Database servers on chip multiprocessors: limitations and

• pportunities
• N. Hardavellas
• I. Pandis
• R. Johnson
• N. Mancheril
• A. Ailamaki
• B. Falsafi

Benjamin Reilly September 27, 2011

Tuesday, 27 September, 11

The fattened cache (and CPU)

Cache capacity = Cache latency More data on hand, but higher cost to retrieve it CPUs show similar trend in development: continually larger, and more complex

Tuesday, 27 September, 11

OVERVIEW

• Motivation
• Experiment design
• Results and observations
• What now?
• Summary and discussion

Tuesday, 27 September, 11

Dividing the CMPs

CMPs? Chip multiprocessors: several cores sharing on-chip resources (caches) Vary in:

• # of cores
• # of hardware threads (“contexts”)
• Execution order
• Pipeline depth

Tuesday, 27 September, 11

The ‘Fat Camp’ (FC)

Key characteristics

• Few, but powerful cores
• Few (1-2) hardware contexts
• OoO –– Out-of-Order execution
• ILP –– Instruction-level parallelism

Core 0 Core 1

Thread Context

Tuesday, 27 September, 11

Hiding data stalls: FC

OoO Out of Order Execution ILP Instruction-level parallelism

• p 0
• p 1
• p 2

Wait for... input Compute

• p 1
• p 2

earlier

• perations

a += b b += c d += e

Tuesday, 27 September, 11

The ‘Lean Camp’ (LC)

Key characteristics

• Many, but weaker cores
• Several (4+) hardware contexts
• In-order execution (simpler)

Core 0 Core 1 Core 5 Core 2 Core 3 Core 4 Core 7 Core 6

Tuesday, 27 September, 11

Core 0 Core 0 Core 0 Core 0 Core 0 Core 0 Core 0 Core 0 Core 0 Core 0

Hiding data stalls: LC

Hardware contexts interleaved in round-robin fashion, skipping contexts that are in data stalls. Running Idle (runnable) Stalled (non-runnable)

Tuesday, 27 September, 11

(Un)saturated workloads

Workloads

• DSS
• OLTP

Number of requests

• Saturated: work always available for each

hardware context

• Unsaturated: work not always available

Tuesday, 27 September, 11

LC vs. FC Performance

LC has slower response time in unsaturated workloads

+12% (low ILP for FC) +70% (high ILP for FC)

Tuesday, 27 September, 11

LC vs. FC Performance

LC has higher throughput in saturated workloads

+70% (ILP not significant for FC)

Tuesday, 27 September, 11

LC vs. FC Performance

Observations:

• FC spends 46-64%
• f execution on data

stalls

• At best (saturated

workloads), LC spends 76-80% on computation

Tuesday, 27 September, 11

Data stall breakdown

Larger (and hence slower) caches are decreasingly optimal Consider three components

• f data cache stalls:
• 1. Cache size

Tuesday, 27 September, 11

Data stall breakdown

CPI contributions for: OLTP DSS L2 hit stalls responsible for an increasingly large portion of the CPI

Tuesday, 27 September, 11

Data stall breakdown

• 2. Per-chip core integration

SMP CMP Processing 4x 1-core 1x 4-core L2 cache(s) 4MB / CPU 16 MB shared

Fewer cores per chip = fewer L2 hits

Tuesday, 27 September, 11

Data stall breakdown

• 3. On-chip core count

8 cores:

• 9% superlinear increase in

throughput (for DSS) 16 cores:

• 26% sublinear decrease

(OLTP)

• Too much pressure on L2

Tuesday, 27 September, 11

How do we apply this?

1.Increase parallelism

• Divide!

(more threads ⇒ more saturation)

• Pipeline/OLP (producer-consumer pairs)
• Partition input (not ideal; static and complex)

Tuesday, 27 September, 11

How do we apply this?

2.Improve data locality

• Reduce data stalls to help with unsaturated

workloads

• Halt producers in favour of consumers
• Use cache-friendly algorithms

3.Use staged DBs

• Partition work by groups of relational operators

Tuesday, 27 September, 11

Summary & Discussion

• 1. LC typically performs better than FC
• LC is best under saturated workloads.
• Is there room for FC CMPs in DB applications?
• 2. L2 hits are a bottleneck
• Why were DBs ignored in HW design?
• How can we avoid incurring the cost of an L2

hit?
