53

Four Fours Using only four 4’s and any operation, make the numbers 1 to 20, inclusive. Extension: Can you find the numbers 21 to 50? Can you find the numbers 1 to 20 using Five 5’s?

slide-54
SLIDE 54

www.drpaulswan.com.au |

Can you make it an inquiry task?

Dr Paul Swan and David Dunstan Developing a Whole School Approach 54

Mystery Spinner Pages 141 – 144 Years 5 - 8

slide-55
SLIDE 55

www.drpaulswan.com.au | Dr Paul Swan and David Dunstan Developing a Whole School Approach 55

slide-56
SLIDE 56

www.drpaulswan.com.au |

Leadership: Adopt a Menu Approach

Dr Paul Swan and David Dunstan Developing a Whole School Approach 56

slide-57
SLIDE 57

www.drpaulswan.com.au |

Menus

  • It is one thing to know a word
  • It is quite another thing to use it
  • Menu provides the opportunity for children to use words
  • Leadership
  • Teachers can try and report
  • Everyone can own/lead something

Dr Paul Swan and David Dunstan Developing a Whole School Approach 57

slide-58
SLIDE 58

www.drpaulswan.com.au |

E.L.P.S

Experience Language Picture Symbols

Liebeck, P . (1991). How children learn mathematics. Penguin

Dr Paul Swan and David Dunstan Developing a Whole School Approach 58

slide-59
SLIDE 59

www.drpaulswan.com.au |

Mystery Bag

Dr Paul Swan and David Dunstan Developing a Whole School Approach 59

slide-60
SLIDE 60

www.drpaulswan.com.au |

9 Card Bingo

Dr Paul Swan and David Dunstan Developing a Whole School Approach 60 From
