Design, status and perspective of the Mu2e crystal calorimeter

Gianantonio Pezzullo

INFN of Pisa

• n behalf of the Mu2e calorimeter group

• G. Pezzullo (INFN of Pisa)

TIPP’17 - May 22 2017

2

Outline

• The Mu2e experiment
• Calorimeter design
• The role of the calorimeter in Mu2e
• R&D
• Conclusion

• G. Pezzullo (INFN of Pisa)

TIPP’17 - May 22 2017

3

The Mu2e collaboration

Argonne National Laboratory, Boston University, Brookhaven National Laboratory University of California, Berkeley, University of California, Irvine, California Institute of Technology, City University of New York, Joint Institute for Nuclear Research, Dubna, Duke University, Fermi National Accelerator Laboratory, Laboratori Nazionali di Frascati, Helmholtz-Zentrum Dresden-Rossendorf, University of Houston, University of Illinois, INFN Genova, Kansas State University, Lawrence Berkeley National Laboratory, INFN Lecce and Università del Salento, Lewis University, University of Louisville, Laboratori Nazionali di Frascati and Università Marconi Roma, University of Minnesota, Muons Inc., Northern Illinois University, Northwestern University, Novosibirsk State University/Budker Institute of Nuclear Physics, Institute for Nuclear Research, Moscow, INFN Pisa, Purdue University, Rice University, University of South Alabama, Sun Yat Sen University, University of Virginia, University

• f Washington,

Yale University

~200 scientists from 35 institutions

• G. Pezzullo (INFN of Pisa)

TIPP’17 - May 22 2017

4

What is µ→e conversion

• μ converts to an electron in the presence of a nucleus

Ee = mµ c2 - Bµ(Z) - C(A) = 104.973 MeV

Bµ(Z) is the muon binding energy (0.48 MeV) C(A) is the nuclear recoil energy (0.21 MeV)

µ−N → e−N

{

• for Aluminum:

νMSM Muon conversion : R≈10-52 Supersymmetry : R ≤10-13 Heavy neutrino Lepto-quark
 exchange Z’ exchange Effective contact interaction

νN

w w

µ- q q e-

νi

• μ conversion in the SM is induced by neutrino masses and mixing at a

negligible level ~ 10-52

• Many SM extensions enhance the rate through mixing in the high

energy sector of the theory (other particles in the loop…)

• G. Pezzullo (INFN of Pisa)

TIPP’17 - May 22 2017

Hinks and Pontecorvo TRIUMF SINDRUM II Lagarrigue and Peyrou

Limit @ 90% CL

5

• Mu2e will improve by a factor 104 the present best limit!

Historical perspective

Mu2e II

arXiv:1307:5787

TIPP’17 - May 22 2017

• G. Pezzullo (INFN of Pisa)

6

Experimental setup

calorimeter tracker cosmic ray veto Al stopping
 target

(1) (2) (3)

(1) Production Solenoid: ➡ Proton beam strikes target, producing mostly pions ➡ Graded magnetic field contains backwards pions/muons and reflects slow forward pions/muons
 (2) Transport Solenoid: ➡ Select low momentum, negative muons ➡ Antiproton absorber in the mid-section
 (3) Detector Solenoid: ➡ Capture muons on Al target ➡ Measure momentum in tracker and energy in calorimeter ➡ Graded field “reflects” downstream conversion electrons emitted upstream


8 GeV protons

TIPP’17 - May 22 2017

• G. Pezzullo (INFN of Pisa)

7

Calorimeter design

• 2 disks; each disk contains 678 undoped CsI crystals 20 x 3.4 x 3.4 cm3
• Disk separation ~ 75 cm
• Inner/outer radii: 37.4/66 cm
• Crystal choice: undoped CsI provides light yield (LY) > 100 pe/MeV,

longitudinal response uniformity
 < 10%, emission decay time 𝛖 ~ 16 ns

• Photosensor choice: custom array


2x3 of 6x6 mm2 UV-extended SiPM

SiPM array + FEE (I. Sarra talk) undoped CsI (R. Y. Zhu talk)

TIPP’17 - May 22 2017

• G. Pezzullo (INFN of Pisa)

8

Calibration methods

• Liquid source FC 770 + DT generator: 6 MeV + 2 escape peaks
• Laser system to monitor SiPM performance

10k entries/crystal/min Liquid source prototype Laser system - test station

TIPP’17 - May 22 2017

• G. Pezzullo (INFN of Pisa)

R [mm] 400 450 500 550 600 650 Dose [krad/ year]

3 −

10

2 −

10

1 −

10 1 10

2

10

3

10

Total FLASH DEUTERON OOT PHOTON NEUTRON PROTON DIO

R [mm] 400 450 500 550 600 650 Dose [krad/ year]

3 −

10

2 −

10

1 −

10 1 10

2

10

3

10

9

Radiation Environment

SiPM dose

R [mm] 400 450 500 550 600 650 /year]

2

1 MeV-eq [# /cm

n

φ

8

10

9

10

10

10

11

10

12

10

13

10

SiPM
 neutron-damage

• High level of dose impact on Si devices and crystals performance

crystal dose

TIPP’17 - May 22 2017

• G. Pezzullo (INFN of Pisa)

10

Simulation results

pile-up separation CE + background

• Offline simulation including background hits
• Experimental effects included: longitudinal response uniformity (LRU),

electronic noise, digitization, etc

• Waveform-based analysis to improve pileup separation

TIPP’17 - May 22 2017

• G. Pezzullo (INFN of Pisa)

11

PID: e/µ separation

e

t [ns] ∆ 20 − 15 − 10 − 5 − 5 10 15 20 Entries / 0.20 ns 2000 4000 6000 8000 10000 12000

e

µ

/ ndf

χ 322.2 / 57 Constant 14.5 ± 2429 Mean 0.010 ± 5.375 − Sigma 0.009 ± 1.671

µ

/ ndf

χ 322.2 / 57 Constant 14.5 ± 2429 Mean 0.010 ± 5.375 − Sigma 0.009 ± 1.671

CE @ 105 MeV/c µ

E/p 0.2 0.4 0.6 0.8 1 1.2 Entries / 0.01 1000 2000 3000 4000 5000 6000

CE @ 105 MeV/c µ

µ mimicking the CE

Al target tracker calorimeter

• 105 MeV/c e- are ultra-relativistic, while

105 MeV/c µ have β~ 0.7 and a kinetic energy of ~ 40 MeV

• Likelihood rejection combines


𝚬t = ttrack - tcluster and E/p:

ln Le,µ = ln Pe,µ(∆t) + ln Pe,µ(E/p)

TIPP’17 - May 22 2017

• G. Pezzullo (INFN of Pisa)

12

Calo seeded track finder

• Cluster time and position are used for filtering the straw hits:

✓ time window of ~ 80 ns ✓ spatial correlation

no selection calorimeter selection

• black crosses = straw hits, red circle = calorimeter cluster,


green line = CE track

TIPP’17 - May 22 2017

• G. Pezzullo (INFN of Pisa)

13

Calorimeter trigger

Hit pre-selection helix search Kalman filter

ϵce ϵce

Bkg rejection

Standalone calorimeter Cali-Seeded track finder

• Calo info can provide additional trigger capabilities in Mu2e:
• Calorimeter seeded track finder:

✓ factorized into 3 steps: hit pre-selection, helix search and track fit

✓ ϵ ~95% for a background rejection of 200

• Standalone calorimeter trigger that uses only calo info:

✓ ϵ ~65% for a background rejection of 200

TIPP’17 - May 22 2017

• G. Pezzullo (INFN of Pisa)
• Small prototype tested @ the BTF in Frascati during April 2015
• Array 3 x 3 with undoped CsI 3 x 3 x 20 cm3


coupled with Hamamatsu MPPC

• All channels were read out with the 12 bit


250 Msps waveform digitizer board V1720

14

Test with small prototype

h

Entries Mean 0 RMS 0

Energy [GeV] 0.02 0.03 0.04 0.05 0.06 0.07 0.08 0.09 [ns]

t

σ 0.05 0.1 0.15 0.2 0.25 0.3

h

Entries Mean 0 RMS 0 / ndf

2

χ 38 / 17 a 0.00015 ± 0.0049 b 0.0033 ± 0.087 / ndf

2

χ 38 / 17 a 0.00015 ± 0.0049 b 0.0033 ± 0.087

b ⊕ = a/E

t

σ

Single crystal @ 0 deg All crystals above 10 MeV @ 0 deg Cosmics Neighboring crystals @ 50 deg Single crystal @ 50 deg Most energetic crystal @ 50 deg All crystals above 10 MeV @ 50 deg

Total energy [GeV] 0.07 0.075 0.08 0.085 0.09 0.095 0.1 0.105 /E [%]

E

σ 4 4.5 5 5.5 6 6.5 7 7.5 8 8.5 9

/ ndf

2

χ 2.866 / 3 a 0.3253 ± 1.38 b 1.092 ± 4.911 / ndf

2

χ 2.866 / 3 a 0.3253 ± 1.38 b 1.092 ± 4.911

data Monte Carlo

b ⊕ E [GeV] a = E

E

σ

Calorimeter prototype

Energy [GeV] Energy [GeV] σt [ns] σE/E [%]

TIPP’17 - May 22 2017

• G. Pezzullo (INFN of Pisa)

15

New prototype

• Large prototype: 51crystals + 102 SiPM + 102 FEE boards
• Mechanics and cooling system similar to the final ones
• Beam test successfully performed on 4-14 May 2017 @ BTF in Frascati

using e- beam in the range [60, 120] MeV

• Energy & timing resolution studied @ normal and 50 deg incidence
• Analysis is underway

BTF experimental hall

• G. Pezzullo (INFN of Pisa)

TIPP’17 - May 22 2017

16

Conclusions

• The Mu2e calorimeter has been designed to:

✓ operate in a very harsh environment (high ɣ and neutron dose) ✓ provide background rejection capabilities via PID ✓ make the track search more robust against background occupancy ✓ triggering capabilities

• R&D steps well defined

✓ pre-production of crystals and SiPM already started ✓ QA processes of the main components already established ✓ large-scale prototype built and already under test using e- beam

17

backup slides
