Modeling a New Concept of Tether Deployer with Retrievable Capability for Space Applications 1 st Symposium on Space Educational Activities Padova, December 11 th , 2015 Gilberto Grassi , Riccardo Mantellato MSc Aerospace Engineering

slide-1
SLIDE 1

Modeling a New Concept of Tether Deployer with Retrievable Capability for Space Applications

Gilberto Grassi⋆, Riccardo Mantellato

⋆ MSc Aerospace Engineering Department of Industrial Engineering

University of Padova

1st Symposium on Space Educational Activities Padova, December 11th, 2015

slide-2
SLIDE 2

2 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Overview

  • 1. Introduction
  • 2. Proposed concept
  • 3. Models & control
  • 4. Simulations
  • 5. Conclusions
slide-3
SLIDE 3

3 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Introduction

slide-4
SLIDE 4

4 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

What did we want to do?

  • 1. Model a tether deployer with retrievable capability
  • 2. Simple & reliable
  • 3. Compact & light

Scope & Requirements

slide-5
SLIDE 5

5 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

1992 – TSS-1 – 20 km tether

  • 670 kg satellite + tether
  • 4800 kg pallet & support

Tether heritage (1/2)

slide-6
SLIDE 6

6 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

1994 – SEDS-II – 20 km tether

  • 33 kg tip mass + tether
  • 10 kg deployer hardware

Tether heritage (2/2)

slide-7
SLIDE 7

7 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Proposed concept

slide-8
SLIDE 8

8 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Openable bail

Proposed concept (1/2)

Fixed spool

slide-9
SLIDE 9

8 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Fixed spool Openable bail Tether

Proposed concept (1/2)

Deployment phase

slide-10
SLIDE 10

8 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Openable bail Tether

Proposed concept (1/2)

Retrieval phase DC motor Fixed spool

slide-11
SLIDE 11

9 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

How to control tether motion during deployment?

Proposed concept (2/2)

PD control … Inductive Brake (TSS-like) Low-Inertia (SEDS-like)…

slide-12
SLIDE 12

9 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Proposed concept (2/2)

PD control How to control tether motion during deployment? … Inductive Brake (TSS-like) Low-Inertia (SEDS-like)…

slide-13
SLIDE 13

9 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Proposed concept (2/2)

PD control How to control tether motion during deployment? … Inductive Brake (TSS-like) Low-Inertia (SEDS-like)…

slide-14
SLIDE 14

10 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Models & control

slide-15
SLIDE 15

11 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

x y z m

  • θ

l

M

Models (1/2)

Dumbbell tether model

slide-16
SLIDE 16

12 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Mechanical brake (low-inertia) Tether Rollers Actuator Motion Friction

Models (2/2)

x

slide-17
SLIDE 17

13 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Control (1/2)

Reference trajectory optimization – Nelder-Mead algorithm

slide-18
SLIDE 18

14 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Control (2/2)

Tether/probe dynamics PD controller l, l . lref(t), lref(t) control tension T . Reference trajectories feed-forward – lref(t), lref(t) .

  • ε
slide-19
SLIDE 19

15 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Equations (deployment)

LI IB

slide-20
SLIDE 20

15 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

LI IB Control Inner friction

Equations (deployment)

slide-21
SLIDE 21

15 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

LI IB Control Inner friction

Equations (deployment)

15 mN 150 mN

slide-22
SLIDE 22

16 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Simulations

slide-23
SLIDE 23

17 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Deployment scenario (1/2)

x z Chaser Target E.g. active debris removal local vertical

slide-24
SLIDE 24

17 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Deployment scenario (1/2)

x z Target local vertical E.g. active debris removal Chaser

slide-25
SLIDE 25

17 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Deployment scenario (1/2)

x Target local vertical E.g. active debris removal Chaser Tethered de-orbit package

slide-26
SLIDE 26

18 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Deployment scenario (2/2)

slide-27
SLIDE 27

18 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Deployment scenario (2/2) θ0 lgoal l0 .

slide-28
SLIDE 28

( ): insufficient initial velocity ( ): successful deployments

19 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Results

Simulations results ( ): insufficient brake authority control

slide-29
SLIDE 29

( ): insufficient initial velocity ( ): successful deployments

19 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Results

Simulations results ( ): insufficient brake authority control Required higher launch velocity

slide-30
SLIDE 30

( ): insufficient initial velocity ( ): successful deployments

19 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Results

Simulations results ( ): insufficient brake authority control Less control authority w.r.t. IB

slide-31
SLIDE 31

20 of 24

Deployment example (1/3)

Successful deployment

1st Symposium on Space Educational Activities Padova, December 11th, 2015

slide-32
SLIDE 32

21 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Deployment example (2/3)

Deployment failure – insufficient launch velocity

slide-33
SLIDE 33

22 of 24

Deployment example (3/3)

Deployment failure – insufficient deployer control authority

1st Symposium on Space Educational Activities Padova, December 11th, 2015

slide-34
SLIDE 34

23 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Conclusions

slide-35
SLIDE 35

24 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Conclusions

Low-inertia

  • 1. Easier ground test phase
  • 2. Requires less energy (T0)
  • 3. Higher tolerance of design

inaccuracies (less parts in

  • synch. motion)

Inductive brake

  • 1. More control authority
  • 2. Less actuators
  • 3. Some critical issues during

deployment are addressed

slide-36
SLIDE 36

24 of 24

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Conclusions

Low-inertia

  • 1. Easier ground test phase
  • 2. Requires less energy (T0)
  • 3. Higher tolerance of design

inaccuracies (less parts in

  • synch. motion)

Inductive brake

  • 1. More control authority
  • 2. Less actuators
  • 3. Some critical issues during

deployment are addressed

slide-37
SLIDE 37
  • Questions? -
slide-38
SLIDE 38

2007 – YES2

  • 12 kg endmass + tether
  • 24 kg deployment hardware

Extras – YES2

slide-39
SLIDE 39

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Extras – motion equations

slide-40
SLIDE 40

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Extras – motion equations

Tether tension (control) Gravity gradient Centrifugal Convective Stabilizing if l > 0 .

slide-41
SLIDE 41

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Low-inertia Inductive brake Higher inner friction in IB due to more sliding parts

Extras – system parameters

slide-42
SLIDE 42

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Extras – deployment scenario

LH LV C LV C T@eo d T@bod

No relative motion

T@bod ≡ T@eod Easier deployment but higher vrel @eod!

Relative motion

LH

slide-43
SLIDE 43

1st Symposium on Space Educational Activities Padova, December 11th, 2015

θ0 values chosen in the simulations

Extras – deployment scenarios

slide-44
SLIDE 44

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Extras – Nelder-Mead algorithm

slide-45
SLIDE 45

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Extras – Nelder-Mead algorithm

slide-46
SLIDE 46

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Extras – abort capability

slide-47
SLIDE 47

1st Symposium on Space Educational Activities Padova, December 11th, 2015

p d x 2α α Mechanical brake

Extras – mechanical brake

slide-48
SLIDE 48

1st Symposium on Space Educational Activities Padova, December 11th, 2015

d x 2α α p α x d/p = 3

Extras – models

slide-49
SLIDE 49

1st Symposium on Space Educational Activities Padova, December 11th, 2015

d x 2α α p α 9 cm 60° x d/p = 3

Extras – models

slide-50
SLIDE 50

1st Symposium on Space Educational Activities Padova, December 11th, 2015

What could we do? New docking techniques

Extras – applications

slide-51
SLIDE 51

1st Symposium on Space Educational Activities Padova, December 11th, 2015

Extras – DC motor

J R τ

  • V
