FD DAQ General and Backend & Computing Requirements

Kurt Biery, Giles Barr, Josh Klein FD DAQ Design Workshop 30-Oct-2017

Full DAQ Requirements (docdb 112)

• For nonbeam data, a DUNE far detector module shall adopt a data acquisition

strategy suitable for the DUNE SNB physics capabilities.

• A DUNE far detector module shall transmit continuously digitized channel

waveforms to the DAQ at an appropriate sampling frequency.

• A DUNE far detector module shall provide the continuously digitized channel

waveforms at a frequency that optimizes both the charge resolution and determination of closely spaced tracks.

• A DUNE far detector module shall collect events with visible energy of >100

MeV with no dead time

• For events with visible energy < 100 MeV, a DUNE far detector module shall
• ptimize the energy resolution over the detection efficiency.
• A DUNE far detector module shall have the ability to trigger at the time of the

beam pulse regardless of the presence of a beam interaction in the module.

• A DUNE far detector module shall be able to contribute data into a unified

event that includes data from all active modules for offline analysis.

30-Oct-2017 Kurt Biery | DAQ Back-End & Computing 2

Full DAQ Requirements (docdb 112)

• The TPC, photon detector, electronics, and DAQ shall be designed to allow

testing in surface facilities and laboratories before transporting underground.

• The far detector shall measure event times with high efficiency such that for

events with visible energy above 200 MeV the drift coordinate can be measured with sufficient precision.

• For beamline events, the far detector shall measure the absolute time of the

event with accuracy sufficient to correlate it with the beam spill.

• The far detector shall measure the event time for events with visible energy

<200 MeV with high efficiency and sufficient precision to correct for drift time and improve energy resolution.

• The far detector shall measure absolute event time with sufficient accuracy to

allow global analysis of a supernova neutrino wave front.

30-Oct-2017 Kurt Biery | DAQ Back-End & Computing 3

Full DAQ Requirements (docdb 112)

• The FD Data Acquisition shall assemble data from all active modules into a

unified event for offline analysis.

• The FD data acquisition systems shall allow control and monitoring during

detector operations.

• The FD data acquisition shall be integrated into the global DAQ for

LBNF/DUNE.

• The FD data acquisition shall have the capability of notifying the world-wide

science community of an astronomical event in a timely way.

• LBNF/DUNE shall have a Global Data-Acquisition (DAQ) system capable of

collection and readout of all needed experimental data (from beam systems, near, far detectors) to attain the primary objectives of the Long-Baseline Neutrino Facility and Deep Underground Neutrino Experiment.

• The far detector TPC shall be configured so that continuous data taking can

be performed even if some fraction of the detector is not operational.

30-Oct-2017 Kurt Biery | DAQ Back-End & Computing 4

High Level / System Requirements (1)

Flexibility

• Commercial networking and software processing would

allow us to respond to changes in the required rates and rejection factors “Software” compression, noise filtering, zero-suppression, event filtering

• Could include co-processors, but the let’s say software-

driven for starters

• Software processing before event assembly?

Software triggering?

30-Oct-2017 Kurt Biery | DAQ Back-End & Computing 5

High Level / System Requirements (2)

Requirements driven by physical considerations

• Limitations on power or cooling underground
• Underground and above-ground disk buffer?
• Whatever steps are needed for hand-off to offline?

30-Oct-2017 Kurt Biery | DAQ Back-End & Computing 6

High Level / System Requirements (3)

Provide data transfer; event assembly Provide necessary data throughput; disk-writing rates, disk buffer Control and DAQ monitoring Real-time data quality monitoring Graceful handling and communication of back-pressure Provide necessary elements for downstream data management Partitioning Provide necessary uptime, reliability, startup & restart times

30-Oct-2017 Kurt Biery | DAQ Back-End & Computing 7

Requirements for various components

Run Control

• Graphical, scriptable, command-line variant?
• Pick system components
• Pick configuration
• Minimal set of user-visible states while still allowing fast turn around when

needed.

DQM

• Parasitic to primary data flow (crashes do not affect).
• Support for monitoring-application-specific trigger type, rate, etc. requests?
• Is there a need to see all events?
• Web-based displays? World or VPN/VNC viewable

Etc, etc.

30-Oct-2017 Kurt Biery | DAQ Back-End & Computing 8

Backup Slides

30-Oct-2017 Kurt Biery | DAQ Back-End & Computing 9

Computing System

First-pass-reference (FPR) design:

• Commercial servers and components
• Size of system varies based on architecture choices

30-Oct-2017 Kurt Biery | DAQ Back-End & Computing 10

Computing ¡System

Run Control & Data Management

30-Oct-2017 Kurt Biery | DAQ Back-End & Computing 11

Online ¡software ¡in ¡green; ¡Run ¡Control ¡Software ¡in ¡blue
