DESIGN APPROACH

WHOLISTIC

  • Big picture

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

SITE PLAN

  • Considering future developments
  • Greater connection
  • Utilize the site

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-3
SLIDE 3

DESIGN APPROACH

SITE ISSUES

  • Smell and noise pollution from

Narai Hotel

SITE PLAN

  • Over looking office building
  • Level changes

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

  • Visual barriers
  • Weak entrance experience
slide-4
SLIDE 4

DESIGN APPROACH

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

SITE ISSUES

  • Smell and noise pollution from

neighbours

  • Over looking office building
  • Level changes
  • Visual barriers
  • Weak entrance experience
slide-5
SLIDE 5

DESIGN APPROACH

SOLUTION

  • 2 storey U-shaped building
  • Shield from overlooking building
  • Reduce smell and noise from

Narai Hotel

  • Create large central courtyard
  • Open up central area to connect

with old clubhouse

  • Utilize the site
  • Remove visual barriers

COURTYARD U-SHAPED BUILDING

SITE PLAN

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-6
SLIDE 6

DESIGN APPROACH

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

SOLUTION

  • 2 storey U-shaped building
  • Shield from overlooking building
  • Reduce smell and noise from

Narai Hotel

  • Create large central courtyard
  • Open up central area to connect

with old clubhouse

  • Utilize the site
  • Remove visual barriers
slide-7
SLIDE 7

DESIGN APPROACH

ENHANCEMENT

  • Improved experience

POOLSIDE REDEVELOPMENT INCREASED AREA

SITE PLAN

ROTATE TENNIS COURTS

  • New facilities
  • Broader demographic
  • Family friendly atmosphere
  • New events spaces
  • Relocated office to free up

clubhouse for development

  • Potential to rotate tennis

courts to free up land adjacent to Surawong road

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-8
SLIDE 8

DESIGN APPROACH

SENSE OF PLACE

  • Strong connection between old

and new

  • An architectural timeline
  • Redevelopment will add value to

the British Club NEW OLD

SITE PLAN

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-9
SLIDE 9

DESIGN APPROACH

CONNECTIVITY

  • Linking the old and the new
  • Wider thresholds
  • Extended lawn
  • Central event space
  • Re-routed traffic flow
  • Connection within poolside

area CONNECTION

SITE PLAN

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

IN/OUT PARKING

slide-10
SLIDE 10

DESIGN APPROACH

MULTI-PURPOSE

WEEKEND MARKET SPORTS BAR/ EVENTS INTERACTIVE SQUASH KIDS AREA

SITE PLAN

  • Lawn area is a flexible event

space

  • Squash courts used for Padel

and interactive squash

  • New sports bar and events

space

  • Kids area can be used during

summer camps

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-11
SLIDE 11

DESIGN APPROACH

FUTUREPROOF

  • Advanced IT integrated into

design

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

SITE PLAN

i

  • WIFI in public areas
  • USB charging ports
  • Interactive information screen
slide-12
SLIDE 12

PLANNING OPTION 1

GROUND FLOOR

DEMOLISH EXISTING BUILDINGS

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

DRINKS BAR PLAYGROUND OUTDOOR DINING & SEATING SEATING AREA CHANGING ROOMS KIDS POOL KIDS AREA A/C STAFF HOUSE GUARD HOUSE DRIVER ROOM SURAWONG SALA FEMALE CHANGING MALE CHANGING SPA SQUASH COURT 1 SQUASH COURT 2 SQUASH SOCIAL AREA GAMES ROOM KITCHEN CARE ROOM

slide-13
SLIDE 13

PLANNING OPTION 1

FIRST FLOOR

DEMOLISH EXISTING BUILDINGS

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

SPORTS BAR DANCE STUDIO DANCE STUDIO FITNESS SUITE

slide-14
SLIDE 14

PLANNING OPTION 2

GROUND FLOOR

KEEP PART OF EXISTING BUILDINGS

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

DRINKS BAR PLAYGROUND OUTDOOR DINING & SEATING SEATING AREA DRINKS BAR PLAYGROUND OUTDOOR DINING & SEATING SEATING AREA CHANGING ROOMS KIDS POOL FAMILY AREA STAFF HOUSE GUARD HOUSE DRIVER ROOM SURAWONG SALA FEMALE CHANGING MALE CHANGING SPA SQUASH COURT 1 SQUASH COURT 2 SQUASH SOCIAL AREA STORAGE KITCHEN TOILETS SPA

EXISTING BUILDING

slide-15
SLIDE 15

PLANNING OPTION 2

FIRST FLOOR

KEEP PART OF EXISTING BUILDINGS

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

DANCE STUDIO DANCE STUDIO FITNESS SUITE

slide-16
SLIDE 16
slide-17
SLIDE 17

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-18
SLIDE 18

BRITISHNESS

“The British have a remarkable talent for keeping calm, even when there is no crisis”

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-19
SLIDE 19

FOLDS AND CREASES OFFER ABSTRACT FORMS A CONTEMPORARY TWIST ON A BRITISH CLASSIC

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-20
SLIDE 20

CONCEPT DIAGRAMS

CONCEPT APPLICATION

By draping the iconic Union Jack over the massing, an architectural language is

  • established. Well allow the forms to be

dictated by the unusual geometry of the distorted Union Jack.

BRITISH IDENTITY

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-21
SLIDE 21

CONCEPT DIAGRAMS

CONCEPT APPLICATION

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

By draping the iconic Union Jack over the massing, an architectural language is

  • established. Well allow the forms to be

dictated by the unusual geometry of the distorted Union Jack.

DRAPE & FOLD

slide-22
SLIDE 22

CONCEPT DIAGRAMS

CONCEPT APPLICATION

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

By draping the iconic Union Jack over the massing, an architectural language is

  • established. Well allow the forms to be

dictated by the unusual geometry of the distorted Union Jack.

DECONSTRUCT

slide-23
SLIDE 23

CONCEPT DIAGRAMS

ARCHITECTURAL EXPRESSION ARCHITECTURAL EXPRESSION

A series of pre-fab architectural elements create a unique façade design. A combination of Aluminium louvers, composite wood, perforated metal and vertical gardens produce a striking modern statement for the British Club.

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

ARCHITECTURAL LANGUAGE

ALUMINIUM LOUVERS VERTICAL GARDENS COMPOSITE LOUVERS

slide-24
SLIDE 24

VIEW OF REDEVELOPMENT FROM SILOM ENTRANCE

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-25
SLIDE 25

VIEW OF REDEVELOPMENT FROM LAWN

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-26
SLIDE 26

VIEW OF KIDS PLAY POOL

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-27
SLIDE 27

ISOMETRIC VIEW OF REDEVELOPMENT

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-28
SLIDE 28
slide-29
SLIDE 29

PHASE A PROGRAMME: KIDS AREA, GAMES ROOM, OFFICE SPACE, INTERACTIVE SUITE, SILOM SALA TIME FRAME: 9 MONTHS

PHASING STRATEGY

PHASE A

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-30
SLIDE 30

PHASE B PROGRAMME: SQUASH COURTS, FITNESS SUITE, DANCE STUDIO, KITCHEN, CHANGING ROOMS, SPA TIME FRAME: 11 MONTHS

PHASING STRATEGY

PHASE B

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-31
SLIDE 31

PHASE C (SEPARATE COST ESTIMATE) PROGRAMME: SURAWONG SALA, SPORTS BAR/EVENT SPACE TIME FRAME: 6 MONTHS – NOT IN ORIGINAL BRIEF

PHASING STRATEGY

PHASE C

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-32
SLIDE 32

AREA SCHEDULE & COST ESTIMATE

PLANNING OPTION 1(DEMOLISH EXISTING BUILDING)

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-33
SLIDE 33

AREA SCHEDULE & COST ESTIMATE

PLANNING OPTION 2 (KEEP PART OF EXISTING BUILDING)

POOLSIDE REDEVELOPMENT ARCHITECTURAL CONCEPT DESIGN

slide-34
SLIDE 34
