The next gas lift well integrity & reliability leap forwards: Barrier SPM's with retrievable check valves

www.ptc.as

Introduction

• Established reputation for developing

equipment in response to client demands

• Integrity
• Reliability
• Productivity
• Entered the Gas Lift Market in 2004 and

delivered the worlds first

• Well Barrier Accredited Gas Lift

Valves

• Unique check valve and bellows

design

• 10k pressure rating facilitating

deeper lift

• Now responding to client demands for

enhanced SPM’s

www.ptc.as

Well Barrier SPM’s

• 3 Messages
• The challenge the market asked us to address
• How we have addressed the challenge
• The benefits

www.ptc.as

The challenges to be addressed

• GLV is part of primary containment barrier
• But if the GLV is removed
• Casing / wellhead become the primary barrier
• And the secondary barrier ……….
• Maybe we should be setting a deep plug?
• Market demanded SPM’s w permanent check valves
• To maintain well integrity during GLV changeout
• At least one exists of course
• But the market likes to see competition
• And continuous improvement
• Second (Independent device) check valve in SPM
• Also enhances well reliability during gas lift ops

www.ptc.as

The challenges to be addressed

• Well Reliability:
• The SPM check valve solution in the market to date
• Tubing retrievable
• In the event it were to fail
• Expensive to replace
• So the market demanded
• A wireline retrievable SPM check valve solution

www.ptc.as

Well Barrier SPM’s

• Just 3 Messages
• The challenge the market asked us to address
• How we have addressed the challenge
• The benefits

www.ptc.as

How we addressed the challenge

• A few years ago ………..
• A client came to us with another challenge
• Somehow they had installed a SPM facing downwards
• Easy done SPM’s usually box/box
• We developed an upside down pulling tool
• To facilitate change out

www.ptc.as

How we addressed the challenge

Patent Pending Upwards facing latch retrievable GLV or IPO Downwards facing latch retrievable GLV check valve module

www.ptc.as

How we addressed the challenge

• Changing Primary GLV
• As per normal operation
• But lower GLV check valve

stays in place

• So primary well containment

envelope remains intact

• No U tubing

www.ptc.as

How we addressed the challenge

• Replacing the “permanent” GLV
• Utilises upside down kick over tool
• Primary well barrier is temporarily

lost unless a deep set plug is installed

• But frequency of operation much less

than with conventional solution

www.ptc.as

Well Barrier SPM’s

• Just 3 Messages
• The challenge the market asked us to address
• How we have addressed the challenge
• The benefits

www.ptc.as

The benefits

• Enhanced well integrity
• Primary barrier not compromised during routine

GLV change outs

• Enhanced well reliability
• 2 High reliability (independent) check valves
• Reduced lifecycle costs
• If “permanent” check valve fails
• it can be replaced using wireline

www.ptc.as

The costs

• Can’t talk about benefits without also considering the costs
• Not going to share the actual costs in this public forum:
• But lets play with some numbers, what if
• The incremental cost to install PTC barrier SPM’s is £150k/well
• Oil price was $100 / bbl ( £62 )
• The average gas lifted well produced 1000 stb oil/day
• How many days of accelerated production over the life of the well

would be required to payback the investment

• 2.5 days
• Over the life of your well, could enhanced reliability / simplified

well ops deliver that ?

• On that basis you could argue the enhanced integrity is for free!!

www.ptc.as

Thanks for listening

• Happy to take any questions
