DELTA / ASIC

Microchip for every industry – ‘Make more with less’

DELTA Microelectronics

Agenda

DELTA Microelectronics and IoT IoT elements: Focus on Sensors Choice for Wireless Bridge for Sensor Capture IoT is not only wearables Examples of IoT products Conclusions

DELTA Microelectronics

Worked at DELTA since 1982 (34 years) Worked as test engineer, DSP solutions, quality assurance, project manager and sales Business development driver, personally turned a part

• f DELTA ( microelectronics ) from consultancy

company to component supplier Helps major customers to drive innovations and technology intros Vice President for Sales & Marketing since 2010

Gert Jørgensen

VP Sales & Marketing

Organisation

DELTA

ASIC Sensor systems Reflectometers Acoustics EMC Wireless Reliability LAN cable test Certification CE, E1, FCC … Point of Care Idemolab SenseLab Test & Consultancy Microelectronics Incubator Light & Optics Management

DELTA Microelectronics

History & Highlights

1976 ME test activities starts, RAM, PROM & CPUs 1984 ASIC design centre established 1992 First space components delivered 1999 OEM supplier 2001 Order of 600,000 DSRC chips 2002 RF test centre starts 2004 First 10 mill components delivered 2008 Single contract of 10 mill chips 2009 25th anniversary: ASIC design From hand-drawn chips to nanotechnology and DSRC 2010 IBM partnership contract 2011 Celebrates more than 100 mill components delivered 2012 GlobalFoundries partnership contract 2015 First projects for real IOT applications starts

Services Turnkey

DELTA can provide:

From specification / GDSII to silicon – wafer or packaged ASIC design and IPs Package design and evaluation Wafer and component test Bumping and packaging in the Far East Storage and dedicated logistics team Supply chain management

DELTA Microelectronics offers

One Stop Shop - Predictable path to success

Microelectronics & IoT focus areas

4 focus areas within ASIC turnkey solutions

Medical ICs Optical chip solutions Wireless IoT using RFID Chips for payment

IoT general elements

Add intelligence and create new business cases

• Sensor network
• Data capture
• Data network
• Routers in e.g. a house
• Data banks in the cloud

DELTA Microelectronics focus

• n sensors or products

Add intelligence and create new business WIFI typical products powered BLE product or nodes powered or battery Sensor nodes battery or passive COST VOLUME

DELTA ME focus area: Component supply to Sensor or equipment data capture nodes: Optical Temperature Humidity Movement Accellerometer Colour / luminance / lux detection Payment

Wireless bridge - a choice between performance or cost

Wireless Bridge for Sensors WIFI BT/ BLE NFC / RFID Battery consumption Highest Lower Lowest (can be passive) Data capture System System System Data rate High High Low Energi harvesting Low Low High Distance 10-20 m 10-20 m 1 cm or 10 m Reader coverage High High Lower Communication type Battery Battery Passive Frequency 2.4- 5.0 GHz 2.4 GHz 13.5 MHz or 900 MHz Size (module) Equal Equal Equal Cost High Lower Lowest

Active or passive data transmission

Use RFID as battery management and may be primitive data communication Data Power

DELTA’s RFID wireless bridge solution

RFID sensor platform “THOR”

RFID no-power wireless bridge Built-in temperature sensor A/D external sensor interface (16 bit) NFC compliant RFID interface Multiprotocol ISO 14443 / ISO 15693 On-chip data logging Low power – long battery lifetime (<0.1µA) Low cost development platform Demo kit available for fast prototyping Scan the QR code to watch video on THOR demo kit or note this URL: http://bit.ly/1BTXsnL

2.7mm

Technical details for THOR

Front-end comply with ISO 14443A-4 and ISO 15693 Fully configurable temperature logging profile in the range -30°C to + 100ºC with accuracy: ±0.5°C (abs), ±0.1°C (relative) 16 bits linear low-offset Sigma-Delta SPI master interface for auxiliary slave

• penMSP430 CPU

Available as Tested Dies (KGD) or in QFN DES encryption hardware support 12 K samples storage capacity Firmware upgradable Ultra low power tag storage mode (< 0.1μA) Ultra low power clock -

• ptional external crystal

Can be operated with and without battery power External sensor can be attached

NFC RFID ver. 1 migrates to RFID ver. 2

Today and in RFID ver. 1, RFID is a proven alternative to barcodes when it comes to security Drug counterfeit: Identify drugs using a tag with unique code and ID Instrument safety: Location and status (sterilised or not) to eliminate fatal errors due to unclean instruments Packaging and logistics: Information regarding seal time and packaging date logged on RFID read/write tags SurgiChip tag: External surgical marker to minimise the risk of wrong surgeries Patient identification VeriChip: Implanted transponder storing unique electronic ID code to access patient identification and corresponding health information in a database

Today! NFC tags contain unique codes or links to unique coded data Tomorrow! RFID ver. 2 … Tags generate and communicate data such as temperature, pulse, blood

pressure and e.g. glucose (blood sugar)!

IoT - Wearables - Glucose measurement – Make your eye lens intelligent!

Monitoring glucose levels in tears Challenge Continuous instead of Discrete measurement Not distracting the patient No batteries / wires in the eyes Fast reading …

Source: Google

Solution MEMS/Nano sensors and a RFID link to a mobile phone unit implemented in a device positioned in the eye!

”THOR” integrated with novel blood sugar sensor + NFC coil for energy harvesting and data transmission Optional: Spectacles that continuously read eye sensor via RFID and communicate with mobile phone over Bluetooth Low Energy (BLE)

Blood sugar measurement – The solution

DELTA / Medella Health version

IoT application – Temperature Make your patch intelligent!

More focus on Monitoring continuously Not disturbing the patient Identifying trends Getting alerts Applications Infant temperature measurement Patient monitoring Wound inflammation monitoring (inflammation is critical for diabetes patients)

Source: Vivalnk

T2 T1 T0 R1 R2 IT

40C

med. recom.

D>2C

Alert

A somewhat different RFID temperature application

Ready for Pregnancy

Can either replace hormone treatment or to “optimise” the process of getting pregnant.

Measure signs of oestrus or “heat” in order to detect readiness to get

• bred. Detect pregnancy when heat cycle is missing. This works for

mammals and women alike.

IoT – Cigar box with temperature / humidity logger – Make your cigar box intelligent!

A Cuban cigar company wants to improve traceability To improve taste, cigars are stored in temperature and humidity controlled environment over many years (like single malt Scottish whisky) Storage time can be up to 10-20 years To improve traceability and to make this data available to the end customer They add electronics to make the wooden box intelligent Customers will be able to read stored data via mobile phone in the shops

Cigar company gets higher trust in promised storage data Open data to customers in the shops reading data via their own mobile phone with their own Apps

Consequence: Higher price for a cigar box by adding intelligence!

IoT – Cigar box with temperature / humidity logger (cont)

IoT - Ear-plugs and measure noise IoT – Teeth protection for sport or others IoT – Swimwear goggles for elite sport IoT – Shoes for demens tracking

Simple products made intelligent

Tid Sted Wifi net Vibration Network Blue Tooth

Data created from your mobile phone

Demo board for IoT / NFC

First generation Next generation

Battery (thin film) Cover sheet THOR Antenna + circuitry

Add intelligence to capture data IoT can be an intelligent product or a creation of data with the product IoT is not expensive - Think smart! To sell data can create bigger business than production of product Many electronic new-comers in IoT which are not from typical electronics area Let’s get started! You are welcome to consult us for a discussion!

Conclusion

DELTA Microelectronics Gert Jørgensen

VP Sales & Marketing gj@delta.dk Mobile +45 40 41 47 23

Questions ??
