INTEGRALE MOBIELE PROCESWATERVOORZIENING VOOR EEN ECONOMISCHE DELTA

BASF Water Management & IMPROVED

BASF worldwide & BASF Antwerp: We create chemistry

Some figures / characteristics BASF Antwerp Portfolio Verbund & sustainability

Water management @ BASF Antwerp

Sustainability: drinking water → surface water (Biesbosch) Process water production Demineralized water production

IMPROVED @ BASF Antwerp

Why? → negative effects surface water Biesbosch water treatment optimization Condensate treatment

3/07/2018 BASF: Water management & IMPROVED

353

production sites

115.490

employees

• No. 1

in chemistry

64

billion euro

BASF AROUND THE WORLD

Regional centres Selected production sites Most important research sites Verbund sites Freeport Geismar

Antwerp

Nanjing Kuantan Ludwigshafen

Evides Waterdag 22/09/11 Vinck / De Kever

6

km²

A MAJOR PRESENCE

6 km²

city centreAntwerp

1,200 football pitches 580 km of pipes 60 km of road 44 km of railway track 6 km²

6

km²

3,159

employees

A PROFESSIONAL TEAM

• approx. 6

billion euro

6

km²

3,159

employees

A HEALTHY COMPANY

# Employees 3.159 Total site surface 598 ha Turnover 6,06 billion EUR # Plants 54 Internal roads 60 km Internal railways 44 km Pipelines (above ground) 580 km Gas consumption (vs Belgian consumption) 4.1% Electricity consumption (vs Belgian consumption) 3.2% Water consumption 1300 m³/h

BASF Antwerp at a glance

BASF PORTFOLIO

CHEMICALS PERFORMANCE PRODUCTS FUNCTIONAL MATERIALS & SOLUTIONS AGRICULTURAL SOLUTIONS OIL & GAS

Dispersions & pigments Catalysts Oil & gas

Antwerp Belgium

Nutrition & health Paper chemicals Petro-chemicals Care chemicals Performance materials Construction chemicals Crop protection Monomers Intermediates Performance chemicals Coatings Petro-chemicals Care chemicals Performance materials Construction chemicals Crop protection Monomers Intermediates Performance chemicals Coatings

BASF IN BELGIUM

Petro-chemicals Care chemicals Performance materials Monomers Intermediates Performance chemicals

SUSTAINABILITY

HOW DO WE DO THAT?

"Verbund"

VERBUND PRODUCT INTEGRATION

Less transport Intelligent use

• f by-products

Less environmental impact Sharing knowledge EXAMPLE

From naphtha to nappies

1 2 3 4 5

VERBUND PRODUCT INTEGRATION

Ethylene Propylene Benzene Ethylene oxide Acrylic acid Ethylbenzene/Styre ne Tensides Acrylates Polystyrene Ethylene glycol Ethanolamine Pure acrylic acid Styrolux Nitrobenzene Aniline Ethylenimine Super absorber MDI Nitric acid Hydrogen Formaldehyde Phosgene

Steam cracker

VERBUND ENERGY AND ENVIRONMENTAL INTEGRATION

STEAM CONSUMPTION STEAM PRODUCTION

Energy producing processes Energy consuming processes

VERBUND ENERGY AND ENVIRONMENTAL INTEGRATION

Albert canal connected with river Maas Pitwater from the Kalmthout heather

Until 2010

SUSTAINABILITY: DRINKING WATER → SURFACE WATER

Since 2011

SUSTAINABILITY: DRINKING WATER → SURFACE WATER

Evides Waterdag 22/09/11 Vinck / De Kever

Biesboschwater

Drinking water

Braakman

BB water

Kraaijenberg filtration BB water

NL B BASF site

Biesboschwater

filtration BB water Demin Evides Demin BASF

Process water tank Evides (10.000m³, J400) Process water tank BASF (10.000m³, A160) BASF DEMIN (1.100 m³/h, D550) Evides DEMIN + RO’s (450 m³/h, G500)

SUSTAINABILITY: DRINKING WATER → SURFACE WATER

SUSTAINABILITY: DRINKING WATER → SURFACE WATER

Which benefits by switching water source?

• 1. Reliable and redundant supply of Process water & DEMIN water

➔Process water supply via The Netherlands (Evides) & Belgium (AWW) ➔ DEMIN water delivery via 2 suppliers (resp. J400/A160 & D550/G500)

• 2. Decreased production cost for Process water & DEMIN water
• 3. Contribution to BASF Group Goal Drinking Water:

➔Goal 2020: Consumption -50% (30 → 15 mio m³/j) versus 2010 ➔BASF Antwerp: Reduction of 8,4 mio m³/j versus 2010 = Reduction of >90% BASF Antwerp = Reduction of 28% BASF Group = Contribution of 56% to BASF Group Goal

• 4. No more use ground water for industrial processes (~3 mio m³/j)

Process water DEMIN cold Condensate Return GDW warm STEAM

.

Direct to production plants Condensate loss

90%

1000 m³/h BASF 400 m³/h Evides

10% 30% 70% <1%

LD HD High DEMIN quality needed 80% 20%

± 1500 m³/h ± 1300 m³/h 70%

Water management @ BASF Antwerp

IMPROVED @ BASF Antwerp

1 2 3 4 5 Doel Timing (weken) 1 RO

• Referentie

5 2 UF RO

• Stabiliteit

6 3 IX MB1

• Referentie

5 4 MD

• Kwaliteit + stabiliteit

5 5 ED MB2

• Kwaliteit + stabiliteit

5 6 UF IX MB1

• Kwaliteit + stabiliteit

elk 2 UF GAC IX MB1 - UF AOP GAC IX MB1

Week 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 Train 1 RO IX - MB1 Buffer UF - RO Buffer Train 2 MD ED - MB2 UF - IX - MB1 GAC - IX - MB1 AOP - IX - MB1 Buffer

IMPROVED @ BASF Antwerp

Application 1: BB water treatment optimization

→ GOAL: TOC reduction in DEMIN water → GOAL: meet specifications high pressure steam quality

1 2 Doel Timing (weken) 1 MD Kwaliteit + stabiliteit 4 2 RO Kwaliteit + stabiliteit 4 3 Mixed Bed Referentie 4 4 Scavenger/kation MB Kwaliteit + stabiliteit 4 Week 16 17 18 19 20 21 22 23 Train 1 MB MD/MS Train 2 RO Scavenger/Kation-MB

IMPROVED @ BASF Antwerp

Application 2: Condensate treatment

→ GOAL: reliable & alternative technology → GOAL: decrease # regenerations with chemicals (HCl, NaOH)

IMPROVED @ BASF Antwerp

Depending on TOC composition ≠ organic acids formed with different corrosion effects

Study corrosion effects of organic acids

IMPROVED @ BASF Antwerp

CONTACT

Arne Verliefde Professor Universiteit Gent Arne.Verliefde@Ugent.be 09/264.60.02
