DAQ : General Status

R.Itoh, KEK

FE dig FE dig FE dig FE dig FE dig tx tx tx tx tx rx rx rx rx R/O PC R/O PC R/O PC R/O PC Event Builder 1 ~250 COPPERs HLT (~5000 cores) ~40 R/O PCs Rocket IO

• ver fiber

CDC SVD PID ECL KLM Event Builder 2 PXD FE dig PXD readout box (ONSEN) HLT distributor reco rder reco rder reco rder reco rder ...... ..... DATCON

Belle2link

Express Reco FTSW Trigger FTSW FTSW Pocket DAQ

Belle II DAQ System

Belle II Schedule

• The operation of SuperKEKB accelerator had been started from the

beginning of this year although the beams are not yet collided.

• “BEAST” detector was implemented in the IP to monitor the

background level June 18, 2016 (LER beam current at 970 mA, HER at 870 mA)

ECL

Actjvitjes of data-taking towards Global CRT

CDC+T OP (B4) Global CRT CDC in BelleII bECL bKLM TOP in Belle II KLM CDC TOP ARICH ECL KLM

4

ARICH test in clean room

eKLM

Global Belle II DAQ(COPPER to storage) Pocket DAQ in E-hut PocketDAQ of each det. Gr.

• Backend DAQ is fmexible for standalone or combined cosmic data tests.
• FTSW : one combined CRT + standalone CRTs.

(Except for CDC. It can be combined with another sub-detector like CDC+TOP)

• > As for backend DAQ and TTD(not trigger source), combined CRT

by global DAQ system is possible. install Combined CRT for some sub- detectors? Pre-GCRT period

DESY VXD Beam test?

Jul. Aug. Dec. Jan. …

Note : Each tjmeline is not precise. It depends on sub-detector’s installatjon/commissioning schedule.

Deferred to Oct. S.Yamada

DAQ status

• DAQ integration of outer detectors is in progress.

+ Detectors integrated in structure: * ECL (barrel) - Completed and stably running with the global Belle II DAQ. * KLM (barrel) - Being tested with Pocket DAQ. Firmware debugging in progress. * TOP - All installed modules are being tested using Pocket DAQ(stand-alone DAQ), module by module basis. Integration in Belle II DAQ is in progress. + Cosmic ray data taking with Pocket DAQ is going on for all installed modules + Feature extraction firmware (TOP) is still under debugging. + CDC test stand: * A separate Belle II DAQ is prepared. * The cosmic ray data taking with 60 FEE modules is stably running. * One TOP module is installed near the CDC for the test in the cosmic ray with a tracking information. * The data stream from TOP is combined with the CDC data stream and the data taking is started.

• > The ending date of data taking was enlonged to Sep(?).

Live CDC event display

• Full readout chain confirmed to work:

FEE->COPPER->Readout PC-> HLT processing (Unpacker)

• > Storage(sampling) -> Express Reco -> evdisp

• VXD integration was tested in DESY test beam

+ The DESY test beam DAQ was fully operational and worked stably up to 2 kHz in beam. + The Run Control was fully implemented with both SVD and PXD readouts. + “Event mixing” was observed inside both of SVD readout (FTB) and DHE/DHC/ONSEN in PXD readout, although the event mis-match at event builder 2 was not occurred. * Event numbers are properly distributed to detectors from FTSW which are embedded in the raw data header of each detector data. * Event numbers embedded in the raw data body in PXD/SVD were mis-matched.

• > Investigation by both PXD and SVD FEE experts is being done.

+ The RoI feedback from HLT to ONSEN was confirmed to work. * Because of channel mismatch between DHP and DHE, the remapping had to be implemented, which could not be completed during beam test.

• > Had to use large-size RoIs.

2 PXD sensors RoIs obtained from tracks track reconstructed by HLT

DAQ for DESY beam test

COPPER COPPER FTB

FTSW

ttdcpu

DHP DHE DHC

Onsen R/O PC 1

hltin hltctl hltwn1 hltwn2 hltwn3 hltout

R/O PC 2

ExpReco

Event display FTB

FADC FADC

TLU

swi tch switch

SVD 4 layers PXD OB 2 scinti.

coincidence POCKET DAQ HLT

HLT RoI

PXD R/O

DATCON RoI

EVB2 Storage ExpressReco Belle2link “Pocket TTD”

“Full functionality of Belle II DAQ”

DATCON DHP DHE DHC PXD IB

DQM server

Histo browserr

DQM histos

Goals of this workshop (for DAQ)

• Discussion on the status and problem in the further

detector integration * TOP <- On-going top-priority issue. * KLM <- When can we integrate in global DAQ? Urgent issue. * ARICH * Endcap ECL

• Prospects for GCRT (Global Cosmic-Ray Test)

* Trigger for GCRT * Schedule : What detectors in DAQ?, Detector Roll-in schedule.

• Preparation for Phase II run

* Test of VXD readout at DESY-TB * Issues in DAQ preparation for Phase II run. * DAQ configuration for Phase II

Beast SVD

(single crate)

CDC ECL/TOP ARICH/ KLM HLT 1 HLT 4 Storage 1 Storage 4 COPPER ROPC Event Builder 1

FEE FEE FEE

Timing Distribution Trigger for beam from GDL HLT 2 Storage 2 HLT 3 Storage 3 Pocket DHC

EVB2

Partitioned DAQ operation during Phase II run

beam data VXD data

Pocket ONSEN

RoI merger

Beast PXD Beast SVD

Full DHC

Full ONSEN

Full PXD

Full SVD

Full SVD

RoI RoI direct 10GbE connection

* All DAQ equipments are placed in E-hut/server room and operated in “partitioned DAQ” framework. * Need to lay fibers from B1 to E-hut.

Placed in B1 floor

COPPER ROPC

Full FADC/ FTB Beast FADC/ FTB Cosmic trigger locally generated

• Tim. dist.
