Date: July 2014 Terebo Olugbenga Why Pensonic? Why Pensonic LED? - - PowerPoint PPT Presentation

Date: July 2014 Terebo Olugbenga

Why Pensonic LED?

• IN MALAYSIA- Key partner on the Malaysian ETP program. Focus on local manufacturing, design

research and development.

• Local design- Our products are designed for the Malaysian Market.
• Local manufacturing- Most of our project series and made locally.
• Local sales support- We have a list of project dealers to bring service support to your door step.
• Local technical support- Design services for std and non std products.
• Local logistic hub-Two strategic PDC’s in Malaysia. Penang and Kuala Lumpur
• Local focus- Focus on the Malaysian market.
• Strategic partnership with technology partners in the LED market.
• Cree
• Osram Optoelectronics,
• LG Innotek
• Dominant LED on LED’s .
• We get the latest technology locally, to you.

Why Pensonic?

Pensonic Starlight CFL range

Types of light

Pensonic Starlight CFL range

Global Lighting Market = $108 Billion USD

*Source: Freedonia Group estimate for 2012 (Excludes manufactured goods) / *** Source: Philips Lighting

The Market is Large and Adoption Low

Lamps Fixtures

Outdoor** Residential Commercial Industrial Residential Outdoor** Commercial Industrial

Pensonic Starlight CFL range



The world lighting market is expected to grow 35% (CAGR) from 2011 to 2015 onwards



Total market size for lighting is around the USD 100 billion

Total shipments Growth rate PA

The WW LIGHTING Market HOW BIG BY REGION

Pensonic Starlight CFL range

LED Lighting- Growth by sector

46%

Growth

Pensonic Starlight CFL range

LED Lighting- Growth by technology

53.8% Growth

Pensonic Starlight CFL range

2013- LED Penetration less than 20% 2020- LED Penetration more than 80%

*** Source: Philips Lighting

Pensonic Starlight CFL range

THE BAN !

Key drivers to LED adoption

Pensonic Starlight CFL range

LED’s are getting brighter!

Evolution of Lighting

Evolution of Lighting

Pensonic Starlight CFL range

BUNNY SAYS SAVE ME !

Types of light

Pensonic Starlight CFL range

Effects of different Light sources

Pensonic Starlight CFL range

Light Sensitivity Curve of the Sun The Sun

• pg. 16

Visible Light Spectrum

• f Various Sources
• Which one is closer to the Sun?
• Normalizing Incandescent to CRI = 100 makes the CRI scale somewhat

arbitrary

• A new standard – Color Quality Index (CQI) is currently being set for ALL

light sources

LED FL HID

Pensonic Starlight CFL range

Light Sensitivity Curve

Gravity-Hi-Power Project Range

Gravity-Hi-Power Project Range

Benefits of LED Lighting

• Easy to Install. Most are retrofit.
• Low and longer maintenance periods. Long term cost savings
• Shock Resistant. Does not have any fragile parts.
• Environmental Friendly ( No Mercury, RoHS Free )
• Flicker Free
• Operating Life (35,000 - 50,000 hours)
• Run cooler. No radiated heat. Cooler work areas.
• Safe (low voltage, low heat, low fire risk, no IR/UV light)
• LEDs mostly fail by dimming over time, rather than burn-out
• Better object reflection. We see better.
• LED Lights don’t kill chocolate bunnies!

Pensonic Starlight CFL range

Ready for sale !!

PCFL-09U2CA Std price: PCFL-09U2WA Std price: PCFL-11U3CA Std price: PCFL-11U3WA Std price:

Pensonic Starlight CFL range

PCFL-15U3CA Std price: PCFL-15U3WA Std price: PCFL-18U3CA Std price: PCFL-18U3WA Std price:

Ready for sale !!

CFL Range

Pensonic Starlight CFL range

PCFL-23U3CA Std price: PCFL-23U3WA Std price:

Ready for sale !!

CFL Range

Coming new range of Spiral CFL

Available in end qtr 4

Pensonic Starlight CFL range

PCFL-23HSWA Std price: PCFL-23HSCA Std price

Ready for sale !!

CFL Range

Pensonic Starlight CFL range

Certification of MFC

Pensonic Starlight CFL range

Candle bulb E14

Coming Soon !!

Model: PSLED-04CC-WW Specifications:

• 1. Rated Power ：4W
• 2. Base: E14
• 3. CRI : > 75
• 4. Color Temperature : 2700K
• 5. Rated Voltage : 220-240V
• 6. Luminous Flux : 300 Lm
• 7. Beam Angle : 45⁰
• 8. Size : Ф37 * L98 mm
• 9. Average Life : 15,000 h

30W to 40W incandescent bulbs replacement

Pensonic Starlight CFL range

Candle bulb E14

Coming soon !!

Model: PSLED-05CD-WW Specifications:

• 1. Rated Power ：5W
• 2. Base: E14
• 3. CRI : > 75
• 4. Color Temperature : 2700K
• 5. Rated Voltage : 220-240V
• 6. Luminous Flux : 330 Lm
• 7. Beam Angle : 160⁰
• 8. Size : Ф37 * L 98 mm
• 9. Average Life : 15,000 h

30W to 40W incandescent bulbs replacement

Pensonic Starlight CFL range

MR16 GU5.3

35 W Halogen replacement

Model: PSLED-05M53-P-WW Specifications:

• 1. Rated Power ：5W
• 2. Base: GU5.3
• 3. CRI : > 75
• 4. Color Temperature : 2700K
• 5. Rated Voltage : 220-240V
• 6. Luminous Flux : 350Lm
• 7. Beam Angle : 45⁰
• 8. Size : Ф50 * H57 mm
• 9. Average Life : 15,000 h
• 10. Comes complete with a power supply

Coming Soon !!

Pensonic Starlight CFL range

MR16 GU 5.3 With PSU

35 W Halogen replacement

Coming Soon !!

Model: PSLED-05M53-P-WW Specifications:

• 1. Rated Power ：5W
• 2. Base: GU5.3
• 3. CRI : > 75
• 4. Color Temperature : 2700K
• 5. Rated Voltage : 220-240V
• 6. Luminous Flux : 350Lm
• 7. Beam Angle : 45⁰
• 8. Size : Ф50 * H57 mm
• 9. Average Life : 15,000 h
• 10. Comes complete with a power supply

Pensonic Starlight CFL range

MR16 GU10

35 W Halogen replacement Direct AC

Ready for sale !!

Model: PSLED-05MR10WA Specifications:

• 1. Rated Power ：5W
• 2. Base: GU10
• 3. CRI : > 75
• 4. Color Temperature : 2700K
• 5. Rated Voltage : 220-240V
• 6. Luminous Flux : 250 Lm
• 7. Beam Angle : 45⁰
• 8. Size : Ф50 * H57 mm
• 9. Average Life : 25,000 h

Pensonic Starlight CFL range

MR16 GU10

50 W Halogen replacement Direct AC

Ready for sale !!

Model: PSLED-05MR10WA Specifications:

• 1. Rated Power ：7W
• 2. Base: GU10
• 3. CRI : > 75
• 4. Color Temperature : 2700K
• 5. Rated Voltage : 220-240V
• 6. Luminous Flux : 450 Lm
• 7. Beam Angle : 45⁰
• 8. Size : Ф50 * H57 mm
• 9. Average Life : 25,000 h

Pensonic Starlight CFL range

BULB

20 to 40 W Incandescent bulb replacement Model: PBLED-04WA Specifications:

• 1. Rated Power ：6W
• 2. Base: E27
• 3. CRI : > 75
• 4. Color Temperature : 3000K
• 5. Rated Voltage : 220-240V
• 6. Luminous Flux : 300Lm
• 7. Size : Ф60 * H108 mm
• 8. Average Life : 25,000 h

Pensonic Starlight CFL range

20 to 40 W Incandescent bulb replacement Model: PBLED-06CA Specifications:

• 1. Rated Power ：6W
• 2. Base: E27
• 3. CRI : > 75
• 4. Color Temperature :

5500K

• 5. Rated Voltage : 220-240V
• 6. Luminous Flux : 320Lm
• 7. Size : Ф60 * H108 mm
• 8. Average Life : 25,000 h

Pensonic Starlight CFL range

BULB

20 to 40 W Incandescent bulb replacement

Pensonic Starlight CFL range

20 to 40 W Incandescent bulb replacement Model: PL-A19O-60008-2120 Specifications:

• 1. Rated Power ：8W
• 2. Base: E27
• 3. CRI : > 75
• 4. Color Temperature : 6000K
• 5. Rated Voltage : 220-240V
• 6. Luminous Flux : 380Lm min
• 7. Size : Ф60 * H108 mm
• 8. Average Life : 25,000 h
• 9. LED from OSRAM Semiconductors

BULB

Pensonic Starlight CFL range

BULB

20W Incandescent Bulb replacement Model: PBLED-08WA/ CW Specifications:

• 1. Rated Power ：8W
• 2. Base: E27
• 3. CRI : > 75
• 4. Color Temperature : 3000K/ 6000K
• 5. Rated Voltage : 220-240V
• 6. Luminous Flux : 700 lm
• 7. Size : Ф60 * H118 mm
• 8. Average Life : 25,000

Pensonic Starlight CFL range

BULB

60W Incandescent Bulb replacement

1 year warranty !

SP RM : RCP RM Qty 50 pcs per box

Pensonic Starlight CFL range

BULB

60W Incandescent Bulb replacement

1 year warranty !

Model: PBLED-10CA/WA Specifications:

• 1. Rated Power ：10W
• 2. Base: E27
• 3. CRI : > 75
• 4. Color Temperature : 3000K/

6000K

• 5. Rated Voltage : 220-240V
• 6. Luminous Flux : 810 Lm
• 7. Size : Ф60 * H108 mm
• 8. Average Life : 25,000 hr

SP RM : RCP RM Qty 24 pcs per box

Pensonic Starlight CFL range

BULB

60 W Incandescent bulb replacement

1 year warranty !!

Model: PBLED-09WA/CA Specifications:

• 1. Rated Power ：9W
• 2. Base: E27
• 3. CRI : > 75
• 4. Color Temperature :

3000K/6000K

• 5. Rated Voltage : 220-240V
• 6. Luminous Flux : 700Lm
• 7. Size : Ф75 * H140 mm
• 8. Average Life : 25,000 h

SP RM : RCP RM Qty 50 pcs per box

Pensonic Starlight CFL range

BULB

100 W Incandescent bulb replacement

1 year warranty !!

Model: PBLED-13WA/CA Specifications:

• 1. Rated Power ：13W
• 2. Base: E27
• 3. CRI : > 75
• 4. Color Temperature :

3000K/6000K

• 5. Rated Voltage : 220-240V
• 6. Luminous Flux : 1050Lm
• 7. Size : Ф75 * H140 mm
• 8. Average Life : 25,000 h

SP RM : RCP RM Qty 50 pcs per box

Pensonic Starlight CFL range

4Inch Down-Light Model No: PL-DL4D-60010-2120 CW/Daylight Model No: PL-DL4D-30010-2120 WW 15X1,18X1W CFL 4 inch vertical replacement

Pensonic Starlight CFL range

4 Inch Down-Light

Consumer range | Table lamp

Pensonic Starlight CFL range

Model: PTL-103B Specifications:

• 1. LED Bulb: 4W
• 2. ON/OFF easy control
• 3. Strong forceful spring fasten lamp
• 4. Color temperature: 3000 / 5500K
• 5. Luminous Flux: 800lux（30cm）
• 6. Able to accept bulbs from 4W to 7W

Dealer price: RM Lowest dealer price: RM SPECIAL FEATURE: a) Available in Blue and Pink color b) Replaceable bulb feature

Pensonic Starlight CFL range

Model: PTL-102 Specifications:

• 1. High Intensity LED panel: 5W
• 2. On/off mechanical control
• 3. Illumination: 700LUX （35cm）
• 4. Color Temperature: 5500K
• 5. Attached Charger: 5V 2.5a

SPECIAL FEATURE: a) Long adjustable arm b) Tightening feature on the top and bottom base of the lamps

Pensonic Starlight CFL range

Model: PTL-102 Specifications:

• 1. High Intensity LED panel: 8W
• 2. Slender black and silver body
• 3. Illumination: 700LUX （35cm）
• 4. Color Temperature: 5500K

Attached Charger: 5V 2.5a SPECIAL FEATURE: a) Touch On/off for main lamp b) Touch Dimmable c) USB Output for charging smart phones

Pensonic Starlight CFL range

Model: PTL-101 Specifications:

• 1. High Intensity LED panel: 10W
• 2. Color: Cool White
• 3. Illumination: 700LUX （35cm）
• 4. Color Temperature: 5500K
• 5. Attached Charger: 5V 2.5a

SPECIAL FEATURE: a) 1W NIGHT LIGHT. b) Touch On/off for main lamp and night light

Pensonic Starlight CFL range

THE SOLAR CUBE

Features Light output Max Light output of 20000 mcd Color Color 6500K color cool white Power source Built in solar panel for charging or 240V power supply Dimming 4 step dimming feature Extra features MP3 and radio function Media interface USB and SD (Std and mini) Battery 2800 maH Operating Temp

• 10 to 45 deg C

Storage Temp range

• 20 to 65 deg C

Storage Temp 10 to 95 %

Model No PLED-40C

PSL Commercial | Project range

LED MR-16 ~ 5 W LED MR-11 ~ 2.5W LED MR16-12W ~DIMMABLE 8W A19 Bulb ~DIMMABLE 4 inch DL ~ 10 W 6 inch DL ~ 13 W

Gravity Low Power-Project Range

8 inch DL ~ 15 W LED MR 16 ~ 8 W

Gravity-Mid power Project Range

4 inch DL ~ 23 W 6 inch DL ~ 23 to 25 W PAR30 and 38 ~ 13 to 18 W AR111 ~ 23 W 2 ft tube ~ 9 to 10 W 4 ft tube ~ 18 to 20 W Laser-lite ~ 18 W

Pensonic Starlight CFL range

Gravity Mid Power-Project Range

LED Flood lights ~ 30 to 50W LED Flood lights ~ 30 to 50 W

High-Bay ~ 100 to120 W Flood Light ~ 110 W

Gravity-Hi-Power Project Range

High-Bay ~ 200 W Flood Light ~ 180W

Flood Light ~ 130 W Streetlight ~ 130W

Gravity-Hi-Power Project Range

Flood Light ~ 150 to 200W Streetlight ~ 180 W Streetlight ~ 100W Streetlight ~ 150W

MR11 Spotlight

Model number: BL-M11C-30002-2029 BL-M11C-60002-2029

Specifications:

• 1. Rated Power ：2.5W
• 2. LED Type : CREE XPG
• 3. Base : GU4.0
• 4. CRI : 80 (Warm & Neutral White) 70 (CW)
• 5. Color Temperature : 7000k (C) 3600k (WW) 4500k (NW)
• 6. Voltage: AC/DC 12V
• 7. Luminous Flux : 154Lm (CW) 123Lm (NW) 134 (WW)
• 8. Average Life : 25,000 h

20W Halogen replacement

Ready for sale !!

Pensonic Starlight CFL range

MR16 Spotlight

Model number: PL-M16C-30005-2025

35W Halogen replacement

Appication Area Indoor Specification Wattage : 5W LED Type : Cree XML Lumen : 320 lumens Color Temp : 3000 Warm White CRI : 75 min Material Specification Heat-sink : Aluminium housing Optics : PMMA 35 deg Installation & Mounting Plug and play : GU5.3 Net Weight (kg) : 25 grams Compatibility LED drivers : 80% Electronic ballast : 70% Magnetic ballast : 50%

Ready for sale !!

Ezy-White technology

Pensonic Starlight CFL range

Pensonic Starlight CFL range

MR16 Spotlight Dimmable 8W system

Warm White: PL-M16LD30008-2030 Cool White: PL-M16LD60008-2030

Description: Pensonic MR16 Spot Light is a product ideal for commercial and household application such as boutiques, restaurants, showrooms and general businesses premises. This spot light system is a TRUE 50 W halogen replacement with performance rating of

• ver 500 lumens from this 8W total system.

It is also dimmable which provides the flexibility needed for most spot MR16 replacements.

Dimmable !!

Pensonic Starlight CFL range

SPECIFICATION:

Part number PL-M16LD30008-2030 PL-M16LD60008-2030 Input Voltage 240VAC 240VAC Power Consumption 8W 8W System Efficiency 63.7 lm/w 81.2 lm/w Luminous Flux (lm) 510 lm 690 lm Color Temperature 3000K 6000K CRI 80+ 70+ Working Temperature

• 20 dec C to 40 deg C
• 20 dec C to 40 deg C

Working Humidity 10 % to 90% RH 10 % to 90% RH Strorage Temperature 10 deg C to 85 deg C 10 deg C to 85 deg C Life Time 35000 hrs 35000 hrs Application Indoor only Indoor only Casing Construction Aluminium + Plastic Aluminium + Plastic Weight 370 g 370g Dimension Height 43 43 Diameter

49 49

Warranty

2 years 2 years

Pensonic Starlight CFL range

SYSTEM PERFORMANCE:

WW Performance: 500 lumens at 8W Total system CW Performance: 690 lumens at 8W Total system

Pensonic Starlight CFL range

PHOTOMETRIC and PACKING :

Pensonic Starlight CFL range

MR16 Spotlight Dimmable 12W

Warm White: PL-M16ZD30012-2020 Cool White: PL-M16ZD60012-2020

Pensonic LED MR16 12W Dimmable system is a product ideal To replace the conventional 50W and above halogen spot light. This system comes complete with its own dimmable power supply and

• Casing. This high lumen output system easily surpasses the lumen

Output of the conventional halogen Maintaining the single light source

• utlook, the MR16 system, will radiate a beam pattern similar to conventional

halogens . The casing allows multi directional tilting to suit your personalized needs.

Pensonic Starlight CFL range

Part number PL-M16ZD30012-2020 PL-M16ZD60012-2020 Input Voltage 240VAC 240VAC Power Consumption 12W 12W System Efficiency 54 lpw 61 lpw Luminous Flux (lm) 640 730 Color Temperature 3000K 6000K CRI 80+ 70+ Working Temperature

• 20 dec C to 40 deg C
• 20 dec C to 40 deg C

Working Humidity 10 % to 90% RH 10 % to 90% RH Strorage Temperature 10 deg C to 85 deg C 10 deg C to 85 deg C Life Time 25000 hrs 25000 hrs Application Indoor only Indoor only Casing Construction Aluminium + Plastic Aluminium + Plastic Weight 178 178 Dimension Height 70 70 Diameter 85 85 Warranty 2 years 2 years

Pensonic Starlight CFL range

Model No : PL-A19G-60008-2120 CW/Daylight Model No: PL-A19G-30008-2120 WW/ Warm White Std Dealer Price:

40W replacement !!

Dimmable !!

Pensonic Starlight CFL range

Pensonic Starlight CFL range

4 ft 18W T9 LED Tube

Pensonic’s latest LED T9 tube is designed with the most up to date LED’s and drivers available today. Its efficiency is from 88 to 100 lm/w and with very higher efficiency and low THD. This new T9 LED tubes are ideal for linear lighting applications in offices, shopping malls, Retail outlets, car park and numerous other applications.

Part number PLDT90D-30018-2120 PLDT90D-60018-2120 Input Voltage 240VAC 240VAC Power Consumption 18W 18W System Efficiency 90 lm/w 100 lm/w Luminous Flux (lm) 1650 1800 Color Temperature 3000K 6500K CRI 80+ 80+ Viewing Angle 120 deg 120 deg Working Temperature

• 20 dec C to 45 deg C
• 20 dec C to 45 deg C

Working Humidity 10 % to 90% RH 10 % to 90% RH Strorage Temperature 10 deg C to 85 deg C 10 deg C to 85 deg C LED Life Time 50000 hrs 50000 hrs Application Indoor only Indoor only Casing Construction Aluminium + Polycarbonate Aluminium + Polycarbonate Weight 398 gm 398 gm Dimension Length 1200 mm 1200 mm Diameter

28 mm 28 mm

Height

29 mm 29 mm

4 ft 18W T9 LED Tube Part number: PLDT9D-60018-2120

Pensonic Starlight CFL range

Pf: More than 0.9 THD: Less than 15% 4 ft 18W T8 LED Tube

Pensonic Starlight CFL range

4 ft 18W T8 LED Tube Dimensions and Installation guide

Pensonic Starlight CFL range

Description Pesonic LaserLite CW/DL Pensonic Laserlite WW Warranty 4ft/2ft 4ft/2ft Input Voltage DC24(22 to 25.5) DC24(22 to 25.5) Input Current DC0.62A/DC0.21A DC0.62A/DC0.21A Total LED W 14.9/7.45 14.9/7.45 Power consumption 18.4/9.2 18.4/9.2 CCT 5700 2700 LED lumen typical 1250/625 1050/525 1

42 to 44 W Fluorescent tube replacement Model No:LH-LL4G-60018-2080

Pensonic Starlight CFL range

15X1,18X1,23WX1 CFL 6 inch vertical replacement 6 Inch Down-Light

Ready for sale !!

Specifications:

• 1. Rated Power ：13W
• 2. CRI : 75 to 80
• 3. Color Temperature : 6500k (DL) 3500k (WW)
• 4. Rated Voltage : 240V AC
• 5. Luminous Flux : 920Lm (CW) 780Lm (WW)
• 6. Size : 183mm (D) * 100mm (H)
• 7. Average Life : 25,000h

Model No: PL-DL6D-60013-2090 CW/Daylight

Std SP :

Model No: PL-DL6D-30013-2090 WW

Std SP:

Pensonic Starlight CFL range

6 Inch Down-Light with casing

White Casing: PLWDL6D-30012-2090 WW PLWDL6D-60012-2090 Daylight Black Casing: PLBDL6D-30012-2090 WW PLWDL6D-60012-2090

Part number PLWDL6D-30012-2090 PLWDL6D-60012-2090 PLBDL6D-30012-2090 PLBDL6D-60012-2090 Input Voltage 240VAC 240VAC 240VAC 240VAC Power Consumption 12W 12W 12W 12W System Efficiency 62 lm/w 83 lm/w 62 lm/w 83 lm/w Luminous Flux (lm) 750 lm 1000 lm 750 lm 1000 lm Color Temperature 2700K to 3500K 5500K to 6500K 2700K to 3500K 5500K to 6500K CRI 80+ 70+ 80+ 70+ Working Temperature

• 20 dec C to 40 deg C
• 20 dec C to 40 deg C
• 20 dec C to 40 deg C
• 20 dec C to 40 deg C

Working Humidity 10 % to 90% RH 10 % to 90% RH 10 % to 90% RH 10 % to 90% RH Strorage Temperature 10 deg C to 85 deg C 10 deg C to 85 deg C 10 deg C to 85 deg C 10 deg C to 85 deg C Life Time 35000 hrs 35000 hrs 35000 hrs 35000 hrs Application Indoor only Indoor only Indoor only Indoor only Casing Construction Aluminium + Plastic Aluminium + Plastic Aluminium + Plastic Aluminium + Plastic Weight 426g 426g 426g 426g Dimension Height 100 mm 100mm 100 mm 100mm Diameter 183 mm 183 mm 183 mm 183 mm Casing Color White White Black Black Warranty 2 years 2 years 2 years 2 years

Pensonic Starlight CFL range

SPECIFICATION

Pensonic Starlight CFL range

6 Inch Down-Light with casing

Pensonic Starlight CFL range

4 inch down-light 23W version

Ezy-White technology

Application Area Indoor Specification System : 23 Total Watt LED Type : CREE CXA20 Lumen : 1100 warm white Lumen : 1300 cool white LED Type : Ezy White technology Driver : External Driver Color Temp : 3000 Warm White : 5000 Day Light CRI : 75 min Material Specification Housing : Epoxy Powder Coated : High pressure die cast : Aluminium housing Optics : Tempered Glass Installation & Mounting Gear Component Integrated : Yes Net Weight (kg) : 1.8 Diemensions Diameter : 144mm Width : N.A Height : 113mm Mounting System : Resting on ceiling panel Screwable ceiling clamp : Yes

15WX2 18 X 2 CFL replacement

Model: Cool white SD-DL4C-50023-2065 Warm white: SD-DL4C-30023-2065

Pensonic Starlight CFL range

Model No: SD-DL6C-50023-2065 CW/Daylight Model No: SD-DL6C-30023-2065 WW 6 Inch Down-Light 23W

Pensonic Starlight CFL range

6 Inch Down-Light 23W Model No: SD-DL6D-50023-2065 CW/Daylight Model No: SD-DL6C-30023-2065 WW Dealer Price RM 168 RCP RM 220

Pensonic Starlight CFL range

8 Inch 15W Down-Light Model No: GM-DL8E-60015-2140 CW/Daylight Model No: GM-DL8E-30015-2140 WW

ADVANTAGES:

• Replacement for 8 inch 15W X 2 CFL or CFL.

SMD LED Technology ensures the operations of 35,000 hours. 60% - 80% energy saving Enhanced heat sink technology ensures lower operating temperature Zero warm up time. Mercury and lead free.

The PENSONIC 8 inch Down Light is IP20 rated to be used in indoor applications.

Pensonic Starlight CFL range

8 Inch Down-Light Model No: GM-DL8E-60015-2140 CW/Daylight Model No: GM-DL8E-30015-2140 WW

Pensonic Starlight CFL range

8 Inch Down-Light Model No: PL-DL8D-60018-2090 CW/Daylight Model No: PL-DL8D-30018-2090 WW

ADVANTAGES:

Replacement for 8 inch 18W X 2 CFL or 23W X 2 CFL. SMD LED Technology ensures the operations of 50,000 hours. 60% - 80% energy saving Enhanced heat sink technology ensures lower

• perating temperature.

Zero warm up time. Mercury and lead free.

The PENSONIC 8 inch Down Light is IP20 rated to be used in indoor applications.

Pensonic Starlight CFL range

8 Inch Down-Light

Pensonic Starlight CFL range

Power factor: More that 0.9 THD: Less than 20% Model No: PL-DL8D-60018-2090 CW/Daylight Model No: PL-DL8D-30018-2090 WW 8 Inch Down-Light

Pensonic Starlight CFL range

22W AR111 Down-light

Ready for sale !!

DESCRIPTION: Pensonic AR111 Down Light is designed to replace conventional AR111. It was design with LED which is give better performance than conventional AR111. Pensonic AR11 also consume less power, environmental friendly and it’s proven to be >60% energy saving. ADVANTAGES:

• CREE LED with LM-80 tested to last

>50,000 hours

• More than 50% energy saving
• Light up instantaneously
• Robust design: able to withstand

shock and vibration

• Environmental friendly: Mercury and

lead free

• IP23 rated to be used in indoor

application

70W CDRM or Halogen AR111 replacement

Model No: PL-AR1C-30022-2040 Warm white

Pensonic Starlight CFL range

TYPE Daylight Warm White Power Consumption 22W Beam Angle 40°

• No. of LED

12 LED Luminous Efficiency >122 lm System Efficiency >75 lm Driver Efficiency (%) >85% Luminous Flux (lm) 1,500lm 1,200lm Color Temperature 6,500K 3,000K Color Index (CRI) Typ: 75 Typ: 80 Working Temperature

• 20°C ~ 40°C

Working humidity 10% ~ 90% RH Storage Temperature 10°C - 85°C Life Time 50,000 hrs Application Indoor usage Casing Construction Aluminum Weight 371g Dimension Height 35 mm Diameter 120 mm Warranty 2 year(s)

Pensonic Starlight CFL range

DESCRIPTION: Built for down lightings and spotlights, it offers and instant replacement in E27 type fixtures, The low energy and long life characteristic allow the customer to lower both maintenance and energy cost. Feature:

• RoHs Compliant
• Degress of Ingress Protection: IP65
• Excellent thermal performance
• No UV light

Application :

• Commercial Lighting
• Architectural Lighting
• Landscape Lighting
• Interior Commercial Lighting

Note :

• This product shall be used with 100-240V AC

without transformer

• The applied ambient temperature must be

lower than 40C

• No Suitable for poorly ventilated lighting

fixture

• Not suitable for dimmers

Model No: KP-P30C-30013-2024 WW Model No: KP-P30C-60013-2024 CW/ Daylight

Ready for sale !! Ezy-White technology

Pensonic Starlight CFL range

Pensonic Starlight CFL range

Pensonic High-bay 120W system

Type 120W Input power 240 VAC LED Cree XPG Beam Angle 60/100 LED Luminous Efficiency >122 lumens System Efficiency >75 lumens Driver Efficiency(%) >85% Luminous Flux(lm) 9000 lm Color Temp 6000 CRI Typ:75 Working Temp

• 20 to 40 deg C

Working Humidity 10% to 90% RH Storage Temp 10 deg C to 85 deg C Casing Construction Aluminium Weight 6kg Dimensions Height 490 mm Diameter 415 mm

Advantages:

• GREE LED with LM-80 tested to last >50,000

hours

• More than 50% energy saving
• Instant start
• Robust design: able to withstand shock and

vibration

• Environmental friendly: Mercury and lead

free

• IP23 rated to be used in indoor application

Model No: PL-HB0C-60120-2060 60 deg Model No: PL-HB0C-60120-2100 100 deg

Pensonic Starlight CFL range

Pensonic High-bay 120W system

Pensonic Starlight CFL range

Pensonic High-bay 100W system

Advantages:

• CREE LED with LM-80 tested to last >50,000

hours

• More than 50% energy saving
• Instant start
• Robust design: able to withstand shock and

vibration

• Environmental friendly: Mercury and lead

free

• IP23 rated to be used in indoor application

Model No: PL-HB0C-60100-2040 40 deg Model No: PL-HB0C-60100-2060 60 deg

Part number PL-HB0C-60100-2040 PL-HB0C-60100-2060 Input Voltage 240VAC 240VAC Power Consumption 150W 100W System Efficiency

• ver 90 lm/W
• ver 90 lm/W

Luminous Flux (lm) 9000 9000 Color Temperature 6000K 6000K CRI > 70 > 70 Viewing Angle 40 deg 60 deg Working Temperature

• 20 dec C to 40 deg C
• 20 dec C to 40 deg C

Working Humidity 10 % to 90% RH 10 % to 90% RH Strorage Temperature 10 deg C to 85 deg C 10 deg C to 85 deg C Life Time 25000 hrs 25000 hrs Application Indoor and outdoor Indoor and outdoor Casing Construction Aluminium + Polycarbonate Aluminium + Polycarbonate Weight 4.5 kg 4.5 kg Dimension Height 436 mm 436 mm Diameter

250 mm 250 mm

Warranty

2 years 2 years

Pensonic Starlight CFL range

LUX LEVELS and POLAR DIAGRAM

Pensonic Starlight CFL range

Model No: PL-HB0C-60150-2040 150 W Model No: PL-HB0C-60150-2040 150W

150W High bay

Pensonic Starlight CFL range

Part number PL-HB0C-60150-2040 PL-HB0C-60150-2060 Input Voltage 240VAC 240VAC Power Consumption 150W 150W System Efficiency

• ver 90 lm/W
• ver 90 lm/W

Luminous Flux (lm) 13800 13800 Color Temperature 6000K 6000K CRI > 70 > 70 Viewing Angle 40 deg 60 deg Working Temperature

• 20 dec C to 40 deg C
• 20 dec C to 40 deg C

Working Humidity 10 % to 90% RH 10 % to 90% RH Strorage Temperature 10 deg C to 85 deg C 10 deg C to 85 deg C Life Time 25000 hrs 25000 hrs Application Indoor and outdoor Indoor and outdoor Casing Construction Aluminium + Polycarbonate Aluminium + Polycarbonate Weight 4.5 kg 4.5 kg Dimension Height 436 mm 436 mm Diameter 250 mm 250 mm Warranty 2 years 2 years

150W High bay

Pensonic Starlight CFL range

150W High bay

Pensonic Starlight CFL range

30W LED Flood Light 30W LED FLOOD LIGHT

Part number PL-FL0D-60030-2115 PL-FL0D-30030-2115 Input Voltage 240VAC 240VAC Power Consumption 30W 30W System Efficiency

• ver 80 lm/W
• ver 67 lm/w

Luminous Flux (lm) 2500 lm 2000 lm Color Temperature 6000K 3000K CRI > 70 > 80 Viewing Angle 115 deg 115 deg Working Temperature

• 20 deg C to 50 deg C
• 20 dec C to 50 deg C

Working Humidity 10 % to 90% RH 10 % to 90% RH Storage Temperature 10 deg C to 65 deg C 10 deg C to 65 deg C Life Time 25000 hrs 25000 hrs Application Outdoor Outdoor Casing Construction Aluminium Aluminium Weight 450 gm 700 gm Overall size 125 X 122 mm 125 X 122 mm

Pensonic Starlight CFL range

50W LED FLOOD LIGHT

Part number PL-FL0D-30050-2115 PL-FL0D-60050-2115 Input Voltage 240VAC 240VAC Power Consumption 50W 50W System Efficiency 60 lm/W 80 lm/W Luminous Flux (lm) 3000 4000 Color Temperature 3000K 6000K CRI 80+ 70+ Viewing Angle 115 deg 115deg Working Temperature

• 20 dec C to 40 deg C
• 20 dec C to 40 deg C

Working Humidity 10 % to 90% RH 10 % to 90% RH Strorage Temperature 10 deg C to 85 deg C 10 deg C to 85 deg C Life Time 25000 hrs 25000 hrs Application Indoor and outdoor Indoor and outdoor Casing Construction Aluminium + Polycarbonate Aluminium + Polycarbonate Weight 1.8 kg 1.8 kg Dimension Height 95 mm 95 mm Width 253 mm 253 mm Length 194 mm 194 mm Warranty 2 years 2 years

Pensonic Starlight CFL range

50W LED FLOOD LIGHT 50W LED Flood Light

Pensonic Starlight CFL range

Part number PL-FL0C-30050-2040 PL-FL0C-60050-2040 PL-FL0C-30050-2060 PL-FL0C-60050-2060 Input Voltage 240VAC 240VAC 240VAC 240VAC Power Consumption 50 50 50 50 System Efficiency 61 lm/W 82 lm/W 61 lm/W 82 lm/W Luminous Flux (lm) 3100 4100 3100 4100 Color Temperature 3000K 6000K 3000K 6000K CRI 80+ 70+ 80+ 70+ Viewing Angle 40 deg 40 deg 60 deg 60 deg Working Temperature

• 20 dec C to 40 deg C
• 20 dec C to 40 deg C
• 20 dec C to 40 deg C
• 20 dec C to 40 deg C

Working Humidity 10 % to 90% RH 10 % to 90% RH 10 % to 90% RH 10 % to 90% RH Strorage Temperature 10 deg C to 85 deg C 10 deg C to 85 deg C 10 deg C to 85 deg C 10 deg C to 85 deg C Life Time 25000 hrs 25000 hrs 25000 hrs 25000 hrs Application Indoor and outdoor Indoor and outdoor Indoor and outdoor Indoor and outdoor Casing Construction Aluminium + Polycarbonate Aluminium + Polycarbonate Aluminium + Polycarbonate Aluminium + Polycarbonate Weight 1.8 kg 1.8 kg 1.8 kg 1.8 kg Dimension Height 95 mm 95 mm 95 mm 95 mm Width 253 mm 253 mm 253 mm 253mm Length 194 mm 194 mm 194 mm 194 mm Warranty 2 years 2 years 2 years 2 years

SPECIFICATION

Pensonic Starlight CFL range

130W LED FLOOD LIGHT

Part number PL-FL0C-60130-2025 Input Voltage 240VAC Power Consumption 130W System Efficiency 85 lm/W Luminous Flux (lm) 11000 Color Temperature 6000K CRI 70+ Viewing Angle 25 deg Working Temperature

• 20 dec C to 40 deg C

Working Humidity 10 % to 90% RH Storage Temperature 10 deg C to 85 deg C Life Time 25000 hrs Application Indoor and outdoor Casing Construction Aluminium + Polycarbonate Weight 12 kg Dimension Height 375 mm Width 187 mm Length 310 mm Warranty 2 years

Pensonic Starlight CFL range

200W LED FLOOD LIGHT

Part number PL-FL0C

• 30200-2010

PL-FL0C-60200- 2010 PL-FL0C-30200-20AS PL-FL0C-60200-20AS Input Voltage 240VAC 240VAC 240VAC 240VAC Power Consumption 200W 200W 200W 200W System Efficiency 60 lm/W 80 lm/W 60 lm/W 80 lm/W Luminous Flux (lm) 12000 15800 12000 15800 Color Temperature 3000K 6000K 3000K 6000K CRI 80+ 70+ 80+ 70+ Viewing Angle 10 deg 10 deg 140 X 84 deg 140 X 84 deg Working Temperature

• 20 dec C to 40 deg

C

• 20 dec C to 40 deg

C

• 20 dec C to 40 deg C
• 20 dec C to 40 deg

C Working Humidity 10 % to 90% RH 10 % to 90% RH 10 % to 90% RH 10 % to 90% RH Strorage Temperature 10 deg C to 85 deg C 10 deg C to 85 deg C 10 deg C to 85 deg C 10 deg C to 85 deg C Life Time 25000 hrs 25000 hrs 25000 hrs 25000 hrs Application Indoor and outdoor Indoor and outdoor Indoor and outdoor Indoor and outdoor Casing Construction Aluminium + Polycarbonate Aluminium + Polycarbonate Aluminium + Polycarbonate Aluminium + Polycarbonate Weight 15 kg 15 kg 15 kg 15 kg Dimension Height 400 mm 400 mm 400 mm 400 mm Width 121 mm 121 mm 121 mm 121 mm Length 340 mm 340 mm 340 mm 340 mm Warranty 2 years 2 years 2 years 2 years

Pensonic Starlight CFL range

Pensonic street Light 400W Metal- Hi replacement

Description: Pensonic LED Street light is designed to replace existing HPS or Metal Halide Street

• lamp. It is built by using the good heat

dissipation materials to ensure long term reliability and the best performance. Pensonic LED Street Light also designed in modular form and using lightweight heat sinks, therefore lowering the production cost. Thus directly the cost benefits to our customer. Advantages:

• Save more than 50% energy

Long life:> 50,000 operating hours Light up instantaneously Low pollution imprint to the environment IP 66 compliance Intelligent and precise current source to prevent

• verdrive
• The Pensonic Street Lamp is IP66 rated to be

used in outdoor applications. Using Cree’s latest high power LED

Model No: PL-SL0C-60120-20AS 120W Model No: PL-SL0C-60180-20AS 180W

Pensonic Starlight CFL range

Pensonic Street Light

Part number PL-SL0C-60120-20AS PL-SL0C-60180-20AS Input Voltage 240VAC 240VAC Power Consumption 120W 180W System Efficiency 75 lm/W 76.6 lm/W Luminous Flux (lm) 9000 13800 Color Temperature 6000K 6000K CRI 70+ 70+ Viewing Angle AS A Working Temperature

• 20 dec C to 40 deg C
• 20 dec C to 40 deg C

Working Humidity 10 % to 90% RH 10 % to 90% RH Storage Temperature 10 deg C to 85 deg C 10 deg C to 85 deg C Life Time 25000 hrs 25000 hrs Application Indoor and outdoor Indoor and outdoor Casing Construction Aluminium + Polycarbonate Aluminium + Polycarbonate Weight 8 kg 12 kg Dimension Height 100 mm 100 mm Width 320 mm 320 mm Length 550 mm 730 mm Warranty 2 years 2 years

Pensonic Starlight CFL range

Actual Lighting Effects 120W Lux Performance 180W Lux Performance Actual Lighting Effects

Pensonic Starlight CFL range

120W System Dimensions 180W System Dimensions

Pensonic Starlight CFL range

Compatible pole dimension

Pensonic Starlight CFL range

Technology partners

Pensonic is grateful to be aligned with some of the world’s leading LED lighting manufacturers to provide LED luminaires of the highest quality to the consumers. Aided by the exceptional innovative technologies from these partners, we believe Pensonic will enhance its ever growing reputation globally.

THE PROJECTS

Gravity - Projects Completed Texas Instruments Ulu Klang Malaysia

The CFL Problem

Gravity - Projects Completed Cempaka International School @ Cheras – LED Tubes

Gravity - Projects Completed NI Penang

Gravity - Projects Completed: Sharp Batu Pahat

“I feel it’s brighter (than high bay), and we can definitely feel the heat is reduced”

Facility Assistant Manager Sharp (BP)

The CFL Problem

Gravity - Projects Sime Darby Medical Centre Subang

The CFL Problem

Gravity - Projects Completed Prudential Branches Across Malaysia- LED Tubes

Gravity - Projects Completed Genting Pavilion New Wing

Greater KL project

Gravity- Projects- Ecoworld Jalan Ipoh

Gaia 16 Ampang Taman Ukay

Gravity - Projects- Perfect Eagle O2 City

Gravity - Projects- MPAJ Bukit Teratai Cheras

Gravity- Projects- Bangsar Pullman Hotel Lobby

Gravity- Projects- Perfect Eagle O2 City Gravity - Projects- Hydro Hotel Penang

Gravity- Projects- Perfect Eagle O2 City Gravity - Projects Completed Hotel Royal Penang

Gravity - Projects Completed myNEWS.COM

Gravity - Projects Completed myNEWS.COM KLIA 2

Gravity - Projects Completed

Gravity- Projects- Polo Ralf Lauren Australia

Gravity - Projects Completed Sembonia

Gravity - Projects Completed SEMBONIA IOI MALL - PAR 30,PAR38 and AR111

Gravity - Projects Completed

THANK YOU
