Design and Calibration of the Jaguar XK Adaptive Cruise Control System

Tim Jagger MathWorks International Automotive Conference 2006

slide-3
SLIDE 3

Page 3

JAGUAR XK

slide-4
SLIDE 4

Page 4

ADAPTIVE CRUISE CONTROL(ACC) MODEL BASED CALIBRATION

  • Adaptive Cruise Control – The Driver’s Perspective
  • The Adaptive Cruise Control System – Control Aspects
  • Jaguar XK Adaptive Cruise Control System
  • Jaguar XK Adaptive Cruise Control Virtual Vehicle Model
  • Model Correlation
  • Jaguar XK Adaptive Cruise Control Calibration Development
  • Queue Assist Development
slide-5
SLIDE 5

Page 5

ADAPTIVE CRUISE CONTROL THE DRIVER’S PERSPECTIVE

  • Driver Comfort Feature
  • Allows Host Vehicle to follow a target vehicle
  • Automatically Resumes to set speed in absence of target vehicle
  • Driver selects headway
  • Available Headways

–

1.0s, 1.4s, 1.8s, 2.2s

  • Driver Selects Cruise Speed

–

  • Min. 20mph, Max. 112mph
slide-6
SLIDE 6

Page 6

ADAPTIVE CRUISE CONTROL CONTROL APSECTS

slide-7
SLIDE 7

Page 7

JAGUAR XK ADAPTIVE CRUISE CONTROL

  • New Adaptive Cruise Control Algorithms for XK
  • New Features

–

Queue Assist Algorithms

–

Lead Vehicle Acceleration Algorithm (LVA)

  • Initial Functional Testing – April 2005
  • Initial Calibration Testing – May 2005
  • Unexpected Results ….
slide-8
SLIDE 8

Page 8

APPROACH XK v S-TYPE

20 40 60 80 100 120 140

  • 26
  • 24
  • 22
  • 20
  • 18
  • 16
  • 14
  • 12
  • 10
  • 8
  • 6
  • 4
  • 2

2 Range m Range Rate m/s COMPARISON OF XK v S-TYPE ACC APPROACH TO LEAD VEHICLE TRAVELLING AT 50mph XK Headway 1 90mph XK Headway 1 100mph S-TYPE Headway 1 90mph S-TYPE Headway 1 100mph S-TYPE shows smooth continuous reduction

  • f range rate with range

XK shows discontinuous reduction

  • f range rate with range
slide-9
SLIDE 9

Page 9

TEST & DEVELOPMENT

  • Results from 1st ACC Test Session

–

Harsh Early Brake Intervention

–

LVA Algorithm gave unpredictable results

–

Generally unrefined ACC Performance

  • Expectation was that XK ACC would only need small scale refining

–

Developed from ACC3

slide-10
SLIDE 10

Page 10

TEST & DEVELOPMENT

  • In reality major development was required
  • Second test period was for validation NOT development
  • Tight timescales & challenging vehicle allocation
slide-11
SLIDE 11

Page 11

ADAPTIVE CRUISE CONTROL VIRTUAL VEHICLE MODEL

slide-12
SLIDE 12

Page 12

MODEL CORRELATION

20 40 60 80 100 120 20 25 30 35 40 45 Time s ACC Host Vehicle Speed m/s X150 ACC-QA Simulink Model Validation Test - SDV1143 Simulation - CADS-X150-CP39-SDB4-trj04h.mdl Approach 1 Approach 2 Auto-Resume to Set Speed Cruising at Set Speed Approach 3 Following Target Vehicle

slide-13
SLIDE 13

Page 13

MODEL CORRELATION

20 40 60 80 100 120

  • 1.5
  • 1
  • 0.5

0.5 1 1.5

Range m Range Rate Error m/s

Residuals approach 1 Residuals approach 2 Residuals approach 3

X150 ACC-QA Simulink Model Validation Test Vehicle - X150 SDV1143 Simulation - CADS-X150-CP39-SDB4-trj04h.mdl

slide-14
SLIDE 14

Page 14

CALIBRATION DEVELOPMENT

  • Test Results indicated seven parameters influenced ACC refinement

–

Lead Vehicle Acceleration Algorithm (LVA)

–

ACC brake gain

–

Brake demand slew rate

–

Time to collision gain

–

Residual Distance

–

Coast Deceleration Estimate

–

Headway Control Maps

slide-15
SLIDE 15

Page 15

CALIBRATION DEVELOPMENT

  • Test Matrix of 8 possible ACC configurations
  • 4 days per configuration to test on vehicle = 32 days vehicle testing
  • Complete test matrix was evaluated by simulation in 10 days

ACC Vehicle Simulation was vital for calibration development

slide-16
SLIDE 16

Page 16

SIMULATION PREDICTIONS V TEST RESULTS

20 40 60 80 100 120 140

  • 15
  • 10
  • 5

5

Range m Range Rate m/s

20 40 60 80 100 120 140

  • 20
  • 15
  • 10
  • 5

5

Range m Range Rate m/s

20 40 60 80 100 120 140

  • 25
  • 20
  • 15
  • 10
  • 5

5

Range m Range Rate m/s

20 40 60 80 100 120 140

  • 30
  • 25
  • 20
  • 15
  • 10
  • 5

5

Range m Range Rate m/s

Test - 90mph Simulation - 90mph Test - 112mph Simulation - 112mph Test - 100mph Simulation - 100mph Test - 80mph Simulation - 80mph

Headway 1 Approach Results. Test v Simulation Predictions

slide-17
SLIDE 17

Page 17

COMPARISON OF SIMULATION PREDICTIONS WITH PRODUCTION CALIBRATIONS

  • Two calibrations changed from simulation to production
  • Changes based on subjective driver assessment
slide-18
SLIDE 18

Page 18

QUEUE ASSIST

  • Extension of ACC operating range to 0mph
  • Headway opened significantly at low speeds
  • QA host vehicle unable to track target vehicle accelerating at a

moderate rate

  • Filtering of ACC Speed demand introduced significant lag
slide-19
SLIDE 19

Page 19

QUEUE ASSIST

10 20 30 40 50 60 70 80 5 10 15 20 25 Time s Speed m/s Jaguar XK QA Simulation. Acceleration from 5mph to 30mph. Headway 1 0.1g. Baseline Calibration Lead Car Speed Headway 1 0.1g. Baseline Calibration Follow Speed Headway 1 0.1g. Baseline Calibration Vehicle Speed 10 20 30 40 50 60 70 80 10 20 30 40 50 60 70 Time s Range m Jaguar XK QA Simulation. Acceleration from 5mph to 30mph. Headway 1 0.1g. Baseline Calibration

slide-20
SLIDE 20

Page 20

FILTER CUT-OFF FREQUENCY

10

  • 2

10

  • 1

10

  • 60
  • 30

Phase (deg)

System: follow_speed_filt_current Frequency (Hz): 0.15 Phase (deg): -42

  • 4
  • 3
  • 2
  • 1

Magnitude (dB)

System: follow_speed_filt_current Frequency (Hz): 0.151 Magnitude (dB): -3

FREQUENCY RESPONSE OF THE FOLLOW SPEED FILTER R44 CALIBRATION.

FREQUENCY Hz 10

  • 1

10

  • 35
  • 30
  • 25
  • 20
  • 15
  • 10
  • 5

Phase (deg)

System: follow_speed_filt_new_02 Frequency (Hz): 0.979 Phase (deg): -29.9

  • 5
  • 4
  • 3
  • 2
  • 1

Magnitude (dB)

System: follow_speed_filt_new_02 Frequency (Hz): 0.979 Magnitude (dB): -3 FREQUENCY RESPONSE OF FOLLOW SPEED FILTER - DESIGN 02.

Frequency Hz

  • Use frequency response toolbox to re-calculate filter constant
slide-21
SLIDE 21

Page 21

EFFECT OF NEW FILTER CONSTANT

10 20 30 40 50 60 70 80 10 20 30 40 50 60 70 Time s Range m Jaguar XK QA Simulation. Acceleration from 5mph to 30mph Baseline Calibration filter cut-off @ 0.15Hz Filter cut-off @ 1Hz 10 20 30 40 50 60 70 5 10 15 20 25 Time s Speed m/s X150 QA Simulation. Headway 1. Acceleration from 5mph to 30mph. Follow Speed Filter -3db @ 1Hz

Headway 1 0.1g CADS Cal. R44. Follow Speed Filter -3dB @ 1Hz Lead Car Speed Headway 1 0.1g CADS Cal. R44. Follow Speed Filter -3dB @ 1Hz Follow Speed Headway 1 0.1g CADS Cal. R44. Follow Speed Filter -3dB @ 1Hz Vehicle Speed

slide-22
SLIDE 22

Page 22

JAGUAR XK MODEL BASED DESIGN AND CALIBRATION

SUMMARY

  • Jaguar XK ACC system modelled in simulink
  • ACC Model shows good correlation with test results
  • Model was used to develop Jaguar XK ACC Calibrations
  • Development time per calibration loop reduced from 30 days to 10 days

(Typically 3 - 4 calibration loops on a vehicle program)

  • Vehicle test time now used for validation - not experimentation
slide-23
